Manhattan 176149 User manual

MAN-176149-UM-1206-03
PCI 3-In-1
TV Tuner Card
uSer ManuaL
MODEL 176149

2
Thank you for purchasing the MANHATTAN®PCI 3-in-1 TV Tuner Card, Model 176149. This card
brings free-to-air digital terrestrial and analog TV and FM radio to desktop computers with advanced
features and controls that enhance viewing options: Digital Personal Video Recording captures and
directly saves TV programs to the hard drive for replay or transfer to CDs and other portable media
devices; Electronic Program Guide lets you browse program summaries, conduct channel/program
searches, schedule reminders and more; Time-shifting lets you replay favorite scenes, skip annoying
ads and apply pause/rewind/fast forward control to live video and recorded programs.
Package Contents:
• PCI 3-in-1 TV Tuner Card
• DVB-T and FM antennas, plus PAL-NTSC connector
• Remote control receiver and multifunction cables
• Low-prole bracket
• Remote control (AAA batteries included)
• User manual and software/driver CD
System Requirements:
• Pentium 4 1.6 GHz or AMD Athlon 1.6 or above; 256 MB RAM, 100 MB HDD space recommended
• DirectX 9.0 or above
• VGA graphics with 32 MB RAM and DirectX 8.1 support
• AC97-compatible sound card
• Windows 2000/XP/Vista

3
InPuT/ouTPuT ConneCTIonS
TV: Connects to your home antenna or cable for analog TV and digital terrestrial TV.
AV Cable: Connects the AV cable to the 9-pin connector of the PCI 3-in-1 TV Tuner Card.
S-Video: For external devices like VCRs or camcorders.
Composite Video: For external devices like VCRs or camcorders.
Audio In: Connects to the audio of external devices such as VCRs, camcorders, etc.
Audio Out: Connects to the sound card of the PC.
Remote: Connects to the IR remote cable.
S-Video AV Cable
Composite
Video
Audio In
Audio Out
Remote

4
SoFTWare InSTaLLaTIon
1. Once the tuner card is connected, the prompt
"New Device" may appear. Click "Cancel."
2. Insert the driver CD; an install screen will
automatically be displayed. Click "Next."
3. When prompted by the "Video Capture" screen,
click "Continue Anyway."

5
4. When prompted by the "Audio Capture" screen,
click "Continue Anyway."
5. When prompted by the "DVB-T Capture" screen,
click "Continue Anyway."

6
6. When the DirectX setup screen displays, select "I accept
the agreement," then click "Next."
7. Click "Next" again.

7
8. When the installation is complete, the system will direct
you to restart the computer. Click "Finish."
9. When the TotalMedia installation screen displays, click
"Next."

8
10. Read the license agreement and click "Yes."
11. Click "Browse" to select a destination folder to
place the program in. (The default folder is
C:\ProgramFiles\ArcSoft\TotalMedia.)

9
12. Once a destination folder is selected, click "Next."

10
13. Once the installation of TotalMedia is complete,
click "Finish."
