Marksman M11RF-LCD User manual

User’s Manual
Model: M11RF-LCD
Two-Way Communication LCD Transmitter
4/5/6
54
C
For Technical Assistance, please call [phone],
or visit www.magnadyne.com
M11RF-LCD-UM 9/10/04 9:48 AM Page 1

The remote control is powered by a 1.5V type AAA Alkaline battery. When the power of the battery
weakens the battery icon will be displayed on the LCD screen. When the old battery is replaced
with a new one, there will be a beep to indicate the power is up and the clock on the LCD screen
returns to AM12:00 after displaying all the icons. Correct the time by pressing SET for 3 seconds
before using. Note: Even if the battery is replaced, your programmed set values shall remain
unchanged. The remote control automatically reads and memorizes all the previous set information
saved in the main control module.
2
Congratulations on your purchase of a quality Marksman automotive security and remote start
system. Marksman security products have been designed to provide the consumer with a
technologically superior product with years of trouble free operation. The information enclosed will
provide a ready reference of the operation and maintenance of your new Marksman security and
remote start system.
Remote Control Transmitters
Door
Unlock/Disarm
Silent
Arm/Disarm
Door
Lock/Arm
Battery Replacement
Engine
Start/Stop
System’s
Status Check
The LCD screen on the remote control displays graphic icons. It provides
you visual information on any trigger of the sensors and around the clock
surveillance to your vehicle as well as showing the present status of the
system.
4/5/6
54
C
Warning:
Press the button two times when the
battery compartment is empty,
then insert the new battery.
SET
Bi 6
M11RF-LCD-UM 9/10/04 9:48 AM Page 2

3
Remote Control Transmitters Operation
Transmitter Button System Function Remark
Lock Doors & Arm System
Panic Function Press and Hold
for 3 Seconds
Car Locator Under Armed Mode
Arm and Delete the 2 Stage
Shock Sensor
Press Twice within
3 Seconds
Silent Arming/Disarming Ignition in “OFF” Position
Active Anti-Car Jacking Mode Ignition in “ON” Position,
Press and Hold for 2 Seconds
Channel #4 Timer Output (4)
Channel #5 Timer Output (5)
Channel #6 Timer Output (6)
Unlock Doors & Disarm System
Two Steps Door Unlock and
Disarm System Press Twice within 3 Seconds
Trunk Release
Channel 3 Press and Hold for 2 Seconds
Passive Arming
Bypass
While the System
is in “Disarmed” Mode
Arm System and
Hidden Alarm Function Press within 3 Seconds
Activate or Turn Off
the Remote Start Press Twice within 3 Seconds
-
+
+
+
+
-
-
+
( )
-
-
M11RF-LCD-UM 9/10/04 9:48 AM Page 3

4
LCD Display Transmitter Operations
Transmitter Button System Function Remark
SET (C) Systems Trigger Record Check Press within
3 Seconds
SET SET (C) System’s Status Check Press within
3 Seconds
SET Button Lock Press within 3 Seconds and Hold
“Lock” Button for 2 seconds
SET Optional Driving Pager Press within
3 Seconds
SET Monitor Interior Temperature Press within
3 Seconds
SET Daily Timer Start Press within
3 Seconds
SET LCD Screen Lamp
Turns ON for 5 Seconds Press and Hold for 1 Second
SET-SET-SET Clear the Flash Icon and Melody
Sound on the LCD Screen Transmitter
Button Lock:
Button Lock is useful if you want to disable the transmission function of the remote control
temporarily to prevent from any inadvertent pressing of buttons by others.
The regular remote control transmitter:
Press the button first, within 3 seconds press and hold the button for 2
seconds to activate or cancel the button lock function. The “LED” will pause flash for a few
seconds to indicate the remote control transmitter is on “Button Lock” mode while pressing
the transmitter button.
The 2-Way remote control transmitter:
Press the SET button first, within 3 seconds press and hold the button for 2
seconds to activate or cancel the button lock function.
Note: The icon will display on the LCD screen to show the remote transmitter is in “Button
Lock” mode.
Chirp Indicators
-
--
-
-
-
-
=
=
=
=
Chirp Function
1 Chirp System is Armed
2 Chirps System is Disarmed
3 Chirps Defective Reminder
4 Chirps Disarm / Triggered
5 Chirps Car Locator
M11RF-LCD-UM 9/10/04 9:48 AM Page 4

