Marantz AV7702 User manual

AV Pre Tuner
AV7702 /U1B/N1B
AV7702
S1313V04DM/DG1607
Copyright 2016 D&M Holdings Inc. All rights reserved.
WARNING: Violators will be prosecuted to the maximum extent possible.
Ver. 4
•Some illustrations using in this service manual are slightly different from the actual set.
•Please use this service manual with referring to the operating instructions without fail.
•For purposes of improvement, specications and design are subject to change without notice.
Please refer to the
MODIFICATION NOTICE.
Service
Manual

ABOUT THIS MANUAL.............................................................3
What you can do with this manual ............................................3
Using Adobe Reader (Windows version) ..................................4
SAFETY PRECAUTIONS ..........................................................6
NOTE FOR SCHEMATIC DIAGRAM.........................................7
NOTE FOR PARTS LIST ...........................................................7
TECHNICAL SPECIFICATIONS................................................9
DIMENSION ...............................................................................9
Precautions During Service...................................................10
Initializing This Unit .................................................................10
Service Jigs.............................................................................10
DISASSEMBLY........................................................................11
1. FRONT PANEL ASSY ........................................................13
2. RADIATOR ASSY...............................................................14
3. DIGITAL PCB .....................................................................15
4. VIDEO PCB........................................................................16
5. INPUT PCB ........................................................................16
6. XLR PCB............................................................................17
7. SMPS PCB.........................................................................17
8. TRANS POWER ................................................................17
SPECIAL MODE ......................................................................18
Special Mode Conguration Buttons.......................................18
1. Version Display Mode ........................................................19
2. PANEL / REMOTE LOCK Selection Mode.........................23
3. Selection Modes for Service-related Operations................24
DIAGNOSTIC PATH DIAGRAM.........................................29
4. CX870 / CY920 Reboot mode............................................71
5. CX870 / CY920 Initialization mode ....................................71
JIG FOR SERVICING ..............................................................72
Procedure after Replacing the Microprocessor, etc. ..........75
Firmware Update Procedure..................................................75
1. Updating by USB................................................................75
2. Updating by DPMS.............................................................84
SURROUND MODES AND PARAMETERS............................91
TROUBLE SHOOTING............................................................94
1. POWER..............................................................................94
2. Analog video ......................................................................95
3. HDMI/DVI ...........................................................................98
4. AUDIO..............................................................................100
5. Network/Bluetooth/USB ...................................................102
6. SMPS ...............................................................................107
Audio Check PASS ..............................................................109
CLOCK FLOW & WAVE FORM IN DIGITAL BLOCK ...........110
LEVEL DIAGRAM.................................................................. 111
POWER DIAGRAM................................................................118
WIRING DIAGRAM................................................................119
PRINTED WIRING BOARDS.................................................120
SCHEMATIC DIAGRAMS (1/41) ...........................................127
SCH01_DIGITAL_CONNECT ...............................................127
SCH02_DIGITAL_POWER ...................................................128
SCH03_MAIN_CPU ..............................................................129
SCH04_SUB_CPU................................................................130
SCH05_CPU_LEVEL_CHG..................................................131
SCH06_DIR ..........................................................................132
SCH07_AUDIO_PLD ............................................................133
SCH08_DSP1 .......................................................................134
SCH09_DSP2 .......................................................................135
SCH10_DSP3 .......................................................................136
SCH11_DSP4........................................................................137
SCH12_ADC .........................................................................138
SCH13_ZONE_DAC .............................................................139
SCH14_CY920......................................................................140
SCH15_VIDEO_DECODER .................................................141
SCH16_HDMI_SW2..............................................................142
SCH17_HDMI_SW1..............................................................143
SCH18_VSP_IP_OSD ..........................................................144
SCH19_VIDEO_PLD ............................................................145
SCH20_HDMI_TX_SCALER ................................................146
SCH21_ADAPTER................................................................147
SCH22_BLUETOOTH...........................................................148
SCH23_INPUT......................................................................149
SCH24_PREOUT..................................................................150
SCH25_FRONT_HDMI .........................................................151
SCH26_VIDEO .....................................................................152
SCH27_RC-5_MX-PORT......................................................153
SCH28_RS232C_TRIGGER.................................................154
SCH29_CONNECT_A...........................................................155
SCH30_CONNECT_B ..........................................................156
SCH31_MAIN DAC1 .............................................................157
SCH32_MAIN DAC2 .............................................................158
SCH33_XLR..........................................................................159
SCH34_REGULATOR & TUNER..........................................160
SCH35_H-DAM_AMP1 .........................................................161
SCH36_H-DAM_AMP2 .........................................................162
SCH37_H-DAM_AMP3 .........................................................163
SCH38_H-DAM_AMP4 .........................................................164
SCH39_H-DAM_AMP5 .........................................................165
SCH40_FRONT ....................................................................166
SCH41_SMPS ......................................................................167
EXPLODED VIEW .................................................................168
PACKING VIEW .....................................................................169
SEMICONDUCTORS .............................................................170
1. IC's ...................................................................................170
2. FL DISPLAY .....................................................................193
2
CONTENTS

