Manitowoc QuietQube Series User manual

Part Number: 000015431 Rev01 5/19
QuietQube Series Ice Machines
Technician’s Handbook
®

Safety Notices
Read these precautions to prevent personal injury:
• Read this manual thoroughly before operating,
installing or performing maintenance on the
equipment. Failure to follow instructions in this
manual can cause property damage, injury or death.
• Routine adjustments and maintenance procedures
outlined in this manual are not covered by the
warranty.
• Proper installation, care and maintenance are essential
for maximum performance and trouble-free operation
of your equipment.
• Visit our website www.manitowocice.com for manual
updates, translations, or contact information for
service agents in your area.
• This equipment uses high voltage electricity and
contains refrigerant charge. Installation and repairs are
to be performed by properly trained technicians aware
of the dangers of dealing with high voltage electricity
and refrigerant under pressure. The technician
must also be certified in proper refrigerant handling
and servicing procedures. All lockout and tag out
procedures must be followed when working on this
equipment.
• As you work on this equipment, be sure to pay close
attention to the safety notices in this handbook.
Disregarding the notices may lead to serious injury
and/or damage to the equipment.

DEFINITIONS
DANGER
Indicates a hazardous situation that, if not avoided,
will result in death or serious injury. This applies to the
most extreme situations.
nWarning
Indicates a hazardous situation that, if not avoided,
could result in death or serious injury.
,Caution
Indicates a hazardous situation that, if not avoided,
could result in minor or moderate injury.
Notice
Indicates information considered important, but not
hazard-related (e.g. messages relating to property
damage).
NOTE: Indicates useful, extra information about the
procedure you are performing.

nWarning
Follow these electrical requirements during
installation of this equipment:
• All field wiring must conform to all applicable
codes of the authority having jurisdiction. It is
the responsibility of the end user to provide the
disconnect means to satisfy local codes. Refer to
rating plate for proper voltage.
• This appliance must be grounded.
• This equipment must be positioned so that the plug
is accessible unless other means for disconnection
from the power supply (e.g., circuit breaker or
disconnect switch) is provided.
• Check all wiring connections, including factory
terminals, before operation. Connections can
become loose during shipment and installation.

nWarning
Follow these precautions to prevent personal injury
during installation of this equipment:
• Installation must comply with all applicable
equipment fire and health codes with the authority
having jurisdiction.
• Connect to a potable water supply only.
• To avoid instability the installation area must be
capable of supporting the combined weight of the
equipment and product. Additionally the equipment
must be level side to side and front to back.
• Remove all removable panels before lifting and
installing and use appropriate safety equipment
during installation and servicing. Two or more
people are required to lift or move this appliance to
prevent tipping and/or injury.
• Do not damage the refrigeration circuit when
installing, maintaining or servicing the unit.
• This equipment contains refrigerant charge.
Installation of the line sets must be performed by
a properly trained and EPA certified refrigeration
technician aware of the dangers of dealing with
refrigerant charged equipment.
• Ice machines require a deflector when installed on
an ice storage bin. Prior to using a non-OEM ice
storage system with this ice machine, contact the
bin manufacturer to assure their ice deflector is
compatible.
• Prior to installing a non-OEM ice storage system
with this ice machine, follow the manufacturers
installation procedures and verify the location and
installation meets the local/national mechanical
codes and stability requirements.

nWarning
Follow these precautions to prevent personal injury
while operating or maintaining this equipment:
• Legs or casters must be installed and the legs/casters
must be screwed in completely. When casters
are installed the mass of this unit will allow it to
move uncontrolled on an inclined surface. These
units must be tethered/secured to comply with all
applicable codes. Swivel casters must be mounted
on the front and rigid casters must be mounted on
the rear. Lock the front casters after installation is
complete.
• Refer to nameplate to identify the type of refrigerant
in your equipment.
• Only trained and qualified personnel aware of the
dangers are allowed to work on the equipment.
• Read this manual thoroughly before operating,
installing or performing maintenance on the
equipment. Failure to follow instructions in this
manual can cause property damage, injury or death.
• Crush/Pinch Hazard. Keep hands clear of moving
components. Components can move without
warning unless power is disconnected and all
potential energy is removed.
• Moisture collecting on the floor will create a
slippery surface. Clean up any water on the floor
immediately to prevent a slip hazard.