5
LED Display
Parking Light
System Characteristics
Siren/Horn Parking Light LED Doors Starter Dome Light
1. Arming 1 or 3 Chirps 1 Flash Slow Flash Locking Disabled
2. Disarming 2 or 4 Chirps 2 or 3 Flashes Unlocking Turns on for
30 Seconds
3. Trigger Alarming Flashes Slow Flash Disabled Flashes
4. Passive
Starter
Disable
Fast Flash Disabled
5. Panic Alarming Flashes Flashes
6.Car
Jacking Alarming Flashes Disabled Flashes
7.Car
Locator 6 Chirps 12 Flashes Locking
LED Function
OFF System is Disarmed
Slow Flashing System is Armed
Flash System in Passive Starter Disable
Fast Flashing System in Passive Arming
On Solid System in Valet Mode
Zone 1, Warn Away Trigger
2 Flashes - Pause Zone 2, Trigger on Trunk/Hook
3 Flashes - Pause Zone 3, Trigger on Door Switch
4 Flashes - Pause Zone 4, Trigger on Shock Sensor
5 Flashes - Pause Zone 5, Trigger on Ignition Switch
Flash Function
1 Flash System is Armed
2 Flashes System is Disarmed
3 Flashes Disarmed / Triggered
12 Flashes Car Locator
Constant On Under Remote Start
M11RF-LCD-UM 9/10/04 9:48 AM Page 5

6
Active Arming: Lock & Arm
1. Press the button on the transmitter.
2. The siren will chirp once and parking lights will flash once indicating that the system is now
armed. The vehicle door will lock upon arming when interfaced with the security system.
Clear the Flash Icon:
Press the SET button 3 times
within 3 seconds to clear the
flash icon on the LCD screen
transmitter.
Defective Sensor Reminder:
If the siren sounds 3 times, there is a Door, Trunk, or Hood left open. (See Alarm Feature I-4)
Silent Arming/Disarming:
Press the transmitter or button at the same time will arm or disarm your security system,
No chirp sound will be heard, arm/disarm confirmation will be through the vehicles
parking lights only.
Shock Sensor Bypass:
Press the button on the transmitter two times within 3 seconds. This will arm the security
system and bypass the shock sensor. The system will chirp one additional time to confirm the
sensor bypass mode was activated. The sensor bypass feature is programmed to activate for one
arming cycle only. The security system will return to normal operation during the
next arming cycle.
Passive Arming:
Active arming/disarming is controlling your security system via the remote transmitter. This
security system is equipped with an optional passive arming feature which allows the security
system to arm 30 seconds after the last door is closed. Operation is as follows:
1. Turn the ignition to the “OFF” position and exit the vehicle.
2. After all entrances are closed, the security system LED will flash fast for 30 seconds. If you
reopen any Door, Hood, Trunk, the security system LED will stop flashing. It will begin flashing
again once the vehicles entrances are closed.
3. After the 30-second timer has elapsed, the security system will automatically “ARM”. The
siren/horn will chirp once and the parking lights will flash once also.
Passive Arming with Passive Door Locking (See Alarm Feature 1-2 Programming)
The vehicle doors will automatically lock after passive arming cycle has been completed.
Passive Arming Bypass
While the system is in disarmed mode, press the button twice. The horn/siren will respond
with one chirp and the LED will turn “ON”. The security system will remain in this mode for as
long as you wish. To exit this mode press the or buttons and the system will return to normal
status.
System Armed Door Ajar Trunk/Hood Ajar
M11RF-LCD-UM 9/10/04 9:48 AM Page 6

