OWNER’S MANUAL
ELECTRIC COUNTER TILTING ROUND SKILLET
R-1600E
An Employee Owned Company
35 Garvey Street ●Everett ●MA ●02149-4403 Form No. S-6000 ●03/07
Tel: [phone] ●Fax: [phone] (MA)
Toll Free: [phone] ●Outside MA Fax: [phone]
Customer Service: custserv@mi.com ●Visit Us At: www.mi.com

TABLE OF CONTENTS
1
INSTALLATION
INSTALLATION ........................................................1
SERVICE CONNECTIONS ......................................2
DIMENSIONS & SERVICE CONNECTIONS ..........2
OPERATION
OPERATING INSTRUCTIONS ................................3
THERMOSTAT SETTINGS ......................................3
MAINTENANCE
PERIODIC CLEANING ............................................3
ADJUSTMENTS ......................................................3
ILLUSTRATED PARTS LIST
ELECTRIC SKILLET EXPLODED VIEW .................4
ELECTRIC SKILLET PARTS LIST ..........................5
INSTALLATION
INSTALLATION:
Position unit on counter allowing sufcient rear clear-
ance from wall to tilt freely and completely without
obstruction.
Mark four corner locations of unit base, as shown in
gure 1.
Remove unit from counter and locate position of four
holes as per gure 1.
Apply a continuous bead of silastic or other equiva-
lent sealant along the complete perimeter edge of the
unit base.
Use 5/16-18 hex cap screws with suitable at wash-
ers to bolt down. Screw length must be 1 1/4” long
plus counter top thickness.
Wipe off excess sealant.
A control box with power supply equivalent to electri-
cal rating of appliance should be located conveniently
1.
2.
3.
4.
5.
6.
7.
nearby.
A waterproof electrical connection for power supply to
console housing must be provided.
Ground unit to terminal provided inside console hous-
ing.
Turn power on and check for proper operation.
Figure 1
8.
9.
10.

INSTALLATION
2
521mm
20.5"
267mm
175mm
324mm
908mm
33.75"
22.88"
12.88"
581mm
533mm
21"
26"
660mm ID
E
43.25"
1426mm
56.13"
737mm
29"
371mm
14.625"
162mm
6.38"
12.75"
29.25"
D
743mm
E
6.88"
98mm
3.88"
D
406mm
PATH
POUR
222mm
8.75"
1099mm
10.5"
327mm
143mm
5.62"
D
16"
0.75" 19mm
MIN. CLEARANCE
24"
610mm
(Optional Stand)
(Optional Stand)
OPTIONAL
STAND
SERVICE CONNECTIONS:
Electrically Operated:
E Electrical Characteristics
208V 220V 240V 380V 415V 480V Phase
kW AMP kW AMP kW AMP kW AMP kW AMP kW AMP
7.5
7.5
36.0
20.8
7.5
7.5
34.1
19.7
7.5
7.5
31.3
18.1
--
7.5
--
11.4
--
7.5
--
10.4
--
7.5
--
9.0
1
3
D Drain - 11/4” O.D. tubing from tray pan.

OPERATION
3
OPERATING INSTRUCTIONS:
Insure that the unit has been electrically con-
nected and that circuit breakers are on.
Place power switch to on position.
Set the thermostat dial to high (#10).
Preheat the unit and allow it to cycle thus equal-
izing that across the entire surface.
Cooking should be done at various temperature
settings on the dial as determined by the user.
Water will boil faster with the use of the optional
cover.
At end of cooking cycle return thermostat to off,
turn power switch off and remove food. Put a
small amount of water in the pan and allow to
soak for ease of cleaning.
•
•
•
•
•
•
•
THERMOSTAT SETTINGS:
Simmering 1-4 200oF
Sautéing 5-6 225-27oF
Searing 7-8 300-350oF
Pan Frying 8-9 325-375oF
Grilling 9-10 350-425oF
CAUTION:
When tilting pan to remove contents take care
not to tilt too far too fast as contents are hot and
may splash on the operator causing injury.
MAINTENANCE
PERIODIC CLEANING:
NOTICE:
Contact the factory, a factory representative or
local service company to perform maintenance
and repairs
As a safety precaution, disconnect the power
during cleaning and servicing.
CAUTION:
Do not use cleaning agents that are corrosive.
The gas red round tilting skillet should be cleaned
after each use.
Keep exposed cleanable areas of unit clean at
all times.
Thoroughly wash pan and lid. if necessary soak
1.
2.
pan to remove product that is stuck to pan sur-
face. Use mild detergent and clear warm water.
Clean around burner air mixer and orice it lint
has accumulated. Bottom cover must be re-
moved to clean this area.
Rinse entire unit and dry. Do not get water in
electrical box or any other electrical component.
ADJUSTMENTS:
WARNING:
At least twice a year, have an authorized service
person clean and adjust the unit for maximum
performance.
All units are adjusted at the factory. In case os prob-
lems in operation at initial installation, check type of
gas and manifold pressure and compare it with infor-
mation on rating plate.
3.
4.

ILLUSTRATED PARTS LIST
4

ILLUSTRATED PARTS LIST
5
ITEM
PART
NO. DESCRIPTION QTY.
1 97-5995 COVER ASSEMBLY 1
2 97-5996 PAN ASSEMBLY 1
3 97-5337 KNOB, RED 1
4 97-5778 HANDLE 1
5 97-5116 ACORN NUT 1
6 97-5997 BEARING 2
** 7 97-5998 ELEMENT, 2.5 KW, 208V 3
97-5999 ELEMENT, 2.5 KW, 220V (380V) 3
97-6000 ELEMENT, 2.5 KW, 240V (415V) 3
97-6001 ELEMENT, 2.5 KW, 277V (480V) 3
8 97-6002 CAPILLARY CLAMP 1
9 97-6003 ELEMENT CLAMP 1
10 97-6004 INSULATION PAN 1
11 97-6005 BOTTOM COVER 1
12 97-6006 LEFT HAND CONSOLE COVER 1
13 97-6007 RIGHT HAND CONSOLE COVER 1
14 97-5642 HI-LIMIT THERMOSTAT 1
15 97-6008 POWER SWITCH 1
16 97-5419 PILOT LIGHT, AMBER 1
** 17 97-5786 DIAL, F 1
97-5787 DIAL, C 1
18 97-5012 BEZEL 1
19 97-5107 THERMOSTAT 1
20 97-6009 OPERATING DECAL 1
21 97-5846 COMPONENT MOUNTING PLATE 1
** 22 97-5609 CONTACTOR - 280, 220, 240V 1
97-5609 CONTACTOR - 220/380, 240/415, 480V 1
23 10-6962 TERMINAL BLOCK, END SECTION 1
24 10-6963 TERMINAL BLOCK, 208, 240, 480V 3
10-6963 TERMINAL BLOCK - 240/415, 220/380V 4
25 97-5052 GROUND LUG 1
** 26 * 97-5616 TRANSFORMER - 380/220, 480/240,V, 50/60 Hz, 100VA 1
97-5613 TRANSFORMET - 480/240V, 60 Hz, 100VA 1
** 27 * 97-6010 FUSE, 600V, 1 AMP - 380, 415, 480V UNITS 2
28 * 97-5359 FUSE HOLDER 2
* NOT SHOWN.
** SELECT AS REQUIRED.
