Marshall Amplification CV730-NDI User manual

Broadcast A/V Division
CV730-NDI
CV730-NDIW
30X UHD60 PTZ Camera with NDI®|HX
User Manual

Marshall 2
Copyright Information
Copyrights © Marshall Electronics Incorporated. All rights reserved.
Marshall Electronics is a trademark of Marshall Electronics Incorporated
Copying, reproducing or transmitting this file is not allowed if a license is not provided by
Marshall Electronics Inc. unless copying this file is for the purpose of backup after purchasing
this product.
In order to keep improving the product, Marshall Electronics Inc. hereby reserves the right to
make changes to product specifications without prior notice. The information in this file is
subject to change without prior notice.
To fully explain or describe how this product should be used, this manual may refer to names
of other products or companies without any intention of infringement.
Disclaimer of warranties: Marshall Electronics Inc. is neither responsible for any possible
technological, editorial errors or omissions, nor responsible for any incidental or related
damages arising from providing this file, using, or operating this product.
Table of Contents
1. Safety Instructions
2. Package Contents
3. Function Introduction
3.1 I/O Functions Introduction
3.3 Tally Lamp Function Description
3.2 Description of LED Indicator
4. Instruction for Installation
4.1 Preparation before Installation
4.2 Instruction for Installation
4.3 Ceiling Mounting
4.3 Connecting Devices
5. Remote Control and Setting Menu
5.1 Functions of Remote Control
5.2 Setting Menu
6. Network Function Settings Description
6.1 Connecting Camera to Network
6.2 Web Page Function Description
7. DIP Switch Setting
7.1 Dip Switch
8. Troubleshooting
Warranty
FCC Declaration of Conformity 47 CFR § 2.1077 Compliance Information
04
06
07
07
09
09
10
10
11
11
17
20
20
21
30
30
33
46
46
47
49
48
CV730-NDI Manual
www.marshall-usa.com1 2

Marshall 3
Chapter 1 Safety Instructions
Always follow these safety instructions when setting up and using this product:
1 Operation
1.1 Please use the product in the recommended operating environment.
1.2 Do not place this product in tilted position.
1.3 Do not place the product on an unstable trolley, stand or table.
1.4 Do not use this product near water or source of heat.
1.5 Use attachments only as recommended.
1.6 Use the type of power source indicated on this product. If you are not sure of the type
of power available, consult your distributor or local electricity company for advice.
1.7 Always take the following precautions when handling the plug. Failure to do so may
result in sparks or fire:
Ensure the plug is free of dust before inserting it into a socket.
Ensure that the plug is inserted into the socket securely.
1.8 Do not overload wall sockets, extension cords or multi-way plug boards as this may
cause fire or electric shock.
1.9 Do not block the slots and openings in the case of this product. They provide
ventilation and prevent this product from overheating.
1.10 Except as specifically instructed in this User Manual, do not open or remove covers,
otherwise it may expose you to dangerous voltages and other hazards. Refer all
servicing to licensed service personnel.
1.11 Unplug this product from the wall outlet and refer servicing to licensed service
personnel when the following situations happen:
If the power cords are damaged or frayed.
If liquid is spilled into the product or the product has been exposed to rain or water.
2 Installation
2.1 For security considerations, please make sure the standard hanging rack you bought
is in line with UL or CE safety approbations and installed by technician personnel
approved by agents.
3 Storage
3.1 Do not place the product where the cord can be stepped on as this may result in
fraying or damage to the lead or the plug.
3.2 Never push objects of any kind through cabinet slots. Never allow liquid of any kind to
spill into the product.
3.3 Unplug this product during thunderstorms or if it is not going to be used for an
extended period.
3.4 Do not place this product or accessories on top of vibrating equipment or heated
objects.
4 Cleaning
4.1 Unplug all the cables before cleaning. Use a damp cloth for cleaning. Do not use
liquid or aerosol cleaners.
5 Remote control (if the accessories are equipped with remote control)
5.1 Using an incorrect battery type in the remote control may result in breakdown. Follow
local instructions on how to dispose of used batteries.
Understanding Quick setup of CV730-NDI with NDI®|HX
This section explains how to quickly congure the Marshall CV730-NDI camera with NDI®|HX.
It also explains how to update the device, and where you can nd additional NDI software to extend your
workow. Complete NDI® Tools can be found here: https://www.ndi.tv/tools/
Here you will choose whether you will require NDI® Tools for Windows or Mac and download.
After completing this short section, you will be all set to begin using your new NDI®|HX camera.
OVERVIEW: Unlike typical cameras, CV730-NDI leverages the easy plug-n-play benets of the NDI-based IP
workow supported by leading video software and hardware developers around the globe.
GETTING READY: Your new CV730-NDI uses the NDI®|HX protocol for audio/video transmission, and more.
Your rst step will be to install NDI|HX drivers if using a TriCaster, or Microsoft HEVC decode on non-TriCaster
systems, as appropriate for your computer platform or device.
1. Navigate to ndi.tv/formats in your web browser and follow the relevant directions to download and install
the drivers for your computer platform. NOTE: The NDI|HX driver also installs NewTek’s NDI Studio
Monitor application, which will not only display the output of your camera but also provide easy access to
its settings. Also contains built-in PTZ controls.
2. NDI Studio Monitor and other useful NDI tools can be found here: https://www.ndi.tv/tools/
3. Then simply plug the Ethernet (NDI) port to same Network your computer or Newtek equipment are
plugged into and o󰀨 you go.
NOTE: The End User License Agreement under which you use the NDI|HX driver species that “you may use up
to ve (5), and no more than ve, copies on separate machines at one time.”
OPTIONAL – for Microsoft Windows® users, downloading and installing the NewTek NDI® Tools pack, available
at no cost from ndi.tv/tools/, the download pack will provide learning tools and utilities to maximize your NDI®|HX
experience.
FINAL NOTE – if you are experience any problems with the NDI® platform, NDI® software, NDI® drivers please
contact Newtek for technical assistance or join the NDI community to review HOW-TO videos, social media,
forums, blogs: www.ndi.tv/community
If you are having a hardware problem, and need assistance please contact Marshall Electronics.
Marshall Customer Support
Toll Free: 800-800-6608 or 310-333-0606
Email: [email protected]
CV730-NDI Manual
www.marshall-usa.com3 4

