Manhattan 158206 User manual

Model
158206
Add one serial port with fewer conflicts.
Compatible with most RS232 peripherals, the MANHATTAN®Serial PCI Card with one external
DB9 port is an ideal solution for attaching a serial device — modems, barcode scanners, printers
and more — through a single PCI card. Its high-speed 16C550/16C450 UART serial DB9 Com port
fully supports PCI IRQ sharing even if accessed simultaneously to help save valuable resources for
other expansion cards. Universal bus power design for 5 V and 3.3 V allows for greater variety
of peripheral devices.
Easy Installation
Windows 2000/XP/Server 2003/Vista 32/64-bit compatibility, Plug and Play capability and automatic IRQ and
IO address selection make installation easy to help avoid configuration conflicts with other devices.
Lifetime Warranty
Strict manufacturing standards ensure the highest quality in all MANHATTAN products. All items carry a
full Lifetime Warranty — the strongest quality commitment anyone can make.
Serial PCI Card
One External DB9 Port, Low-Profile

Features
• Adds one high-speed 16C550/16C450 UART serial DB9
Com port to desktop computers
• Maximum 115.2 kbps throughput
• Universal bus power design for 5 V and 3.3 V
• Fully supports PCI IRQ sharing
• Automatically selects IRQ and Com address
• Lifetime Warranty
Specifications
STANDARDS AND CERTIFICATIONS
• CE
• FCC
• RS232c
• PCI 2.3
• WEEE
GENERAL
• (1) serial DB9 male connection
• Maximum 115.2 kbps throughput
• MosChip 9865 chipset
• Requires available punch-out expansion and PCI slots
• Windows 2000/XP/Server 2003/Vista 32/64-bit compatible
BUS
• PCI 2.3 32-bit, 33 MHz
• Supports 32/64-bit PCI slot
• 5 / 3.3 V bus power
PHYSICAL
• Dimensions: 124 x 122 x 23 mm (4.9 x 4.8 x 0.9 in.)
• Weight: 51 g (1.8 oz.)
PACKAGE CONTENTS
• Serial PCI Card, One External DB9 Port, Low-Prole
• User manual and driver CD
Model
158206
MH-158206-DS-0409-02
