Marshall Amplification CV420e User manual

Broadcast A/V Division
CV420e
Compact UHD60fps ePTZ Camera
(USB, IP & HDMI)
User Manual

CV420e User Manual
www.marshall-usa.com
1 2
Table of Contents
Chapter 1 Package Contents .........................................................................2
Chapter 2 Function Introduction.....................................................................3
2.1 I/O functions Introduction ..............................................................3
2.2 Tally Lamp Function Description....................................................3
Chapter 3 Instruction for installation...............................................................4
3.1 Basic Devices ................................................................................4
Chapter 4 System diagram.............................................................................5
Chapter 5 Remote Control and Setting Menu ................................................6
5.1 Functions of remote control...........................................................6
5.2 Setting Menu..................................................................................7
Chapter 6 Network Function Settings Description .......................................13
6.1 Web System Requirements .........................................................13
6.2 Web Page Function Description ..................................................14
Chapter 7 Troubleshooting ...........................................................................27
Chapter 8 Safety Instructions .......................................................................28
Warranty Information ............................................................................................29
CV420e Power Cord Power Adapter
Remote CVM-5 Stand Warranty Card
CHAPTER 1: PACKAGE CONTENTS

CV420e User Manual
www.marshall-usa.com
3 4
Front View Back View
Bottom
Item Function Descriptions
1 IR receive Support infrared remote control
2 Tally Lamp Display the Tally Lamp status of the camera
3 Lens HD camera lens
4 Power indicator Display the status of the camera
5 DC 12 V power connector AC power supply connecting port
6 Network port Network cable port supports routers or hubs of
IEEE802.3af with PoE power supply
7 Audio input Support Line In/Mic In audio input
8 HDMI 2.0 output Connect to HDMI output signal source
9 USB 3.0 Type-B port Connect to the computer using a USB cable; capture
images via the software
10 Reset button Press and hold for 5 seconds to reset the machine
11 Tripod locating holes Tripod locating holes
12 Tripod screw holes Support 1/4”, 20 UNC
2.2 Tally Lamp Function Description
2.2.1 The tally indicator light function may be enabled through the control of VISCA
command. The setting method is as follows:
Tally Mode: 8x 01 7E 01 0A 01 0p FF
p = 0: OFF
p = 4: On (half-brightness)
p = 5: On (full-brightness)
2.1 I/O Functions Introduction
CHAPTER 2: FUNCTION INTRODUCTION
3.1 Basic Devices
CHAPTER 3: INSTRUCTIONS FOR INSTALLATION
3.1.1 CV420e size
Length x Width x Height: 122.06 x 70 x 51 mm Weight: 0.35 Kg
3.1.2 Installation Method
You can use the included Marshall CVM-5 monitor
and desk stand, or any ¼”- 20 capable camera
mount type to attach to tripods, wall mounts,
ceiling mounts, etc
9
54 6
3 87 10
12
1112
#

CV420e User Manual
www.marshall-usa.com
5 6
CHAPTER 4: SYSTEM DIAGRAM
Line/Mic Device Audio In ComputerDisplay
CHAPTER 5: REMOTE CONTROL & SETTING MENU
5.1 Functions of Remote Control*
*IR remote included in this package
Item Description
v w r sv w r s Move the lens
Back Light Turn on/off back light
compensation
Camera select Choose Camera ID 1~3
Focus- Manual /Far/Near Reserved
Focus-Auto Reserved
Freeze Freeze the screen
Home-Enter Go back to the main page /
Execute
Info Status information
L/R Direction Set L/R Direction / Normal
Menu Display OSD menu
Mirror Rotate the image
(OFF / Mirror / Flip / Rotate)
Pan/Tilt Reset Clear the Pan / Tilt setting
Picture Switch image effect
(OFF / Neg / B&W)
Power Power Switch
Preset Appoint an ID (0~9) to save the
current position data
Reset Appoint an ID (0~9) to delete the
current position data
Zoom-Fast Adjust image size
Zoom-Slow Fine-tune image size
Power Supply AV over IP switch

CV420e User Manual
www.marshall-usa.com
7 8
5.2 Setting Menu
Press [Menu] on the remote control to enter the setting menu;
the bold underlined values in the following table are defaults.

CV420e User Manual
www.marshall-usa.com
910

CV420e User Manual
www.marshall-usa.com
11 12

CV420e User Manual
CHAPTER 6: NETWORK FUNCTION SETTING DESCRIPTION
6.1 Web System Requirements
6.2 Connecting Camera to Network
Two common connection methods are shown below
1. Connecting via switch or router
2. To connect directly through network cable, the IP address of the computer should
be changed so that it is on the same network segment as the camera
E.g.: The factory-preset default IP address of the camera is 192.168.100.100.
The computer IP address must be set with the same network segment, such as
192.168.100.101, so that the computer can be connected correctly with the camera
14
AV over IP switch
13

CV420e User Manual
www.marshall-usa.com
15 16

CV420e User Manual
www.marshall-usa.com
17 18

CV420e User Manual
www.marshall-usa.com
19 20

CV420e User Manual
www.marshall-usa.com
21 22

CV420e User Manual
23

CV420e User Manual
www.marshall-usa.com
25 26

CV420e User Manual
www.marshall-usa.com
27 28
CHAPTER 8: SAFETY INSTRUCTIONS

29
20608 Madrona Avenue, Torrance, CA 90503
Tel: [phone] • Fax: [phone]
www.marshall-usa.com
[e-mail]
Marshall Electronics warranties to the first consumer that this device will, under normal use,
be free from defects in workmanship and materials, when received in its original container, for
a period of two years from the purchase date. This warranty is extended to the first consumer
only, and proof of purchase is necessary to honor the warranty. If there is no proof of purchase
provided with a warranty claim, Marshall Electronics reserves the right not to honor the warranty
set forth above. Therefore, labor and parts may be charged to the consumer. This warranty
does not apply to the product exterior or cosmetics. Misuse, abnormal handling, alterations or
modifications in design or construction void this warranty. No sales personnel of the seller or
any other person is authorized to make any warranties other than those described above, or to
extend the duration of any warranties on behalf of Marshall Electronics, beyond the time period
described above.
Due to constant effort to improve products and product features, specifications may change
without notice.
