SOLID STATE RELAY ASSY.
FOR CA200, CA260, FA290 AND HA300 DISPENSERS
Manitowoc Ice, Inc.
2110 South 26th Street, P.O. Box 1720, Manitowoc, WI 54221-1720 USA
Telephone [phone], Fax - Sales: 920-683-7589, Service/Parts: 920-683-7585, Other: 920-683-7879 8010213
Web Site - www.manitowocice.com Rev. 08/20/03
IMPORTANT
Before replacing this relay on a QPA310 ice dispenser:
Check for moisture on the two-pin Molex connector for the dispense switch
wiring harness.
If moisture is present, dry and seal the ends of the connector with silicone
sealant.
Moisture on this connector can simulate a defective relay.
Black Power Cord
Black Power Cord
Drill one .136 dia. hole for solid state relay.
Attach relay with two screws provided.
Drill two .136 dia. holes for solid state relay.
Attach relay with two screws provided.
Vend Switch
Black Vend Switch
Black
Black T3
Gear Moto
r
Switch Sinpac
Switch
Black T3
Gear Motor
Sinpac
Switch
Capacitor
CA200/CA260
Switch
White
White
Coil
1.88
White
Power Cord
Junction Box
FA290/HA300
Capacitor 1.88
Junction Box
White
Power Cord
White
Coil
White
1
34
2
Solid State
