De La Espada TABLE ONE User manual

0
1
M
A
N
U
E
L
A
I
R
E
S
M
A
T
E
U
S
PARTS
1x Tabletop
2x Leg frames
2x Side beams
HARDWARE
(6x) Universal connector (6x) Metal dowel
(8x) M8x65 Caphead screw (8x) M8 Washer
YOU WILL NEED
-6mm Allen Key
-The help of 3 or 4 friends
NOTES
NOTE 1: Be certain that all assembly is carried out on a at
and stable surface. This will ensure a good nal result.
Reverse the steps to disassemble the piece.
NOTE 2: Your furniture arrives packed in numerous layers that
protect it during transport. It is important that you remove
the packaging carefully to avoid damaging your furniture. Refer
to our information sheet “Unpacking Your Furniture” for further
details.
NOTE 3: Great care is required when assembling our products.
Use blankets to soften the assembly surface - hard surfaces
such as wood or stone ooring may damage the furniture if in
direct contact.
NOTE 4: We advise that assembly and disassembly is undertaken
by a minimum of 4 people.
NOTE 5: When screwing in bolts, tighten well, but be sure
NOT TO OVERTIGHTEN. This can cause the thread to strip thus
resulting in a poor connection.
NOTE 6: While you work, be sure all connections are ush with
no gaps.
NOTE 7: After assembly, ensure that the table is resting on a
level surface.
ASSEMBLY INSTRUCTIONS
TABLE ONE BY MANUEL AIRES MATEUS
[e-mail] M
DELAESPADA.COM

0
2
M
A
N
U
E
L
A
I
R
E
S
M
A
T
E
U
S
ASSEMBLY INSTRUCTIONS CONTINUED
TABLE ONE
INSTRUCTIONS
1) REMOVE TRANSPORT BRACES FROM UNDERSIDE OF TABLETOP
a) Place the tabletop face down onto a clean, soft surface such
as blanket or carpet on the oor.
b) Locate the transport braces located at either end of the
tabletop.
[e-mail] M DELAESPADA.COM
c) Using an Allen Key, unscrew each of the caphead screws
securing the transport braces in place. Remove the caphead
screws, washers, and the transport braces and place them to one
side.

0
3
M
A
N
U
E
L
A
I
R
E
S
M
A
T
E
U
S
ASSEMBLY INSTRUCTIONS CONTINUED
TABLE ONE
[e-mail] M DELAESPADA.COM
d) The tabletop should now look like this.
2) ATTACH LEG FRAMES TO TABLETOP
a) Insert Universal Connectors into the rebates in the side-
beams and central beam.

0
4
M
A
N
U
E
L
A
I
R
E
S
M
A
T
E
U
S
ASSEMBLY INSTRUCTIONS CONTINUED
TABLE ONE
[e-mail] M DELAESPADA.COM
b) Screw metal dowels into the pre-drilled holes in each leg
frame, as indicated below.

0
5
M
A
N
U
E
L
A
I
R
E
S
M
A
T
E
U
S
ASSEMBLY INSTRUCTIONS CONTINUED
TABLE ONE
[e-mail] M DELAESPADA.COM
c) Push the parts together while guiding the metal dowels into
the Universal Connectors. Tighten the connections rmly with an
Allen key.

0
6
M
A
N
U
E
L
A
I
R
E
S
M
A
T
E
U
S
ASSEMBLY INSTRUCTIONS CONTINUED
TABLE ONE
[e-mail] M DELAESPADA.COM
3) ATTACH SIDE BEAMS
a) Place the sidebeams into position between the legs at either
end of the table, aligning the pre-drilled holes with those in
the tabletop. Insert the caphead screws with washers into each
of the pre-drilled holes and tighten rmly with an Allen key.
4) TURN THE TABLE INTO AN UPRIGHT POSITION
a) With the help of 3 or 4 friends, carefully turn the table
over into an upright position, taking care not to place any
weight/force on the table legs while turning.

0
7
M
A
N
U
E
L
A
I
R
E
S
M
A
T
E
U
S
ASSEMBLY INSTRUCTIONS CONTINUED
TABLE ONE
[e-mail] M DELAESPADA.COM
b) Assembly is now complete and the table is ready for use.
