Wallbeds Australia NB1 User manual

NB1- Bookcase Assembly Instructions
Note: If you have two ofthe same cabinet each cabinet will have adifferent cabinet number.
Panel Stickers/Labels –Donotremove any cabinet stickers from the panels until the
units have been built, as these will assist with assembly. Most of the stickers are placed
on the “back” orunderside of the cabinet and will notbe seen once assembled.
NB1 Bookcase Cabinetry Panels
1
End Panel Back Panel End Panel
Top & Bottom Panel
Kick Panel
Adjustable Shelf

Cam Pins Insert all Cam Locks into the following panels asdescribed bythe cabinet part located
on the cabinet sticker.
Cam Lock Cam Pin 28mm Wood Screw Shelf Pin
AB1 Hardware Parts
Back Bottom Top
Rail
End End Bottom Top
NOTE: In the Top and
Bottom Panels Insert the
cam pins on the opposite
side to the Cam Lock.
Step 1– Inserting Hardware
Cam Locks – Insert all Cam Locks into the following panels asdescribed by the cabinet part
located on the cabinet sticker.
2

3
Removing Panel Stickers/Labels
Remove once installed, heat up with hair dryer & then to remove any sticky residue use wax and
grease remover or similar.
Avoid using a razor blade as you may damage the cabinetry.
Step 2 - Bookcase Assembly
Start the Bookcase assembly by using either one of the Bookcase End Panels and fixing it to the
Back Panel. Ensure the cam locks on the Back Panel are not facing what will be the inside of the
Bookcase when built.
Back Panel - Place the Bookcase Back Panel onto the End Panel. Match up the cam locks with the
cam pins. Tighten the cam locks and cam pins together by using a Phillips head hand screwdriver.
Bottom & Bottom Panels - With the cam locks facing away from the inside of the Bookcase attach
the Bottom Panel to the End Panel and Back Panel. Repeat this process with the Top Panel.
Place the remaining End Panel on top of the previously assembled panels. Ensuring the cam pins
are lined up with the cam locks. Tighten the cam pins to the cam locks.
Tip: You may need to lightly tap the cam pins into the cam locks with a rubber mallet. Ensure you
do this where the cam pins are. Failure to do so may result in damage to the End Panel.
Step 3 - Fixing Bookcase to the Wall Bed
Attaching to the WallBed - Place the Bookcase next to the side of the Wallbed. Check that the
Bookcase End Panel is flush with the front edge of the wall bed End Panel.
Using existing shelf-pin holes (two towards the top of the Bookcase and two at the bottom)
attach the bookshelf to the wall bed cabinet by using the 28mm wood screws supplied.
Note: It is recommended that these holes are pre-drilled.
Caution: Do Not over tighten the wood screws into the side of the wall bed End Panel as it may
end up protruding through the opposite side of the panel.
Adjustable Shelf - Insert the shelf pins into the shelf pin holes at the desired height for your shelf.
If you find it too high or too low for the books you want to store, relocate the shelf pins to the
holes at the required height.
IMPORTANT SAFETY INFORMATION
All WallBeds Australia Bookcases and Cabinets must be securely attached to the WallBed before
use. Ensure that children DO NOT climb or hang on any part of the Bookcase Or Cabinet. Failure
to do so may result in personal injury.
