MARLO MR M Series User manual

MR 150M–1050M
SINGLE –SYSTEM 4
MX-III CONTROLLER
COMMERCIAL WATER CONDITIONERS
INSTALLATION, OPERATION,
AND MAINTENANCE MANUAL
MODEL NO:
SERIAL NO:
DATE INSTALLED:
DEALER:
COMPLETE FOR FUTURE REFERENCE:
Marlo Incorporated
2227 South Street
P.O. Box 044170
Racine, WI 53404-7003
www.Marlo-Inc.com
A2170381 8-313 R3
FOR MODELS MANUFACTURED
FROM OCTOBER 2017

MR 150M–1050M SINGLE – MXIII CONTROLLER
2
IMPORTANT PLEASE READ:
• Warranty of this product extends to manufacturing defects.
• The information, specications and illustrations in this manual are based on the latest information available at the time of printing.
The manufacturer reserves the right to make changes at any time without notice.
• This product should be installed by a plumbing professional on potable water systems only.
• This product must be installed in compliance with all local and state and municipal plumbing and electrical codes. Permits may be required at
the time of installation.
• If operating pressure exceeds 100 psi a pressure reducing valve must be installed. If operating pressure drops below 30 psi a booster
pump must be installed.
• Do not install the unit where temperatures may drop below 32°F or rise above 100°F.
• A prelter should be used on installations in which free solids are present.
• A constant voltage of 120V/60Hz (unless otherwise specied) must be supplied to the controller to maintain proper function.
• Union or ange ttings are recommended at the control valve’s inlet, outlet, and drain connections
• If distance of drain line is over a 10 ft. vertical or 25 ft. horizontal run, increase drain line one pipe size over that provided on the control valve.
• Do not make a direct connection to the drain. Provide an air gap of at least four times the diameter of the pipe to conform to sanitation codes
and to permit observation of the ow.
PLEASE CIRCLE AND/OR FILL IN THE APPROPRIATE DATA FOR FUTURE REFERENCE:
Softener Model: MR _____________
System Size: Single/Twin/Triple/Quad
Meter Size: ________________
Conguration: Timeclock/Twin Alt/Parallel/Progressive
Unit Capacity: ________________ Grains
Feed Water Hardness: ________________ Grains
Treated Water: ________________ Gallons/Liters
BW/Regen Time ________________ AM/PM or OFF
Additional Notes: _______________________________________________________________________________
_____________________________________________________________________________________________
_____________________________________________________________________________________________
_____________________________________________________________________________________________
_____________________________________________________________________________________________
_____________________________________________________________________________________________

MR 150M–1050M SINGLE – MXIII CONTROLLER
3
TABLE OF CONTENTS
SYSTEM INFORMATION
Product Warranty...........................................................................................................................................................1
General Arrangement Drawings ...................................................................................................................................2
Dimension Width ...........................................................................................................................................................3
Specication Table ........................................................................................................................................................4
Wiring Diagram..............................................................................................................................................................5
Tubing Diagrams ...........................................................................................................................................................6
INSTALLATION
General Installation........................................................................................................................................................9
Piping Installation ..........................................................................................................................................................9
Resin & Gravel Loading ..............................................................................................................................................10
Brine Tank Installation ................................................................................................................................................ 11
OPERATION
Start-Up Instructions ...................................................................................................................................................12
Volume Remaining/Batch Calculation .........................................................................................................................13
General Softener Operation ........................................................................................................................................14
Flow Diagrams.............................................................................................................................................................15
Brine Maker Operation ................................................................................................................................................16
Features of the MX III Controller .................................................................................................................................17
User Mode Programming Flow Chart..........................................................................................................................18
Network Communication Cables and Connections .....................................................................................................22
Controller Display Screen Examples...........................................................................................................................23
Programming Parameters ...........................................................................................................................................24
Master Mode Programming Flow Chart.......................................................................................................................25
Diagnostic Mode Programming Flow Chart.................................................................................................................35
MAINTENANCE
MX III Replacement Parts............................................................................................................................................38
Replacement Valves....................................................................................................................................................39
Aquamatic Valve Repair Kits .......................................................................................................................................40
2536 Flow Sensor........................................................................................................................................................41
Brine Tank Assemblies ...............................................................................................................................................42
Error Codes ................................................................................................................................................................44
Troubleshooting...........................................................................................................................................................45

