Manning YB8 User manual

Operating and
Instruction Manual
Manual No. YB
Revision 0-600 w/12 March 2014 Errata
MODEL YB8
STATIONARY
PERISTALTIC SAMPLERS
Manning Environmental, Inc.
101 Bar T Drive
Florence, Texas 76527-4445 USA
Office: [phone]
[phone]
Fax: [phone]
www.manningenvironmental.com

Manning Environmental Limited Factory Warranty
Manning Environmental, Inc., warrants this product to the original purchaser against any defects that are
due to faulty workmanship or material for a period of one year (365 days) from the date of shipment.
During the warranty period Manning Environmental, Inc. will repair or replace, at its sole discretion, any
defective equipment or parts. Manning’s liability is strictly limited to repair and/or replacement. Any
product repaired or replaced under this warranty will be warranted only for the remainder of the original
product warranty period.
This warranty does not apply to consumable products or consumable components of products such as,
but not limited to tubing, intake hose, differential pressure switches and bottles.
Items may not be returned without authorization from Manning Environmental, Inc.
This warranty applies only to products sold under the Manning trademark and is the sole express
warranty made by Manning Environmental, Inc. All implied warranties, including without limitation, the
warranties of merchantability or fitness for a particular purpose, are disclaimed.∗
Limitations:
This warranty does not cover the following:
1. Damage caused by acts of God, natural disaster, labor unrest, acts of war (declared or
undeclared), terrorism, civil strife or acts of any governmental jurisdiction
2. Damage caused by normal wear, neglect, misuse, accident, corrosion or improper application or
installation
3. Damage caused by any repair, attempted repair or modifications not authorized by Manning
Environmental, Inc.
4. Any product not used in accordance with the instructions furnished by Manning Environmental,
Inc.
5. Freight charges to return merchandise to Manning Environmental, Inc.
6. Freight charges on expedited or express shipment of warranted parts or products.
7. Travel and lodging fees associated with on-site warranty repair
8. Manning 6.1 cubic foot refrigerators, which are covered under the refrigerator manufacturer’s
warranty
9. Labor performed at the factory to clean the equipment so that it can be safely and properly
repaired
This warranty constitutes the final, complete, and exclusive statement of warranty terms. Manning
Environmental, Inc. does not authorize any other person to make any other warranties or representations
on its behalf.
In no event shall Manning Environmental, Inc. be liable for any incidental or consequential damages of
any kind for breach of warranty or negligence. The remedies of repair or replacement as stated above
are the exclusive remedies for the breach of this warranty.
A Return Material Authorization (RMA) must be obtained prior to sending any equipment to Manning for
warranty service. Contact the Manning Service Department at:
Manning Environmental, Inc.
101 Bar T Drive
Florence, Texas 76527-4445
Phone: [phone], Fax: [phone].
∗
Some states within the United States do not allow the disclaimer of implied warranties and if this is true in your state the above
limitation may not apply to you. This warranty gives you specific rights- you may also have other rights that vary from state to state.
Manning Environmental, Inc. December 2005

Table Of Contents
Section Contents – Installation and Operation
Introduction...........................................................................................................................................Page A-1
Hardware Page......................................................................................................................................Page A-2
Functional Specifications..........................................................................................................Page A-2
Size................................................................................................................................Page A-2
Weight...........................................................................................................................Page A-2
Environmental Protection ............................................................................................ Page A-2
Sample Cooling ............................................................................................................Page A-2
Temperature Limits.......................................................................................................Page A-2
Sample Pump................................................................................................................Page A-2
Safety ............................................................................................................................Page A-2
Pump Tubing.................................................................................................................Page A-2
Tube Life.......................................................................................................................Page A-2
Maximum Lift...............................................................................................................Page A-2
Transport Velocity ........................................................................................................Page A-2
Sample Volume.............................................................................................................Page A-2
Accuracy.......................................................................................................................Page A-2
Repeatability.................................................................................................................Page A-2
Liquid Sensor................................................................................................................Page A-2
Controller......................................................................................................................Page A-3
Electronics.....................................................................................................................Page A-3
Internal Clock................................................................................................................Page A-3
Internal Battery .............................................................................................................Page A-3
Power ............................................................................................................................Page A-3
Battery Back-Up ...........................................................................................................Page A-3
Analog Input .................................................................................................................Page A-3
Subassemblies...........................................................................................................................Page A-3
Electronics Enclosure....................................................................................................Page A-3
The Controller...................................................................................................Page A-3
Peristaltic Pump............................................................................................................Page A-4
Liquid Sensor................................................................................................................Page A-5
Refrigerator...................................................................................................................Page A-5
Wetted Parts..................................................................................................................Page A-5
Intake Hose .......................................................................................................Page A-5
Strainer..............................................................................................................Page A-5
Pump Tubing.....................................................................................................Page A-6
Discharge Tubing..............................................................................................Page A-6
Bottle Full Sensor .............................................................................................Page A-6
Sample Bottles..................................................................................................Page A-7
Assembly...................................................................................................................................Page A-8

