Mammoth 1000 User manual

MAMMOTH 1000
Air Purifier
E
xperience Pure Air
of Sensational
Altitude
USER GUIDE

Please read all of the information provided in this user’s guide before
operating your new air unit.
Q. What is Nano photo-catalytic filter?
A. The action of this filter is based on photo-catalytic oxidation (PCO)
technique. Airborne pollutants are treated by semiconductor photo-catalysis,
in which the key material is TiO2.TiO2 particles are used as photo-catalyst
because it is non-toxic, chemically stable, and possesses relatively high
photo-catalytic activity.
WARNING
This air unit is not a medical device. Do not stop or alter any medical therapy
programs or medications without the advice of your physician. Excessive ozone
concentrations may cause mucous membrane or respiratory irritation.
Q. How does it compare to air filters?
A. Air Purifiers do not rely on the air to actually pass through the machine to
be cleaned like air filters. It’s not a filter at all. Air Purifiers produce
activated oxygen’s, which reduces both odors and negative ions, which settle
on particles.
Q. What’s the function of UV light?
The Ultraviolet Light destroys bacteria, viruses, fungi, yeast, and mold; it
reduces or prevents mold growth, thereby allowing them to function at peak
efficiency. These high-output, long-lived UV lamps can be used in industrial
commercial and residential applications.
Q. Where should I place the Air Purifier in my home or office?
A. The Air Purifier should be placed in the room where you have the most
pollutants. The Air Purifier is easy to move so you might want to try it in a
couple of locations to help decide what works best for your environment. An
elevated location is better to distribute ions and activated oxygen more
evenly. The Air Purifier works best if it is placed within 10 feet of a cold air
return.
Q. How long will the Air Purifier last?
A. The air purifier is made of stainless steel and solid wood construction.
Because of the quality material and superior craftsmanship that goes into
each Air Purifier you will enjoy it for many years.
Q. Is it difficult to install?
A. No. Just plug the power cord (located in separate box packaged inside the
carton), into the unit and set the time for the area you will be treating. Install
the Air Purifier in any room; try to find a place where it can be up off the
ground four feet or more. Some customers prefer to have more than one unit
to better improve the air quality in the home.
CAUTION
RISK OF ELECTRICAL SHOCK
D
O
N
O
T
O
PEN
ATTENTION
This “exclamation point” calls attention to a feature for
which you should read the enclosed literature carefully to
prevent operating and maintenance problems.
This “bolt of lightning” indicates that insulated material
within your unit may cause an electrical shock. For the
safety of everyone, do not remove product covering.
Caution: This unit is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision concerning use of the unit
by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the unit.
-1- -10-

COMMONLY ASKED QUESTIONS
Q. What does the Air Purifier do?
A. It treats the air in your home or office by breaking down odor causing
pollutants and dropping airborne particles from your breathing space.
Q. How does the Air Purifier treat the air?
A. The Air Purifier goes through 5 stages of air purification systems to purify
the air and create a health and comfortable living environment.
Q. How does the Air Purifier work?
A. It is a four-stage process
1. The Air Purifier uses a needlepoint ionizer to trap dust, smoke
and other harmful particles from the air we breathe. In our homes
and offices there is a lack of negative ions and an abundance of
positive ions. The buildings we spend most of our time in block
out the natural occurring negative ions. The Air Purifier recreates
the natural balance of positive to negative ions to significantly
reduce airborne particles.
2. The Air Purifier uses a Nano photo-catalytic filter to treat the
airborne pollutants; it is revitalized when caught by the UV light.
3. The ultraviolet light destroys microorganisms such as bacteria,
mold and viruses in the air.
4. The HEPA filter captures particles below 0.3 microscopic sizes
such as radioactive dust in atomic plants. The HEPA filter is
mainstreamed in areas that require clean air such as hospitals,
sanitary rooms, and high-tech manufacturing plants.
Q. How does nature produce ions?
A. Waterfalls, lightning, and the waves of the ocean all create negative ions.
Congratulations on your purchase. You have obtained a
state-of-the-art air purification system with wood cabinetry
and a high quality laminated surface. Only the finest
materials surround the finest air purification technology.
We hope that you will enjoy your purchase for years to
come.
Read ALL instructions carefully before using this
product
FOR YOUR RECORDS
Please record the model and serial number below, for easy reference, in case of
loss or theft. These numbers are located on the back panel of your air
purification unit. Space is also provided for other relevant information.
Model number
Serial Number
Date of Purchase
Purchased From
-9- -2-

