Manufacturas Lenin COUNTERTOP ECO LENIN PRESS User manual

OPERATION’S MANUAL
COUNTERTOP ECO LENIN PRESS
MEXICANTORTILLAMACHINE.COM

OPERATION’S MANUAL
COUNTERTOP ECO LENIN PRESS
The total or partial reproduction of this manual
is prohibited by any means, whether printed or electronic;
without the prior, express and written authorization ot the author.
VER. 2.0 · FEBRUARY 2022

GENERAL SAFETY INSTRUCTIONS 4
CAUTION 5
ELECTRICAL INSTALLATION 6
COMPONENTS 7
OPERATING INSTRUCTIONS 8
CLEANING AND MAINTENANCE 9
INDEX

4
OPERATION’S MANUAL
COUNTERTOP ECO LENIN PRESS
GENERAL SAFETY INSTRUCTIONS
WARNING: To reduce the risk of injury, read all instructions properly.
Failure to follow the instructions listed below can cause electric shock, fire, serious injuries, mutilation and/or
damage to the equipment.
A. SAFETY IN THE WORK AREA.
* Keep the work area clean and lit. Crowded or dark areas lead to accidents.
* Keep children, customers and non-company personnel away from the electrical and mechanical operation
area of the equipment.
* It is recommended to have a minimum space of one meter or three feet around the machine for safety
measure and to optimize work.
B. ELECTRICAL SAFETY.
* Machinery connections must be adapted to the power outlets.
* Do not use adapters for the switches: since you run the risk of receiving an electric shock.
* Do not expose the switches and / or electrical connections to rain or humidity. If water enters these
elements, there is a risk that they will break down or suffer an electric shock.
* Use cable in a single piece, if there are joints in the connections these can produce a short circuit.
* Do not expose cables or electrical connections to heat, oil, sharp edges, or moving parts, as damaged
cables can cause electric shock or short circuit.
C. PERSONAL SAFETY.
* Do not operate the equipment if you are tired, under the influence of alcohol or drugs.
* Wear appropriate clothing, do not wear loose clothing, or necklaces, earrings, watches, if you have long
hair wear a tie to keep it up.
* Do not climb on the structure of the machine for any reason, falls or injuries may occur.
* Avoid using headphones, cell phones or any other equipment that works as a distraction to the operator.
* Make correct use of personal protective equipment if any maintenance is to be carried out on the machine.
* If any change is made to the model or component of the equipment, be it electrical or mechanical related, it
must be de-energized and stop the machine completely to avoid accidents.
* Keep limbs away from all moving parts.

5
OPERATION’S MANUAL
COUNTERTOP ECO LENIN PRESS
CAUTION
The following symbols indicate the safety measures that must be taken before and after starting up
the equipment.
HEAT HAZARD Some parts of the machine are hot while in operation.
ELECTRICAL RISK In which you can suffer electric shocks, if you do not comply with the
electrical safety provisions.
CRUSHING HAZARD Keep hands away from the cam press when be in operation.

6
OPERATION’S MANUAL
COUNTERTOP ECO LENIN PRESS
ELECTRICAL INSTALLATION
Verify that the electrical connection is 220v. Inspect that there are no short circuits, no loose or bare wires.
Ensure that all cables are isolated and without contact, check contactors and switches in good condition.
It is recommended to use a 12 gauge cable for the installation of the Countertop Eco Lenin Press.
B
A
ELECTRICAL INSTALLATION
A220v electrical installation
(or the machine’s specified voltage).
B12 gauge cable (conduit cable) 220V.
or 10 gauge cable (conduit cable) 110V.
B

7
OPERATION’S MANUAL
COUNTERTOP ECO LENIN PRESS
COMPONENTS
THICKNESS ADJUSTMENT
KNOBS
TEMPERATURE
CONTROL
ON/OFF
MOTOR ON/OFF
EMERGENCY STOP
CONTROL PANEL
PYROMETER
LOWER AND UPPER
PILOT LIGHT
SLIDER
GEARMOTOR
PLATE CLAMPING KNOBS

8
OPERATION’S MANUAL
COUNTERTOP ECO LENIN PRESS
1
3
5 6
4
2
Plug the machine to an electrical outlet
Adjust the temperature to:
160° for 30 to 35 grams dough balls
180° for 60 to 70 grams dough balls
The lower and upper pilot lights will turn on.
They turn off automatically once the selected
temperature is reached.
Take the dough ball Place the dough ball in the press
each time the plates are open
Turn the motor switch ON
Turn the temperature control switch ON

9
OPERATION’S MANUAL
COUNTERTOP ECO LENIN PRESS
7 8
Check the shape, thickness
and size of the tortilla.
Start production.
To adjust the thickness of the tortilla:
Turn the knobs counterclockwise
for thinner tortillas.
And turn the knobs clockwise
for thicker tortillas.
CLEANING PROCEDURE
WARNING: The Countertop Eco Lenin Press must be cleaned with the machine completely stopped to avoid
accidents such as crushing.
COUNTERTOP ECO LENIN PRESS CLEANING
1. Remove excess dough on both aluminum plates.
2. Clean the plates with a damp non-abrasive cloth and scrub the aluminum plates.
3. Repeat until the plates are left with no residue of flour or dough.
4. Clean the control panel, sides, sheets, motor and buttons.
A B
Turn the left knob counter-clockwise Turn the right knob counter-clockwise

10
OPERATION’S MANUAL
COUNTERTOP ECO LENIN PRESS
C
E F
D
Remove the upper plate from the press
Clean both plates with a cloth Check that both plates are clean
Plates with wheat flour
G H
Place the upper plate back in the press Turn both knobs clockwise

11
OPERATION’S MANUAL
COUNTERTOP ECO LENIN PRESS
The following figures show the schematic location of the parts that require lubrication.
Lubricate bearings
with BAT 3 grease (A)
Lubricate bearings
with BAT 3 grease (A)
LUBRICANT
(A) BAT3 Grease
MAINTENANCE
Clean the machine before and after using it.
The duration of the spare parts will depend on the preventive maintenance and care taken to the machine.
The more frequent this maintenance is done, the parts will have a longer life.
LUBRICATION
The following table shows the parts, the type of lubricant and the frequency with which the machines and their
parts must be lubricated.
PIECE LUBRICANT PERIOD
Bearings BAT3 Grease Every 3 days

HEADQUARTERS
AV. INDUSTRIAS #3655, ZONA INDUSTRIAL
CP 78395 SAN LUIS POTOSÍ, SLP. MÉXICO
444 127 11 80 444 129 29 79
[email protected]
MEXICANTORTILLAMACHINE.COM