Marshall 4
Precautions
Warning: To reduce the risk of fire or electric shock, do not expose this appliance to rain
or moisture.
If the UHD camera will not be used for an extended time, unplug it from the power socket.
Caution: To reduce the risk of electric shock, do not remove cover (or back). No
user-serviceable parts inside. Refer servicing to licensed service personnel.
This symbol indicates that
this equipment may contain
dangerous voltage which
could cause electric shock.
This symbol indicates that
there are important
operating and maintenance
instructions in this User
Manual with this unit.
FCC Warning
This UHD Camera has been tested and found to comply with the limits for a Class A computer
device, pursuant to Article 15-J of FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This digital apparatus does not exceed the Class A limits for radio noise emissions from digital
apparatus as set out in the interference-causing equipment standard entitled “Digital
Apparatus,” ICES-003 of Industry Canada.
Cet appareil numerique respecte les limites de bruits radioelectriques applicables aux appareils
numeriques de Classe A prescrites dans la norme sur le material brouilleur: “Appareils
Numeriques,” NMB-003 edictee par l’Industrie.
EN55032 (CE Radiation) Warning
Operation of this equipment in a residential environment could cause radio interference.
Caution
Risk of Electric Shock
Please do not open it by yourself.
Marshall 5
Chapter 2 Package Contents
CV730-NDI
Power Cord Power Adapter
Appearance may vary
depending on
country/region
Metal Plate A
RS-422 Connector
Remote Control
Metal Plate B
M3 Screws
Silver x8 / Black x2
CV730-NDI Manual
www.marshall-usa.com5 6