MR 150M–1050M SINGLE – MXIII CONTROLLER
1
COMMERCIAL AND INDUSTRIAL PRODUCT WARRANTY
Marlo Incorporated warrants all water treatment products manufactured and/or distributed by it to be free from defects
in materials and workmanship for a period of one (1) year from installation or 18 months from the date of shipment
whichever comes rst. Fiberglass pressure vessels are warranted against defects in materials and workmanship for a
period of ve (5) years from the date of shipment.
If during that period any products shall be proven to the Marlo Incorporated’s satisfaction to be defective, those
products will be replaced FOB factory or the price refunded at the Marlo Incorporated’s option.
Marlo Incorporated’s obligations for non-performance, defects, or any damage caused by its products or their use,
and buyer’s exclusive remedy therefore, shall be limited to product replacement or refund and shall be conditioned
upon Marlo Incorporated’s receiving written notice together with a demand for such replacement or refund.
The foregoing warranty is exclusive and in lieu of all other expressed or implied warranty (except of title)
including but not limited to implied warranty of merchantability and tness for particular purpose.
Marlo Incorporated will not be subject to and disclaims the following:
1. Any other obligations or liabilities arising out of breach of contract or out of warranty.
2. Any obligations whatsoever arising from tort claims (including negligence and strict liability) or arising under other
theories of law with respect to products sold or services rendered by Marlo Incorporated or any undertakings, acts,
or omissions relating thereto.
3. All consequential, incidental, and contingent damages.
Labor charges, charge backs or handling charges are excluded from Marlo Incorporated’s warranty provisions.
COMMERCIAL AND INDUSTRIAL WATER SOFTENER GUARANTEE
Under normal operating conditions:
1. The softener e󰀪uent shall be zero soft as determined by a soap test.
2. The loss of softening resin through attrition during the rst three (3) years shall not exceed 3% per year.
3. The softening resin shall not be washed out of the system during backwash.
4. The color and turbidity of the softener e󰀪uent shall not be greater than the incoming water.

MR 150M–1050M SINGLE – MXIII CONTROLLER
SYSTEM INFORMATION
2
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
A A B B C C
D D
DATE
FRAC.
DRN.
APP'D.

DEC.

DRAWING NO.
SCALE FILE ID.
SHEET
REV.
OF
MR SINGLE WATER SOFTENER SYSTEM NXT
GENERAL ARRANGEMENT
MR SINGLE NXT
11
Anthony
5/25/2011
REVISIONS
NO. BY REMARKS
INCORPORATED
DATE
BRINE TANK
BT DIAMETER
MINERAL TANK
MT DIAMETER
INLET=_________ OUTLET=_______
PIPE SIZES
INJECTOR=_______
DRAIN=__________
H=_______
MT=_______
DIMENSION TABLE
BT=_______
MR-______________
W=_______ L=_______
H
L
W
INLET 30-100 PSIG
OUTLET
BY-PASS VALVE
(NORMALLY CLOSED)
INLET ISOLATION
VALVE
OUTLET ISOLATION
VALVE
BRINE INJECTOR RAW WATER INLET
30-100 PSIG
BACKWASH FLOW
CONTROLLER
DRAIN
STRAINER
OPTIONAL WATER
METER
NOTES: ALL PIPING, FITTINGS, ETC SHOWN WITH DASHED LINES
ARE PROVIDED BY OTHERS. GENERAL PLUMBING CONNECTIONS ARE SHOWN FOR
CLARITY ONLY. MINERAL TANKS SMALLER THAN 36" DIAMETER HAVE
HANDHOLES.
OVER FLOW
TO DRAIN
CONTROLLER

MR 150M–1050M SINGLE – MXIII CONTROLLER
SYSTEM INFORMATION
3
DIMENSION CHART
MODEL PIPE SIZE DIMENSION TABLE
INLET/OUTLET DRAIN INJECTOR HEIGHT WIDTH LENGTH
MR-150-1 1 1
2.0-050 6’-0”
2’-5”
7’-4”
MR-150-1-1/4 1-1/4 1 2’-6”
MR-150-1-1/2 1-1/2 1 2’-6”
MR-150-2 2 1 2’-10”
MR-210-1-1/4 1-1/4 1
3.5-075 6’-1”
2’-8”
8’-0”
MR-210-1-1/2 1-1/2 1 2’-8”
MR-210-2 2 1 3’-0”
MR-210-2-1/2 2-1/2 1 3’-1”
MR-300-1-1/2 1-1/2 1
5.0-075 6’-4”
3’-2”
9’-0”
MR-300-2 2 1 3’-6”
MR-300-2-1/2 2-1/2 1 3’-7”
MR-300-3 3 1 3’-8”
MR-450-1-1/2 1-1/2 1
5.0-075 6’-10”
3’-2”
9’-6”
MR-450-2 2 1 3’-6”
MR-450-2-1/2 2-1/2 1 3’-7”
MR-450-3 3 1 3’-8”
MR-600-1-1/2 1-1/2 1-1/2
7.0-100 7’-5”
3’-8”
11’-3”
MR-600-2 2 1-1/2 4’-0”
MR-600-2-1/2 2-1/2 1-1/2 4’-1”
MR-600-3 3 1-1/2 4’-2”
MR-750-2 2 1-1/2
7.0-100 8’-5”
4’-0”
11’-3”MR-750-2-1/2 2-1/2 1-1/2 4’-1”
MR-750-3 3 1-1/2 4’-2”
MR-900-2 2 2
10.0-100 7’-10”
4’-6”
12’-6”MR-900-2-1/2 2-1/2 2 4’-7”
MR-900-3 3 2 4’-8”
MR-1050-2 2 2
10.0-100 8’-10”
4’-6”
13’-2”MR-1050-2-1/2 2-1/2 2 4’-7”
MR-1050-3 3 2 4’-8”