7
Active Disarming Unlock & Disarm
1. Press the button on the transmitter.
2. The siren will chirp twice and parking lights will flash twice indicating that the system is now
disarmed. The vehicle door will unlock and the dome light will turn on for 30 seconds upon
disarming when interfaced with the security system.
Shock Sensor Triggered Ignition Triggered
Clear the Flash Icon:
Press the “SET” button 3 times within 3 seconds
will clear the flash icon on the LCD screen
transmitter.
Tamper Disarming:
If the security system is triggered, upon disarm, the siren will chirp 4 times and parking lights will
flash 3 times.
Pathway Illumination:
This feature turns the parking lights “ON” for 30 seconds upon a unlock signal and for 10 seconds
upon the lock signal.
Two Steps Door Unlock:
This feature will independently unlock the drivers door only when disarming the security
system. Pushing the button a second time within 3 seconds will unlock the other doors.
Automatic Rearm:
If this feature is selected, the security system will automatically rearm itself within 60 seconds
after disarming with the remote transmitter. Automatic re-arm will cancel if any door is opened
before the 60 second timer is up.
Disarming without a Transmitter:
The override function may be used if the remote transmitter is lost or inoperative.
1. Enter the vehicle and turn the ignition switch to “ON” position (alarm will sound).
2. Within 10 seconds push and release the valet switch, the alarm will stop sounding and enter
the disarm mode. You can now start and operate the vehicle normally.
System Disarmed Doors Triggered Trunk/Hood Triggered
M11RF-LCD-UM 9/10/04 9:48 AM Page 7

The valet switch allows you to temporarily bypass all alarm functions eliminating the need to hand
your transmitter to parking attendants or garage mechanics. When the system is in valet mode, all
alarm functions and remote start functions are bypassed, however the remote panic feature and
remote door locks will remain operational. To use the valet mode, the system must first be
disarmed either by using your remote transmitter, or by operating the manual override sequence.
Valet Mode (System in Disarm or Valet Mode)
Enter the Valet Mode:
1. In the disarmed mode, turn the ignition to “ON”
position.
2. Push and hold the valet switch for 2 seconds
until the LED turns on solid. The LED will
remain on solid while the unit is in the valet
mode.
Exit the Valet Mode:
1. To return to normal operation, turn “ON” ignition.
2. Push and hold valet switch for 2 seconds. The LED will turn off to indicate the system is now
out of the valet mode.
Remote Door Lock Remote Door Unlock
While in the armed mode, press the button to activate car locator function. The siren/horn will
chirp six (6) times. The parking lights will flash 12 times to help you locate your car.
Car Locator
The transmitter can be used as a remote panic switch to manually trigger the alarm system in case
of an emergency.
1. Press and hold the button for 3 seconds. The security system will begin to sound and
the parking lights will begin to flash.
2. During panic mode, the normal functions of this transmitter becomes temporarily inoperable.
The transmitter and buttons can be used to lock and unlock the door
(if the option is installed), however, once the button is pressed, the vehicle’s starter
disable device, (where installed) will be enabled allowing the vehicle to start.
3. To stop the alarm, press and hold the transmitter or buttons on the
transmitter again for 3 seconds. Also, if any transmitter button other than or is pressed and
release, the panic mode will be turned off immediately.
4. If the button is not pressed, the alarm will automatically stop after 30 seconds.
Panic Function
When armed, your vehicle is protected as follows:
1. Light impact will trigger the warn-away signal.
2. Heavy Impacts/Doors Open/Hood Open/Trunk Open/Ignition Key Activated will trigger the
programmed sequence. The starter disable relay (if installed) prevents the vehicle’s starter from
cranking. The siren, horn, parking lights and dome light will turn on to alert of an intrusion for
60 seconds. If one of the sensors or detectors are still active, the security system will sound a
maximum of 6 times for 30 seconds.
Trigger the System
8
M11RF-LCD-UM 9/10/04 9:48 AM Page 8