Assembling the Model YB8 Sampler ...........................................................................Page A-8
Refrigerator.......................................................................................................Page A-8
Electronics Enclosure........................................................................................Page A-9
Distribution Assembly Installation.............................................................................Page A-10
Single Bottle Sampling...................................................................................Page A-10
Multiple Bottle Sampling................................................................................Page A-10
Suspension Plate Installation ..............................................................Page A-10
Distributor Assembly..........................................................................Page A-10
Bottle Installation............................................................................................Page A-13
One Liter and Half-Liter Plastic Bottles Page A-13
Spout Position Page A-13
Installing The Sampler............................................................................................................Page A-13
Connecting Power.......................................................................................................Page A-14
Sample Intake Line .....................................................................................................Page A-14
Intake Hose Placement................................................................................................Page A-14
Running a Test Cycle..............................................................................................................Page A-15
The Sampling Cycle................................................................................................................Page A-15
Sample Recovery....................................................................................................................Page A-16
External Connections..............................................................................................................Page A-17
Contact In & Analog In Connections..........................................................................Page A-17
Bottle Full Sensor & Stepper Motor Connections......................................................Page A-17
Bottle Full/Stepper Motor...............................................................................Page A-17
Contact Closure...............................................................................................Page A-18
Analog Signal (Optional)................................................................................Page A-18
Section Contents – Programming
Introduction...........................................................................................................................................Page B-1
Sampler Configuration..........................................................................................................................Page B-1
Sampling Modes ...................................................................................................................................Page B-1
Multi-Bottle Sampling Modes ..................................................................................................Page B-1
Single Bottle Modes..................................................................................................................Page B-1
<RESET>..................................................................................................................................Page B-2
<TEST CYCLE> ......................................................................................................................Page B-2
<BOTTLE ADV>.....................................................................................................................Page B-2
<CLEAR>.................................................................................................................................Page B-2
<CLOCK> ................................................................................................................................Page B-2
<DISPLAY>.............................................................................................................................Page B-2
*.................................................................................................................................................Page B-2
EEEE.........................................................................................................................................Page B-2
Key Not Active .........................................................................................................................Page B-2
Display Information..............................................................................................................................Page B-3
Time of Day..............................................................................................................................Page B-3
Program Status..........................................................................................................................Page B-3
Sampler Ready..............................................................................................................Page B-3

Programming.................................................................................................................Page B-3
Active Program.............................................................................................................Page B-3
Sampler Configuration Functions.........................................................................................................Page B-4
*99 Sampler Set-Up..................................................................................................................Page B-4
*20 Volume Calibration............................................................................................................Page B-7
*19 Pump Utilities ....................................................................................................................Page B-9
*91 Data Logging ...................................................................................................................Page B-11
ID Menu......................................................................................................................Page B-12
View Menu..................................................................................................................Page B-12
Exit Menu....................................................................................................................Page B-16
Download Menu..........................................................................................................Page B-16
Clear Menu..................................................................................................................Page B-18
*14 Clear Log Data.....................................................................................................Page B-18
Analog Option Programming..............................................................................................................Page B-19
Totalizing................................................................................................................................Page B-19
*08 Analog Display Routine.......................................................................................Page B-20
Add-On Programming Functions........................................................................................................Page B-22
Multiple Bottles per Sampling Event......................................................................................Page B-22
Multiple Samples per Bottle ...................................................................................................Page B-22
Delay Start - Time...................................................................................................................Page B-24
*15 - Active Sampling........................................................................................................Page B-24-A
General Programs................................................................................................................................Page B-25
Time Mode - *START............................................................................................................Page B-25
Time Mode - Single Time Interval .........................................................................................Page B-26
Flow Mode..............................................................................................................................Page B-28
Flow Mode - Pulse Accumulation ..........................................................................................Page B-29
Multi-Bottle Sampling Programs........................................................................................................Page B-30
*01 Flow Mode - Independently Time Spout Advance..........................................................Page B-30
*02 Flow Mode - Time Interval Override...............................................................................Page B-31
*03 Flow Mode - External Event............................................................................................Page B-32
*04 Time Mode - Multiple Intervals.......................................................................................Page B-33
*07 Flow Mode - Time Delay Interval...................................................................................Page B-35
Analog Sampling Programs................................................................................................................Page B-36
*05 Flow Mode - Totalizing Analog ......................................................................................Page B-36
*06 Analog Level Mode .........................................................................................................Page B-38
*09 Hydrologic Level Event Mode.........................................................................................Page B-41
Multi-Bottle Flow Composite Programs.............................................................................................Page B-45
*10 Flow Mode - Multiple Bottle Composite.........................................................................Page B-45
*11 Flow Mode - Totalizing Analog Multiple Bottle Composite...........................................Page B-47
*12 Flow Mode - Multiple Bottle Composite with Bottle Groups.........................................Page B-49
*13 Flow Mode- Totalizing Analog Multiple Bottle Composite with Bottle
Groups.....................................................................................................................................Page B-52