MR 150M–1050M SINGLE – MXIII CONTROLLER
SYSTEM INFORMATION
4
SPECIFICATION CHART
SYSTEM SIZE
MODEL 150 210 300 450 600 750 900 1050
VALVE SIZE (IN)
1141221412222122223122223122223 2 223 2 223 2 223
MAX CAPACITY (KILOGRAINS) 150 210 300 450 600 750 900 1050
MIN CAPACITY (KILOGRAINS) 100 140 200 300 400 500 600 700
FLOWRATE (GPM)
SERVICE - CONTINUOUS (GPM)
32 42 45 57 41 64 80 115 68 92 140 165 63 82 120 140 72 110 140 175 90 140 160 105 150 188 95 135 173
SERVICE - PEAK (GPM)
55 78 69 97 57 86 110 160 92 125 190 230 90 115 170 190 94 125 190 250 116 190 230 133 218 279 124 210 259
BACKWASH & FAST FLUSH
(GPM) 10 15 20 20 30 30 45 45
BRINE DRAW & RINSE (GPM) 2.5 3.5 5 5 7 7 10 10
TIMER
SETTINGS
BACKWASH & FAST FLUSH (MIN) 10 10 10 10 10 10 10 10
BRINE DRAW & RINSE (MIN) 60 60 60 60 60 60 60 60
FAST FLUSH (MIN) 6 6 6 6 6 6 6 6
SOFTENER TANK
SIZE (IN) 20x54 24x54 30x54 30x60 36x60 36x72 42x60 42x72
GRAVEL (LBS) 100 200 300 300 400 400 600 600
RESIN (FT3)5 7 10 15 20 25 30 40
FREEBOARD (IN) 24 24 27 20 23 27 20 25
BRINE SYSTEMS
EQUIPMENT
TANK SIZE 24x50 24x50 24x60 30x60 39x60 39x60 42x60 50x60
MAX SALT STORAGE (LBS) 700 600 600 1000 1900 1700 1900 2300
INJECTOR CODE 2.0-050 3.5-075 5.0-075 5.0-075 7.0-100 7.0-100 10.0-100 10.0-100
INJECTOR COLOR RED WHT BLUE BLUE RED RED WHT WHT
SALT
SALT DOSAGE- MAX (LBS) 75 105 150 225 300 375 450 525
SALT DOSAGE- MIN (LBS) 30 42 60 90 120 150 180 210
BRINE VALVE FLOAT HEIGHT - MAX 12 19 26 26 19 26 26 19
BRINE VALVE FLOAT HEIGHT - MIN 3 8 9 9 8 9 9 8