Jump to the target of a schematic
diagram connector
Click the Ref. No. of the target connector in the red
box around a schematic diagram connector.
•The screen jumps to the target connector.
•Pagemagnicationstaysthesameasbeforethe
jump.
CP401
CP106
v
ABOUT THIS MANUAL
Read the following information before using the service manual.
What you can do with this manual
Search for a Ref. No. (phrase)
(Ctrl+Shift+F)
You can use the search function in Acrobat Reader to
search for a Ref. No. in schematic diagrams, printed
wiring circuit diagrams, block diagrams, and parts
lists.
1.Press Ctrl+Shift+Fonthekeyboard.
• The Search window appears.
2.EntertheRef.No.youwanttosearchforinthe
Search window, and then click the Search button.
•A list of search results appears.
3.Click an item on the list.
• The screen jumps to the page for that item, and the
searchphraseisdisplayed.
Ctrl
Shift
F
3

Using Adobe Reader (Windows version)
• Properties
Click this button and check that the printer is set to a
suitable paper size.
• Page to print
Select the following checkbox.
"More Options" : "Current View"
• Page Sizing & Handling
Select the following checkbox.
"Size" / "Size Options" : "Fit"
Add notes to this data (Sign)
TheSignfunctionletsyouaddnotestothedatain
this manual.
Savetheleonceyouhavenishedaddingnotes.
[Example using Adobe Reader X]
On the "View" menu, click "Sign".
• The Sign pane appears.
[Example using Adobe Reader 9]
On the "Document" menu, click "Sign".
Magnify schematic / printed circuit
board diagrams - 1
(Ctrl+Space, mouse operation)
Press Ctrl+Spaceonthekeyboardanddragthe
mousetoselecttheareayouwanttoview.
• Theselectedareaismagnied.
• Whenyouwanttomovetheareashown,hold
down Space and drag the mouse.
• Whenyouwanttoshowafullpageview,press
Ctrl+0onthekeyboard.
Ctrl Space
0
Print a magnied part of the manual
ThePropertiesdialogboxandfunctionswillvarydependingonyourprinter.
1. Dragthemousetomagnifythepartyouwanttoprint.
2. On the "File" menu, click "Print".
3. CongurethefollowingsettingsinthePrintdialogbox.
4. Click the Print button to start printing.
4

Magnify schematic / printed circuit
board diagrams - 2
(Pan & Zoom function)
ThePan&Zoomfunctionletsyouseewhichpartof
amagnieddiagramisbeingshowninaseparate
window.
[Example using Adobe Reader X]
On the "View" menu, point to "Zoom", and then click
"Pan & Zoom".
• The Pan & Zoom window appears on the screen.
[Example using Adobe Reader 9]
On the "Tools" menu, point to "Select & Zoom", and
then click "Pan & Zoom Window".
Magnify schematic / printed circuit
board diagrams - 3
(Loupe Tool function)
TheLoupeToolfunctionletsyoumagnifyaspecic
part of a diagram in a separate window.
[Example using Adobe Reader X]
On the "View" menu, point to "Zoom", and then click
"Loupe Tool".
• The Loupe Tool window appears on the screen.
[Example using Adobe Reader 9]
On the "Tools" menu, point to "Select & Zoom", and
then click "Loupe Tool Window".
5