nWarning
Follow these precautions to prevent personal injury
while operating or maintaining this equipment:
• Objects placed or dropped in the bin can affect
human health and safety. Locate and remove any
objects immediately.
• Never use sharp objects or tools to remove ice or
frost.
• Do not use mechanical devices or other means to
accelerate the defrosting process.
• When using cleaning fluids or chemicals, rubber
gloves and eye protection (and/or face shield) must
be worn.
DANGER
Do not operate equipment that has been misused,
abused, neglected, damaged, or altered/modified
from that of original manufactured specifications. This
appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge,
unless they have been given supervision concerning
use of the appliance by a person responsible for their
safety. Do not allow children to play with, clean or
maintain this appliance without proper supervision.

DANGER
Follow these precautions to prevent personal injury
during use and maintenance of this equipment:
• It is the responsibility of the equipment owner to
perform a Personal Protective Equipment Hazard
Assessment to ensure adequate protection during
maintenance procedures.
• Do Not Store Or Use Gasoline Or Other Flammable
Vapors Or Liquids In The Vicinity Of This Or Any
Other Appliance. Never use flammable oil soaked
cloths or combustible cleaning solutions for
cleaning.
• All covers and access panels must be in place and
properly secured when operating this equipment.
• Risk of fire/shock. All minimum clearances must be
maintained. Do not obstruct vents or openings.
• Failure to disconnect power at the main power
supply disconnect could result in serious injury or
death. The power switch DOES NOT disconnect all
incoming power.
• All utility connections and fixtures must be
maintained in accordance with the authority having
jurisdiction.
• Turn off and lockout all utilities (gas, electric, water)
according to approved practices during maintenance
or servicing.
• Units with two power cords must be plugged
into individual branch circuits. During movement,
cleaning or repair it is necessary to unplug both
power cords.

nWarning
Follow these precautions to prevent personal injury
while operating or maintaining this equipment.
• Refer to nameplate to identify the type of refrigerant
in your equipment.
• Only trained and qualified personnel aware of the
dangers are allowed to work on the equipment.
• Read this manual thoroughly before operating,
installing or performing maintenance on the
equipment. Failure to follow instructions in this
manual can cause property damage, injury or death.
• Crush/Pinch Hazard. Keep hands clear of moving
components. Components can move without
warning unless power is disconnected and all
potential energy is removed.
• Moisture collecting on the floor will create a
slippery surface. Clean up any water on the floor
immediately to prevent a slip hazard.
• Never use sharp objects or tools to remove ice or
frost. Do not use mechanical devices or other means
to accelerate the defrosting process.
• When using cleaning fluids or chemicals, rubber
gloves and eye protection (and/or face shield) must
be worn.

nWarning
Follow these precautions to prevent personal injury
during use and maintenance of this equipment:
• Units with two power cords must be plugged
into individual branch circuits. During movement,
cleaning or repair it is necessary to unplug both
power cords.
• Never use a high-pressure water jet for cleaning on
the interior or exterior of this unit. Do not use power
cleaning equipment, steel wool, scrapers or wire
brushes on stainless steel or painted surfaces.
• Two or more people are required to move this
equipment to prevent tipping.
• Locking the front casters after moving is the
owner’s and operator’s responsibility. When casters
are installed, the mass of this unit will allow it to
move uncontrolled on an inclined surface. These
units must be tethered/secured to comply with all
applicable codes.
• The on-site supervisor is responsible for ensuring
that operators are made aware of the inherent
dangers of operating this equipment.
• Do not operate any appliance with a damaged cord
or plug. All repairs must be performed by a qualified
service company.

THIS PAGE INTENTIONALLY LEFT BLANK

Table of Contents
Part Number: 000015431 Rev01 5/19 13
Safety Notices ...............................3
Definitions ..............................4
General Information
How to Read a Model Number ................19
Head Sections ..........................19
CVD Condensing Units ...................20
Ice Cube Sizes ..............................20
Model/Serial Number Location................21
Warranty ..................................22
Warranty Registration....................22
Model Numbers ............................23
QuietQube® Models .....................23
LuminIce® II ................................24
Installation
Stacking Two Ice Machines on a Single Storage
Bin....................................25
Ice Deflector ...........................25
Location of Ice Machine ......................26
Head Section ...........................26
Ice Beverage Models.....................27
Location of CVD Condensing Units .........28
Clearance Requirements .....................29
Dual Evaporator Model Installation on a Manitowoc
Bin........................................30
Ice Machine on a Dispenser Installation ........31
Water Supply and Drains .....................32
Lineset Applications .........................33
QuietQube® Remote Condensing Unit ..........34
Additional Refrigerant Charge For 51' to 100' Line
Sets .......................................35

