INSTRUCTION BOOK FOR
Designer Manual

2
For Wall Mounting
Hardware Provided
(2) “V” Bars ( one is factory mounted to the back of the case; one will be mounted to the wall)
(6) Toggle Bolts, 4"
(6) Lead Shields, #1014 x 11/2"
(6) Phillips Flat Head Wood Screws, #10 x 2"
Tools Required
Electric Drill
Masonry Bit 5/16" (if mounting in solid masonry or concrete)
Screw Driver, #2 Flat Tip (if using toggle bolts)
or #2 Phillips (if mounting in solid masonry or concrete)
Mount Top Of
"V" Bar Flush
With Top Of Case
"V" Bar Mounted
To The Wall
"V" Bar Mounted To
The Back Of The Case
At The Factory
Wall
Floor Line
Ceiling
Allow A Minimum Of 1 ¼"
From The Ceiling
Determine
Measurement
To The Top Of
The Case
4"
4 ¼"

3
Installation Instructions Maintenance
Determine the height of the top of the case from the loor.
This will be the height of the wall mounted “V” bar.
Hold the loose “V” bar to the wall at the height determined above
(MAKE SURE IT IS LEVEL), and mark the location for the screw
holes. To mount the “V” bar on solid concrete or masonry wall,
drill 5/16" holes and insert the lead shields. Fasten the “V” bar to
the wall using the #10 x 2" wood screws. If you are mounting to a
hollow wall, drill 1/2" holes and insert the toggle bolts. Then fasten
the “V” bar to the wall with the toggle bolts. Now set the case in
place on the wall with the “V” bar of the case nestled into the
“V” bar on the wall.
For Ceiling Suspension
Position and properly anchor screw hooks into ceiling, beam
or other solid surface. Then proceed to use the two “D” rings
that are factory mounted to the top of the case to hang the
case securely.
To Lower And Raise Picture Surface
To lower the picture surface, pull the screen down all the way.
Then hesitate and allow the screen to retract very slowly until it
locks in place. To raise the picture surface pull down on the pull
bail, then raise quickly, as a window shade. Keep control of the
picture surface. Do not allow it to roll uncontrolled into the case
or damage to the screen is sure to result.
Projection Screen Maintenance
Protect your screen by keeping it rolled in its case when not
in use. Always examine both front and back of surface before
rerolling into case to make certain screen is free of dust, dirt
or other foreign matter. Use a very soft duster brush to gently
remove foreign particles.
Case Maintenance
The case of the screen has a Resistovar inish. This inish is
resistant against: water, alcohol, marring, scratching, and nail
polish remover. To help maintain the best appearance of the
case it is recommended that the case be polished with any
reputable liquid or paste wax polish. An oil type polish is not
recommended because it allows for the collection of dust and
inger prints. When necessary, this inish may be wiped with
a damp soft cloth using a mild soap solution, rinsed with
clear water and dried with a soft cloth.

LIMITED ONE YEAR WARRANTY ON DA-LITE PRESENTATION PRODUCTS
Milestone AV Technologies LLC warrants certain Da-Lite branded products to the original purchaser only, to be free from defects in
materials and workmanship for a period of one (1) year from the date of purchase by the original purchaser; provided they are properly
operated according to Da-Lite's instructions and are not damaged due to improper handling or treatment after shipment from the
factory.
This warranty does not apply to equipment showing evidence of misuse, abuse or accidental damage, or which has been tampered
with or repaired by a person other than authorized Da-Lite personnel.
Da-Lite’s sole obligation under this warranty shall be to repair or to replace (at Da-Lite’s option) the defective part of the merchandise.
Returns for service should be made to your Da-Lite dealer. If it is necessary for the dealer to return the screen or part to Da-Lite,
transportation expenses to and from Da-Lite are payable by the purchaser and Da-Lite is not responsible for damage in shipment.
To protect yourself against damage or loss in transit, insure the product and prepay all transportation expenses.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS
OR IMPLIED, INCLUDING WARRANTIES AS TO FITNESS FOR USE AND MERCHANTABILITY. Any implied warranties of itness for use,
or merchantability, that may be mandated by statute or rule of law are limited to the one (1) year warranty period. This warranty gives
you speciic legal rights, and you may also have other rights, which vary from state-to-state. TO THE MAXIMUM EXTENT PERMITTED
BY APPLICABLE LAW, NO LIABILITY IS ASSUMED FOR EXPENSES OR DAMAGES RESULTING FROM INTERRUPTION IN OPERATION
OF EQUIPMENT, OR FOR INCIDENTAL, DIRECT, OR CONSEQUENTIAL DAMAGES OF ANY NATURE.
In the event that there is a defect in materials or workmanship of a Da-Lite product, you may contact our Sales Partners at PO Box 137,
Warsaw, IN 465810137, (574) 2678101, (800) 6223737.
IMPORTANT: THIS WARRANTY SHALL NOT BE VALID AND DA-LITE BRANDED PRODUCTS SHALL NOT BE BOUND BY THIS
WARRANTY IF THE PRODUCT IS NOT OPERATED IN ACCORDANCE WITH THE DA-LITE WRITTEN INSTRUCTIONS.
Keep your sales receipt to prove the date of purchase and your original ownership.