Section Contents – Maintenance
Maintenance..........................................................................................................................................Page C-1
Suggested Maintenance Schedule.............................................................................................Page C-1
Peristaltic Pump........................................................................................................................Page C-2
Replacement of Pump Tubing ......................................................................................Page C-3
Cleaning the Control Panel and Electronics Enclosure ............................................................Page C-6
Cleaning the Wetted Parts.........................................................................................................Page C-6
Intake Hose ...................................................................................................................Page C-7
Liquid Sensor................................................................................................................Page C-7
Bottle Full Sensor (Single Bottle Units Only) ..............................................................Page C-8
Spout (Multiple Bottle Units Only)..............................................................................Page C-8
Sample Containers ........................................................................................................Page C-8
Refrigerator...................................................................................................................Page C-8
Environmental Protection .......................................................................................................Page C-10
Removing and Replacing the Controller.................................................................................Page C-10
Troubleshooting..................................................................................................................................Page C-11
System Non-Responsive.........................................................................................................Page C-11
Works Inconsistently ..............................................................................................................Page C-11
Weak Draw .............................................................................................................................Page C-11
Pump Operates but no Fluid ...................................................................................................Page C-12
Pump Rotor Does Not Rotate .................................................................................................Page C-12
Purges Constantly ...................................................................................................................Page G-12
Low Sample Volume ..............................................................................................................Page C-12
Excessive Sample Volume......................................................................................................Page C-12
Controller Does not Respond to Command............................................................................Page C-12
Keypad Inoperative.................................................................................................................Page C-12
*99 Self Test Indicates Error ..................................................................................................Page C-12
Section Contents - Appendices
Glossary
Appendix A...............................................................................................................................Page D-1
How to Return Equipment............................................................................................Page D-1
Address for Repairs.......................................................................................................Page D-1
Parts List
Errata

MODEL YB8 INSTALLATION AND OPERATION
April 1999/Manning Environmental Inc.
Installation and Operation
Section Contents
Introduction...........................................................................................................................................Page A-1
Hardware Page......................................................................................................................................Page A-2
Functional Specifications..........................................................................................................Page A-2
Size................................................................................................................................Page A-2
Weight...........................................................................................................................Page A-2
Environmental Protection ............................................................................................ Page A-2
Sample Cooling ............................................................................................................Page A-2
Temperature Limits.......................................................................................................Page A-2
Sample Pump................................................................................................................Page A-2
Safety ............................................................................................................................Page A-2
Pump Tubing.................................................................................................................Page A-2
Tube Life.......................................................................................................................Page A-2
Maximum Lift...............................................................................................................Page A-2
Transport Velocity ........................................................................................................Page A-2
Sample Volume.............................................................................................................Page A-2
Accuracy.......................................................................................................................Page A-2
Repeatability.................................................................................................................Page A-2
Liquid Sensor................................................................................................................Page A-2
Controller......................................................................................................................Page A-3
Electronics.....................................................................................................................Page A-3
Internal Clock................................................................................................................Page A-3
Internal Battery .............................................................................................................Page A-3
Power ............................................................................................................................Page A-3
Battery Back-Up ...........................................................................................................Page A-3
Analog Input .................................................................................................................Page A-3
Subassemblies...........................................................................................................................Page A-3
Electronics Enclosure....................................................................................................Page A-3
The Controller...................................................................................................Page A-3
Peristaltic Pump............................................................................................................Page A-4
Liquid Sensor................................................................................................................Page A-5
Refrigerator...................................................................................................................Page A-5
Wetted Parts..................................................................................................................Page A-5
Intake Hose .......................................................................................................Page A-5
Strainer..............................................................................................................Page A-5
Pump Tubing.....................................................................................................Page A-6
Discharge Tubing..............................................................................................Page A-6
Bottle Full Sensor .............................................................................................Page A-6
Sample Bottles..................................................................................................Page A-7