MR 150M–1050M SINGLE – MXIII CONTROLLER
SYSTEM INFORMATION
5
WIRING DIAGRAM
MODEL 48 STAGER
WITH MARLO LOGO
MX III CONTROLLER WIRING
B1046050
MRP
VB
5/24/11
NTS 1 1
B1046050 5
1. 10/23/12 KCA SENSOR WIRES WERE WIRED TO
TERMINALS 7,8 & 9 RESPECTIVELY. ADDED AUX RELAY WIRING.
2 8/26/13 MRP ADDED SOLENOID TO DRAWING
3. 9/29/15 KCA VARIOUS UL CHANGES.
4. 11/3/17 JH VARIOUS UPDATES
1 2 3 4 5 6 7 8 9 10
Seqn Item Number Qty Description
1
2
3
4
TRANSFORMER 40VA 120V/24VAC (T40F3)
A2242066 1
POWER CORD
XFMR
GROUND
A2173315 A2155115 A2090040
1 1 1
CONTROL NXT STAGER 48 W/SOLENOID
WIRE JOINT INSULATED #18-#12
CORD POWER 18/3 8FT 10A (1FD82)
SW1
SW2
TERMINALS
BLACK
SHIELD
BLACK
CLEAR
RED
BLACK
RED RED
GREEN
RED
WHITE
BLACK
FLECK
SIGNET
CLACK
AUTOTROL
FLOW METER WIRING
BLK
RED
GRN
P-2
METER
CIRCUIT BOARD
(MOUNTED ON
INSIDE OF DOOR)
P-1
24VAC
RED
PURPLE
ORANGE
BLACK
WHT/BLK
YELLOW
RED
WHITE
BLK
RED
GRN
UPPER DRIVE
PURPLE
BLACK
ORANGE
BLACK
1
2
3
4
5 6 7 8 9
10
STAGER INTERNAL WIRING
(SEE ENCLOSURE ON RIGHT)
PROGRAM CAM
AUX CAM #1
STAGER MOTOR
24VAC 50/60Hz
4 WATT
N.O.
N.C.
N.O.
N.C.
C
C
BLUE
BLUE
STAGER
MOUNTED SCREW
GROUND
LUG
GROUND
SCREW
GREEN/YELLOW
GRN/YEL
SW2
SW1
(HOMING CAM)
(SWITCH HOUSING)
IS RED
(CYCLECAM)
SWITCHED HOT
NEUTRAL
BLACK BLACK
P4
AUX
LOCKOUT
REMOTE START
GND
OPTIONAL REMOTE
SIGNAL START
SWITCH (N.O.)
OPTIONAL INTERLOCK
SWITCH (N.O.) CLOSED CONTACT
PREVENTS REGENERATION
-INPUT SIDE PULLED UP TO 32 VDC
CLOSED CONTACT
INITIATES REGENERATION IF OPTION ENABLED
-INPUT SIDE PULLED UP TO 32 VDC
OPTIONAL MOTOR/PUMP ON DURING REGENERATION
OR CPO DEVICE ON DURING SERVICE (N.O. OUTPUT)
DRY CONTACT
24VAC/3A MAX. RESISTIVE
30VDC/3A MAX. RESISTIVE
LOWER
DRIVE
OPTIONAL SOLENOID VALVE ENERGIZED
DURING REGENERATION OR STANDBY
(P6 OUTPUT - 24VAC 50/60Hz, 1.0A MAX.)
CAN1 CAN2
P8
DEVICE T-9 T-10T-8
DC(-) DC(+)SIGNAL(S)
RED RED
5A2169003 4MOUNTING FEET
P6
S-1
3
3
TORQUE TO lbs-in
TERMINAL RATING
5.3
USE GAUGE
WIRE ONLY
10 - 22
WHT
RED
ORG
BLK
WHT
BLK
GRN
11
120V
LINE IN
12
240V
LINE IN
13
208V
LINE IN
14
NEUTRAL
IN
WHT
OPTIONAL
AUX CAM #2
N.O.
N.C.
C
SW3
BLACK RED
GREENPULSE
RED
RED
BLU
YEL
BRN
RED
PURP
PURP
RED
BROWN
REMARKSBYNO. DATE
REVISIONS
5. 12/21/17 KA ADDED/MODIFIED WIRE COLORS.

MR 150M–1050M SINGLE – MXIII CONTROLLER
SYSTEM INFORMATION
6
TUBING DIAGRAM - VALVE NEST - MULTITANK - ASCO SOLENOID

MR 150M–1050M SINGLE – MXIII CONTROLLER
SYSTEM INFORMATION
7
TUBING DIAGRAM - VALVE NEST - MULTITANK - PARKER SOLENOID
Note: All valves normally open except optional valve 2A.
1
3
2
Flow
Solenoid Energized
1
3
2
Flow
Solenoid De-energized
Energized To Close TheNXTStagercontrolcanoperateanoptional24VAC solenoidtocontrolwhenatankisoffline.Thissolenoidis electricallyconnectedtothe"lowerdrive"connectiononthe circuitboard,andcontrolpressureisrunthroughthesolenoid totheserviceoutletdiaphragmvalve. Thesolenoidinstalledatthefactoryisauniversaltype.Itis plumbedinanenergizetocloseconguration. WhenatankentersRegenerationorStandbythesolenoidis energized.Pressurefromsolenoidport1passestoport2.The diaphragmvalve#2willclose. WhenatankentersInServicethesolenoidisde-energized. Theinletpressuretosolenoidport2isstopped.The diaphragmvalveisventedthroughsolenoidport2toport3 (drain).Thevalve#2opens.