CLEANING & MAINTENANCE
Understanding the Air Purifier
(Front View)
When the purifier no longer produces enough ozone to be effective, the ozone plate
should be cleaned. A good rule of thumb is every month. Some environments cause
ozone output to be reduced in a shorter time but other environments may take longer.
To clean a plate, first turn the unit OFF and UNPLUG it from the wall outlet. Remove
the 4”x4” plates from back of unit. Pull plates firmly in the center to remove them from
the slot. With plate firmly supported in the hand; apply a solution of warm water and
ammonia (50/50 solution is suggested) or a strong grease cutting detergent. Scrub with a
stiff brush if necessary. Be careful not to drop the plate or scrub off the silicone. Clean
both the metal screen and the ceramic tile. Rinse plate in hot water and DRY
COMPLETELY before installing. If available you may use a hair dryer to dry the plate.
Reinstall plate, making sure it is secured and flush with the back of the unit. Plug unit
into a grounded electrical outlet, turn unit on and start enjoying clean fresh air.
To clean needlepoint ionizer, first turn it OFF and UNPLUG it from the wall outlet.
Remove the fan grill cover. The needle point ionizer will be easy to find in front of the
fan by looking for two pieces of wire. Take a q-tip or cotton swab dipped in alcohol and
clean any dust that may have accumulated on the needlepoints. This process may be
done when plates are being cleaned. While you have the front grill cover off the unit you
may also clean the fan and grill itself. To clean the fan, simply wipe the blades with a
damp cloth or vacuum. The grill cover may also be cleaned with warm soapy water.
Make sure that the fan grill cover is completely dry before installing.
Fan Grill
Manual Button
LCD
Display
panel Remote
Controller
PART FUNCTION
LCD display panel Displays working status, time; with blue backlight
optional.
Remote Controller Controls the working status of the air purifier.
Manual Button Controls the air purifier by hand.
Fan Grill Removable fan grill. Wash with warm soapy water,
dry completely before replacing.
(Unplug unit before removing)
The control for the negative ion generator is separate from the O3control.
Negative ions can be created around the clock to reduce dust and particles.
O3 - also known as activated oxygen is normally kept at modest levels in
occupied spaces. To remove heavy odors, the units may be adjusted to a higher
level for a period of time. Some use a timer to completely deodorize the home
or office while away. Unused O3reverts back to O2in approximately one hour.
If you suspect a problem with your unit check the following:
•Make sure plate is clean (see above).
•Unit is plugged in properly and turned on.
•Check the fuse to make sure it is installed properly and not burned out. To replace
fuse, push in and turn fuse holder to the left, remove old fuse, replace with spare.
Use 1 amp fuse, 1.25 inches long.
•Confirm that the wall outlet is active.
•Check plate alignment making sure the ceramic plate is flush with back of unit.
•It is important that the Air purifier be properly grounded to avoid potential shock.
TROUBLESHOOTING
Caution: Turn Power Switch OFF when opening the back panel of the unit
to replace parts.
-3- -8-