Trigger the System (Continued)
Ignition Trigger (Clear the Flash Icon and Melody Sound):
When the Security System is triggered, the LCD screen will alert the user through melody sound
and flashing icons. By pressing the “SET” button 3 times within 3 seconds it will clear the flashing
icons and stop the melody sound.
Stop the Melody Sound:
When the Security System is triggered, it will alert the user with flashing icons on the LCD Display
and audible melody sound. To stop the melody sound, press any button on the LCD transmitter.
Noise Abatement:
This security system has a “Noise Abatement Circuit”. This circuit prevents annoying, repetitive
false alarms by filtering out environmental conditions.
If the security system is triggered five times or more, the circuit will interpret this as a false alarm.
After the fifth trigger, the noise abatement circuit ignores, or bypasses that switch or sensor until
the next switch or sensor is activated.
Noise Abatement Circuit covers doors, hood and trunk switches differently. If the security system
is triggered by one of these switches for three cycles, the switch will be bypassed until the trigger
ceases.
Anti-Car Jacking
Warning: This security system has a car jacking feature. Its default setting is “OFF”. So, be sure to
enable this feature if you feel it is needed.
Active Anti-Car Jacking
1. Press and hold the transmitter and buttons at the same time for 2 seconds while the
vehicle’s ignition is “ON” and all doors are closed. The parking lights will turn on for 1.5
seconds to indicate this feature.
2. Once the system is armed, and you are forced from your vehicle, the system will trigger when
the door is opened and closed while the ignition is “ON”.
Passive Anti-Car Jacking
1. Turn the ignition switch to the “ON” position, the system will arm.
2. Once the system is armed, if you are forced from your vehicle, the system will trigger when the
door is opened and closed while the ignition is “ON”.
9
Doors Triggered Trunk/Hood
Triggered
Warn Away
Trigger
Shock Sensor
Trigger
Ignition
Trigger
M11RF-LCD-UM 9/10/04 9:48 AM Page 9

Anti-Car Jacking (Continued)
Trigger the Anti-Car Jacking Mode
Three Timer circuits will function as follows:
First Timer Circuit
1. 50 seconds after the car jacking mode has been activated, the siren will begin to sound for 15
seconds.
2. During the 15 second activation period, you will be alerted to push the valet switch once to
turn off the car jacking feature.
3. If by now the valet switch has not been pushed, it will enter the second timer circuit.
Second Timer Circuit
65 seconds after the system has been triggered, the siren starts sounding and the parking lights
start flashing.
Third Timer Circuit
90 seconds after the security system has been triggered:
1. The vehicles siren is still sounding, parking light are flashing
2. The starter disable mode will activate to prevent the vehicle from starting
3. It will remain active until the vehicles battery power is exhausted
Override the System to Turn Off Anti-Car Jacking
Turn the ignition switch from OFF to ON and within 10 seconds, push the valet switch. The siren
will stop sounding and the security system is now disarmed.
Systems Trigger Check
Press the transmitter “SET” button first, within three seconds press the
(C) button. The transmitter will respond with one melody sound and all
trigger’s records will immediately displayed on the transmitter LCD screen.
System Status Check
When you want to check the security systems present status through the transmitter LCD, press the
transmitter “SET” button twice, within three seconds press the (C) button. The security system
responds with one melody sound and the LCD screen should be illuminated.
Driver Paging
It is useful in the event that someone wants to page the driver of the parked vehicle. (Optional)
Inside the Vehicle Paging
With the ignition switch in the "OFF" position, press the valet switch for 2 seconds to page the
driver. One chirp will sound from the vehicle and the LCD transmitter will begin to sound with a
melody. The icon will then appear on the LCD transmitter to confirm this function.
Outside the Vehicle Paging
To page the driver from outside of the vehicle, "Knock" on the windshield glass to activate the LCD
transmitter with a melody sound. The icon will then appear on the LCD screen (only when the
optional knock sensor, model # M10-Page, is installed).
10
M11RF-LCD-UM 9/10/04 9:48 AM Page 10

Dome Light Supervision
The Security System has a unique feature for using your vehicle’s dome light.
1. Upon disarming the vehicles security system, the interior dome light will remain on
for thirty seconds.
2. If the security system is triggered, the dome light will flash for the same duration
as the horn/siren.
Ignition Controlled Door Locks
If the vehicles door locks have been interfaced with the security system, the system will
automatically lock the vehicle’s doors when the ignition key is turned to the “ON” position and or
unlock the doors when ignition key is turned to the “OFF” position.
Channel 3: Trunk Release Output
Press and hold the button for two seconds to activate the trunk release
(Channel 3 output) and/or any other devices connected.
Channel 4: Timer Control Output
Press and hold the and button at the same time to activate the Channel 4 output.
Channel 4 is user programmable output. You may program the built in timer to send a ground
signal for any time duration from 1 second to 120 seconds.
Channel 5: Timer Control Output
Press and hold the and button at the same time to activate the Channel 5 output. Channel 5
is user programmable output. You may program the built in timer to send a ground signal for any
time duration from 1 second to 120 seconds.
Channel 6: Timer Control Output
Press and hold the and button at the same time to activate the Channel 6 output. Channel 6
is user programmable output. You may program the built in timer to send a ground signal for any
time duration from 1 second to 120 seconds.
Note: These timer outputs (4-6) may be used to turn on the Headlights, Power Windows or Power
Sunroofs (Factory Settings are Momentary Outputs). 11
System Status Check (Continued)
1. First press the SET button on the transmitter, within 3 seconds press the buttons to
activate outdoor driver paging function. The vehicle will then respond with chirps from the
horn/siren and a melody sound from the LCD transmitter. The icon will then appear on the
LCD transmitter screen.
2. When the windshield knock sensor is activated, the vehicle will then respond with chirps from
the horn/siren and a melody sound from the LCD transmitter. The icon will then appear on
the LCD transmitter screen.
3. A. Turn on the ignition switch or press the button to arm the system.
B. Press the button to disarm the system. This will then exit this function.
M11RF-LCD-UM 9/10/04 9:48 AM Page 11

