Makita LS0714 Quick start guide

Parts Breakdown LS0714

Page 1 of 5 2/8/2008

Parts Breakdown LS0714

Page 2 of 5 2/8/2008

Parts Breakdown LS0714

Fig # Part ID Part Name Quantity

1 911228-4 P.H. SCREW M5X18, N1900B 1

2 267136-0 FLAT WASHER 5, 9046 1

3 418656-9 SAFETY COVER, LS0714 1

3 419224-1 SAFETY COVER, LS0714 1

3 419944-7 SAFETY COVER, LS0714 1

4 265008-3 SCREW M5, LS1011 1

5 265461-3 HEX. BOLT M6X18, LS711DWBEK 1

6 224151-7 INNER FLANGE, 5007FK 1

7 285715-2 BEARING RETAINER 55, LS0714 1

8 323798-5 SPINDLE, LS711DWBEK 1

9 211129-9 BALL BEARING 6201DDW, N9501B 1

10 317037-3 HOUSING W/O BEARING, LS0711Z 1

11 213565-5 O-RING, LS0714 1

12 257010-0 RING 12, 5600B, 5620DWA 1

13 226497-7 HELICAL GEAR 47, LS0711Z 1

14 211021-9 BALL BEARING 607LLB, LS1013 1

15 263005-3 RUBBER PIN 6,LS1013 1

16 183885-0 BLADE CASE, LS0714 1

16 188246-9 BLADE CASE, LS0714 1

17 231934-8 SPIRAL SPRING 26, LS711DWBEK 1

18 344639-2 CENTER WASHER, LS711DWBEK 1

18 345589-4 CENTER WASHER, LS0714 1

19 265473-6 HEX BOLT M6X14, LS0711Z 1

20 344641-5 CENTER COVER, LS711DWBEK 1

21 345410-7 CENTER PLATE, LS711DWBEK 1

21 345585-2 CENTER PLATE, LS0714 1

22 224275-9 OUTER FLANGE, 5620DWA 1

23 911223-4 P.H. SCREW M5X16, 4301BV 2

24 922331-6 H.S.H. BOLT M6X20, LS1013 1

25 253804-1 F. WASHER 6, 6012HDW 1

26 257163-5 RING 6, LS1011 1

27 154643-1 LINK PLATE CPLT., LS0714 1

27 345411-5 LINK PLATE, BLS712SFK 1

28 257163-5 RING 6, LS1011 1

29 253804-1 F. WASHER 6, 6012HDW 1

30 961018-5 STOP RING E-5, LS1011 1

31 266061-2 T. SCREW BIND CT4X8, JN1601 1

32 213460-9 O RING 35, HM1500 1

33 416133-5 DUST NOZZLE, LS1013 1

33 419277-0 DUST NOZZLE, LS1013 1

34 819063-3 MAKITA LABEL, 6992DWDE 1

34 819197-2 MAKITA LOGO LABEL, LS0714 1

35 265381-1 HEX. BOLT M6X16, LS711DWBEK 1

36 262001-8 RING 5, 6906 1

37 265717-4 SCREW M6X43, LS1211 1

38 345438-5 GUARD PLATE, LS0714 1

39 911113-1 P.H. SCREW M4X10, 4301BV 1

40 423333-0 GUARD, LS0714 1

72 266046-8 T. SCREW FLANGE PT5X50,HR2010 2

73 263002-9 RUBBER PIN 4, HR2400 1

74 211101-1 BALL BEARING 6001LLB,9218PB 1

75 263002-9 RUBBER PIN 4, HR2400 1

76 233092-6 COMP. SPRING 5, 5740NB 1

77 344642-3 SHAFT LOCK, LS0711Z 1

78 240030-1 FAN 70, LS0714 1

79 510063-3 ARMATURE ASS'Y, LS0714 1

80 681644-1 INSULATED WASHER, 9227C 1

Page 3 of 5 2/8/2008