MODEL YB8 INSTALLATION AND OPERATION
April 1999/Manning Environmental Inc.
Assembly...................................................................................................................................Page A-8
Assembling the Model YB8 Sampler ...........................................................................Page A-8
Refrigerator.......................................................................................................Page A-8
Electronics Enclosure........................................................................................Page A-9
Distribution Assembly Installation.............................................................................Page A-10
Single Bottle Sampling...................................................................................Page A-10
Multiple Bottle Sampling................................................................................Page A-10
Suspension Plate Installation ..............................................................Page A-10
Distributor Assembly..........................................................................Page A-10
Bottle Installation............................................................................................Page A-13
One Liter and Half-Liter Plastic Bottles Page A-13
Spout Position Page A-13
Installing The Sampler............................................................................................................Page A-13
Connecting Power.......................................................................................................Page A-14
Sample Intake Line .....................................................................................................Page A-14
Intake Hose Placement................................................................................................Page A-14
Running a Test Cycle..............................................................................................................Page A-15
The Sampling Cycle................................................................................................................Page A-15
Sample Recovery....................................................................................................................Page A-16
External Connections..............................................................................................................Page A-17
Contact In & Analog In Connections..........................................................................Page A-17
Bottle Full Sensor & Stepper Motor Connections......................................................Page A-17
Bottle Full/Stepper Motor...............................................................................Page A-17
Contact Closure...............................................................................................Page A-18
Analog Signal (Optional)................................................................................Page A-18

MODEL YB8 INSTALLATION AND OPERATION
April 1999/Manning Environmental Inc. Page A-1
Introduction
Congratulations on the purchase of a Manning Environmental, Inc. Model YB8 Sampler. The model
selected is the latest in a long line of state of the art equipment produced for over twenty three years by
Manning Environmental Inc. Based on this experience, if there is one thing Manning can claim it is that we
know samplers. T here are Manning samplers still used in regular service today that are o ver twenty years
old. I t is almost impossible to find an o rganization with the commitment of producing equipment with such a
history of reliability, dependability, quality and value as exhibited by Manning samplers. E ven so,
improvement is a never ending goal at Manning. We are always interested in the perceptions and experiences
of our users. If there are any suggestions or comments on our equipment, this manual, or anything Manning
does, please feel free to contact us.
The YB8 is a stationary peristaltic pump based model which can automatically collect and hold Non-Toxic,
Toxic, and Suspended Solid samples from a liquid source. The unit was designed from the ground up with
active user participation to ensure the features and options that are important to field use were incorporated
into the unit. It employs a high speed, peristaltic pump to draw the samples and an industrial grade
refrigeration unit to cool and maintain them at the EPA recommended 4 C. Backed by Manning’s reputation
0
for quality and dependability, it will provide years o f reliable service.
Even if t he sampler will not be used immediately upon receipt, unpack and examine it. This will help to
familiarize the user with t he equipment. V erify t hat all of the parts have been received and that no damage
has occurred in shipment. I f damage is noticed, immediately report the extent o f it to both t he transportation
company and to Manning Environmental Inc. In addition, check the packing list to verify that it matches the
items sent and that all accessories ordered are included with the shipment. Manning strives for 100 percent
accuracy in the delivery of our equipment, but even with the most stringent quality assurance, mistakes do
occur. O missions, damage, or mistakes must be reported to Manning Environmental Inc. within 10 working
days of receipt of the shipment.
This manual is designed to communicate a complete understanding of the equipment, its operation,
maintenance, and functions. Manning recommends this manual and the equipment be examined completely
before placing the unit into service. M anning’s commitment t o producing reliable, t op quality products is
legendary, but the possibility o f breakdown or malfunction always exists. T his manual should enable the
diagnosis and solving of many potential problems. If the problem cannot be solved, please feel free to call
our service department at 1-800-863-9337 to obtain help. Our first priority is making sure the experience
with Manning equipment is an excellent one. In almost all instances the difficulty can be addressed over the
phone, but in the rare instance it cannot, the equipment may need to be sent back to Manning for service.
Please contact our customer service department at 1-800-863-9337 to obtain a Return Authorization
Number. T hen follow the shipping instructions that will be given. P lease note t he malfunction o n t he paper
work so a diagnosis and a solution to the problem can be arrived at with the least amount of delay.
We recommend the following steps before attempting to use the sampler:
1. Review this manual. Read the errata sheets at the end of this manual for the latest updates.
2. Follow the instructions beginning on page 1-8 to assemble the YB8.
3. Set the time and activate a test cycle.