Remote Start Operation
To Remote Start Your Vehicle by Using the Remote Transmitter:
1. Press the button twice on the remote transmitter.
2. The parking lights will turn “ON” to indicate the remote start is activated.
3. The engine will start in approximately 5 seconds.
4. Once the engine is running, the parking lights will turn back on to indicate climate controls are
activated to your pre-settings (While the vehicle is running, the “minute” digits will appear
flashing on the LCD screen of the transmitter. It will indicate the count down timer based on the
5, 10, 20 or 30 minute run time set up by your installation center).
5. The vehicle will run for 5 to 30 minute cycles and automatically shut down (When the unit
shuts off the count down timer will turn off and the transmitter will play a melody tune).
Note: The Remote Start unit will not start if any of these conditions exist:
1. The hood is opened.
2. The brake pedal is pressed.
3. Move the optional remote start enable toggle switch to “OFF” position (if installed).
4. The gear selector is in any gear other than “Park” or “Neutral”.
Safe Start (Child Safety Mode):
The factory default setting to remote start your vehicle is to press the button twice. If the child
safety mode has been activated, press the and the buttons at the same time to remote start
the vehicle.
To Operate the Vehicle While in the Remote Start Feature:
1. Insert the Ignition key, turn it to the “ON” position “NOT THE START POSITION”.
2. Press the brake pedal.
Note: If the Brake Pedal is pressed before the key is in the “ON” position, the engine will
automatically shut off.
Temporary Stop Feature:
This feature allows the vehicle to remain running after the key has been removed from the
ignition. This feature is useful for occasions when you wish to exit and lock the vehicle for short
periods of time. This will keep the engine running for climate controls to stay on.
1. Before turning the engine off with the ignition key, press the button once. The LED will flash
three times to indicate the feature is activated.
2. Turn the ignition key to the “OFF” position (the engine will stay running).
3. The engine will run until the pre-programmed time elapsed or shutdown input is received.
12
M11RF-LCD-UM 9/10/04 9:48 AM Page 12

Timer Start:
This unit can be programmed to start and run the engine every 3 hours, 2 hours or punctually at
the same time every morning. The engine will run for the programmed running time and then shut
down.
Important! Timer start should be used only in open areas. Never start, or most importantly leave a
vehicle running in an enclosed area.
3 or 2 Hour Timer Start with Temperature Control Off:
This feature is designed for an extreme cold climate usage. The system will auto start the
vehicle every three hours to prevent the engine from freezing and creating a hard-to-start
condition. A MAXIMUM OF SIX CYCLES CAN OCCUR.
3 or 2 Hour Timer Start with Temperature Control On:
The system can be programmed to automatically start the vehicle’s engine whenever the
temperature inside the vehicle reaches and/or drops below a pre-programmed temperature
level. There are three temperature levels to choose from. A MAXIMUM OF SIX CYCLES CAN
OCCUR.
Daily Timer Start:
Press the “SET” button first, within three seconds press the button. The parking lights will
flash six times and the siren/horn will sound six times. The vehicle is now programmed to start the
next day.
Exit the Timer Start:
Timer start can be stoped manually as follows:
1. Make sure the remote start system is not operating
2. Turn the ignition “ON”. The LED and parking light will flash four times. The horn/siren sounds
for four times. Or:
1. Press the button twice to remote start the vehicle. As soon as the vehicle is running and
parking light has turned ON or are flashing
2. Immediately press the button then press and hold the button for two seconds. The
parking light will flash four times. The siren/horn will sound four times. The vehicle is no
longer programmed to start automatically.
Remote Start Operation
Interior Temperature Check
The temperature sensor can monitor the vehicle’s interior temperature through the LCD transmitter.
1. Press the SET button, within 3 seconds press the buttons. The interior temperature will be
displayed on the LCD transmitter.
13
M11RF-LCD-UM 9/10/04 9:48 AM Page 13

