MARS GAMING MSB1 User manual

User Manual MARS Gaming by
MSB1
USER MANUAL

Contents
1. Introduction
2. Battery warnings
3. Getting started
4. Cable connection
5. Bluetooth connection
6. NFC Connection
7. Microphone usage
8. LED Display Status
9. Battery charging
10. Product care

Specications
MARS GAMING: MSB1
Output power: 8W
Battery Capacity: 850mAh
S/N: >85dB
Frequency range: 30Hz-20KHz
Power supply: Lithium battery or USB cable
Audio source: iPhone, iPad, Smart phone, Notebook, MP3, MP4, etc
Function spec: Bluetooth, Microphone, Line-in
Size: 110mmX81mmX66mm
Rechargeable battery with charging option from USB cable
Operating range up to 20 meters
1. Introduction
Thank you for purchasing the MARS GAMING MSB1 system. This device can be easily
connected with your audio source or video devices during your traveling and daily
use. It supports both Bluetooth and line-in usage.

3. Getting started
ON/OFF AUX
Micro USB
Play/ Pause/
Answer calls
Previous Next
Microphone
Volume down Volume up
Bluetooth
paring key
4. Cable connection
Audio input cable

5. Bluetooth connection
Pairing MARS GAMING MSB1 to your Smart phone(smart phone should be away from
your speaker within 20 meters)
1. Activate pairing mode on MARS GAMING MSB1 by switching “ON/OFF” button
to “ON”. The LED will ash in red color.
2. On your smart phone, navigate to the Bluetooth function (refer to the smart
phone owner’s manual to locate Bluetooth function).
3. Select “Set Up” Bluetooth or turn “ON”Bluetooth.
4. Select “Search” or “Discover” devices.
5. Select “Bluetooth”.
6. If requested, type the password 0000
7. Press the Enter key.
After completing the steps above, a message on your smart phone will appear to
conrming that your device is now paired/connected.
In case of unsuccessful pairing, Push to “OFF”and restart it to “ON”.
Notice:
1. If you turn o the device, but the Bluetooth on your smart phone remains open,
when you restart the device, the Bluetooth will be connected automatically.
2. When your smartphone and this speaker are apart beyond bluetooth receiving
range, after 10 minutes, this speaker will disconnect with your smartphone and turn
into pairing mode. If within 10 minutes your smartphone is back, will connect with this
speaker automatically.
3. If long press “ ” button, the speaker will be disconnected and ready to pair with
other smartphone.

6. NFC Connection
NFC: Near Field Communication, is a set of standard for Smart phone and this speaker
to establish Bluetooth radio communication with each other by touching them
together or bringing them into close proximity, usually no more than a few
centimetres.
Please activate the NFC function (subjects to tablets own setting) of your Bluetooth
device. Bring your Bluetooth device close to speaker, as above picture.
Your Bluetooth device will ask you whether you need to pair the speaker, conrm by
“Yes” or “OK”, then the pairing process is completed.
7. Microphone usage
When a phone call comes in, you could talk through the microphone on speaker.
Long press pause button you could call the last number you called on your call
records.

8. LED display status
9. Battery charging
The device has a built-in rechargeable lithium battery that can be charged by
connecting to the USB port of your computer or into an AC adapter which contains a
USB port. When charging is completed, the red light will go o.
Ready to pair
Stay solid Paired
No light Power O/ Full charged
Flash quickly Low battery
Stay solid Charging
RED
Light
GREEN
Light
Flash
LED Display Light indication

10. Product care
Your device is designed to be light, compact and durable. As an electronic device, it
must be treated carefully. Putting unnecessary pressure on it or striking the device
against other objects may cause damage.
Do not drop, crush, bend or apply excessive force to the device.
Do not expose your device to moisture, extreme or prolonged heat, cold, humidity, or
other adverse conditions. Avoid storing it in damp, humid or wet places. It is not
waterproof.
Clean the unit with a soft cloth or damp chamois leather. Never use solvents.
The Unit can only be opened by qualied person.
This device contains magnets. Keep magnetic eld sensitive products such as credit
cards and video screen away from this device to avoid damage or malfunction.

2. Battery warnings
The device can be powered by a built-in rechargeable lithium battery. Please charge
the battery for at least 8 hours before your rst use of device.
If the device is not used for a long period of time, the battery may be out of power.
Please charge the battery.
Rechargeable batteries are only to be charged under adult supervision. Use only the
supplied USB micro cable to recharge the battery. Improper charging may damage the
battery and the device.
Do not attempt to open the rechargeable battery or battery pack. There is not servi-
ceable part inside.
Should a battery leak, the device may become damaged. Clean the battery compart-
ment immediately, avoiding to touch your skin.
Keep the battery out of reach of children. If swallowed, consult a physician immediate-
ly.
Avoid storing the battery in extremely hot or cold environment. A device with a hot or
cold battery may not work temporarily, even when the battery is fully charged.
Do not dispose batteries in a re as they may explode. Batteries may also explode if
damaged. Please dispose them according to local regulation. Do not dispose them as
household waste.