INSTALLATION AND OPERATION MODEL YB8
April 1999/Manning Environmental Inc.
Page A-2
4. Program the YB8.
Hardware
Functional Specifications:
Size Control Unit: 10.75" (27.305cm)W x 7" (17.78cm)H x 9.75" (24.765cm)D
Refrigeration Unit: 23.875" (60.65cm)W x 34.5" (87.63cm)H x 24" (60.96cm)D
Total Unit: 23.875" (60.65cm)W x 41.5" (105.41cm)H x 24" (60.96cm)D
Weight Dry Weight: 110 lb (49.89 kg) with refrigerator.
Environmental Nema 4X, 6 housing around electromechanical components.
Protection
Sample Cooling Industrial Grade refrigeration unit.
Temperature 0°C to 50°C (32°F to 122°F) without optional enclosure and heater.
Limits
Sample Pump High Speed peristaltic, dual roller design with impact and corrosion resistant Delrin
Safety Integral safety kill switch. E nsures when t he clear plastic face plate is removed from
®
plastic pump body.
the pump, it prevents accidental powered rotation.
Pump Tubing 3/8" ID by 5/8" OD by 1/8" thick medical grade silicone rubber pump tubing.
Tube Life Recommended maximum of 1,000,000 pump revolutions based on a standard sample.
A standard sample equates to 5ft of head, 10 foot PVC intake tube, and 200 ml sample
size.
Maximum Lift 28 ft (8.5344 m).
Transport Minimum of 3 ft/s at 3 ft of lift (0.9144 m/s at 1 m) and 2.0 ft/s at 20 ft of lift (0.6096
Velocity m/s at 6.1 m).
Sample Volume Programmed directly in increments of 1 millilit er up to a maximum of 9,999 ml.
Accuracy ± 10ml or ± 10% of t he programmed volume, whichever is greater.
Repeatability ± 5ml or ± 5% o f the average largest and smallest sample volume in a sample set,
whichever is greater.
Liquid Sensor Continuity type or Ultrasonic (optional)

MODEL YB8 INSTALLATION AND OPERATION
April 1999/Manning Environmental Inc. Page A-3
Figure 1 - Electronics
Enclosure
Controller Microprocessor based 1 board system which controls all functions of the unit.
Membrane Ergonomically designed, hermetically Sealed, 24 key, multiple function, with 2 line by
Switch 20 character alphanumeric backlighted display.
Electronics 100% Solid State.
Internal Clock Indicates real time with ± 1min/month accuracy.
Internal Battery 5 year internal lithium battery t o maintain program lo gic, RAM memory, real time
clock and date.
Power 115 volt AC, 60 Hz. - Standard
Battery Back-Up Optional 12 VDC battery backup for continued operation in case of 115 volt power
220 volt AC, 50 Hz . - Optional
failure. C ontinues to operate t he sampling control unit only, not t he refrigerator.
Analog Input 4-20 mA - Optional
Subassemblies
The sampler consists of three major subassemblies: the electronics enclosure, the refrigerator, and the wetted
parts. As a unit these subassemblies form an environmentally resistant enclosure.
Electronics Enclosure
The electronics enclosure includes the microprocessor-based controller, the
peristaltic pump, and the liquid sensor. Constructed of structural resin, the
enclosure conforms to Nema 4X,6 requirements when latched.
The Controller
The controller electronics consists of 1 board. The board converts outside
power to the appropriate internal use and controls the input/output signals
associated with the sampler. The CPU board contains a Z180 microprocessor,
RAM and ROM memory, and interfaces for the keyboard, and the display. The micro board also contains the
logic for the liquid sensor and the RPM counter. The user communicates to the sampler via a 24 key multiple
function membrane switch. The keys are clearly marked with their designated functions. An internal battery
maintains the program lo gic, RAM memory, and t he controller's real-time clock and date function. T he
electronics are mounted on the back of the controller.