Marshall 6
Chapter 3 Function Introduction
3.1 I/O functions Introduction
3.1.1 Front View
NO.
Item
Function Descriptions
1.
Tally Lamp
Display the Tally Lamp status of the camera
2.
Camera lens
30x UHD camera lens
3. Power LED
indicator
Display the status of the camera, please refer to 3.2 Description of
LED indicator
4. Standby LED
indicator
Display the status of the camera, please refer to 3.2 Description of
LED indicator
Marshall 7
3.1.2 Back View
NO.
Item
Function Descriptions
5. RS-232 output
RS-232 output port, at most 7 cameras can be connected in a
serial connection
6. RS-232 input
RS-232 input port, at most 7 cameras can be connected in a serial
connection
7.
HDMI 2.0 output
HDMI 2.0 output (Audio output supported)
8. RS-422 port
RS-422 connecting port, at most 7 cameras can be connected in a
serial connection
9.
OUTPUT SWITCH
Adjust the resolution setting. The default is 3840 x 2160/59.94p
10.
Audio input
Support Line In/Mic In
11.
Network port
Network port, supporting routers or hubs of PoE++ (IEEE802.3BT)
12.
DC 12 V power
connector
AC power supply connecting port
13.
IR SELECT
The remote control ID setting is only controlled after
corresponding to the Camera Select on the remote control
14.
Kensington lock
hole
Safety lock slot
15.
USB 3.0 port
A reserved hole. The current firmware does not support this
function. Please refer to the firmware update information on the
webpage for the official release schedule.
16.
12G-SDI output 12G-SDI output (Audio output supported)
CV730-NDI Manual
www.marshall-usa.com7 8

Marshall 8
3.1.3 Bottom
NO.
Item
Function Descriptions
17.
Mute cooling fan
The cooling fan automatically controls its rotation speed and
performs cooling in cope with the operation temperature of the
machine
18.
Tripod deck lock
hole
The camera is mounted on a (specification) 1/4” - 20 UNC tripod
deck
19.
Rotatable foot
pad
When using the metal plates of accessories, remove 4 pieces of
rotatable food pads on the bottom by rotating counterclockwise, and
then install the mental plates
3.2 Description of LED indicator
Status
Power
Standby
Startup in progress
(initialization)
Green light Orange light
In use
Green light
No indicator
In standby mode
No indicator
Orange light
3.3 Tally Lamp Function Description
3.3.1 Tally Lamp function may be enabled through the control of RS-232 command. The
setting method is as follows:
Tally Mode: 8x 01 7E 01 0A 01 0p FF
p = 0: OFF
p = 4: Red light (half-brightness)
p = 5: Red light (full-brightness)
p = 6: Green light (full-brightness)
17
18
19
Marshall 10
Chapter 4 Instruction for installation
4.1 Camera dimension:
4.1.1.1 Camera front view and side view
Length x width x height: 232 x 188 x 189 mm
Weight: 3.0Kg (excluding the metal plate)
4.1.1.2 Camera base
The camera base has tripod mount lock holes and can be installed on the tripod
deck of a standard specification 1/4”-20 UNC.
CV730-NDI Manual
www.marshall-usa.com9 10
Marshall 9
p = 7: Orange light (full-brightness)

Marshall 11
4.2 Preparation before installation
Installation and connection of CV730-NDI UHD camera requires special skills. To install
by yourself, please follow necessary steps, ensure steady and tight installation of the device,
and pay attention to your safety to avoid any accident.
4.2.1 Ensure the safety of the installation environment. Please do not install the device on
unstable ceiling or in a place where the device is in danger of falling to avoid any accident.
4.2.2 Please check whether accessories in the box are complete or not.Please contact the
supplier for any shortage, and make sure to keep the accessories in the box intact.
4.2.3 Please choose a proper place for installation of camera in advance. Please determine
an installation place according to the following requirements
4.1.1.1 Confirm the position for the object to be captured.
4.1.1.2 Confirm whether the camera is set at a proper distance from other light sources.
4.3 Instruction for installation
4.3.1 I would like to install camera on the desk
4.3.1.1 Precautions for installation
Please install the machine on a flat desk
Do not grab the camera head by hand when handling the device
Do not rotate the camera head by hand. Improper rotation may result in breakdown
of the camera
4.3.1.2 Installation steps
1. Place the camera on a flat desk directly to ensure the normal vertical and
horizontal operation of the machine
4.3.2 I would like to install the camera on the ceiling
4.3.2.1 Prepare for the parts and equipment required during the installation
1. Accessories in the box (metal plates A, B, M3 screw silver x 8, black x 2)
2. Screw for locking on ceiling mounted hanger x 4
3. Drilling machine, screwdriver, ladder
Marshall 12
4.3.2.2 Metal Plate size diagram
Metal plate B - ceiling side
Metal plate B locking screw Metal plate B locking bolt
M3 threaded hole
M3 threaded hole
M3 threaded hole
CV730-NDI Manual
www.marshall-usa.com11 12

