Marantz VP4001 User manual

RS-232C Control Specification :
Rev 00
Marantz America, Inc. 2006
All rights are reserved. Reproduction in whole or in part is prohibited without the written consent of copyright.
All specifications might be subject to change without notice.
VP4001
RS-232C Control Specification
Category :
Video Projector
Document Version :
1.0
Author(s) :
Marantz America, Inc.
Date : 2006/10/07
Number of Page : 15

VP4001 RS-232C Control Specification Page: 2 / 15
Document Version [1.0]
Company Restricted
Table of Contents
1. Introduction ............................................................................................................................................................ 3
1-1. Purpose ............................................................................................................................................................ 3
1-2. Scope................................................................................................................................................................ 3
1-3. Abbreviations ................................................................................................................................................... 3
2. Global Description ................................................................................................................................................ 3
2-1. Overview........................................................................................................................................................... 3
2-2. Block Diagram.................................................................................................................................................. 3
2-3. Interface connection specification of the product........................................................................................... 3
2-3-1. RS-232C Cross Cable............................................................................................................................. 3
2-3-2. Signal Discription ..................................................................................................................................... 4
3. Detailed Description.............................................................................................................................................. 4
3-1. Connection format ........................................................................................................................................... 4
3-1-1. Physical connection................................................................................................................................. 4
3-2. Transmission data format................................................................................................................................ 4
3-2-1. Transmission data format from Host to Slave........................................................................................ 4
3-2-1-1. Form1: Command ........................................................................................................................... 4
3-2-2. Transmission data format from Slave to Host........................................................................................ 5
3-2-2-1. Form1: OK/ERR .............................................................................................................................. 5
3-2-2-2. Form2: Status answer and Auto status feedback.......................................................................... 5
3-3. The transaction sequences and the regulations............................................................................................ 5
3-3-1. The transaction sequences..................................................................................................................... 5
3-3-2. The transaction regulations..................................................................................................................... 5
4. Definitions of Command and Status.................................................................................................................. 6
4-1. Commands....................................................................................................................................................... 6
4-1-1. Normal Command for General ............................................................................................................... 6
4-1-2. Normal Command for COMPONENT 1 Input ....................................................................................... 9
4-1-3. Normal Command for COMPONENT 2 Input ..................................................................................... 10
4-1-4. Normal Command for S-VIDEO Input.................................................................................................. 11
4-1-5. Normal Command for VIDEO Input .....................................................................................................12
4-1-6. Normal Command for RGB Input ......................................................................................................... 13
4-1-7. Normal Command for HDMI Input........................................................................................................14
5. Revision history................................................................................................................................................... 15

VP4001 RS-232C Control Specification Page: 3 / 15
Document Version [1.0]
Company Restricted
1. Introduction
1-1. Purpose
This document was written as a reference specification of products that are controled by the host
controller.
1-2. Scope
This document would be using by software or hardware engineers for production of the product.
1-3. Abbreviations
Abbreviation Description
2. Global Description
2-1. Overview
A Host controller can control or watch out the product as a Slave very easily via the communication cable.
2-2. Block Diagram
* The product connector is using 9-pin Mini DIN connector.
* D-SUB to Mini DIN adapter is attached as an accesory.
* Cross type RS232C cable have to be used (D-SUB 9-pin female on product side).
2-3. Interface connection specification of the product
2-3-1. RS-232C Cross Cable
Connector Pin
#
Signal
Name
Connection Signal
Name
Pin
#
Connector
1 CD CD 1
2 RD RD 2
3 SD SD 3
4 ER ER 4
5 SG SG 5
6 DR DR 6
7 RS RS 7
8 CS CS 8
9 CI
CI 9
<Adapter connector>
D-SUB 9-pin, Male
HOST
(Controller)
SLAVE
(VP4001)
RS232C cable (Cross)
Connector:
Mini DIN 9-pin