Interference
4/5/6
54
C
SET
Bi 6
Note: The transmission range may
become shorter if the system is
interfered by a stronger radio
frequency from sources of high
voltage electric power or obstacles
like tall buildings. The transmitter
uses low output powered
frequency.
14
Turbo Timer Mode (Also See Installation Manual)
Turbo Timer Mode keeps the engine running after arriving at you destination for a programmable
time period of 1, 3 or 5 minutes. This allows the system’s time to conveniently cool down the turbo
after you have left the vehicle.
To Activate:
1. While the engine is running, set the emergency brake and place the transmission to "Park".
2. Before turning off the engine, press and release and buttons at the same time. The light
will flash to indicate the remote start has entered turbo charge mode.
3. Remove the “Ignition Key” from the key cylinder. The engine will keep running.
4. Exit and secure the vehicle. The Engine continues running until the pre-programmed time
elapsed.
Turn Off Remote Start
When the engine is running by remote start and you wish to stop the engine from remote start:
1. Press the button twice on the remote transmitter.
2. Move the optional remote start toggle switch to the “OFF” position (if installed).
3. Press the vehicle’s brake pedal, the engine will stop running and the parking lights turn off to
indicate the engine has stopped.
Shut Down Input for Remote Starter
If any of the following conditions exist while the system is operating, the engine will not start or will
shut down immediately:
1. The hood is opened.
2. The brake pedal is pressed.
3. Engine is over reeved (Tachometer Type Only).
4. The pre-programmed run time (5-10-20-30 minutes) has elapsed.
5. Press the button once on the remote transmitter while in remote start mode only.
6. Move the optional remote start enable toggle switch to “OFF” position (if installed).
7. The vehicle refused to start running after 3 unsuccessful attempts.
M11RF-LCD-UM 9/10/04 9:48 AM Page 14

Door Lock
Lock your Vehicles Doors
Door Unlock
Unlock your Vehicles Doors
Armed Mode
Security System is Armed
Valet Mode
Security System is Armed
Remote Transmission
Transmitting a Signal
In-Range Indicator
You are within Remote Range
Door Triggered
Doors are Opened
Trunk/Hood Triggered
Trunk/Hood are Open
Shock Sensor
Shock Sensor Triggered
Warn Away
(Zone 1) Shock Sensor Triggered
Ignition
Engine Starting by Remote
Engine Running
Your Vehicles Engine is Running
Timer Control Start
Automatic Engine Start (Timed)
Temperature Monitor
Monitors the Temperature Inside
Vehicle
Time Monitor
Displays Time
Alert Alarm
Alarm Timer
Count Down Monitor
Power Save Mode
Saves The Battery Power when
Transmitter is not in Use
Vibrate Mode
Vibrates when Security System is
triggered
Button Lock
Disables Transmission Function
Temporarily
Paging
A Page Signal is being Received from
your Vehicle
Low Battery
Replace the Battery with Alkaline AAA
size
Remote LCD Icons
15
M11RF-LCD-UM 9/10/04 9:48 AM Page 15