INSTALLATION AND OPERATION MODEL YB8
April 1999/Manning Environmental Inc.
Page A-4
Figure 2 - Pump Assembly
Figure 3 - Keypad
Figure 4 - Liquid Sensor - Continuity Type
The Manning Model YB8 employs a high speed, dual
roller, vertically mounted, peristaltic pump. The pump is
belt driven by a 12VDC industrial grade mo tor. T his
ensures quite, smooth performance even while the unit is
subjected to very intense performance conditions. It
utilizes a face plate constructed of clear PVC for easy
visual identification of pump parameters, such as tube
alignment, and spindle and roller operation. The pump
body is made of impact and corrosion resistant Delrin®
plastic for long life. It securely holds the pump tubing in
place by firmly clamping the two halves of the pump
case together. The pump is capable of vertical lifts of up
to 28 feet and produces sample transport velocities of
2.0 feet per second over a wide range of draw heights
Liquid Sensor
The Model YB8 utilizes a liquid sensor, located near
the entrance to the peristaltic pump, which is capable of
detecting the presence of source fluid as it approaches
the pump inlet. The sensor is either a continuity type
probe (base) or an ultrasonic sensor (optional).
The liquid sensor is used for two reasons.It enables the
sampler to rinse the intake line. After the initiation of a
sampling sequence the first operation is to turn on the
peristaltic pump. The pump begins rotating
counter-clockwise causing air to be forced out of the
intake tubing. After the set amount of purge time has
elapsed, t he unit will reverse the pump so the rollers are
moving in a clockwise direction. This creates vacuum in
the pump tube, which in turn causes the source liquid, to
begin traveling up the intake line. As soon as the fluid
reaches the liquid sensor, the sampler will immediately
recognize that fluid has reached the inlet to the pump. It
will instantaneously reverse the direction o f the pump
(rollers will be mo ving in a counter-clockwise rotation),
sending the water that had been drawn up back out of
the intake line. This in effect rinses the line. When the
unit has performed the set number of rinses, a sample
will be drawn. T he rinse o ption is set in *99
(configuration mode). The sampler can be programmed
to not rinse the line or to rinse the line up to 3 times.
It makes it possible fo r t he sampler to deliver precise, repeatable samples even in changing lift conditions.
Peristaltic Pump

MODEL YB8 INSTALLATION AND OPERATION
April 1999/Manning Environmental Inc. Page A-5
Figure 5 - Refrigerator
Figure 6 - Intake Hose
Whenever a sampling sequence is initiated the sampler follows the steps outlined above, and draws a sample.
The controller then determines the transit time of the sample to reach the liquid sensor. Assume for example
there was an increase in the amount of lift from the source liquid to the unit. This would increase the time
needed for a sample to reach the liquid sensor and the pump. The controller, in a case such as this, will
automatically compensate for the change in lift by increasing the amount of time the peristaltic pump is able
to pull source liquid. This ensures the sampler has enough time to collect the correct amount of sample fluid.
The compensation applies to either an increase or decrease in lift height.
Refrigerator
The refrigerator is an industrial grade unit with t he ability t o cool and maintain
samples at the EPA recommended 4ºC. Modifications have been performed on the
refrigerator that enable it to withstand event the harshest environments. The
condenser has been baked dip-coated with enamel and the copper refrigerant lines
are coated with asphalt cork tape to prevent hydrogen sulfide gas from attacking
the copper lines and the brazed joints. The thermostat is located inside the
refrigerator which affords it additional protection from the environment. The
evaporation coils and cabinet both have two coats of baked on acrylic enamel with
the cabinet having the additional protection of an iron phosphate pre-treatment.
Both the fan motor and the compressor are designed for greater durability and
resistance to atmospheric attack. The unit boasts extensive insulation for
maximum cooling retention, and a full perimeter magnetic door gasket with a
urethane coating to resist corrosion and seal the cold inside. The door is also
available with an optional locking hasp to prevent unauthorized entry. The sample containers, suspension
plate, and distributor arm for multiple bottle operation are located within the environmentally controlled
chamber of the refrigerator.
Wetted Parts
Wetted parts are those pieces of the sampler that come in direct contact with the sample liquid. The main
components of the wetted parts for the Manning Model YB8 are the intake hose and strainer, the pump
tubing, the discharge tubing, the bottle full sensor (in single bottle units) the distribution assembly (in multiple
bottle units) and t he sample bottles. I f the source liquid t o be sampled is a non-priority pollutant (Non-
Toxic) t hen all parts that touch the liquid are either PVC (Polyvinyl Chloride), medical grade silicone rubber,
ABS (Acrylonitrile Butadiene Styrene) plastic, or Stainless Steel. Parts in contact with a sample source that
is a priority pollutant (Toxic) are required to be Teflon , glass, stainless steel, or medical grade silicone
®
rubber. These materials are recognized and accepted as non-contaminating materials. This permits the
sampling of a wide variety of toxic pollutants such as hydrocarbons and chlorine-based compounds.
Intake Hose
The 3/8" ID by 5/8" OD intake hose is constructed of either PVC (Polyvinyl
Chloride) or PTFE. Y ou can differentiate t he hoses by
their physical characteristics. The PVC is flexible and slightly tacky to the
touch. T he PTFE is not very flexible and is also very
smooth and slick to the touch.

