18000 With
21000 MAX-ER
Luffing Jib Raising Procedure
Luffing Jib No. 79A on Boom No. 55 or No. 55A
with 140 Ft. (42.7m) Mast No. 56
Wheeled Counterweight
Manitowoc Cranes, Inc.
Manitowoc, Wisconsin 54220 U.S.A.
Recommended boom and luffing jib raising and lowering procedure.
Machine must be equipped with 492,000 Lb. (223 170 kg) crane counterweight, 320,000 Lb.
(145 150 kg) carbody counterweight and 0 Lb. (0 kg), 464,000 Lb. (210 470 kg) or 860,000 Lb.
(390 090 kg)wheeledcounterweight.Refer toluffingjibriggingassemblyNo. A08238forboom
and luffing jib make-up of inserts, straps, struts, strut raising procedure, jib stop positioner setup
and operation, jib stop raising and lowering procedure and miscellaneous parts, etc.
Boom and luffing jib combinations must be raised and lowered using jack-knife method.
Release swing brake (disengage swing lock) and slowly raise boom while jib point dolly is
allowed to roll on ground. Tension should be applied to luffing jib hoist to keep jib strut off
luffing jib during boom raising. Boom up until boom to luffing jib angle reaches 140 degrees.
Extend jib stop positioner cylinders (see procedure). Continue to boom up until boom to
luffing jib reaches value specified in table. Tighten luffing jib suspension with luffing jib
hoist. Boom and luffing jib are then raised together using boom hoist until boom reaches
desired boom operating angle. Luffing jib radius must be within capacity chart before
swinging over side of machine when raising over end of blocked crawlers.
Position boom at 85 degrees prior to lowering luffing jib. Lower luffing jib until boom to
luffing jib angle reaches value specified in table. Lower boom until luffing jib point is just
above ground. Position dolly under upper jib point, then lower upper jib point onto dolly.
Release swing brake (disengage swing lock) and continue to lower boom while luffing jib
rolls along ground until boom to luffing jib angle reaches 140 degrees. Keep enough tension
on luffing jib hoist to keep jib strut off luffing jib. Retract jib stop positioner cylinders (see
procedure). Continue to lower boom while luffing jib rolls along ground.
CAUTION: Do not under any condition allow boom to luffing jib angle to become less than
70 degrees.
WITH OR WITHOUT BOOM AND/OR JIB CATWALKS
Maximum Boom and Luffing Jib Lengths Lifted Unassisted Using Jack-Knife Method
Boom
Length
Over End of Blocked Crawlers Over Side of Crawlers
0 Lb. (0 kg) Wheeled Counterweight
Luffing Jib No. 79A
Boom to
Luffing Jib
Angle Luffing Jib No. 79A
Boom to
Luffing Jib
Angle
Feet Meters Feet Meters Degrees Feet Meters Degrees
160 48.8 90 - 130 27.4 - 39.6 140 90 27.4 140
150 - 270 45.7 - 82.3 90 110 - 210 33.5 - 64.0 90
290 - 310 88.4 - 94.5 70 230 - 310 70.1 - 94.5 70
180 54.9 90 - 210 27.4 - 64.0 90 90 - 110 27.4 - 33.5 90
230 - 310 70.1 - 94.5 70 130 - 270 39.6 - 82.3 70
200 61.0 90 - 190 27.4 - 57.9 70 — ——
Load blocks, hook and weight ball on ground until boom and luffing jib are erected.
REFERENCE
ONLY!

8596-A, 2011-10-07/GA
Page 2 of 3
Manitowoc Cranes, Inc.
Manitowoc, Wisconsin 54220 U.S.A.