VP4001 RS-232C Control Specification Page: 4 / 15
Document Version [1.0]
Company Restricted
2-3-2. Signal Discription
Pin # Signal Name I/O Reference
1 CD Not Connected
2 RD Receive Data Input Connected to Internal Circuit
3 SD Send Data Output Connected to Internal Circuit
4 ER
5 SG Signal Dround Connected to Internal Circuit
6 DR
7 RS Request to Send Connected to Internal Circuit
8 CS Clear to Send Connected to Internal Circuit
9 CI
3. Detailed Description
The interface specification between the product and a Host controller is described below.
3-1. Connection format
3-1-1. Physical connection
Baud Rate : 9600bps or 115200pbs
Data Bits : 8bit
Parity : None
Stop bit : 1bit
Handshaking : None
3-2. Transmission data format
3-2-1. Transmission data format from Host to Slave
There are two kinds of transmission data form from Host shown below.
3-2-1-1. Form1: Command
Command is a data that requests some status change.
Commands from the Host are sent in the following order: command, parameter, and return code.
After the projector processes the command from the host, it sends a response code to the computer.
Command Format
C1 C2 C3 C4 P1 P2 P3 P4 0DH
Command (4 digits) Parameter (4 digits Return Code
Start character : None
COMMAND : see “Command list”
End character (CR) : 0Dh
Note:
• When controlling the projector by using RS-232C commands, wait for at least 30 seconds after the power
has been turned on, and then transmit the commands.
• When more than one code is being sent, send each command only after the response code for the
previous command from the projector is verified.
1 2
3 6
7 9
8
4 5

VP4001 RS-232C Control Specification Page: 5 / 15
Document Version [1.0]
Company Restricted
3-2-2. Transmission data format from Slave to Host
There are two kinds of transmission data form from Slave shown below.
3-2-2-1. Form1: OK/ERR
OK is a reply data from Slave when Slave got an acceptable command data from Host.
Command Format
O K 0DH
Return Code
Reply: OK
End character (CR): 0Dh
ERR is a reply data from Slave when Slave got an incorrect Command data, Status request data or
some other data from Host.
Command Format
E R R 0DH
Return Code
Reply: NAK
End character (CR): 0Dh
3-2-2-2. Form2: Status answer and Auto status feedback
Status answers are reply data when Slave got an acceptable Request status or Command data from
Host. Auto status feedbacks are send to Host data when a Slave’s status is changed.
Start character : None
Answer character : see “Status list”
End character (CR) : 0Dh
3-3. The transaction sequences and the regulations
3-3-1. The transaction sequences
There are three kinds of the transaction sequence,
*A transaction starts from Command from Host and then Slave will return Status answer, OK or ERR.
*A transaction starts from Status request from Host and then Slave will return Status answer or ERR.
*A transaction starts by Auto status feedback from Slave when a Slave’s status was changed.
3-3-2. The transaction regulations
The transactions have some kinds of regulation.
* An reply (OK, ERR or Status answer) transmittion by Slave has to finish within 500ms when got a
Command or a Status request from Host.
* Host must not transmit an another Command or Status request until "it receives a answer by a
previous Command or Status request" or "it passes a term of waitinng time from a finishing of
previous transmission of a Command or a Status request ".
* Slave has to finish a transaction under 500ms when it sends Auto status feedback data.

VP4001 RS-232C Control Specification Page: 6 / 15
Document Version [1.0]
Company Restricted
4. Definitions of Command and Status
This section explains how to define “Command” and “Status”.
4-1. Commands
This chapter will show the commands of this product.
4-1-1. Normal Command for General
Code Status (Return) code
Parameter
Command "_" is Space
"*" is value
Function
C1 C2 C3 C4 P1 P2 P3 P4
"POWER
ON"
"STANDB
Y"
or
"40sec.
within
Power on"
Comment
POWER ON P O W R _ _ _ 1 OK
POWER
POWER OFF P O W R _ _ _ 0
OK or ERR OK or
ERR
COMP.1 I V E D _ _ _ 1
COMP.2 I V E D _ _ _ 2
S-VIDEO I V E D _ _ _ 3
VIDEO I V E D _ _ _ 4
RGB I R G B _ _ _ 1
INPUT
HDMI I R G B _ _ _ 2
OK or ERR ERR
OSD_DISPLAY : ON I M D I _ _ _ 1
OSD
OSD_DISPLAY : OFF I M D I _ _ _ 0
OK or ERR ERR
BACKGROUND : BLUE I M B G _ _ _ 1
BACKGROUND
COLOR BACKGROUND : NONE I M B G _ _ _ 2
OK or ERR ERR
Auto Power Off: NO USE A P O W _ _ _ 0
AUTO POWER
OFF Mode Auto Power Off : USE A P O W _ _ _ 1
OK or ERR ERR
LANGUAGE : English M E L A _ _ _ 1
LANGUAGE : Deutsch M E L A _ _ _ 2
LANGUAGE : Español M E L A _ _ _ 3
LANGUAGE : Nederlands M E L A _ _ _ 4
LANGUAGE : Français M E L A _ _ _ 5
LANGUAGE : Italiano M E L A _ _ _ 6
LANGUAGE : Svenska M E L A _ _ _ 7
LANGUAGE : 日本語
(Japanese) M E L A _ _ _ 8
LANGUAGE : Português M E L A _ _ _ 9
LANGUAGE : 汉语
(Chinese) M E L A _ _ 1 0
OSD
LANGUAGE
LANGUAGE : 한국어
(Korean) M E L A _ _ 1 1
OK or ERR ERR
V-KEYSTONE Keystone Vertical value
(-90 ↔+90) K E Y V _ * * * OK or ERR ERR
The Max. adjustable value :
difined by the combination of
both H/V adjustment.
H-KEYSTONE Keystone Horizontal value
(-90 ↔+90) K E Y H _ * * * OK or ERR ERR
The Max. adjustable value :
difined by the combination of
both H/V adjustment.