MR 150M–1050M SINGLE – MXIII CONTROLLER
INSTALLATION
8
INSTALLATION INSTRUCTIONS
GENERAL INFORMATION
Before beginning installation, thoroughly review the following instructions to familiarize yourself with the general place-
ment and identication of all components. These instructions are written for a single unit installation, but they also
generally apply to twin and triple units.
Refer to specic equipment layout drawing, water meter installation instruction, and interconnecting electrical wiring
diagram for your system.
Catalog softeners are shipped fully assembled with face piping and controllers. Care must be taken not to dam-
age valves or controllers during uncrating and installation. During unpacking the brine tank miscellaneous parts are
shipped inside the brine tank. These parts include hardness test kit, injectors, extra manuals and other parts that may
apply to your particular system. Care should be taken when unpacking the brine tank.
NOTES:
• Install the piping conforming to federal, provincial, and local codes.
• Union or anges are recommended at the control valve’s inlet, outlet, and drain connections
• To enhance the monitoring of the system’s performance sample valves and pressure gauges are be installed at
the inlet and outlet piping to each control valve.
• If distance of drain line is over a 10 ft. vertical, or 25 ft. horizontal run, increase drain line one pipe size over that
provided on the control valve.
• Do not make a direct connection to the drain. Provide an air gap of at least four times the diameter of the pipe to
conform to sanitation codes and to permit observation of the ow.
• It is not recommended that an overhead or a long horizontal drain run be used. The increased backpressure will
cause problems when drawing brine.
PIPING INSTALLATION:
1. Install piping as shown on the layout drawing. Include unions and shut-o󰀨 valves on the inlet and outlet of each
softener. Also, include a shut-o󰀨 valve for each injector provided with the system. It is recommended that a union
be installed in each softener drain-line to facilitate cleaning the backwash ow control.
2. Do not reduce drain-line pipe size. Do not install a shut o󰀨 valve in the drain-line. Provide an air gap in the drain
line in accordance with local codes (minimum four (4) pipe diameters).
3. If your system has a water meter thoroughly read the meter instructions manual located in the back of this manual
before installing any water meters or ow sensors,. Water meters typically must be installed in a particular manner
(i.e. horizontal, plane or with recommend pipe lengths) to function properly.
4. After the piping has been completed, make sure to close all isolation valves.

MR 150M–1050M SINGLE – MXIII CONTROLLER
INSTALLATION
9
INSTALLATION INSTRUCTIONS
SOFTENER LOADING
Do not begin loading until you have conrmed all of the
required media is on site. Locate your unit on the Speci-
cation Table for the correct amount of gravel and resin per
tank and separate quantities.
Before loading, visually check the lower distributor for ship-
ping damage. All radial arms and baskets strainers are in
place and pointing downward. Tighten any loose laterals.
Do not load tank if there is damage is evident. Call the fac-
tory if any damage is observed.
Care should be exercised in the loading of the gravel in
order to insure that the distributors are not damaged. The
equipment provided has a PVC lower distributor system.
GRAVEL LOADING - (Load First)
1. Slowly open the inlet valve and ll the tank half way or
as full as possible with water. There might be a ow of
water to drain.
2. Slowly and gently pour the gravel marked for the min-
eral tank into the unit.
3. Drain the tank down until the gravel and water levels
are the same.
4. Carefully level the gravel before loading the resin.
RESIN LOADING
1. Reopen the inlet valve and ll the tank to1/3 to 1/2 full of water.
2. Pour the quantity of resin marked for the tank in through the top opening.
3. Reopen the inlet valve and ll the tank with water to the top access opening.
4. Close and secure the top access opening.
5. Open inlet valve and continue to ll the tank with water until it is fully
pressurized.

MR 150M–1050M SINGLE – MXIII CONTROLLER
INSTALLATION
10
INSTALLATION INSTRUCTIONS
BRINE TANK INSTALLATION
1. The brine tank should be installed on a smooth level surface. If none is available, the tank should be placed on a
smooth piece of exterior plywood and leveled by placing shims underneath the plywood.
2. Make sure that the salt shelf inside the tank is level and that the brine well is near to vertical as possible. Check
the specications table and make sure that the oat setting is the proper height for the model provided. Brine
tanks are shipped with the oat set for maximum salting. If incorrect, slide the oat to the proper setting. Float
should be approximately one inch above grid plate.
3. Place brine valve into the brine well and set at the bottom of the brine tank. Note: If minimum brine draw is de-
sired, remove the pipe nipple and coupling from the brine assembly. Install remaining brine valve assembly into
elbow using Teon tape or Teon paste, and set oat to minimum salt level see Specication Table for settings.
Place brine valve into brine well. Brine valve assembly will not sit on bottom of brine tank.
4. Connect the brine valve to the brine injector. Open the manual injector feed water valve and allow the brine tank
to ll with water. To speed this process the tank can be lled with a garden hose to about 2” below the platform.
The tank will continue to ll until the oat rises and shuts of the ow (approximately 1” above the platform).
Note: In the process of making brine for the rst regeneration, the solution volume will increase (one gallon of wa-
ter will be 1.2 gallons of brine). The nal level of the liquid will be several inches above the platform.
5. If the rell water shuts o󰀨 below the platform or too far above the platform, the brine valve should be removed and
the oat adjusted up or down until is shuts o󰀨 approximately 1” above the platform. Place the brine well cap seal
in place and open the manual valve in the brine line to the softener tank.
TO INJECTOR
OVERFLOW
(PIPE TO DRAIN)
FLOAT
BRINE VALVE
LIQUID BRINE
DRY SALT
STORAGE
SALT SHELF
BRINE WELL
TO INJECTOR
TOP
EXTENSION
BRINE VALVE
FLOAT HEIGHT
FLOAT