SAFETY PRECAUTIONS
The following items should be checked for continued protection of the customer and the service technician.
leakage current check
Beforereturningthesettothecustomer,besuretocarryouteither(1)aleakagecurrentcheckor(2)alinetochassis
resistance check. If the leakage current exceeds 0.5 milliamps, or if the resistance from chassis to either side of the
power cord is less than 460 kohms, the set is defective.
Be sure to test for leakage current with the AC plug in both polarities, in addition, when the set's power is in each state
(on,offandstandbymode),ifapplicable.
CAUTION Please heed the following cautions and instructions during servicing and
inspection.
◎Heed the cautions!
Cautions which are delicate in particular for servicing
are labeled on the cabinets, the parts and the chassis,
etc. Be sure to heed these cautions and the cautions
described in the handling instructions.
◎Cautions concerning electric shock!
(1) AnACvoltageisimpressedonthisset,soifyou
touch internal metal parts when the set is energized,
youmaygetanelectricshock.Avoidgettingan
electricshock,byusinganisolatingtransformer
and wearing gloves when servicing while the set is
energized,orbyunpluggingthepowercordwhen
replacing parts, for example.
(2) Therearehighvoltagepartsinside.Handlewith
extra care when the set is energized.
◎Caution concerning disassembly and
assembly!
Through great care is taken when parts were
manufacturedfromsheetmetal,theremaybeburrson
theedgesofparts.Theburrscouldcauseinjuryifngers
are moved across them in some rare cases. Wear gloves
toprotectyourhands.
◎Use only designated parts!
Theset'spartshavespecicsafetyproperties(re
resistance,voltageresistance,etc.).Besuretouseparts
which have the same properties for replacement. The
burrs have the same properties. In particular, for the
importantsafetypartsthatareindicatedbythezmark
on schematic diagrams and parts lists, be sure to use
the designated parts.
◎Be sure to mount parts and arrange the wires
as they were originally placed!
Forsafetyseasons,somepartsusetapes,tubesorother
insulatingmaterials,andsomepartsaremountedaway
from the surface of printed circuit boards. Care is also
takenwiththepositionsofthewiresbyarrangingthem
andusingclampstokeepthemawayfromheatingand
highvoltageparts,sobesuretoseteverythingbackas
itwasoriginallyplaced.
◎Make a safety check after servicing!
Check that all screws, parts and wires removed or
disconnected when servicing have been put back in their
original positions, check that no serviced parts have
deteriorate the area around. Then make an insulation
check on the external metal connectors and between
the blades of the power plug, and otherwise check that
safetyisensured.
(Insulationcheckprocedure)
Unplug the power cord from the power outlet, disconnect
the antenna, plugs, etc., and on the power. Using a 500V
insulation resistance tester, check that the insulation
resistancevaluebetweentheinplugandtheexternally
exposedmetalparts(antennaterminal,headphones
terminal,inputterminal,etc.)is1MΩorgreater.Ifitis
less, the set must be inspected and repaired.
Manyoftheelectricandthestructuralpartsusedinthe
sethavespecialsafetyproperties.Inmostcasesthese
propertiesaredifculttodistinguishbysight,andtheuse
ofreplacementpartswithhigherratings(ratedpower
andwithstandvoltage)doesnotnecessarilyguarantee
thatsafetyperformancewillbepreserved.Partswith
safetypropertiesareindicatedasshownbelowonthe
wiring diagrams and the parts list in this service manual.
Be sure to replace them with the parts which have the
designated part number.
(1) Schematicdiagrams.......Indicatedbythez mark.
(2) Partslists.......Indicatedbythezmark.
The use of parts other than the
designated parts could cause electric
shocks,resorotherdangerous
situations.
CAUTION Concerning important
safety parts
6