VP4001 RS-232C Control Specification Page: 7 / 15
Document Version [1.0]
Company Restricted
Code Status (Return) code
Parameter
Command "_" is Space
"*" is value
Function
C1 C2 C3 C4 P1 P2 P3 P4
"POWER
ON"
"STANDB
Y"
or
"40sec.
within
Power on"
Comment
IMAGE SHIFT Image Shift value
(-24 ↔+24) L N D S _ * * * OK or ERR ERR
Freeze: OFF F R E Z _ _ _ 0
FREEZE
Freeze: ON F R E Z _ _ _ 1
OK or ERR ERR
Auto Sync OFF A A D J _ _ _ 0
AUTO SYNC.
Mode Auto Sync ON A A D J _ _ _ 1
OK or ERR ERR
MANUAL AUTO
SYNC. Auto Sync. Adj. Start A D J S _ _ _ 1 OK or ERR ERR This is effective in RGB.
Reset SYNC.
ADJUSTMENT Reset Sync. Adj. I A R E _ _ _ 1 OK or ERR ERR
Eco Mode: ON T H M D _ _ _ 1
LAMP Mode
Eco Mode: OFF T H M D _ _ _ 0
OK or ERR ERR
Iris: WIDE I R I S _ _ _ 1
Iris: MEDIUM I R I S _ _ _ 2
IRIS Position
Iris: NARROW I R I S _ _ _ 3
OK or ERR ERR
Adjust SIGNAL
CLOCK Clock value (-150－+150) I N C L * * * * OK or ERR ERR This is effective in RGB.
Adjust SIGNAL
PHASE Phase value (-30－+30) I N P H _ * * * OK or ERR ERR This is effective in RGB.
Adjust
HORIZONTAL
POSITION
H-Position value
(-150 to +150) I A H P * * * * OK or ERR ERR This is effective in COMP.1/2
and VIDEO.
Adjust
VERTICAL
POSITION
V- position value
(-60 to +60) I A V P _ * * * OK or ERR ERR This is effective in COMP.1/2
and VIDEO.
Overscan H value
(-30－+30) O V S H _ * * *
Set the
OVERSCAN Overscan V value
(-30－+30) O V S V _ * * *
OK or ERR ERR
Adjust the
SUBTITLE Mode Subtittle value (-30－+30) S T S Z _ * * * OK or ERR ERR
Video System: AUTO M E S Y _ _ _ 1
Video System: PAL M E S Y _ _ _ 2
Video System: SECAM M E S Y _ _ _ 3
Video System: NTSC4.43 M E S Y _ _ _ 4
Video System: NTSC3.58 M E S Y _ _ _ 5
Video System: PAL-N M E S Y _ _ _ 6
Video System: PAL-M M E S Y _ _ _ 7
VIDEO SYSTEM
Mode
Video System: PAL-60 M E S Y _ _ _ 8
OK or ERR ERR This is effective in S-VIDEO
and VIDEO.
Reverse: OFF (Front) I M R E _ _ _ 0
INSTALLATION
Mode
(Reverse) Reverse: ON (Rear) I M R E _ _ _ 1
OK or ERR ERR
Inverse: OFF (Table Top) I M I N _ _ _ 0
INSTALLATION
Mode
(Inverse) Inverse: ON (Ceiling) I M I N _ _ _ 1
OK or ERR ERR