INSTALLATION AND OPERATION MODEL YB8
April 1999/Manning Environmental Inc.
Page A-6
Figure 7 - Strainers
Figure 8 - Pump Tubing
Strainer
The 3/8" ID strainer is available in stainless steel, or PVC. By placing
holes no larger than 3/8" ID along the length of the strainer, the intake of
large particles that can plug the hose or any part of the sampler is
prevented. Since the strainer is also weighted, it keeps the hose inlet at the
desired level in the source liquid.
Pump Tubing
The pump tubing Manning Environmental Inc. supplies for the Model
YB8 is medical grade silicone rubber.
Discharge Tubing
The 3/8" ID by 5/8" OD discharge tubing is also medical grade silicone rubber.
®
Bottle Full Sensor
The bottle full sensor is o nly used o n single bottle applications. I t is a
cylinder, with a hole in the middle, to allow the discharge tube to pass
through. Constructed of PVC it has two stainless steel rods that protrude
vertically downward from the main body of the sensor. The user positions
the bottle full sensor in the container with the ends of the rods at the highest
point water should be allowed t o rise. O nce the water level has risen and
contacts the rods, a change in continuity is detected alerting the sampling
unit that the liquid in the container has reached the maximum level allowed by the user.
This ends the sampling cycle
Bottle Full Sensor

MODEL YB8 INSTALLATION AND OPERATION
April 1999/Manning Environmental Inc. Page A-7
Sample Bottles
The bottles are constructed of either polyethylene or glass.
NOTE: The sampler is field convertible from multiple bottle to single bottle.
Contact the Manning Environmental Parts Department for assistance.
Single Bottle Sampling Multiple Bottle Sampling
One (1) - 5 gallon HDPE carboy Twenty-four (24) - 500mL Polyethylene bottles
One (1) - 4 gallon polyethylene carboy Twenty-four (24) - 1000mL Polyethylene bottles
One (1) - 2.5 gallon glass bottle
One (1) - 2.5 gallon polyethylene