MR 150M–1050M SINGLE – MXIII CONTROLLER
OPERATION
11
START-UP INSTRUCTIONS
Before proceeding to start-up:
• Make sure the unit is properly installed with all piping complete
• All of the required media has been properly loaded in the tank
• Read the controls section located in this manual
• Do not ll Brine Tank with salt
With all piping and installation completed, and with the mineral in the tank, proceed as follows:
1. Open the manual by-pass valve. The manual inlet and outlet valves are to remain closed.
2. Connect the power to the MX III controller. The controller display window will light up.
3. Verify the following and change if required.
SYSTEM 4 is displayed in the window for single systems
The K FACTOR is correct for your unit size - (metered units only)
4. Open the cover of the enclosure and manually rotate the stager to the #1 (BACKWASH) position. The stager mo-
tor will rotate back to the #4 (SERVICE) position. This is done to conrm the controller’s homing signal is opera-
tional.
5. Press and hold the EXTRA CYCLE button on the front of the controller. This will advance Unit 1 to the backwash
step. The Unit 1 stager should rotate to the step 1 (BACKWASH) position.
6. Slowly open the softener’s manual inlet supply valve. Do not open fully. Full ow of water could cause loss of me-
dia. Continue to ll slowly until all air is expelled and only water ows to the drain. Water will enter from the bottom
of the resin tank as air is expelled from the top drain. If the system is supplied with an air vent make sure that the
valve is open during this process.
7. When only water ows to the drain and out the air vent (if applicable), open the manual inlet valve all of the way.
Backwash until the water looks clean when caught in a container.
8. Advance Unit to the brine/slow rinse step by pressing and holding the EXTRA CYCLE button. The stager should
rotate to the STEP 2 (BRINE/SLOW RINSE) position. There will be a slow ow to the drain.
9. While the unit is in the Brine/Slow Rinse position, check the level in the brine tank. The level should be dropping
at a slow rate (approximately 2” per minute).
UNIT STAGER

MR 150M–1050M SINGLE – MXIII CONTROLLER
OPERATION
12
START-UP INSTRUCTIONS - (cont’d)
10. Advance Unit to the Fast Rinse position by pressing and holding the EXTRA CYCLE button. The stager should ro-
tate to the STEP 3 (FAST RINSE) position. There will be a high ow of water to the drain. Allow the water to ow
to the drain until clear. During this time, the brine tank will ll with water until the oat closes the brine tank valve.
Check that all brine ttings are tight and that the water level in the brine tank is according to the unit specica-
tions.
11. Advance Unit to the service position by pressing and holding the EXTRA CYCLE button. The stager should rotate
to STEP 4 (SERVICE) position. There will be no ow of water to the drain.
12. Fill the brine tank with the proper amount and type of salt recommended for use with the system.
See RECOMMENDED TYPES OF SALT.
13. Close the manual by-pass valve and open all outlet valves fully. The system is now in service.
VOLUME REAMINING/BATCH CALCULATION
HOW TO CALCULATE SOFTENER’S TREATED WATER CAPACITY
“Batch size” is the term used for the amount of water passing through and being softened by the water softener be-
tween regenerations. This is a simple calculation provided two pieces of information are known:
• Size of the water softener in grains (i.e. MR-600 has 600,000 grains capacity per tank).
• Hardness of the raw water being treated by the water softener.
SAMPLE CALCULATION
Example:
MR-600-2 – Total capacity available is 600,000 grains. Water hardness is 20 grains per gallon.
BATCH SIZE
Batch size = Grain capacity of softener divided by grains per gallon of hardness
BATCH SIZE EQUATION:
Capacity of Softener (grains)
Batch Size = Hardness of Water (grains per gallon)
Capacity of Softener = 600,000 grains
Water Hardness = 20 grains per gallon
Unit is a model MR -600 softener
The hardness of the water was measured to be 20 grains per gallon
Using our equation take 600,000 ÷ 20 = 30,000 gallons.
For immediate regeneration type meter control the meter setting would be at 30,000 gallons. Commonly this value is
adjusted to 90 percent of the actual value (in this example 27,000 gallons) to assure not over-running the softener.
10% Safety factor - reserve capacity = 3,00 gallons.
30,000 gallons – 3,000 gallons = 27,000 gallons (batch size/volume remaining)