VP4001 RS-232C Control Specification Page: 8 / 15
Document Version [1.0]
Company Restricted
Code Status (Return) code
Parameter
Command "_" is Space
"*" is value
Function
C1 C2 C3 C4 P1 P2 P3 P4
"POWER
ON"
"STANDB
Y"
or
"40sec.
within
Power on"
Comment
Special Mode:1 S P M D _ _ _ 1
Special Mode:2 S P M D _ _ _ 2
Special Mode:3 S P M D _ _ _ 3
Special Mode:4 S P M D _ _ _ 4
SPECIAL
DISPLAY Mode
*1
Special Mode:5 S P M D _ _ _ 5
OK or ERR ERR
Check
LAMP STATUS Lamp Status Check T L P S _ _ _ 1
0:OFF
1:ON
2:Re-try
3:Waiting
4:Lamp
Error
0:OFF
4:Lamp
Error
Check
PROJECTOR
STATUS
Abnormal Status Check T A B N _ _ _ 1
0:Normal,
1:High
Temp.,
8: Lamp
life: less
than 5%,
16: Lamp
broken,
32: Failure
of turning
on the
lamp
0: Normal
1: High
Temp.
2: Cooling
Fan Error
4: Open
the lamp
cover
8: Lamp
Life: less
than 5%
16: Lamp
broken
32: Failure
of turning
on the
lamp
64:
Abnormal
high temp.
Check
CURRENT
INPUT
Input Check I C H K ? ? ? ?
1:COMP.1
2:COMP.2
3:S-VIDEO
4:VIDEO
5:RGB
6:HDMI
ERR Read Only
Check
LAMP STATUS Power Status Check T P O W _ _ _ 1
1:ON, 2:
Under
Cooling 3:
Under
shutdown
0: Standby
Check
LAMP TIME
Lamp Elapsed Time
Display T L T T _ _ _ 1 0～9999
(Integer)
0～9999
(Integer)
Check
LAMP LIFE Lamp Life (%) Display T L T L _ _ _ 1
0%～
100%
(Integer)
0%～
100%
(Integer)
Check
MODEL NAME Model Name Check M N R D _ _ _ 1 VP4001 VP4001
RESET ALL All Reset A L R E _ _ _ 1 OK or ERR ERR

VP4001 RS-232C Control Specification Page: 9 / 15
Document Version [1.0]
Company Restricted
4-1-2. Normal Command for COMPONENT 1 Input
Code Status (Return) code
Parameter
Command “_” is Space
“*” is value
Function
C1 C2 C3 C4 P1 P2 P3 P4
“POWER
ON”
“STANDB
Y”
or
“40sec.
within
Power
on”
Comment
Picture mode: Standard V A P S _ _ _ 1
Picture mode: Natural V A P S _ _ _ 2
Picture mode: Dynamic V A P S _ _ _ 3
Picture mode: Theater1 V A P S _ _ _ 4
Picture mode: Theater2 V A P S _ _ _ 5
PICTURE Mode
Picture mode: Memory V A P S _ _ _ 0
OK or ERR ERR
Adjust
CONTRAST Contrast value (-30－+30) V A P I _ * * * OK or ERR ERR
Adjust
BRIGHTNESS Brightness value(-30－+30) V A B R _ * * * OK or ERR ERR
Adjust COLOR Color value(-30－+30) V A C O _ * * * OK or ERR ERR
Adjust TINT Tint value(-30－+30) V A T I _ * * * OK or ERR ERR
Adjust
SHARPNESS Sharpness value(-30－+30) V A S H _ * * * OK or ERR ERR
Adjust RED Red value(-30－+30) V A R D _ * * * OK or ERR ERR
Adjust BLUE Blue value(-30－+30) V A B E _ * * * OK or ERR ERR
Color Temp.: 5500K V A C T _ 0 5 5
Color Temp.: 6500K V A C T _ 0 6 5
Color Temp.: 7500K V A C T _ 0 7 5
Color Temp.: 8500K V A C T _ 0 8 5
Color Temp.: 9300K V A C T _ 0 9 3
COLOR TEMP.
Color Temp.: 10500K V A C T _ 1 0 5
OK or ERR ERR
Brilliant Color: 0 V A W E _ _ _ 0
Brilliant Color: 1 V A W E _ _ _ 1
BRILLIANT
COLOR Mode
Brilliant Color: 2 V A W E _ _ _ 2
OK or ERR ERR
Reset PICTURE
SETTING Picture reset V A R E _ _ _ 1 OK or ERR ERR
Aspect: FULL R A S V _ _ _ 2
Aspect: NORMAL R A S V _ _ _ 7
ASPECT Mode
Aspect: ZOOM R A S V _ _ _ 1
OK or ERR ERR
3D DNR : OFF V A N R _ _ _ 0
3D DNR : Level1 V A N R _ _ _ 1
3D DNR : Level2 V A N R _ _ _ 2
DNR Position
3D DNR : Level3 V A N R _ _ _ 3
OK or ERR ERR
IP Conversion: 2D
Progressive V A I P _ _ _ 0
IP Conversion: 3D
Progressive V A I P _ _ _ 1
PROGRESSIVE
Mode
IP Conversion: Film Mode V A I P _ _ _ 2
OK or ERR ERR