Parts Breakdown LS0714

81 211031-6 BALL BEARING 608LLB, HR2400 1

82 261110-0 URETHANE WASHER 18, LS0711Z 1

83 416537-1 BAFFLE PLATE, LS0711Z 1

84 634306-0 FIELD 115V, LS0711Z 1

85 632847-0 SUPPORT COMPLETE, LS0711Z 1

86 183878-7 HANDLE SET, LS0711Z 1

87 664059-7 POWER SUPPLY CORD #18-2-3.0,LS0711Z 1

88 682503-2 CORD GUARD 8-90, 9005B 1

89 687063-9 STRAIN RELIEF, 4323K 1

90 265995-6 TAPPING SCREW 4X18, 4323K 2

91 151821-4 MOTOR HOUSING CPL., LS0711Z 1

92 416538-9 UPPER COVER, LS0711Z 1

93 911273-9 P.H. SCREW M5X50, HR2400 3

94 191963-2 CARBON BRUSH CB-303 SET, 9227C 1

95 643755-0 BRUSH HOLDER CAP, JR3020 2

96 860820-2 NAME PLATE, LS0714 1

96 862821-6 NAME PLATE, LS0714 1

97 651923-1 SWITCH, LS1211 1

99 416534-7 SWITCH LEVER, LS711DWBEK 1

102 256098-7 PIN 5, LC1230 1

103 416533-9 LOCK OFF LEVER, LS711DWBEK 1

104 231026-3 COMP. SPRING 4, 2416S 1

105 911273-9 P.H. SCREW M5X50, HR2400 3

107 411478-6 SWITCH BUTTON, LS1011 1

109 183878-7 HANDLE SET, LS0711Z 1

110 265995-6 TAPPING SCREW 4X18, 4323K 5

114 317948-2 GUIDE FENCE, LS0714 1

114 317039-9 N/A 1

115 265489-1 HEX. BOLT M6 X 25, LS0714 3

116 251887-5 SCREW M6X10, LS1030 1

117 416535-5 SLEEVE 17, LS711DWBEK 1

118 231638-2 TORSION SPRING 28, LS711DWBEK 1

119 416535-5 SLEEVE 17, LS711DWBEK 1

120 251897-2 SCREW M6X33, LS1211 1

121 231325-3 COMPRESSION SPRING 6, LS1220 1

122 257214-4 RING 26, LS711DWBEK 1

123 317617-5 PIPE HOLDER, LS0714 1

124 266208-8 HEX SOCKET HEAD BOLT M6X8, 5044KB 2

125 687042-7 STRAIN RELIEF, 2711 1

125 687095-6 STRAIN RELIEF, LS1220 1

126 266026-4 TAPPING SCREW 4X12,9046 1

127 416536-3 WRENCH HOLDER, LS711DWBEK 1

128 266026-4 TAPPING SCREW 4X12,9046 1

129 911113-1 P.H. SCREW M4X10, 4301BV 1

130 416006-2 LEVER 100, LS1040 1

131 913106-4 SET SCREW M4X8, LS0714 1

132 252144-4 HEX. NUT M10-17, LS1013 1

133 231266-3 COMP. SPRING 5, LS711DWBEK 1

134 253024-7 F. WASHER 10, LS0714 1

135 286236-7 CAP 16, LS1211 1

136 153463-0 ARM CPL., LS0714 1

137 324295-4 RELEASE PIN, LS0714 1

138 265381-1 HEX. BOLT M6X16, LS711DWBEK 2

139 345299-3 STOPPER PLATE, LS0714 1

140 253726-5 F. WASHER 6, 6000LR 1

141 231663-3 TORSION SPRING 8, LS0714 1

142 265113-6 + PAN HEAD SCREW M5, LS0714 1

143 343678-9 INDICATION PLATE, LS1011 1

144 266026-4 TAPPING SCREW 4X12,9046 1

145 153462-2 FRONT ARM CPL., LS0714 1