14 Part Number: 000015431 Rev01 5/19
Maintenance
Cleaning and Sanitizing ......................37
General................................37
Cleaning/Sanitizing Procedure .............38
Preventative Maintenance Cleaning Procedure
......................................38
iAuCS® ................................38
Exterior Cleaning ........................38
Touchscreen Operation For The Clean Cycle .....39
Starting a clean cycle ....................39
Water curtain/damper operation during the
clean cycle .............................39
Pausing a clean cycle.....................39
Power interruption during clean cycle ......39
Aborting a clean cycle....................39
Cleaning/Sanitizing Procedure ................40
Cleaning Procedure......................40
Sanitizing Procedure .....................43
Parts Removal for Cleaning/Sanitizing.......45
Preventative Maintenance Cleaning Procedure ..54
Removal from Service/Winterization ...........56
Operation
Operational Checks..........................57
General................................57
Ice Thickness Check......................58
Sequence of Operation ......................60
QuietQube® Models .....................60
Initial Start-Up or Start-Up After
Automatic Shut-Off ......................60
Freeze Sequence . . . . . . . . . . . . . . . . . . . . . . . .61
Harvest Sequence .......................63
Automatic Shut-Off ......................64
Restart After Automatic Shut-off ...........64

Part Number: 000015431 Rev01 5/19 15
Menu Navigation
Touch Screen Features .......................69
Home screen icon descriptions ............71
Setup Wizard ...............................73
Menu Navigation Overview...................74
Settings Menu Screen Navigation ..........74
USB Flash Drive Specifications and Formatting .
......................................79
Upgrading Firmware with a Flash Drive .....79
Exporting Data to a Flash Drive ............80
Troubleshooting
Troubleshooting ............................81
Event Log ..............................82
Event Log Detail.........................83
Thaw Cycle.............................88
Safe Operation Mode ....................89
E01 Long Freeze Cycle ..................90
E02 Long Harvest Cycle .................90
Analyzing Why A Service Fault (E01 & E02)
Stopped the Ice Machine .................90
E01 Long Freeze.........................91
E02 Long Harvest........................92

16 Part Number: 000015431 Rev01 5/19
Troubleshooting By Symptom .................93
Symptom #1 Ice Machine Stops Running ...93
Symptom #2 Ice Machine has a Long Freeze
Cycle ..................................93
Symptom #3 Will not harvest, cubes normal .93
Symptom #4 Will not harvest cubes melted..93
Reset To Factory Defaults .................94
Symptom #1 Ice Machine Will Not Run......95
Diagnosing a Condensing Unit
That Will Not Run .......................98
Symptom #2 Low Production, Long Freeze Cycle
......................................99
Symptom #3 Harvest Problems ...........115
Failure Type and Symptoms: .............119
Symptom #3 QuietQube® Models With CVD
Condensing Units ......................121
Symptom #4 QuietQube® Models With CVD
Condensing Units ......................125

Part Number: 000015431 Rev01 5/19 17
Component Check Procedures
Control Board, Display And Touchscreen ...127
Operating an ice machine without a
Touchscreen...........................129
Control Board Relay Test.................130
Programming A Replacement Control Board131
USB Flash Drive Specifications and Formatting .
.....................................132
Exporting Data to a Flash Drive ...........133
Upgrading Firmware with a Flash Drive ....134
Main Fuse ............................135
Bin Switch ............................136
Water Level Control Circuitry .............139
Ice Thickness Probe (Initiates Harvest) .....142
Bin Level Probe ........................146
Thermistors ...........................148
High Pressure Cutout (HPCO) Control ......151
Low Pressure Cutout (LPCO) Control .......152
Compressor Time Delay .................153
Fan Cycle Control.......................154
Harvest Assist Air Pump .................155
Compressor Electrical Diagnostics .........156
Diagnosing Start Components ............158
Refrigeration Components...................159
Head Pressure Control Valve .............159
Suction Accumulator Operation...........165
Recovery/Evacuation/Charging Procedures
QuietQube® Models ........................166
Connections...........................167
Recovery/Evacuation Procedures .........168
Charging Procedures....................169
System Contamination Clean-Up .............170
Determining Severity of Contamination ....170
Contamination Cleanup Chart ............171
Cleanup Procedure .....................172
Liquid Line Filter-Driers..................175
Suction Filter ..........................175
Replacing Pressure Controls Without Removing
Refrigerant Charge .....................176
Total System Refrigerant Charge
QuietQube® CVD Models....................177

