Manitowoc ENDURO 300 KH0180 User manual

KH0180 - IB-0620/0820/1020 ON A CORNELIUS
44.38” WIDE ICE DISPENSER (ENDURO 300)
Installation Instructions
1. Set support on bin and position support approximately 16" from back of dispenser, as shown.
2. Set adapter and bin covers on dispenser. Position the bin covers so that the front flange of the bin cover will lock
under the front lip of the dispenser. Adapter may have to be moved towards the back of the dispenser.
3. Reposition support, if necessary, so front of support lines up with front of adapter.
4. Using the slotted holes in the adapter as a template, drill four (4) 9/64” diameter holes at the bottom of the slots.
NOTE: Do not drill deeper than 1/4” past the sheet metal. Use a drill stop!
5. Fasten adapter to dispenser using the four (4) #8 screws supplied with the adapter kit.
6. Position adapter retaining arm holes over rivnuts.
7. Set the ice machine on top of the adapter. Align holes in ice machine front angle with the rivnuts on the adapter.
8. Secure the ice machine to the adapter with two (2) #8-32 screws supplied with the kit.
9. Set the front bin covers onto the dispenser. Set the left side cover down first and then the right side cover. The
covers will latch together at the center seam and also to the adapter along the back flange of the covers.
10. Rotate retaining arms into position, as shown for normal ice machine operation.
Manitowoc Ice, Inc.
2110 South 26th Street, P.O. Box 1720, Manitowoc, WI 54221-1720 USA
#8-32 Screw
Two (2) Places
Left Bin
Cover
Adapter
RH Retaining Arm
Right Bin
Cover
LH Retaining Arm
Cornelius ED300 Dispenser
#8 Screw
Four (4) Places
Support
16"

Telephone [phone], Fax - Sales: 920-683-7589, Service/Parts: 920-683-7585, Other: 920-683-7879 8006763
Web Site - www.manitowocice.com Rev. 06/17/03