MR 150M–1050M SINGLE – MXIII CONTROLLER
OPERATION
13
GENERAL SOFTENER OPERATION
Hard water passes through the valve manifold into the top of the softener tank. It ows downward through the mineral
bed and out through the bottom of the tank to service. As the water passes through the mineral bed, the hardness
present is removed through the process of ion exchange and at the same time sediment present is removed by
ltration action of the mineral. Once the mineral has extracted all the hardness it can, it must be regenerated and have
its capacity restored by the following procedure:
SERVICE
1. Service – Hard water enters the softener, is treated and exits the system.
REGENERATION
2. Backwash: The ow through the mineral bed is reversed and allowed to ow to drain. The up-ow action washes
any sediment or foreign material collected in the unit out to drain. At the same time the mineral itself is restratied,
thereby eliminating any possibility of channeling (approximately 10 minutes).
3. Brine Draw: The ow through the unit is returned to down-ow to drain at a slow controlled rate and during the rst
stage of this step the brine is injected to react with the mineral and restore its softening capacity (approximately
20 minutes).
4. Slow Rinse: The ow through the unit is a slow ow of water to rinse all of the exchanged hardness and salt from
the unit (approximately 40 minutes).
5. Fast Flush: The downward ow to drain in this step is increased to a high rate which will repack the mineral bed
and remove the last traces of salt and hardness from the regenerated equipment just before its return to service
(approximately 6 minutes)
HOW THE STAGER FUNCTIONS
The regeneration of the equipment provided is carried out through the redirection of ow through the valve manifold.
This manifold consists of individual diaphragm valves, which are controlled by the hydraulic stager mounted at the
bottom of the stager controller. The stager applies or relieves water pressure to close or open valves as required.
When water pressure is applied to the top of a diaphragm valve, it forces a diaphragm in causing it to close the seat
assembly. When pressure is relieved from the top of the valve, by venting it to drain through the stager, the water
pressure under the diaphragm forces it out thereby opening the seat assembly.
Note: If stager somehow gets out of sequence either:
• Rotate thumb wheel in direction of arrow.
• Be patient, unit will return to service position and be in sequence within 2 hours.

MR 150M–1050M SINGLE – MXIII CONTROLLER
OPERATION
14
FLOW DIAGRAM - WATER SOFTENERS

MR 150M–1050M SINGLE – MXIII CONTROLLER
OPERATION
15
BRINE MAKER OPERATION
The brine-maker is an automatic brining system, which is easily
adjusted to provide maximum operating e󰀩ciency of your water
softener. It is a combination salt storage and brine-measuring tank
complete with an automatic valve.
The brine-maker consists of:
1. An open brine tank with a platform dividing it into sections:
• The upper section is used for dry salt storage
• The lower section for brine storage.
2. An automatic brine valve which is housed in a closed tube or “well”.
After each regeneration, water ows from the brine valve and into the
brine tank. When the water level rises slightly above the platform, a
oat closes the automatic brine valve. Salt slowly dissolves to form
concentrated brine. As brine is formed, the liquid volume increases
and the level rises in the salt. The resulting level may be 2 to 10 inches
above the platform depending on the amount of salt for regeneration.
During regeneration, the brine injector creates suction, which opens
the brine valve and draws into the softener tank. When the brine level
falls below the brine valve, the valve seats and prevents air from
entering the system.
RECOMMENDED TYPES OF SALT
Only puried salt should be used in the brining system. Palletized salt (“Button”, “Nugget”, and “Pellet”) or block salt
(free binders) is recommended. Do not use granulated salt, as it will fall through the platform screen.
Rock salt is not normally recommended. Most rock salt contains sludge-forming insoluble that collect on the platform
and prevents proper salt-water contact.
Only salt containing 0.5% or less of insolubles will provide continued satisfactory operation. If, salt with more insolu-
bles is used, the brine maker will require periodic cleaning.
MINIMUM SALTING ADJUSTMENT
Minimum salting is the most e󰀩cient use of salt. But it does minimize the capacity of
the unit, which will decrease the time between regenerations. Only make this adjust-
ment after the unit has completed a brine tank rell step and the water level was
checked to be above the salt platform. Follow these instructions to adjust your unit to
regenerate with minimum salt usage.
• Adjust brine tank rell time to the minimum setting according to the
specication table. Refer to the “Setting the regeneration cycle timer page.
• Monitor the water daily for hardness. It may also be necessary to adjust the
regeneration frequency, since the capacity of the unit has changed.
1. Remove brine valve assembly from brine well.
2. Remove air check from assembly.
3. Shorten the riser tube by removing the top extension pipe.
4. Reassemble brine valve assembly.
5. Reinstall the assembly into the brine well. The assembly will no longer reach the
bottom of the brine tank.
TO INJECTOR
OVERFLOW
(PIPE TO DRAIN)
FLOAT
BRINE VALVE
LIQUID BRINE
DRY SALT
STORAGE
SALT SHELF
BRINE WELL
TO INJECTOR
TOP
EXTENSION
BRINE VALVE
FLOAT HEIGHT
FLOAT