18 Part Number: 000015431 Rev01 5/19
Charts
Cycle Times/24-Hour Ice Production/Refrigerant
Pressure Charts ............................179
IF0600C/CVDF0600 .....................180
IBF0620C/CVDF0600....................181
IBF0820C/CVDF0900....................182
IF0900C/CVDF0900 ....................183
IBT1020C/CVDT1200....................184
IT1200C/CVDT1200.....................185
IF1400C/CVDF1400 .....................186
IF1800C/CVDF1800 .....................187
IF2100C/CVDF2100 .....................188
Diagrams
Wiring Diagrams ...........................189
Wiring Diagram Legend .................189
IF0600C/IBF0620C/IBF0820C/IF0900C 1ph .190
IT1200C/IBT1020C 1ph ..................192
IF1400C/IF1800C/IF2100C 1ph ...........194
CVD 1ph Condensing Unit ...............196
CVD 3ph Condensing Unit ...............198
Electronic Control Board ....................200
Refrigeration Tubing Schematics..............202
IF0600C/CVDF0600 IB0620C/CVDF0600
IBF0820/CVDF0900 IF0900C/CVDF0900 ....202
IBT1020C/CVDT1200 IT1200C/CVDT1200 ..204
Dual Evaporators...........................206
IF1400C/IF1800C.......................206
IF2100C ..............................208

Part Number: 000015431 Rev01 5/19 19
How to Read a Model Number
HEAD SECTIONS
ICE MACHINE SERIES I Indigo U Undercounter KKoolaire RFlake/Nugget BBig shot SS-series IB Ice Beverage
C Countertop
REFRIGERANT TYPE P R290 (propane) F R404A (four) T R410A (ten) B R600A (butane) E R134A (eight)
NOMINAL PRODUCTION @ 70/50 0300 produces ~300 #/day 0320 produces ~320 #/day 0350 produces ~350 #/day etc. . .
Soo is stated in kg/day
CONDENSER TYPE
Aair cooled Wwater cooled N remote (tradional)
CCVD (remote)
POWER CORD OPTION Blank juncon box
Zcord without plug BNEMA plug (USA) F schuko plug (EU) G 13A blade (GBR)
I oblique V blades
(AUS) SPECIAL USE Blankgeneral use
Qcoated condenser
H high pressure Mmarine Pcorreconal Ttop air discharge
XLuminice/Sanitaon Llever V space maker MARKET IDENTIFIER Blank not market specific SSaudi Arabia (GCC) K Korea (KC) CChina (CCC) DGermany (GS) NBrazil (InMetro)
ICE TYPE RRegular DDice
YHalf-dice F Flake NNugget
GGourmet Blank for IB only
ELECTRICAL CONFIGURATION
161 = 115/60/1 261 = 208-230/60/1 251 = 220-240/50/1 (S=230) 263 = 208-230/60/3 271 = 200/50-60/1 273 = 200/50-60/3 453 = 380-415/50/3 463 = 460/60/3
2= 22" wide cabinet
#= all other #s mean producon value
I Y T12 0 0 C –26 1 X
A alternate compressor
General Information

20 Part Number: 000015431 Rev01 5/19
CVD CONDENSING UNITS
CVDT 1200 3
CONDENSING
UNIT MODEL
3 PHASE
CONDENSING
UNIT SERIES
REFRIGERANT TYPE
F = R404A
T = R410
Ice Cube Sizes
Regular
1-1/8" x 1-1/8" x 7/8"
2.86 x 2.86 x 2.22 cm
Dice
7/8" x 7/8" x 7/8"
2.22 x 2.22 x 2.22 cm
Half Dice
3/8" x 1-1/8" x 7/8"
0.95 x 2.86 x 2.22 cm