Understanding the Air Purifier
(Back View)
Some users who are sensitive to ozone set their units up on a timer so that the
purifier does its work only when they are away from home. This allows for a
higher setting and a higher concentration, which can be more effective for
purging purposes. The ozone will normally dissipate in less than one hour after
the purifier is turned off. Simple timers plug into an outlet and are available at
hardware and variety stores.
WHERE TO USE?
•Homes & Living Areas
•All types of offices & stores
•Water & fire damaged areas
•New paint & wallpaper areas
•Odor clean-up
•“Sick” buildings
•Hospitals & nursing homes
•Veterinary offices
•Smoking areas
•Hotel rooms
•High pollen environments
•Newly carpeted rooms
•Kitchens
•Attics & basements
•Laundry rooms
•Doctors’ offices
•Day care centers
•Stables & aviaries
•Locker rooms
•Restaurants & bars
SERVICE
Should you determine that your air unit requires service, please contact your
local dealer.
PART DESCRIPTION
Power Cord 120 Volt grounded cord (unless otherwise
specified). DO NOT bypass ground wire cord.
TiO2 Photo-catalytic Filter Photo-catalytic filter can be replaced very easily. It
is long lasting and does not need replacing often.
HEPA filter The HEPA filter can be replaced by taking off
the screws. Its lifetime is one year.
UV light 365μm wavelength, replaceable by an
authorized technician.
NOTE: As you stand in front of the unit the ionizer will create a slight charge.
If you then touch a metal object there may be a static electric discharge similar
to touching a doorknob during the winter.
UV Light HEPA filter
Power Cord
Socket
USING A TIMER
Power Switch
Photo catalytic
filter
Pre-filter
-7- -4-

Set Unit to desired functions and levels. Turn unit off using the “ON/OFF”
switch on the front display (rear power switch remains “on”). Press
“Time/Set” button once. The “Time/Set” indicator will flash. While flashing,
use “Hour up” or “Hour down” controls to set the desired hour and “Fan up”
or “Fan down” controls for the desired minute to set the time of day you wish
the unit to automatically turn on. Press the “Time/Set” button two final times
to set the timer. The appearance of a clock icon on your LCD panel indicates
that this function has been properly set.
1. Manually, or with remote control, turn unit “on”.
2. Press “Fan △“or “Fan “to adjust airflow speed. There are five speeds
from which to choose.
3.”Sterilize” controls the UV lamps and photo-catalytic filter. You’ll know
that this feature is activated from the soft blue glow visible through the front
grill. Press this button to both activate and de-activate this feature “Don’t
stare directly at the blue light.”
4.” Anion” controls the dispersing of negative ions. You‘ll know that this
feature is activated as the orange bulb will be lit and clearly visible through
the front grill. With the “Sterilize” feature, this button can both activate and
de-activate the negative ions
5.”Sleep” mode dims the LCD panel to a minimum level allowing for a good
night sleep when the unit is used in the bedroom. It is important to note that
use of “Sleep” mode does interrupt the Activated Oxygen setting but leaves
all remaining settings in tact.
6. Proper Installation of photo-catalytic filter. Please be sure if you want
to replace a photo-catalytic filter and reinstall the photo-catalytic filter, you
must install it according to the pictures indicated below otherwise the unit
will not work.
To set the clock to the current time, press the “Time/Set” button twice in
quick succession. The “Time” indicator will flash. While flashing, press
“Hour up” or “Hour down” to set the hour. Press “Fan up” or “Fan down” to
set the minutes. Press the “Time/Set” button one final time to conclude the
process. NOTE: The Air Purifier and Sterilizer employ a US standard 12
hour clock.
Your Air Purifier gives you the option to start or shut
down the unit using the digital timer feature...
To set the “start” time:
To set the “shut off” time:
While unit is on press “Time/Set” button once. As with previous timer
function, “Time/Set” display panel indicator will flash. While flashing, use
“Purify” and “Fan” controls to set desired hour and minute per previous
examples. Press “Time/Set” button twice to conclude this process. As
before, the clock icon appearing on the LCD panel is your indicator that this
function has been properly set.
OPERATION / SETTINGS AND CONTROLS
Adjust Hour Adjust Minute
SETTING THE CLOCK AND DIGITAL TIMER
-5-
Wrong Correct
Hou
r
Hou
r