VP4001 RS-232C Control Specification Page: 10 / 15
Document Version [1.0]
Company Restricted
4-1-3. Normal Command for COMPONENT 2 Input
Code Status (Return) code
Parameter
Command “_” is Space
“*” is value
Function
C1 C2 C3 C4 P1 P2 P3 P4
“POWER
ON”
“STANDB
Y”
or
“40sec.
within
Power
on”
Comment
Picture mode: Standard V B P S _ _ _ 1
Picture mode: Natural V B P S _ _ _ 2
Picture mode: Dynamic V B P S _ _ _ 3
Picture mode: Theater1 V B P S _ _ _ 4
Picture mode: Theater2 V B P S _ _ _ 5
PICTURE Mode
Picture mode: Memory V B P S _ _ _ 0
OK or ERR ERR
Adjust
CONTRAST Contrast value (-30－+30) V B P I _ * * * OK or ERR ERR
Adjust
BRIGHTNESS Brightness value(-30－+30) V B B R _ * * * OK or ERR ERR
Adjust COLOR Color value(-30－+30) V B C O _ * * * OK or ERR ERR
Adjust TINT Tint value(-30－+30) V B T I _ * * * OK or ERR ERR
Adjust
SHARPNESS Sharpness value(-30－+30) V B S H _ * * * OK or ERR ERR
Adjust RED Red value(-30－+30) V B R D _ * * * OK or ERR ERR
Adjust BLUE Blue value(-30－+30) V B B E _ * * * OK or ERR ERR
Color Temp.: 5500K V B C T _ 0 5 5
Color Temp.: 6500K V B C T _ 0 6 5
Color Temp.: 7500K V B C T _ 0 7 5
Color Temp.: 8500K V B C T _ 0 8 5
Color Temp.: 9300K V B C T _ 0 9 3
COLOR TEMP.
Color Temp.: 10500K V B C T _ 1 0 5
OK or ERR ERR
Brilliant Color: 0 V B W E _ _ _ 0
Brilliant Color: 1 V B W E _ _ _ 1
BRILLIANT
COLOR Mode
Brilliant Color: 2 V B W E _ _ _ 2
OK or ERR ERR
Reset PICTURE
SETTING Picture reset V B R E _ _ _ 1 OK or ERR ERR
Aspect: FULL R B S V _ _ _ 2
Aspect: NORMAL R B S V _ _ _ 7
ASPECT Mode
Aspect: ZOOM R B S V _ _ _ 1
OK or ERR ERR
3D DNR : OFF V B N R _ _ _ 0
3D DNR : Level1 V B N R _ _ _ 1
3D DNR : Level2 V B N R _ _ _ 2
DNR Position
3D DNR : Level3 V B N R _ _ _ 3
OK or ERR ERR
IP Conversion: 2D
Progressive V B I P _ _ _ 0
IP Conversion: 3D
Progressive V B I P _ _ _ 1
PROGRESSIVE
Mode
IP Conversion: Film Mode V B I P _ _ _ 2
OK or ERR ERR