MR 150M–1050M SINGLE – MXIII CONTROLLER
OPERATION
16
FEATURES OF THE MX III CONTROLLER
System
Number
System
Description
# of
Tanks
Connect meter
and/or remote
regeneration input
to...
Regeneration Type
Service Outlet
Valve controlled
by...
Operation Discussion
4 Single Unit 1 #1 Controller
Time Clock:
No Meter
Stager
(no solenoid
required)
Single tank conguration. During Regeneration no water avail- able to service unless optional bypass valve #2A installed.
Immediate:
One Meter
Delayed: One Meter
Remote Signal Start: No
Meter
5 Interlocked 2, 3, or 4 Each Controller
Immediate: All Meters Stager
(no solenoid
required)
All tanks in parallel supplying treated water. Each unit in the system will have its own ow meter/sensor input. The control will delay the start of Regeneration if another unit is already in Regenera- tion. Once that unit has completed a Regeneration cycle, and has returned to Service,the unit with longest regeneration queue time will begin Regeneration. No more than one unit will be in Regeneration at a time.
Remote Signal Start: No Meter
6Series
Regeneration 2, 3, or 4 #1 Controller Only
Immediate: One Meter
Stager
(no solenoid
required)
All tanks in parallel supplying treated water. Only #1 control will monitor ow meter/sensor input. When a regeneration is required for the system, it will regenerate valve address #1 rst, immediately followed by #2, then #3, then #4 if installed. No more than one unit will be in Regeneration at a time.
Delayed: One Meter
Remote Signal Start: No Meter
7Twin
Alternating 2 #1 Controller Only
Immediate: One Meter
Solenoid
One tank online supplying treated water, one tank in Standby. Only #1 control will monitor its ow meter/sensor input. Regeneration of a unit will begin after the other control has left Standby and returned to Service. When the Regeneration cycle is complete, the regener- ated unit will enter Standby. Standby on each tank is controlled by a solenoid connected to the service outlet valve of that tank.
Remote Signal Start: No Meter
9Multiple Tank
Alternating 2, 3, or 4 Each Controller
Immediate: All Meters
Solenoid
One, two, or three tanks online supplying treated water, one tank in Standby. Meter/sensor input is required on each tank. Regeneration of a unit will begin after the other control has left Standby and re- turned to Service. When the Regeneration cycle is complete, the re- generated unit will enter Standby. Standby on each tank is controlled by a solenoid connected to the service outlet valve of that tank.
Remote Signal Start: No Meter
14 Demand
Recall 2, 3, or 4 Each Controller Immediate: All Meters Solenoid
Meter/sensor input is required on each tank. Unit #1 will begin In Service with #2, #3, and #4 (if installed) will begin in Standby. At least one unit is In Service at all times. When ow rate to the Primary Service Unit increases to a user specied rate, the next unit in sequence will move from Standby to Service. As the ow rate falls below the user specied rate subsequent tanks will return to Standby. When the Primary Service Unit regenerates, the next unit in sequence will become the new Primary Service Unit. As each units capacity is reached the controller will initiate a Regeneration of that unit. Depending on the number of units in the system, and ow rate demand the regenerated unit will then be placed either into Standby or Service. Only one unit will be in Regeneration at a time.

MR 150M–1050M SINGLE – MXIII CONTROLLER
OPERATION
17
USER MODE PROGRAMMING FLOW CHART
NOTE: User Mode is only displayed when a metered option is chosen under System Type.
Depending on current option settings, some displays cannot be viewed or set.
Entering User Mode:
Hold the Up and Down buttons for 5 seconds.
NOTE: User Mode cannot be entered on the Lag unit for System 6.
1. Enter User Mode
Press and hold the Up and Down buttons for 5 seconds.
2. Set Language Option
Press up or down to select language.
Press the Extra Cycle button to proceed to the next step.
3. Set Feed Water Hardness
Press the Shift, Up, and Down buttons to move the cursor and change the value of the numbers.
Press the Extra Cycle button to proceed to the next step.
NOTE: Only displayed when a metered option is chosen under System Type.
4. Set Regeneration Day Override
To turn on and set the days, press the Down button.
Press the Shift, Up, and Down buttons to move the cursor and change the value of the numbers.
Press the Extra Cycle button to proceed to the next step.
5. Regeneration Time
Press the Shift, Up, and Down buttons to move the cursor and change the value of the numbers.
Press the Extra Cycle button
6. End of User Programming Mode