NOTE FOR SCHEMATIC DIAGRAM
WARNING:
Partsindicatedbythezmarkhavecriticalcharacteristics.UseONLYreplacementpartsrecommendedbythemanufacturer.
CAUTION:
Beforereturningthesettothecustomer,besuretocarryouteither(1)aleakagecurrentcheckor(2)alinetochassisresistancecheck.
If the leakage current exceeds 0.5 milliamps, or if the resistance from chassis to either side of the power cord is less than 460 kohms, the
set is defective.
WARNING:
DONOTreturnthesettothecustomerunlesstheproblemisidentiedandremedied.
NOTICE:
ALLRESISTANCEVALUESINOHM.k=1,000OHM/M=1,000,000OHM
ALLCAPACITANCEVALUESAREEXPRESSEDINMICROFARAD,UNLESSOTHERWISEINDICATED.PINDICATESMICRO-MICRO
FARAD.EACHVOLTAGEANDCURRENTAREMEASUREDATNOSIGNALINPUTCONDITION.CIRCUITANDPARTSARESUBJECT
TOCHANGEWITHOUTPRIORNOTICE.
NOTE FOR PARTS LIST
1.Partsindicatedby"nsp" on this table cannot be supplied.
2.Whenorderingapart,makeacleardistinctionbetween"1"and"I"(i)toavoidmis-supplying.
3.Apartorderedwithoutspecifyingitspartnumbercannotbesupplied.
4.Partindicatedby" ★" mark is not illustrated in the exploded view.
WARNING:Partsindicatedbythezmarkhavecriticalcharacteristics.UseONLYreplacementpartsrecommendedbythemanufacturer.
INSTRUCTIONS FOR HANDLING SEMI-CONDUCTORS AND OPTICAL UNIT
Electrostaticbreakdownofthesemi-conductorsoropticalpickupmayoccurduetoapotentialdifferencecausedby
electrostatic charge during unpacking or repair work.
1. GroundforHumanBody
Besuretowearagroundingband(1MΩ)thatisproperlygroundedtoremoveanystaticelectricitythatmaybe
chargedonthebody.
2. GroundforWorkbench
Besuretoplaceaconductivesheetorcopperplatewithpropergrounding(1MΩ)ontheworkbenchorothersurface,
wherethesemi-conductorsaretobeplaced.Becausethestaticelectricitychargeonclothingwillnotescapethrough
thebodygroundingband,becarefultoavoidcontactingsemi-conductorswithyourclothing
<Incorrect>
CBA
Grounding Band
Conductive Sheet or
Copper Plate
1MΩ
1MΩ
<Correct>
CBA
7

Personal notes:
8

TECHNICAL SPECIFICATIONS

n
 
 200 mV/47 kΩ
10 Hz - 100 kHz — +1, -3 dB(Direct mode)
 105 dB(IHF-A, weighted, Direct mode)
 0.005 % (20 Hz – 20 kHz) (Direct mode)
 Unbalanced XLR pre-output: 1.2 V
Balanced XLR pre-output: 2.4 V
 
 Rated output — 2V (at 0 dB playback)
Total harmonic distortion — 0.008 % (1kHz, 0dB)
S/N ratio — 102 dB
Dynamic range — 100 dB
 Format — Digital audio interface
 
 2.5 mV
 ±1 dB (20 Hz to 20 kHz)
 74 dB (IHF-A)
 150 mV
 0.03 % (1 kHz, 3 V)

n
 
 1 Vp-p, 75 Ω
 5 Hz – 10 MHz — 0, –3 dB
 
 Y signal — 1 Vp-p, 75 Ω
PB / CB signal — 0.7 Vp-p, 75 Ω
PR / CR signal — 0.7 Vp-p, 75 Ω
 5 Hz – 60 MHz — 0, –3 dB

n

  87.5 MHz - 107.9 MHz(for U)
 87.5 MHz - 108.0 MHz(for N)
 530 kHz - 1710 kHz(for U)
 522 kHz - 1611 kHz(for N)
  1.5μV（14.8dBf）
 20 μV
 MONO ― 2.8 μV (20.2 dBf)
 MONO ― 78 dB (IHF-A)
STEREO ― 68 dB (IHF-A)
HD ― 85 dB (IHF-A)
 MONO ― 0.1 % (1 kHz)
SRETEO ― 0.2 % (1 kHz)
HD ― 0.02 % (1 kHz)

n

Conforming to Wi-Fi®z1
  WEP 64 bit, WEP 128 bit
WPA/WPA2-PSK (AES)
WPA/WPA2-PSK (TKIP)
 2.4 GHz
 1 – 11 ch (for U)
1 – 13 ch (for N)
z1 The Wi-Fi® CERTIFIED Logo and the Wi-Fi CERTIFIED On-Product
Logo are registered trademarks of the Wi-Fi Alliance.