VP4001 RS-232C Control Specification Page: 11 / 15
Document Version [1.0]
Company Restricted
4-1-4. Normal Command for S-VIDEO Input
Code Status (Return) code
Parameter
Command “_” is Space
“*” is value
Function
C1 C2 C3 C4 P1 P2 P3 P4
“POWER
ON”
“STANDB
Y”
or
“40sec.
within
Power
on”
Comment
Picture mode: Standard V C P S _ _ _ 1
Picture mode: Natural V C P S _ _ _ 2
Picture mode: Dynamic V C P S _ _ _ 3
Picture mode: Theater1 V C P S _ _ _ 4
Picture mode: Theater2 V C P S _ _ _ 5
PICTURE Mode
Picture mode: Memory V C P S _ _ _ 0
OK or ERR ERR
Adjust
CONTRAST Contrast value (-30－+30) V C P I _ * * * OK or ERR ERR
Adjust
BRIGHTNESS Brightness value(-30－+30) V C B R _ * * * OK or ERR ERR
Adjust COLOR Color value(-30－+30) V C C O _ * * * OK or ERR ERR
Adjust TINT Tint value(-30－+30) V C T I _ * * * OK or ERR ERR
Adjust
SHARPNESS Sharpness value(-30－+30) V C S H _ * * * OK or ERR ERR
Adjust RED Red value(-30－+30) V C R D _ * * * OK or ERR ERR
Adjust BLUE Blue value(-30－+30) V C B E _ * * * OK or ERR ERR
Color Temp.: 5500K V C C T _ 0 5 5
Color Temp.: 6500K V C C T _ 0 6 5
Color Temp.: 7500K V C C T _ 0 7 5
Color Temp.: 8500K V C C T _ 0 8 5
Color Temp.: 9300K V C C T _ 0 9 3
COLOR TEMP.
Color Temp.: 10500K V C C T _ 1 0 5
OK or ERR ERR
Brilliant Color: 0 V C W E _ _ _ 0
Brilliant Color: 1 V C W E _ _ _ 1
BRILLIANT
COLOR Mode
Brilliant Color: 2 V C W E _ _ _ 2
OK or ERR ERR
Reset PICTURE
SETTING Picture reset V C R E _ _ _ 1 OK or ERR ERR
Aspect: FULL R C S V _ _ _ 2
Aspect: NORMAL R C S V _ _ _ 7
ASPECT Mode
Aspect: ZOOM R C S V _ _ _ 1
OK or ERR ERR
3D DNR : OFF V C N R _ _ _ 0
3D DNR : Level1 V C N R _ _ _ 1
3D DNR : Level2 V C N R _ _ _ 2
DNR Position
3D DNR : Level3 V C N R _ _ _ 3
OK or ERR ERR
IP Conversion: 2D
Progressive V C I P _ _ _ 0
IP Conversion: 3D
Progressive V C I P _ _ _ 1
PROGRESSIVE
Mode
IP Conversion: Film Mode V C I P _ _ _ 2
OK or ERR ERR