16
Screen Lamp On:
Press and hold the “SET” button one second, with the melody sound and the LCD screen lamp
will turn on for 5 seconds.
Power Save Mode:
While in the Power Save Mode, the LCD transmitter uses “0” current to save the battery power.
1. Press and hold the “SET” button for 5 seconds. One melody will sound from the transmitter
and the LCD will show “SAVE”. You are now in the “Power Save Mode”.
2. Under the Active Arming Mode and Disarm Mode. Turn the ignition switch to the “ON” position.
The LCD remote transmitter will automatically enter the “Power Save Mode”
Exit Power Save Mode:
Press any button on the LCD transmitter to exit the Power Save Mode.
Clear the Flash Icon and Melody Sound:
Press the SET button 3 times within 3 seconds and it will clear the flashing icon and melody
sound on the LCD transmitter.
Stop the Trigger Melody:
While triggering the alarm, the LCD screen will alert the user through melody sound and flashing
trigger icon. Press any button on the transmitter to stop melody sound only.
Button Lock:
Use this mode to disable the transmission function of the remote control temporarily to prevent
any inadvertent pressing of buttons.
1. Press the “SET” button first, within 3 seconds press and hold the button for 2 seconds to
activate or cancel the button lock function. The icon will be displayed on the LCD screen to
show button lock mode.
Programming the LCD Transmitter
Button Description Operation
SET LCD Screen Lamp Turns ON for Press and Hold for 1 Second
Five Seconds 1 Melody Sounds to Confirm
SET Timer Programming Mode Press and Hold for 3 Seconds
2-Melody Sounds to Confirm
SET Power Save Mode Press and Hold for 5 seconds
1 Melody Sounds to Confirm
SET (3X) Clear the Flash Icon and Melody Sound Press within 3 Seconds
on the LCD Screen
SET & LOCK Button Lock Enabled/Disabled Press within 3 Seconds
SET & UNLOCK Melody/Vibrate Mode Press within 3 Seconds
Program Count Down Timer Press within 3 Second Cycles
SET & (10 m, 20 m, 30 m, 1 hr, 1.5 hr, 2 hr) Leave the Buttons Starting Count
Down then Timer Icon Flashes
SET & Enable/Disable Beep Sound while Press for 2 Seconds
Pressing Button
Programming of the LCD Transmitter
M11RF-LCD-UM 9/10/04 9:48 AM Page 16

Vibration/Melody Mode: This mode is useful when you are in a noisy place and it is difficult to hear
the beep from the remote. The LCD transmitter will vibrate if your security system has been
activated.
Press the “SET” button first, within 3 seconds press the ( ) button for 2 seconds to select the
mode of vibrate/melody. The icon will be displayed on the LCD screen to show mode.
Set-Up Fixed Count Down Timer:
Press the “SET” button first, then within 3 seconds press and hold the button for 2 seconds.
The LCD screen will show the icon and timer (0:10). Press the button again to choose the
desired time.
Out of Range Indication:
1. If the Transmitter is within range, the icon will display on the LCD screen.
2. If you are out of range, the icon will disappear from LCD Screen and transmitter will beep 5
times.
Timer Setting
Programming the LCD Transmitter
17
Button Description Operation
Press and Hold SET
Button for 3 seconds
Time Setting (Hour)
Flash Digit for Adjusting for (-) and (+)
Press the SET
Button Once
Time Setting (Min.)
Flash Digit for Adjusting for (-) and (+)
Press the SET
Button Once
Alert Alarm Time Setting (Hour) Flash
Digit for Adjusting for (-) and (+)
Press the SET
Button Once
Alert Alarm Time Setting (Min.) Flash
Digit for Adjusting for (-) and (+)
Press the SET
Button Once Alert Alarm Setting ON/OFF for (-) and (+)
Press the SET
Button Once
Count Down Timer Setting (Hour) Flash
Digit for Adjusting
(Max 19 Hrs. 59 Min.)
for (-) and (+)
Press the SET
Button Once
Count Down Timer Setting (Min.) Flash
Digit for Adjusting for (-) and (+)
Press the SET
Button Once Count Down Timer Setting ON/OFF for (OFF) and (ON)
Press and Hold
button for 2 seconds
Daily Timer Start Timer Setting
Flash / Icon and hours for Adjusting for (-) and (+)
M11RF-LCD-UM 9/10/04 9:48 AM Page 17

18
Replacement Parts and Accessories
4/5/6
54
C
5-Button Transmitter for
M11a Security System. M11RF-LCD 139.95 ea.
4-Button Transmitter with
SAW Technology for M11RF 59.95 ea.
M11a Security System.
TRANSMITTERS DESCRIPTION MODEL # $ PRICE
BATTERIES
1.5 Volt AAA Alkaline Battery commonly
found in grocery stores, hardware stores,
etc.
CR2025 - 3 Volt Lithium Battery (2 pcs.)
Models:
Radio Shack: #23-161
Duracell: #DL2025
Eveready: #ECR2025
Panasonic: # CR2025
M11RF-LCD-UM 9/10/04 9:48 AM Page 18

