Mars MA-WO-UWB User guide

1
1
2
2
3
3
4
4
A A
B B
C C
D D
Parts List
DESCRIPTIONQTYITEM
Antenna11
U-Bolt M8
22
Flat Washer
43
Lock Washer
44
Hex Nut M84
5
CHNG/REV DESCRIPTION ECN No. DATE APPROVED
DRAWN
POLE
1
2
5 3 4
MOUNT
MOUNTING INSTRUCTION FOR ANTENNA MA-WO-UWB
1. Put U-bolts item 2 on the pole.
2. Adjust mount of antenna with U-bolts.
3. Close U-bolts with fasteners items 3, 4, 5. Tighten nuts item 5 so they hold antenna.
(Don't tighten finally.)
4. Adjust antenna as desirable. Evenly tighten nuts item 5 finally.
Recommended fastening torque for each nut: 10 N*m (100 kg*cm; 87 lb*in).
1
POLE

A (4 plcs.)
1
1
2
2
3
3
4
4
A A
B B
C C
D D
A
Parts List
DESCRIPTIONQTY
ITEM
Antenna11
Ground plane to MG-165
12
NC #8 x 5/16" Philips Pan Head Screw
43
Flat Washer #8
44
Spring washer #8
45
CHNG/REV DESCRIPTION ECN No. DATE APPROVED
DRAWN
MOUNTING INSTRUCTION FOR ANTENNA MA-WO-UWB
WITH GROUND PLANE MG-165; MG-370; MG-400
1. Adjust ground plate item 2 with base of antenna so connector passes thru window
in ground plate. Close ground plate to antenna with items 3, 4, 5 (4 plcs.).
2. Make hole Ø45...50mm in ceiling panel & insert antenna towards down so
surface 'B' lays on ceiling panel.
2
1
1,5
2
543
CONNECTOR
3 4 5
B
CEILING PANEL
NOT SHOWN

A-A ( 1 : 2 )
1
1
2
2
3
3
4
4
A A
B B
C C
D D
Parts List
DESCRIPTIONQTY
ITEM
Antenna11
Ground plate
12
MOUNT13
NC #8 x 5/16" Philips Pan Head
Screw
24
Flat Washer #8
4
5
Lock Washer #8
46
NC #8 x 3/8" Philips Flat Head
Screw
27
NC #8 x 1/2" Philips Flat Head
Screw
28
Hex Nut NC #829
U-Bolt M8
210
Hex Nut M8411
Flat Washer for M8
412
Lock Washer for M8
413
A A
CHNG/REV DESCRIPTION ECN No. DATE APPROVED
DRAWN
MOUNTING INSTRUCTION FOR ANTENNA MA-WO-UWB
WITH GROUND PLANE MG-165 & MOUNT
1. Remove mount item 3 from antenna. (Screws of mount won't be used any more.)
2. Adjust ground plate item 2 with base of antenna so connector passes thru window
in ground plate. Close ground plate to antenna with items 4, 5, 6 (2 plcs.).
3. Connect mount item 3 to base of antenna with items 7 (locktite recommended)
& to ground plate with items 5, 6, 8, 9 (see section 'A-A').
4. Put U-bolts item 10 on the pole. Adjust mount item 3 with U-bolts.
5. Close U-bolts with fasteners items 11, 12, 13. Tighten nuts item 11 so they hold
antenna. (Don't tighten finally.)
6. Adjust antenna as desirable. Evenly tighten nuts item 11 finally.
Recommended fastening torque for each nut:
10 N*m (100 kg*cm; 87 lb*in).
2
1
3
10
11
12
13
POLE
165,0o
1,5
6
5
4
5 6 8 9
7
56 8 9
2
3
6
5
47
8
10
33,0
31,6
CONNECTOR
2
3
3
4
5
6
2
10
131211
POLE

1
1
2
2
3
3
4
4
A A
B B
C C
D D
Parts List
DESCRIPTIONQTYITEM
Antenna11
Ground plate
12
MOUNT13
NC #8 x 3/8" Philips Flat Head Screw44
U-Bolt M8
2
5
Hex Nut M846
Flat Washer for M8
47
Lock Washer for M8
48
PAY ATTENTION
If edge A of mount is near connector -
connector will be farther from pole.
If edge B of mount is near connector -
connector will be closer to pole.
FIG. 1
PAY ATTENTION
Space C between ground plate item 2 & pole
depends on U-bolts' item 5 position on pole.
Space C may be 0.
FIG. 2
CHNG/REV DESCRIPTION ECN No. DATE APPROVED
DRAWN
MOUNTING INSTRUCTION FOR ANTENNA MA-WO-UWB
WITH GROUND PLANE MG-370; MG-400 & MOUNT
1. Remove mount item 3 from antenna. (Screws of mount won't be used any more.)
2. Adjust ground plate item 2 with base of antenna so connector passes thru window
in ground plate. Close mount & ground plate to antenna with items 4 (locktite
recommended). (FIG. 1).
3. Put U-bolts item 5 on the pole. Adjust mount item 3 with U-bolts (FIG. 2).
4. Close U-bolts with fasteners items 6, 7, 8. Tighten nuts item 6 so they hold antenna.
(Don't tighten finally.)
5. Adjust antenna as desirable. Evenly tighten nuts item 6 finally.
Recommended fastening torque for each nut:
10 N*m (100 kg*cm; 87 lb*in).
C
POLE
A
B
34
2
CONNECTOR
1
5
6
7
8
POLE
5
2
5 6 7 8
3