Page 4 of 5 2/8/2008

Parts Breakdown LS0714

146 344643-1 STOPPER ARM, LS711DWBEK 1

147 253948-7 W. WASHER 8, UM140D 1

148 253835-0 F. WASHER 8, LS711DWBEK 1

149 251267-5 P.H. SCREW M6, LS1013 1

150 251961-9 H.S.H. SCREW M6X10, LS1040 1

151 251961-9 H.S.H. SCREW M6X10, LS1040 1

152 271601-3 KNOB 20,LS1030 1

153 213021-5 O RING 5, LS1030 1

154 324183-5 STOPPER PIN, LS0714 1

155 331350-5 PIPE 16-90, LS1030 1

156 153482-6 ARM HOLDER CPL., LS0714 1

157 256100-6 PIN 5, LS711DWBEK 1

158 266320-4 SCREW M10, BLS712SFK 1

159 253024-7 F. WASHER 10, LS0714 1

160 216413-7 THRUST NEEDLE CAGE 1

161 253024-7 F. WASHER 10, LS0714 1

162 252130-5 HEX LOCK NUT M10 LS1211 1

163 257214-4 RING 26, LS711DWBEK 1

164 251897-2 SCREW M6X33, LS1211 1

165 252105-4 HEX LOCK NUT M8-13, HM1800 1

166 253731-2 F. WASHER 8, 2414B 1

167 416355-7 INDICATION PLATE, LS1220 1

168 266026-4 TAPPING SCREW 4X12,9046 1

169 266026-4 TAPPING SCREW 4X12,9046 2

170 266026-4 TAPPING SCREW 4X12,9046 2

171 417993-8 KERF BOARD, LS0714 1

172 417993-8 KERF BOARD, LS0714 1

173 154688-9 TURN BASE CPL., LS0714 1

174 922111-0 H.S.H. BOLT M4X10, LS1011 1

175 153580-6 SQUARE ROD CPL., LS0714 1

176 925251-3 HEX. BOLT M5X30, LS711DWBEK 2

177 266034-5 TAPPING SCREW 4X16, 9524NB 2

178 344601-7 LOCK PLATE, LS1045 1

179 317616-7 PIN HOLDER, LS0714 1

180 256158-5 PIN 3, BJR181 1

181 324288-1 LOCK PIN, LS0714 1

182 231325-3 COMPRESSION SPRING 6, LS1220 1

183 324289-9 ROD 6, LS0714 1

184 416450-3 LOCK LEVER, LS1045 1

185 345272-3 LOCK LEVER PLATE, LS0714 1

186 266034-5 TAPPING SCREW 4X16, 9524NB 2

187 231418-6 COMP. SPRING 9, LC1230 1

188 253731-2 F. WASHER 8, 2414B 1

189 266296-5 ADJUST BOLT M8 X 27, LS0714 1

189 266432-3 N/A 1

190 273515-2 GRIP 32, LS711DWBEK 1

191 286212-1 CAP 20, LS1011 5

192 921472-5 HEX BOLT M8X50,8401 1

193 251887-5 SCREW M6X10, LS1030 2

194 154690-2 BASE CPL., LS0714 1

195 344646-5 SLIDE PLATE, LS711DWBEK 1

196 344646-5 SLIDE PLATE, LS711DWBEK 1

1,001 122523-9 DUST BAG, LS1040 1

1,002 122571-8 VICE ASS'Y, LS711DWBEK 1

1,003 411478-6 SWITCH BUTTON, LS1011 2

1,004 762001-3 TRIANGLE RULE, LS1011 1

1,005 322312-4 HOLDER, LS1040 2

1,006 A-90629 7-1/2 T.C. BLADE,40T,WOOD,LS0711Z 1

1,007 782223-9 BOX WRENCH, LS0714 1

5,001 810150-1 N/A 1

Page 5 of 5 2/8/2008
