Mamiya N Series User manual

Focusing Screens N
English Instructions

Introduction
Six focusing screens are available to address the needs of every photographer, subject and photographic
application.
Screen Properties
Type A Matte An all matte screen with a Fresnel lens
Type A4 Checker
An all matte screen with a Fresnel lens
and a grid pattern. The grid pattern is a compositional
aid and as a reference for multiple exposures
Type B
Rangefinder
An all matte screen with a Fresnel lens
and a central rangefinder spot. The split-image rangefinder
greatly improves focusing precision
Type C Microprism
An all matte screen with a Fresnel lens
and a central rangefinder spot. The split-image rangefinder
greatly improves focusing precision.
Type E
Rangefinder
Spot/Microprism
An all matte screen with a Fresnel lens and a
central rangefinder spot surrounded by a
a microprism
135 Panorama
Spot/Microprism
An all matte screen with a Fresnel lens and a central
rangefinder spot surrounded by a microprism
Changing Focusing Screens
CAUTION
Since the focusing screens’ surfaces are made from plastic and are soft and easily damaged, be
sure to handle them carefully.
Never touch the surface of a screen with your bare fingers.
To remove dust, blow it away using a bulb-type blower. Do not use canned compressed air, as
this may leave a propellant residue on the screen.
Clean the screen with a soft, lint-free cloth and a small amount of ether or benzene. Do not use
petroleum-based solvents, ketones or paint thinners to clean a screen.

Set the Mirror Lock-up Lever to its ‘SQUARE’ position.
Remove the lens.
Slide the Focusing Screen Release Pin (1) to the left using the focusing
screen tweezers. The Focusing Screen Frame (4) will drop down.
Remove the focusing screen from the Focusing Screen Frame by
grasping the focusing screen’s tab (3) with the tweezers, and then
lifting the focusing screen up and out of the Focusing Screen Frame.
Store the screen in a suitable container so that it won’t be damaged.
Using the focusing screen tweezers, grasp the replacement screen by
its tab (3), and then position it into the Focusing Screen Frame (4).
Carefully push the Focusing Screen Frame (4) up until it clicks and locks
into place. Be careful not to damage the screen.
Install the lens.