n
Bluetooth Version 2.1 + EDR
(Enhanced Data Rate)
 Maximum 2.5 mW (Class 2)
 Approx. 32.8 ft/10 m in line of sight
 2.4 GHz band
 FHSS (Frequency-Hopping Spread Spectrum)
 A2DP 1.2 (Advanced Audio Distribution Prole)
AVRCP 1.4 (Audio Video Remote Control Prole)
 SBC, AAC
20 Hz - 20,000 Hz

n
 (for U) : AC 120 V, 60 Hz
(for N) : AC 230 V, 50 Hz / 60Hz
 60W
 0.2W
 0.5W
 2.7W
For purposes of improvement, specications and design are subject to
change without notice.
DIMENSION
Unit： in. (mm) Weight： 22 lb 8 oz (10.2 kg)
1 17/64
(32)
1 31/32 (50)
2 3/32
(53)
1 37/64
(40)
15/32
(12)
6 47/64 (171)
7 9/32 (185)
9 23/32 (247)
14 7/32 (361) 16 3/16 (411)
45/64
(18)
10 33/64 (267)
15 7/16 (392)
25/32
(20)
1 31/32 (50) 13 25/64 (340)
35/64
(14)
17 21/64 (440)
2 23/64
(60)
9

PRECAUTIONS DURING SERVICE
Initializing This Unit
Initialize this unit if you have replaced the microcomputer, one of the parts around the microcomputer, or the digital PCB.
1. Press the power button to turn off the power.
2. Hold down buttons "MOVIE" and "MUSIC" at the same time and press the power button to turn on the power.
3. Release the buttons after conrming that the display ashes in intervals of approximately 1 second.
＊ The unit is initialized.
：• If the status in step 3 does not occur, start again from step 1.
• Initializing the device restores settings congured by the user to the factory settings. Take note of your settings beforehand
and recongure them after initialization.
Service Jigs
The following jigs (extension cable kit) are used when repairing the PCBs.
Order the jigs from your dealer if necessary.
8U- 110084S : EXTENSION UNIT KIT : 1 Set
8U- 110136S : EXTENSION UNIT KIT : 1 Set
(See 72 page)
XMUSIC
MOVIE
10

DISASSEMBLY
• Remove each part in the order of the arrows below.
• Reassemble removed parts in the reverse order.
• Read  before reassembling removed parts.
• If wire bundles are removed or moved during adjustment or part replacement, reshape the wires after completing
the work. Failure to shape the wires correctly may cause problems such as noise.
FRONT PANEL ASSY
See ""
1. FRONT PANEL ASSY
and ""
FRONT PCB
(Ref. No. of EXPLODED VIEW : C5)
HEAD PHONE PCB
(Ref. No. of EXPLODED VIEW : C2)
FRONT SWE PCB
(Ref. No. of EXPLODED VIEW : C1)
FRONT HDMI PCB
(Ref. No. of EXPLODED VIEW : C3)
GUIDE FFC1 PCB
(Ref. No. of EXPLODED VIEW : C11)
FRONT HDMI FFC CABLE PCB
(Ref. No. of EXPLODED VIEW : C7)
TOP COVER
MAIN TRANS
See ""
8. MAIN TRANS
and ""
TRANS,POWER
(Ref. No. of EXPLODED VIEW : C21)
RADIATOR ASSY
See ""
2. RADIATOR ASSY
and ""
H-DAM PCB
(Ref. No. of EXPLODED VIEW : C10)
GUIDE PCB
(Ref. No. of EXPLODED VIEW : C9)
DIGITAL PCB ASSY
See ""
3. DIGITAL PCB ASSY
and ""
DIGITAL PCB
(Ref. No. of EXPLODED VIEW : C37)
GUIDE FFC2 PCB
(Ref. No. of EXPLODED VIEW : C36)
CX870MIDDLE PCB
(Ref. No. of EXPLODED VIEW : C39)
CX870MODULE
(Ref. No. of EXPLODED VIEW : C40)
INPUT PCB ASSY
See ""
5. INPUT PCB ASSY
and ""
INPUT PCB
(Ref. No. of EXPLODED VIEW : C30)
VIDEO PCB ASSY
See ""
4. VIDEO PCB ASSY
and ""
VIDEO PCB
(Ref. No. of EXPLODED VIEW : C35)
XLR PCB ASSY
See ""
6. XLR PCB ASSY
and ""
XLR PCB
(Ref. No. of EXPLODED VIEW : C16)
FRONT CNT PCB
(Ref. No. of EXPLODED VIEW : C13)
SIDE CNT PCB
(Ref. No. of EXPLODED VIEW : C14)
FUSE PCB
(Ref. No. of EXPLODED VIEW : C12)
SMPS PCB
See ""
7. SMPS PCB
and ""
SMPS PCB
(Ref. No. of EXPLODED VIEW : C22)
11


• The angles from which the photos are taken are shown by "：".
• See the diagram below about the shooting direction of each photograph.
• Photographs with no shooting direction indicated were taken from the top of the unit.
• The photograph is AV7702U model.