INSTALLATION AND OPERATION MODEL YB8
April 1999/Manning Environmental Inc.
Page A-8
Assembly
Assembling the Model YB8 Sampler
The unit is normally shipped assembled with accessories packed inside the refrigerator.
Refrigerator
There are several t hings to keep in mind before installing t he refrigerator. T he lo cation is important.
It is best to locate the unit out of direct sunlight and away from heat sources. It is best to locate the
unit at least two inches away from any kind of wall. Ventilation is required from the bottom front
section of the unit. Keep this area open and clear of any obstructions. It is recommended not to use
a power cord to power the unit. It is best if the unit can be plugged directly into the appropriate
power supply outlet. The refrigeration system is equipped with a power supply cord that has a three-
pronged grounded plug. It must be plugged into a mating grounding type receptacle in accordance
with the National Electrical Code and applicable local codes and ordinances. If the circuit does not
have a grounding type receptacle, it is the responsibility and obligation of t he customer t o exchange
the existing receptacle in accordance with the National Electrical Code and applicable local codes an
dordinances. Th ethird ground prong should not under any circumstances, be cut or removed. All
U.L listed refrigerated products are equippedd with this type of plug, except hazardous location
models which are to wired to comply with the National Electrical Code, Article 501-4 for Class I
Divisions 1 and 2
Things to remember about the refrigerator:
A. Allow 24 hours for your refrigerator to reach a new temperature setting.
B. The mo tor will start and stop often. I t must do t his t o maintain t he t emperature yo u
select.
C. Keep you refrigerator as level as possible
D. Unplug the refrigerator before working on anything with the electrical system.
E. Exercise caution when sweeping, vacuuming or mopping near the front of the unit.
Damage t o t he grill can o ccur.
F. For all cleaning of the refrigerator, mix 2 tablespoons baking soda into 1 quart warm
water o r use mild soap. D o not use strong cleaners o r scouring powders o r pads.
G. Keep all flame or sparks away from flammable material storage refrigerators when
opening the door to remove or store commodities.
H. Disconnect electrical power before removing electrical plug
Unpack the refrigerator by removing the bands at the top and bottom of the refrigerator box and
lifting the box off of the refrigeration unit. Open the refrigerator door and check for various
components that might be inside the refrigerator. I tems are o ften packed inside t he unit t o minimize
shipping space. Check the items you have received against the packing list. Call Manning
immediately if yo u cannot match t he packing list to t he it ems shipped. M anning strives fo r 100%
accurate shipments, but mistakes do happen, so please call Manning immediately if t here is a
discrepancy.

Plus Nuts
Discharge Hole
Leveling Feet (2 front, 2 back)
MODEL YB8 INSTALLATION AND OPERATION
April 1999/Manning Environmental Inc. Page A-9
Figure 10 - Refrigerator
Figure 11 -
Refrigerator Plug
Figure 12 - Refrigeration Hole Placement
1. Once you have unpacked the unit, locate the four feet
for the refrigerator (they are in a small plastic bag inside
the refrigerator, with the refrigerator owners manual).
2. With the refrigerator empty, carefully tip it and screw a
foot into the threaded hole in the bottom of each
corner.
3. Adjust the feet so the refrigerator is level and does not
rock.
4. Plug the refrigerator in and begin the cooling the unit down. Manning recommends using a
water proof thermometer and a liter of water to monitor the temperature of the water within
the refrigerator. T his will give a mo re accurate representation of the actual temperature of the
samples o nce sampling begins. Y ou should allow at least 24 hours fo r t he refrigerator to
reach a stable condition.
NOTE: Be careful not to scratch any painted surfaces. The surfaces are painted with corrosion
resistant paint. S cratches in t he paint minimize this protection.
Electronics Enclosure
1. On top of t he refrigerator there will be 4 screws inserted into 4 plus nut holes. R emove the
screws from the holes and set them aside in a safe place.
2. Place the electronics enclosure on top of the refrigerator so the holes in the PVC mounting
bars match up with the threaded inserts in the refrigerator. The front (latches are in the front)
should be facing the door of the refrigerator and the peristaltic pump should be on the right.
3. Insert the screws and tighten snugly.
4. Thread the discharge tube into the center hole in the refrigerator. There
will be a black rubber plug that fit s into t he discharge hole. T his plug is
split to accept either the bottle full sensor cable or the stepper motor
cable depending on the configuration that you ordered. The cable fits
inside the plug.

INSTALLATION AND OPERATION MODEL YB8
April 1999/Manning Environmental Inc.
Page A-10
Figure 13
- Bottle
Full
Sensor
Figure 14 - Gear Arrangement Figure 15 - Distribution System
Distribution Assembly Installation
Single Bottle Sampling
1. Center the sample bottle in the refrigerator.
2. Run the discharge hose through the Bottle Full sensor ring and then place it at the
desired height in t he bottle. T o adjust t he position simply slide t he bottle full
sensor either up or down the discharge hose.
3. Connect the Bottle Full sensor probes to the female contacts on the bottle full
cable comming from the electronics enclosure into the refrigerator.
Multiple Bottle Sampling
Suspension Plate Installation
Position the suspension plate so the handles are on the sides. Slide the plate onto the top
rails in the refrigerator. The plate should be flush with the front of the refrigerator so it
does not interfere with the drain trough in the rear.
Distributor Assembly
1. Verify t hat the spout is correctly aligned on the distribution bracket. The spout should be centered
on the bracket side when the spout is rotated to the side (3 o'clock position).