Credit Card or Money Order Only
(Sorry No Cash, C.O.D. or personal checks accepted)
SHIP TO: (No P.O. Boxes)
LAST NAME FIRST NAME INITIAL
STREET ADDRESS
ADDITIONAL ADDRESS
ADDITIONAL ADDRESS
CITY STATE ZIP CODE
DAY TIME PHONE NUMBER
PART # DESCRIPTION QTY. PRICE EACH TOTAL
Sales Subtotal = ________ . ______
California Residents Add Sales Tax = ________ . ______
Shipping and Handling (See Chart) = ________ . ______
TOTAL = ________ . ______
On regular orders please allow 4-5 weeks for delivery.
Please give a shipping address where this order may be delivered between the hours of 9 am and 5 pm weekdays.
If UPS is unable to deliver, your order will be returned and additional shipping charges will be required.
CREDIT CARD INFORMATION
CREDIT CARD N0. EXPIRATION DATE
CARD HOLDER’S LAST NAME FIRST NAME INITIAL
STREET ADDRESS
CITY STATE ZIP CODE
Mail to: Magnadyne Corporation
ATTN: Consumer Parts Sales
P.O. Box 5365
Carson, CA 90749-5365
Shipping and Handling
Up to $20.00 $5.00
20.01 to 30.00 5.95
30.01 to 45.00 6.50
45.01 to 70.00 6.95
Over 70.01 7.95
VISA
MC
Call: [phone] Fax: [phone]
Parts and Accessories Order Form
19
M11RF-LCD-UM 9/10/04 9:48 AM Page 19

M11RF-LCD-UM 2-10-04 Rev. A
© Copyright 2004 Magnadyne Corporation
Limited Lifetime Warranty
Magnadyne Corporation or its authorized agents will, for the life of the vehicle and to the original
purchaser, repair, replace or refund the retail sales price of said product or any part thereof, at the
option of the Magnadyne Corporation or its authorized agents, if said product or part is found
defective in materials or workmanship, when properly connected and operating on the correct
power requirements designated for the specific product. This warranty and Magnadyne Corporation
or its authorized agents obligations, hereunder do not apply where the product was: damaged while
in the possession of the consumer, subjected to unreasonable or unintended use, not reasonably
maintained, utilized in commercial or industrial operation, or serviced by anyone other than
Magnadyne Corporation or its authorized agent, or where the warning seal on the product is broken
or the power plugs or wires are detached from the unit. Magnadyne Corporation or any of its
authorized agents do not assume any labor costs for the removal and reinstallation of any product
found to be defective, or the cost of transportation to Magnadyne Corporation or its authorized
agents. Such costs are the sole responsibility of the purchaser.
This warranty does not cover the cabinet, appearance items, normal wear and tear or accessories
used in connection with the product resulting from improper installation, alteration, accident,
misuse, abuse or acts of nature.
This Limited Life Time Warranty applies only to the receiver section of the security system. Neither
the siren, transmitters, wire harness or any accessory item added to or used with a Remote Mobile
security system are covered by this Limited Life Time Warranty. Sirens, transmitters, wire harness
or any accessory item are covered by our standard 12 month limited warranty.
Magnadyne Corporation or its authorized agents shall not be liable to anyone for consequential
or incidental damages or claims that may arise due to failure of product to operate properly
except those accorded by law. Magnadyne's or its authorized agents liability to the repair,
replacement of the product as stated above if all conditions of the warranty are met. No
expressed warranty or implied warranty is given except those set forth herein. Magnadyne does
not warrant or guarantee against break in damage or the theft of the vehicle in part or whole, or
against the loss or damage to the contents of any vehicle in which a security system is
installed. Magnadyne security systems are only a deterrent against possible theft.
This warranty extends only to the original purchaser of the product and for the vehicle in which it
was originally installed. This warranty is not transferable or assignable to any person or vehicle.
Defective merchandise should be returned to the original point of purchase or secondly to
Magnadyne Corporation, 1111 W. Victoria Street, Compton, CA 90220. A return authorization must
be obtained before sending, or merchandise may be refused.
M11RF-LCD-UM 9/10/04 9:48 AM Page 20