(Shooting direction:X)［View from the top］
Front side
Shooting
direction: D
Shooting
direction: C
↑Shooting direction: A↑
↓Shooting direction: B↓
12

1. FRONT PANEL ASSY
  →
(1) Remove the screws.
(2) Cut the wire clamp, then remove the connector wires and FFC. Remove the screws.
View from the bottom
Front side
FFC
FFC
CN914
CN916
CN602
CUT
13

2. RADIATOR ASSY
  → →
(1) Remove the screws.
(2) Cut the wire clamp. Remove the screws.
(3) Cut the wire clamp, then remove the connector wires.
View from the bottom
CUT
CN920 CN922 CN484 CN483
CN940
CN481
CN482
CN921 CN923
14

3. DIGITAL PCB
  → →
(1) Remove the screws.
(2) Cut the wire clamp, then remove the connector wires and FFC.
(3) Remove the connector.
FFC
CN903
FFC CN914
CN916
CON1
CON2
CX870 ONLY
CN901
STYLE PIN
STYLE PIN
Front side
BN24A BN25A BN21ABN26A
BN23A
BN27A
15

4. VIDEO PCB
  → → →
(1) Remove the connector.
5. INPUT PCB
  → → → →
(1) Remove the connector.
BN21B
BN28B
BN27B
BN24C BN26C
BN64C
BN23C
From HDAM PCB
CN484 From HDAM PCB CN483
From HDAM PCB
CN481
From HDAM PCB
CN482
16

6. XLR PCB
  → → → → →
→
(1) Remove the screws.
(2) Remove the connector wire.
(3) Remove the connector wire. Remove the screws.
7. SMPS PCB
  → → →
8. TRANS POWER
  → → →
View from the bottom
CN920 CN922 CN484 CN483
CN940
CN481
CN482
CN921 CN923
CN940
CN941
See "EXPLODED VIEW" for instructions on how to remove each PCB of the "".
See "EXPLODED VIEW" for instructions on how to remove each PCB of the "".
17

SPECIAL MODE
Special Mode Conguration Buttons
b No. 1 - 11, 14 : Hold down buttons"A", "B" and "C" at the same time and press the power button to turn on the power.
b No. 12, 13 : Hold down buttons "A" and "B" for at least 3 seconds while the power is on.
b No. 15 ： Press the "A" and "B"buttons simultaneously while inserting the AC plug to turn the power on.
     
1Version Display
(u-COM / DSP Error Display) DIMMER STATUS -
Displays the version of rmware such as the main rmware or DSP,
etc. Errors that have occurred are displayed.
(See 19 page)
2
User Initialization Mode
(Settings for the Installer Setup are not
initialized.)
GAME A-DSX - Initializes backup data.
(Settings for the Installer Setup are not initialized.)
3
Factory Initialization Mode
(Initialization includes settings for the
Installer Setup.)
MOVIE MUSIC - Initializes backup data.
(Initialization includes settings for the Installer Setup.)
4PANEL / REMOTE LOCK Selection Mode BACK ENTER -
Start this unit in the PANEL/REMOTE LOCK selection mode so that
PANEL LOCK and Remote Lock can be selected as ON or OFF.
(See 23 page)
5Check the Video/Audio pass
Mode
ZONE
SELECT BACK -
This is a special mode for service conrmation used during repair
work to simplify the conrmation work for the Audio channel/vid-
eo channel. (See 25 page)
6Protection History Display Mode ↑ ↑ - Displays the protection occurrence history.
(See 68 page)
7232C Standby Clear Mode : ↑ ↑ - Switches from 232C standby mode to normal standby mode.
(See 68 page)
8Operation Info Mode ↑ ↑ -
Displays the total operating time of the set, number of times the
power was switched on, and number of occurrences of each pro-
tection.(See 69 page)
9TUNER STEP mode
(U and N model only) ↑ ↑ - Enables reception STEP of the ANALOG TUNER to be changed. (See 70 page)
10 Installer Setup Mode CURSOR
0BACK -
Access the Remote Maintenance mode via the internet. Installer
Setup is displayed on Setup menu / Network.
b Refer to AVR_RemoteMaintenance_.pdf of SDI.
11 Protection Pass Mode
(No Protection Mode this unit) M-DAX DYNAMIC EQ
DYNAMIC
VOL
Enables the power to be turned on when protection detection is in
the stopped state.
12 CX870 / CY920 Initialization mode BACK ENTER -
Enter this mode only after replacing Flash for CX870 / CY920 and
rewriting the rmware.
(See 71 page)
13 CX870 / CY920 Reboot mode M-DAX DYNAMIC
EQ - Reboot the CX870 / CY920(See 71 page)
14 USB Update Mode HDMI OUT STATUS Switches this unit to USB Update mode.
(See 75 page)
15 Forced USB All Device Write Mode HDMI OUT STATUS -
Mode used when this unit cannot be recovered.
Forcibly switches this unit to USB update mode.
(See 77 page)