18000 With
21000 MAX-ER
Luffing Jib Raising Procedure
Luffing Jib No. 79A on Boom No. 55 or No. 55A
with 140 Ft. (42.7m) Mast No. 56
Wheeled Counterweight
WITH OR WITHOUT BOOM AND/OR JIB CATWALKS
Maximum Boom and Luffing Jib Lengths Lifted Unassisted Using Jack-Knife Method
Over End or Side of Unblocked Crawlers
Boom
Length
464,000 Lb. (210 470 kg)
Wheeled Counterweight
at 40 Ft. (12m) Position
860,000 Lb. (390 090 kg)
Wheeled Counterweight
at 40 Ft. (12m) Position
Luffing Jib No. 79A
Boom to
Luffing Jib
Angle Luffing Jib No. 79A
Boom to
Luffing Jib
Angle
Feet Meters Feet Meters Degrees Feet Meters Degrees
160 48.8 90 - 250 27.4 - 76.2 140 90 - 270 27.4 - 82.3 140
270 - 310 82.3 - 94.5 90 290 - 310 88.4 - 94.5 90
180 54.9 90 - 210 27.4 - 64.0 140 90 - 230 27.4 - 70.1 140
230 - 310 70.1 - 94.5 90 250 - 310 76.2 - 94.5 90
200 61.0 90 - 190 27.4 - 57.9 140 90 - 210 27.4 - 64.0 140
210 - 310 64.0 - 94.5 90 230 - 310 70.1 - 94.5 90
220 67.1 90 - 150 27.4 - 45.7 140 90 - 170 27.4 - 51.8 140
170 - 310 51.8 - 94.5 90 190 - 310 57.9 - 94.5 90
240 73.2 90 - 110 27.4 - 33.5 140 90 - 150 27.4 - 45.7 140
130 - 270 39.6 - 82.3 90 170 - 310 51.8 - 94.5 90
290 - 310 88.4 - 94.5 70
260 79.2 90 - 170 27.4 - 51.8 90 90 - 110 27.4 - 33.5 140
190 - 270 57.9 - 82.3 70 130 - 310 39.6 - 94.5 90
280 85.3 — — — 90 - 270 27.4 - 82.3 90
300 91.4 — — — 90 - 170 27.4 - 51.8 90
Load blocks, hook and weight ball on ground until boom and luffing jib are erected.
REFERENCE
ONLY!

8596-A, 2011-10-07/GA
Page 3 of 3
18000 With
21000 MAX-ER
Luffing Jib Raising Procedure
Luffing Jib No. 79A on Boom No. 55 or No. 55A
with 140 Ft. (42.7m) Mast No. 56
Wheeled Counterweight
Manitowoc Cranes, Inc.
Manitowoc, Wisconsin 54220 U.S.A.
WITH OR WITHOUT BOOM AND/OR JIB CATWALKS
Maximum Boom and Luffing Jib Lengths Lifted Unassisted Using Jack-Knife Method
Over End or Side of Unblocked Crawlers
Boom
Length
464,000 Lb. (210 470 kg)
Wheeled Counterweight
at 59 Ft. (18m) Position
860,000 Lb. (390 090 kg)
Wheeled Counterweight
at 59 Ft. (18m) Position
Luffing Jib No. 79A
Boom to
Luffing Jib
Angle Luffing Jib No. 79A
Boom to
Luffing Jib
Angle
Feet Meters Feet Meters Degrees Feet Meters Degrees
160 48.8 90 - 290 27.4 - 88.4 140 90 - 310 27.4 - 94.5 140
310 94.5 90
180 54.9 90 - 270 27.4 - 82.3 140 90 - 310 27.4 - 94.5 140
290 - 310 88.4 - 94.5 90
200 61.0 90 - 230 27.4 - 70.1 140 90 - 290 27.4 - 88.4 140
250 - 310 76.2 - 94.5 90 310 94.5 90
220 67.1 90 - 210 27.4 - 64.0 140 90 - 270 27.4 - 82.3 140
230 - 310 70.1 - 94.5 90 290 - 310 88.4 - 94.5 90
240 73.2 90 - 170 27.4 - 51.8 140 90 - 230 27.4 - 70.1 140
190 - 310 57.9 - 94.5 90 250 - 310 76.2 - 94.5 90
260 79.2 90 - 130 27.4 - 39.6 140 90 - 190 27.4 - 57.9 140
150 - 310 45.7 - 94.5 90 210 - 310 64.0 - 94.5 90
280 85.3 90 27.4 140 90 - 170 27.4 - 51.8 140
110 - 230 33.5 - 70.1 90 190 - 310 57.9 - 94.5 90
250- 310 76.2 - 94.5 70
300 91.4 90 27.4 90 90 - 130 27.4 - 39.6 140
110 - 230 33.5 - 70.1 70 150 - 310 45.7 - 94.5 90
320 97.5 — — —90 - 110 27.4 - 33.5 140
130 - 270 39.6 - 82.3 90
340 103.6 — — —90 - 250 27.4 - 76.2 90
Load blocks, hook and weight ball on ground until boom and luffing jib are erected.
