Manhattan Comfort FP1 User manual

FIREPLACE TV STAND
FP1

Part Identification
Hardware Identification
Assembly Steps
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Table of Contents Assembly Tools Required
3
4
5-24
FP1Page 2

Part Identification
◆While not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
Now you know
our ABCs.
A TOP (1)
B BOTTOM (1)
C LEFT END (1)
D RIGHT END (1)
E LEFT UPRIGHT (1)
F RIGHT UPRIGHT (1)
G BACK (2)
HSHELF (2)
J TOP MOLDING (1)
K LEFT MOLDING (1)
P DRAWER RIGHT (2)
Q DRAWER BACK (2)
R DRAWER BOTTOM (2)
S FOOT (2)
W FIREPLACE (1)
X TOP BRACKET (1)
Y END BRACKET (2)
Z MIDDLE SHELF (1)
L RIGHT MOLDING (1)
NDRAWER FRONT (2)
O DRAWER LEFT (2)
Page 3
FP1

Hardware Identification
◆Screws are shown actual size. You may receive extra hardware with your unit.
EXTENSION RAIL- 4
1EXTENSION SLIDE- 4 2CAM SCREW -32 3
APPLIQUE CARD- 6
7 8 2-11/16" PAN HEAD SCREW-12
HIDDEN CAM - 32
4PULL - 4
5WOOD DOWEL-8
6
2" PAN HEAD SCREW-11
91-3/16" PAN HEAD SCREW-8 10 3/4" MACHINE SCREW-8 11
1/2" FLAT HEAD SCREW-16
12 14
3/8" PAN HEAD SCREW-15
ZZ
METAL PIN-4
13
FP1Page 4
522,68 22,68
22 kg 22 kg
(Refer to the last step for proper location and application)
WARNING LABEL - 1

HOW TO USE A HIDDEN CAM & CAM SCREW OR CAM DOWEL
NOTE: Various CAM SCREWS or a CAM DOWEL may be used.
Cam Screws Cam Dowel
Turn the CAM SCREW or
the surface of the part.
1.
Hidden CamHidden Cam
Arrow
Push a HIDDEN CAM into
the part. The arrow in the
HIDDEN CAM must point
toward the hole in the
Hole
2.
3.
1
2
Insert the CAM SCREW or CAM DOWEL into the
Page 5
FP1

Step 1
◆Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
Turn thirty-two CAM SCREWS (3) into the TOP (A),
ENDS (C and D), UPRIGHTS (E and F), MOLDINGS
(K and L) and DRAWER FRONTS (N).
◆
FP1Page 6

Arrow
Arrow
Arrow
◆Push sixteen HIDDEN CAMS (4) into the ENDS (C and D),
UPRIGHTS (E and F), BACKS (G).
Step 2
Page 7
FP1
Arrow
The arrow in the HIDDEN
CAM must point toward the
Hole

Arrow
Arrow
Arrow
Push sixteen HIDDEN CAMS (4) into the DRAWER LEFT
(O), DRAWER RIGHT (P) and SHELVES (H).
◆
Step 3
FP1Page 8

Step 4
◆Fasten the MOLDINGS (K and L) to the UPRIGHTS (E
and F). Tighten four HIDDEN CAMS.
Page 9
FP1

Step 5
◆
◆
◆
◆
Separate the WIDE EXTENSION SLIDES (2) from the WIDE EXTENSION RAILS (1) as shown in the upper diagram
below. Be prepared, the parts are greasy.
Fasten the WIDE EXTENSION RAILS (1) to the UPRIGHTS (E and F) and ENDS (C and D). Use four 1/2" FLAT
HEAD SCREWS (12).
NOTE: For each EXTENSION RAIL, turn a SCREW into the hole shown in the enlarged diagram. Then, slide the inner
cartridge of the EXTENSION RAIL in to find the other hole that lines up with the hole in the UPRIGHTS and ENDS.
Turn a SCREW into this hole.
NOTE: The EXTENSION SLIDES will be used later for the DRAWERS.
FP1Page 10
1/2" FLAT HEAD SCREW
(8 used in this step)
Open end
Open end

Step 6
◆Fasten the SHELVES (H) to the UPRIGHTS (E
and F) and ENDS (C and D). Tighten eight HIDDEN CAMS.
Page 11
FP1

Step 7
◆
Fasten the TOP MOLDING (J) to the TOP (A).
Use three BLACK 2'' PAN HEAD SCREWS through
the MOLDING and align to the holes in the top before
you fasten.
FP1Page 12
2" PAN HEAD SCREW
(3 used in this step)

Step 8
◆
◆
Push the WOOD DOWELS (6) into the exact hole shown in
the TOP (A).
Fasten the ENDS (C and D) and the UPRIGHTS (E and F) to the
TOP (A). Tighten eight HIDDEN CAMS.
Page 13
FP1
WOOD DOWEL
(4 used in this step)

Step 9
◆Fasten the BACKS (G) to the TOP (A). Tighten four HIDDEN CAMS.
FP1Page 14

Step 10
◆
◆
◆
Push the WOOD DOWELS (6) into the exact hole shown in
the ENDS (C and D) and the UPRIGHTS (E and F).
Fasten the BOTTOM (B) to the ENDS (C and D), UPRIGHTS (E and F) and the BACKS(G).
Use twelve BLACK 2-11/16" PAN HEAD SCREWS (8).
NOTE: You should align each SCREW to the holes before completely
tightening any of them.
Page 15
FP1
2-11/16" PAN HEAD SCREW
(12 used in this step)
WOOD DOWEL
(4 used in this step)

Step 11
◆
Fasten the FOOT (S) to the BOTTOMS (B).
Use eight BLACK 2'' PAN HEAD SCREWS through
the FOOT and align to the holes in the bottom before
you fasten.
FP1Page 16
2" PAN HEAD SCREW
(8 used in this step)

Step 12
◆
◆
Fasten the DRAWER SIDES (O and P) to the
DRAWER BACK (Q). Use four 1-3/16'' PAN
HEAD SCREWS through the DRAWER SIDES
and please align to the holes in the DRAWER
BACK before you fasten.
Repeat this step for the other drawer.
Page 17
FP1
1-3/16" PAN HEAD SCREW
(8 used in this step)

Step 13
◆
◆
◆
Slide the DRAWER BOTTOM (R) into the
grooves in the DRAWER SIDES (O and P) and
DRAWER BACK (Q).
Repeat this step for the other drawer.
Peel APPLIQUES from the APPLIQUE CARDS (11) and stick them onto each visible HIDDEN CAM.
Be sure the DRAWER
BOTTOM inserts into the
DRAWER BACK groove.
FP1Page 18

Step 14
◆
◆
◆
Fasten the DRAWER FRONT (N) to the DRAWER
SIDES (O and P). Tighten four HIDDEN CAMS.
Fasten the PULLS (5) to the DRAWER FRONT (N).
Use four 3/4" MACHINE SCREWS (11).
Repeat this step for the other drawer.
Page 19
FP1
3/4" MACHINE SCREW
(8 used in this step)

Step 15
◆
◆
Fasten the WIDE EXTENSION SLIDES (2) to the DRAWER SIDES (O and P). Use four 1/2" FLAT HEAD
SCREWS (9).
Repeat this step for the other drawer.
FP1Page 20
1/2" FIAT HEAD SCREW
(8 used in this step)