When the volume indicator displays " ", the set has entered a special mode for developers.
In this case, RS-232C communication cannot be used.
To cancel this special mode, press and hold the "CURSOR f"and "STATUS" buttons for 3 seconds and longer. When the volume indica-
tor returns to the normal display, RS-232C communication can be used.
X
0
BACK ENTER
DYNAMIC
VOL
DYNAMIC
EQ M-DAX
DIMMER
STATUSZONE
SELECT
GAME
MUSIC
MOVIE HDMI OUT
A-DSX
18

1. Version Display Mode
1.1. Actions
Version information is displayed when the device is started in this mode.
1.2. Starting up
Hold down buttons "DIMMER" and "STATUS" at the same time and press the power button to turn on the power.
Press the "STATUS" button after this to show the information in section 1.3 on the display.
b A version list is also displayed on GUIs while the version appears on the display.
1.3. Display Order
Error information(See "") → q Model destination information, Serial Number
→ w Firmware Package Version → e Main µ-com, Main 1st Boot Loader Version
→ r Sub µ-com, Sub 1st Boot Loader Version → t DSP1/2/3/4 ROM → y Audio, Video PLD → u GUI SFLASH
→ i Ethernet 1st Boot Loader, Hardware ID → o Ethernet 2nd Boot Loader, Rhapsody Flag → Q0 Ethernet IMAGE
→ Q1 Ethernet MAC ADDRESS information → Q2 BT MAC ADDRESS information → Q3 MultEQ Pro APP (Displayed when Au-
dyssey Pro is complete) → Q4 HD Radio (For U Region) → Q5 MultEQ Pro ICL (Displayed when Audyssey Pro is complete)
q Model destination information, Serial Number :
  A V 7 7 0 2 U * Case of CX870 : Display "*" at the end
  A V 7 7 0 2 N * Case of CX870 : Display "*" at the end
  S/N. **********
w Firmware Package Version :
  Firm. Package
 Ver.:****
e Main µ-com, Main 1st Boot Loader Version :
  Main :**.***Case of CX870 : Display "*" at the end
 Main FBL :**.**
r Sub µ-com, Sub 1st Boot Loader Version : Model code
  Sub :XXYZ****
 S u b F B L : * * . * *
X ： Model code Y ： Model Z ： Region(E3=1, E2=2, E1C=5)
t DSP 1/2 ROM :
  DSP1 :**.**
 DSP2 :**.**
DSP 3/4 ROM :
  DSP3 :**.**
 DSP4 :**.**
y Audio, Video PLD :
  Audio PLD:**.**
 Video PLD:**.**
19

u GUI SFLASH :
  GUI :XXYZ****

X ： Model code Y ： Model Z ： Region(E3=1, E2=2, E1C=5)
i Ethernet 1st Boot Loader, Hardware ID :
  Ethernet FBL
 ******-AA
AA:Hardware ID
o Ethernet 2nd Boot Loader, Rhapsody Flag :
  Ethernet SBL
 *************-BB
Q0 Ethernet IMAGE :
  Ethernet IMG
 *************
Q1 Ethernet MAC ADDRESS information :
  * N E T M A C A d d r e s s
 *******-*****
Q2 BT MAC ADDRESS information :
  *BT MAC ADDRESS
 ******-*****S
Q3 MultEQ Pro APP :
  * M u l t E Q P r o A P P
 **.**.**.****
Q4 HD Radio (For U Region) :
  *HD :********-
 XYYYY.ZZZ
*Software Congration
XRelease Typte
YBase Version No.
ZBuild No.
Q5 MultEQ Pro ICL :
  * M u l t E Q P r o I C L
 **.**.**.****
20