VP4001 RS-232C Control Specification Page: 12 / 15
Document Version [1.0]
Company Restricted
4-1-5. Normal Command for VIDEO Input
Code Status (Return) code
Parameter
Command “_” is Space
“*” is value
Function
C1 C2 C3 C4 P1 P2 P3 P4
“POWER
ON”
“STANDB
Y”
or
“40sec.
within
Power
on”
Comment
Picture mode: Standard V D P S _ _ _ 1
Picture mode: Natural V D P S _ _ _ 2
Picture mode: Dynamic V D P S _ _ _ 3
Picture mode: Theater1 V D P S _ _ _ 4
Picture mode: Theater2 V D P S _ _ _ 5
PICTURE Mode
Picture mode: Memory V D P S _ _ _ 0
OK or ERR ERR
Adjust
CONTRAST Contrast value (-30－+30) V D P I _ * * * OK or ERR ERR
Adjust
BRIGHTNESS Brightness value(-30－+30) V D B R _ * * * OK or ERR ERR
Adjust COLOR Color value(-30－+30) V D C O _ * * * OK or ERR ERR
Adjust TINT Tint value(-30－+30) V D T I _ * * * OK or ERR ERR
Adjust
SHARPNESS Sharpness value(-30－+30) V D S H _ * * * OK or ERR ERR
Adjust RED Red value(-30－+30) V D R D _ * * * OK or ERR ERR
Adjust BLUE Blue value(-30－+30) V D B E _ * * * OK or ERR ERR
Color Temp.: 5500K V D C T _ 0 5 5
Color Temp.: 6500K V D C T _ 0 6 5
Color Temp.: 7500K V D C T _ 0 7 5
Color Temp.: 8500K V D C T _ 0 8 5
Color Temp.: 9300K V D C T _ 0 9 3
COLOR TEMP.
Color Temp.: 10500K V D C T _ 1 0 5
OK or ERR ERR
Brilliant Color: 0 V D W E _ _ _ 0
Brilliant Color: 1 V D W E _ _ _ 1
BRILLIANT
COLOR Mode
Brilliant Color: 2 V D W E _ _ _ 2
OK or ERR ERR
Reset PICTURE
SETTING Picture reset V D R E _ _ _ 1 OK or ERR ERR
Aspect: FULL R D S V _ _ _ 2
Aspect: NORMAL R D S V _ _ _ 7
ASPECT Mode
Aspect: ZOOM R D S V _ _ _ 1
OK or ERR ERR
3D DNR : OFF V D N R _ _ _ 0
3D DNR : Level1 V D N R _ _ _ 1
3D DNR : Level2 V D N R _ _ _ 2
DNR Position
3D DNR : Level3 V D N R _ _ _ 3
OK or ERR ERR
IP Conversion: 2D
Progressive V D I P _ _ _ 0
IP Conversion: 3D
Progressive V D I P _ _ _ 1
PROGRESSIVE
Mode
IP Conversion: Film Mode V D I P _ _ _ 2
OK or ERR ERR

VP4001 RS-232C Control Specification Page: 13 / 15
Document Version [1.0]
Company Restricted
4-1-6. Normal Command for RGB Input
Code Status (Return) code
Parameter
Command “_” is Space
“*” is value
Function
C1 C2 C3 C4 P1 P2 P3 P4
“POWER
ON”
“STANDB
Y”
or
“40sec.
within
Power
on”
Comment
Picture mode: Standard R A P S _ _ _ 1
Picture mode: Natural R A P S _ _ _ 2
Picture mode: Dynamic R A P S _ _ _ 3
Picture mode: Theater1 R A P S _ _ _ 4
Picture mode: Theater2 R A P S _ _ _ 5
PICTURE Mode
Picture mode: Memory R A P S _ _ _ 0
OK or ERR ERR
Adjust
CONTRAST Contrast value (-30－+30) R A P I _ * * * OK or ERR ERR
Adjust
BRIGHTNESS Brightness value(-30－+30) R A B R _ * * * OK or ERR ERR
Adjust COLOR Color value(-30－+30) R A C O _ * * * OK or ERR ERR
Adjust TINT Tint value(-30－+30) R A T I _ * * * OK or ERR ERR
Adjust
SHARPNESS Sharpness value(-30－+30) R A S H _ * * * OK or ERR ERR
Adjust RED Red value(-30－+30) R A R D _ * * * OK or ERR ERR
Adjust BLUE Blue value(-30－+30) R A B E _ * * * OK or ERR ERR
Color Temp.: 5500K R A C T _ 0 5 5
Color Temp.: 6500K R A C T _ 0 6 5
Color Temp.: 7500K R A C T _ 0 7 5
Color Temp.: 8500K R A C T _ 0 8 5
Color Temp.: 9300K R A C T _ 0 9 3
COLOR TEMP.
Color Temp.: 10500K R A C T _ 1 0 5
OK or ERR ERR
Brilliant Color: 0 R A W E _ _ _ 0
Brilliant Color: 1 R A W E _ _ _ 1
BRILLIANT
COLOR Mode
Brilliant Color: 2 R A W E _ _ _ 2
OK or ERR ERR
Reset PICTURE
SETTING Picture reset R A R E _ _ _ 1 OK or ERR ERR
Aspect: FULL R A S R _ _ _ 2
Aspect: NORMAL R A S R _ _ _ 7
Aspect: ZOOM R A S R _ _ _ 1
ASPECT Mode
Aspect: THROUGH R A S R _ _ _ 3
OK or ERR ERR
3D DNR : OFF R A N R _ _ _ 0
3D DNR : Level1 R A N R _ _ _ 1
3D DNR : Level2 R A N R _ _ _ 2
DNR Position
3D DNR : Level3 R A N R _ _ _ 3
OK or ERR ERR
IP Conversion: 2D
Progressive R A I P _ _ _ 0
IP Conversion: 3D
Progressive R A I P _ _ _ 1
PROGRESSIVE
Mode
IP Conversion: Film Mode R A I P _ _ _ 2
OK or ERR ERR
Input Signal: Auto I A S I _ _ _ 0
Input Signal: RGB I A S I _ _ _ 1
SIGNAL TYPE
Input Signal: Component I A S I _ _ _ 2
OK or ERR ERR Common setting for
RGB&HDMI input

