The CAMEL by Mangar International, is an inatable
lifting device which is designed to sit up and lift a fallen
person from the oor. When inated, the CAMEL lifts
the patient into a raised seated position ready to stand
with or without assistance.
This equipment may be used with or without a helper
as required.
The CAMEL is powered by a Mangar International
Airo Compressor and controlled using a CAMEL Hand
Control. Please refer to the separate Airo compressor
instructions before operating.
Patents Pending
CONTENTS
Pg 3 Standard Package Contents
Pg 3 Connecting the Hand Control and Airo
Pg 3 Extra Air Flow
Pg 4 Airo ‘Auto’ Control Button
Pg 4 Positioning the patient on the CAMEL
Pg 4 Using the CAMEL
Pg 6 After Use
Pg 6 Maintenance
Pg 6 Routine Cleaning & Disinfecting
Pg 6 Specications
Pg 7 Symbols used on packaging
Pg 7 Warranty
2
ME0074 issue 2
PLEASE BE SURE THAT YOU HAVE READ AND
UNDERSTOOD THESE INSTRUCTIONS AND THOSE
PROVIDED WITH THE AIRFLO, BEFORE OPERATING
THIS EQUIPMENT.
WARNINGS
This equipment MUST only be used by persons •
familiar in its use.
The medical state of a person needing to be raised•
MUST be assessed before commencing a lift.
Ensure that the surface on which the CAMEL is to•
be placed is free from sharp objects.
If the slide sheet has been used to transfer the•
patient onto the CAMEL it must be removed from
under the patient before commencing a lift.
Sections 2, 3 and 4 MUST always be fully inated in •
sequence from the bottom up, in order to maintain
stability. NOTE: The backrest may be partially
inated before any other section is raised. Once the
lowest section is fully inated, the backrest can be
raised further as required.

camel
Standard Package Contents - g.
1 x CAMEL (A) including carrying bag (not shown)
1 x CAMEL Hand Control (B)
2 x Airo Compressors (C) with user instructions
1 x Slide Sheet (not shown)
1 x Transfer Belt (not shown)
Connecting the Hand Control and Airo - g.
Remove the CAMEL from the carrying bag, •
unfasten the straps and unroll.
Connect the four hoses (• A) from the Hand Control
to the corresponding numbered and colored
connectors on the CAMEL.
Connect the hose (• B) from the Hand Control to the
Airo compressor.
Position the Airo compressor so that it will not be •
in the way while positioning the patient. Ensure
that the hoses are not kinked.
Extra Air Flow - g.
Select the ‘High’ Air Flow using the switch on the •
underside of the Airo compressor (D).
WARNING: DO NOT operate the Normal/High air ow
switch while the compressor is running.
3
freedom through lightweight solutions
ME0074 issue 2
2
B
A
3
A
B
C
1
Normal High
D
1
2
3

camel
4
ME0074 issue 2
Positioning the patient on the CAMEL - g. 5
Position the CAMEL at the side of the patient so •
that the patient’s head is level with the CAMEL
badge (A).
Transfer the patient onto the CAMEL. The head •
should lie on the CAMEL badge (A) and the body
should lie centrally.
Using the CAMEL
The following instructions apply equally when the
CAMEL is being operated by a person raising
themselves without assistance, or by an assistant
raising a patient.
WARNING: If the slide sheet has been used to
transfer the patient onto the CAMEL it must be
removed from under the patient before commencing
a lift.
Press the number 1 button on the CAMEL Hand •
Control to partially inate the backrest section until
the patient is in a comfortable position - g. 6
Press the number 2 button to inate the bottom •
section - g. 7 until it becomes rigid.
A
5
Airo ‘Auto’ Control Button - g.
The ‘Auto’ function must be selected in order to operate
the CAMEL Hand Control. When selected, the Airo
will work automatically when the CAMEL Hand Control
buttons are pressed.
To switch the ‘Auto’ function • on, press and hold
the button (A) for a few seconds until the LED (B)
lights up.
To switch the ‘Auto’ function • off, Press any of the
Airo buttons.
WARNING: Pressing any of the Airo buttons will
cancel the ‘Auto’ function and the hand control will not
work.
4
B
A
4
6
7

camel
5
freedom through lightweight solutions
ME0074 issue 2
WARNING: In order to maintain stability, sections
must always be fully inated from the bottom up, in
sequence.
Note: only the backrest (section 1) may be partially
inated before the lower sections.
8
9
10
Continue to press buttons 3 and 4 • in sequence
until the sections become rigid, in exactly the
same manner - g. 8
Press button 1 to fully raise the backrest and arrive •
at a sitting position - g. 9
Whether assisted or used alone, the patient should •
now be in a position to stand or transfer - g. 10

camel
6
After Use
To deate, disconnect each of the air hoses from •
the CAMEL by pushing the release collar on the
connector away from the hose and then pulling
the hose clear of the connector. NOTE: The initial
‘rush’ of air as the hoses are disconnected from the
CAMEL, can be reduced by rst disconnecting the
air hose from the Airo and then pressing each of
the buttons on the hand control.
Roll up the CAMEL with the Hand Control in the •
hollow (A) - g. 11 secure the straps and place in
the carrying bag - g. 12
Maintenance
Other than routine cleaning, the CAMEL is maintenance
free. The backrest section or the main lifting section
can be replaced separately if required.
We recommend that a thorough examination of the
CAMEL is carried out regularly; the frequency of
examination may need to be increased depending on
usage and operating environment.
Routine Cleaning
Inate the CAMEL, sponge clean with a detergent
solution and dry thoroughly before storing in a dry
place. Do not dry using hot air.
Disinfecting
Inate the CAMEL, pre-clean with a detergent solution
and then sponge with a disinfecting solution or alcohol
impregnated wipe. Allow to air dry before storage. Do
not dry using hot air.
Specications
Maximum user weight: 700lbs
Seat height (approx): 22”
Overall length (approx): 44”
Overall width (approx): 27½”
Deated & rolled (in bag):
Length : 30”
Diameter: 8”
Weight (Inc. Hand Control): 14lbs
Maximum air pressure: 5psi
Max / Min temperature: +120/-60°F
ME0074 issue 2
44”
22”
27 ½”
11
12
A

camel
7
freedom through lightweight solutions
ME0074 issue 2
symbols used on packaging
Keep packaging dry
Handle with care
Max/Min storage temperature
Net & gross weights
Stack no more than ve high
Recycle packaging
Do not dispose of in trash
Max/Min humidity when transporting in
pressurized aircraft hold
Max/Min pressure when transporting in
pressurized aircraft hold
Max/Min temperature when transporting in
pressurized aircraft hold
Warranty
Mangar International guarantees this product for a period of two years.
The guarantee is given against defects in material and workmanship and comprises piece,
parts and labor. The guarantee is not valid in the case of fair wear and tear, wilful damage,
common neglect, misuse or unauthorized alteration or repair by unqualied persons.
The following statements do not affect the consumer’s statutory rights. This product is sold on the understanding that in
the event of any defect of manufacture or material appearing within two years of the date of receipt of this product, the
defect will be rectied free of charge providing that:
(a) Reasonable evidence is provided (e.g. purchase invoice, delivery note) that the product was not purchased more
than two years prior to the date of the claim.
(b) The defect is not attributable to accidental damage (either in transit or otherwise), misuse or unauthorized repair.
CAMEL serial number: .............................
Airo serial number: .............................
Date of purchase: .............................
Invoice/Delivery note number: .............................
