Mamiya Universal User manual

Contents
Special Pointers for Using Mamiya Universal .......................................... 2
Main Features .................................................................................................. 3
Specifications ...................................................................................................
4
Description of Parts ........................................................................................
5
Assembling ........................................................................................................ 7
Attaching the Lens.. .................................................................................. 7
Pulling Out the Lens from its Retracted Position.. ............................ 7
Attaching the Hand Grip ......................................................................... 8
Stabilizing Plate ........................................................................................ 8
Attaching the Back .................................................................................. 9
MAdapter ................................................................................................... 9
G
Adapter.. ................................................................................................. 10
Polaroid Land Camera Back..
............................................................. 10
Operating the Viewfinder
................................................................................. 10
Selecting Brilliant Frame in the Viewfinder
....................................... 11
Focusing with Coupled Rangefinder..
................................................. 11
Areas of
Viewfinder Field to be Composed ............................................. 12
When Using Roll Film Holder
............................................................... 12
Distance Range Composed by
Brilliant Frame ................................ 12
When Using Polaroid Land Pack Film Holder
................................. 13
Depth of
Field Scale and Infrared Photography .................................... 15
Depth of Field Scale
.............................................................................
15
Infrared Photography
.............................................................................. 15
Shutter Operation
..........................................................................................
.16
Press Focus Operation
.......................................................................... 16
Using Flash
.................................................................................... ................
17
ACCESSORIES
................................................................................................
18
Acceptable Photosensitive Material and Actual Picture Size
............... 19
Roll Film Holder (6
x 9, 6x7) ................................................................... .20
Description of
Parts ................................................................................. 20
Prior to Loading Roll Film
.................................................................... .21
11
Loading Roll Film ..................................................................................... 21
Photographing
..........................................................................................
22
Roll Film Holder Model
K........................................................................... 23
Prior to Loading Roll Film Holder..
...................................................... 23
Loading Roll Film
.................................................................................... 23
Focusing Hood
................................................................................................ 24
Polaroid Land Pack Film Holder
................................................................ 25
Short Course on Photography
............................................................... 25
Accessories for Polaroid Land Pack Film Holder
.................................. 26
Focusing Hood Model
P........................................................................ 26
Optical Viewfinder Model
P.................................................................. 26
Format Gauge
.......................................................................................... 26
Focusing Screen Holder
.............................................................................. 27
Right-angle and Magnifying Focusing Backs
......................................... 28
Composing the Picture by Ground Glass Focusing Screen for
Cut Film
...................................................................................................... 29
Cut Film/Plate Holder Type J
..................................................................... 30
Cut Film/Plate Holder Type A
..................................................................... 31
Extension Rings
............................................................................................. 32
Spacer Set
...................................................................................................... 33
Life-size Photocopying Set
........................................................................ 36
Tetraphoto Adapter
........................................................................................ 37
Accessories for the Viewfinder
.................................................................. 38
Grip and Tripod Adapter
.............................................................................. 39
Cases
................................................................................................................. 41

Special Pointers for Using Mamiya Universal
Refer to the following pages for further details.
The 100 mm f/3.5 lens is a retracting type. When the lens When taking photographs with the vertical format camera
has been retracted, focusing cannot be effected although
l
position, on a tripod, use a tripod adapter on the hand grip
the two images on the rangefinder coincide. socket for vertical format photography.
Page 7 Page 40
Be sure to cock the shutter before keeping the shutter When using the roll film holder for Mamiya RB or the various
I
open with the press focus lever. Disengage the lever lock film holders and adapters for the 2
1/4 x 3 1/4 Graflok®back,
button and turn the lever in the same direction as the shutter
I
made by GRAFLEX®, Inc., use the G adapter instead of the
cock; then the shutter will remain open. M adapter.
By pushing the lever back to its original position, the shutter
will close.
Page 10
Page 16
When framing a 6x9 or 6x7 composition with the finders
brilliant frame, compose it within the inner edges of the
frame width for short distances; use the outer edges as a
guide for long distances.
Page 12
2

Main Features
The Mamiya Universal, the same unique breed as the Mamiya Press used by professional
photographers both at home and abroad, is a large 6 x9 film format camera with the functional
features listed below. It offers the distinct advantage of its large film size not only for general
photography,but also for news photography, commercial work, and scientific application.
*Large film size presents sharp, fine rendition of every detail.
*Variety of interchangeable lenses ranging from 50 mm wide angle to 250 mm telephoto.
*Quick interchangeability of lenses with bayonet ring mounting.
*Accurate focusing through coupled rangefinder.
*Finder with bright, easy-to-see brilliant frame, featuring automatic parallax compensation.
*Further accurate focusing through ground glass focusing screen possible.
*Quick photography with roll film holder (lever winding system).
Available in 6 x 9 and 6 x 7 format for both 120 and 220 films.
*Roll film holder K enables photography in 6 x 9, 6 x 6, or 6 x 4.5 format.
*Also accepts dry plates and cut films, providing for single shots with these films.
*Extreme close-up photography through using spacer set and/or extension rings.
*Use of Polaroid Land pack film holder offers instant photographic prints in 3¼ X4¼ inch for-
mat .
*The G adapter enables using the roll film holder and various film holders for Mamiya RB, in
addition to the film holders of 2¼ x 3¼Graflok back made by Graflex, Inc.
*Easy-to-grasp hand grip with cable release for added versatility.
*Many other accessories available for any type of photography.
3

Specifications
Type
Picture size
Lens mount
Shutter
Standard lens
Rangefinder
Viewfinder
: Interchangeable lens type 6 x 9 format camera
: Photography with 6 x 9, 6 x7, and 6 x 4.5
formats by using various holders. When using
the POLAROID LAND pack film holder, actual
picture size is 73 x 95 mm.
: Breech lock bayonet mount type.
: SEIKO #0 shutter
Shutter speed B, 1 -1/500 second
Flash synchronization, M and X selecting type.
With press focus device (shutter blade arrest-
ing)
: 100 mm f/3.5 retracting type, minimum aper-
ture f/32, with lens hood.
127 mm f/4.7, minimum aperture f/64, with lens
hood.
: Reversed Galileian telescope, couples double-
image coincidence type, instant coupling to
selected lens.
: Adjustable brilliant frame fields for 100 mm,
150 mm, and 250 mm lenses; 6 x 9 and 6 x 7
formats; Automatic parallax compensation.
Use exclusive optical viewfinders for 50 mm
and 75 mm lenses. When photographing
through the Polaroid Land film pack size, use
the optical viewfinder model P for 75, 100,
and 127 mm lenses.
4
Back mount
Grip
Others
Physical dimensions
: Interchangeable back, three types (M adapter,
G adapter, and Polaroid Land camera back)
can be attached.
: Removable hand grip with cable release.
: Flashgun mounting socket, accessory shoe,
camera body stabilizing plate, and tripod
socket are provided.
: (Camera body, with 100 mm f/3.5 lens)
Height: 6 19/32 in. (167 mm)
Width: 4 25/32 in. (121 mm)
without hand grip
Depth: 4 1/2 in. (114 mm)
lens in retracted position, distance
scale at infinity
(Camera body with 127mm f/4.7 lens)
Height: 6 19/32 in. (167 mm)
Width: 4 25/32 in. (121 mm)
without hand grip
Depth: 6 in. (152 mm)
Weight: Camera body: 2 Ibs. 1 1/2oz. (950 gr.)
100 mm f/3.5 lens: 1 lb. 1 oz. (480 gr.)
127 mm f/4.7 lens: 1 lb. 9/16 oz.
(470 gr.)
Hand grip: 10 9/16 oz. (300 gr.)