VP4001 RS-232C Control Specification Page: 14 / 15
Document Version [1.0]
Company Restricted
4-1-7. Normal Command for HDMI Input
Picture mode: Standard R B P S _ _ _ 1
Picture mode: Natural R B P S _ _ _ 2
Picture mode: Dynamic R B P S _ _ _ 3
Picture mode: Theater1 R B P S _ _ _ 4
Picture mode: Theater2 R B P S _ _ _ 5
PICTURE Mode
Picture mode: Memory R B P S _ _ _ 0
OK or ERR ERR
Adjust
CONTRAST Contrast value (-30－+30) R B P I _ * * * OK or ERR ERR
Adjust
BRIGHTNESS Brightness value(-30－+30) R B B R _ * * * OK or ERR ERR
Adjust COLOR Color value(-30－+30) R B C O _ * * * OK or ERR ERR
Adjust TINT Tint value(-30－+30) R B T I _ * * * OK or ERR ERR
Adjust
SHARPNESS Sharpness value(-30－+30) R B S H _ * * * OK or ERR ERR
Adjust RED Red value(-30－+30) R B R D _ * * * OK or ERR ERR
Adjust BLUE Blue value(-30－+30) R B B E _ * * * OK or ERR ERR
Color Temp.: 5500K R B C T _ 0 5 5
Color Temp.: 6500K R B C T _ 0 6 5
Color Temp.: 7500K R B C T _ 0 7 5
Color Temp.: 8500K R B C T _ 0 8 5
Color Temp.: 9300K R B C T _ 0 9 3
COLOR TEMP.
Color Temp.: 10500K R B C T _ 1 0 5
OK or ERR ERR
Brilliant Color: 0 R B W E _ _ _ 0
Brilliant Color: 1 R B W E _ _ _ 1
BRILLIANT
COLOR Mode
Brilliant Color: 2 R B W E _ _ _ 2
OK or ERR ERR
Reset PICTURE
SETTING Picture reset R B R E _ _ _ 1 OK or ERR ERR
Aspect: FULL R B S R _ _ _ 2
Aspect: NORMAL R B S R _ _ _ 7
Aspect: ZOOM R B S R _ _ _ 1
ASPECT Mode
Aspect: THROUGH R B S R _ _ _ 3
OK or ERR ERR
3D DNR : OFF R B N R _ _ _ 0
3D DNR : Level1 R B N R _ _ _ 1
3D DNR : Level2 R B N R _ _ _ 2
DNR Position
3D DNR : Level3 R B N R _ _ _ 3
OK or ERR ERR
IP Conversion: 2D
Progressive R B I P _ _ _ 0
IP Conversion: 3D
Progressive R B I P _ _ _ 1
PROGRESSIVE
Mode
IP Conversion: Film Mode R B I P _ _ _ 2
OK or ERR ERR
Input Signal: Auto I B S I _ _ _ 0
Input Signal: RGB I B S I _ _ _ 1
SIGNAL TYPE
Input Signal: Component I B S I _ _ _ 2
OK or ERR ERR Common setting for
RGB&HDMI input
HDMI_Setting : Normal H M B D _ _ _ 1
HDMI Setting
HDMI_Setting : Expand H M B D _ _ _ 2
OK or ERR ERR

VP4001 RS-232C Control Specification Page: 15 / 15
Document Version [1.0]
Company Restricted
5. Revision history
Ver. Date Owner Change description
1.0 10/07/06 Marantz America, Inc. Issued Revision1.0