Marshall 13
Metal plate A - machine side
Metal plate A locking screw
Marshall 14
4.3.2.3 Precautions for installation
1. Before installation, please confirm the orientation of the machine relative to the
object to be captured
2. It is recommended that the machine should be set at a distance more than 2
meters away from the object to be captured. Please adjust for a best distance
according to the magnification of the lens
3. The machine (including metal plates) is weighed at about 3kg. If it is to be
installed on the ceiling, please use the hanger that has obtained UL security
approval to prevent the machine from falling.
4. Please check whether the camera is installed securely on a regular basis.
5. Please clean the cooling fan located at the bottom to ensure the good heat
dissipation effect of the machine on a regular basis.
4.3.2.4 Installation steps
1. Remove 4 pieces of foot pads on the bottom of the camera by rotating the foot
pads counterclockwise.
<Remark>Please keep the foot pads properly after removal and store them for
future use.
2 meter ↑
Projector
Computer
CV730-NDI Manual
www.marshall-usa.com13 14

Marshall 15
2. Fix the metal plate A on the machine base with 4 M3 silver screws
3. Lock the metal plate B on ceiling mounted hanger
<Caution>:
(1) Please use the hanger that has obtained UL security approval
(2) Please reserve the hole for the connecting wires of the camera
4. Combine the metal plate A and the metal plate B
(1) Push the metal plate A up to the ceiling and then to the right to latch the metal
plate B
(2) And then secure with 2 M3 silver screws and 1 M3 black screw
Marshall 16
.
4.3.2.5 How to remove
1. Remove the connecting wires from the camera
2. Uninstall the camera together with the ceiling, loosen the three screws that fix the
metal plates A and B and push to the left to remove the machine
3. Then remove the screws on the hanger and the machine
black
screw
CV730-NDI Manual
www.marshall-usa.com15 16

Marshall 17
4.4 Connecting devices
4.4.1 Connecting RS-232
With RS-232 in/out, at most 7 Marshall cameras can be connected.
RS-232 pins definition instructions
Po: Change “VC” to “Camera.
Marshall 17
4.4 Connecting devices
4.4.1 Connecting RS-232
With RS-232 in/out, at most 7 Marshall cameras can be connected.
RS-232 pins definition instructions
Po: Change “VC” to “Camera.
Marshall 18
4.4.2 Connecting RS-422
With RS-422, at most 7 Marshall cameras can be connected.
<Caution> When RS-422 connection is being used, do not use RS-232
connection.
RS-422 pins definition instructions
Marshall Compact Camera Controller
SONY Compact Camera Controller
Applicable to
Applicable to
RS-422 Connection Instructions
RS-422 Connection Instructions
RS-422 Pins Instructions
CV730-NDI Manual
www.marshall-usa.com17 18

Marshall 19
RS-422 connection instructions
1. Hold the two sides of RS-422 connector and pull out in the direction shown by the
arrow in the figure below
2. Peel off a section of copper wire (AWG Nos. 28 to 18) and insert it into the connector
hole; then use flat screw driver to fix it
3. Insert the wired RS-422 connector back to the Camera. Now the connection is
completed
Marshall 20
Chapter 5 Remote Control and Setting Menu
5.1 Functions of remote control
<Remark> The below functions are listed alphabetically.
Item
Description


,

,

,

Move the lens
Back Light
Turn on/off back light compensation
Camera select
Choose Camera ID 1 ~ 3
Focus-Manual /
Far/Near
Turn on manual focus to adjust the focal
length
Focus-Auto
Auto Focus
Freeze
Freeze the screen
Home-Enter
Go back to the main page / Execute
Info
Status information
L/R Direction Set
L/R Direction / Normal
Menu
Display OSD menu
Mirror Rotate the image (OFF / Mirror / Flip /
Rotate)
Pan/Tilt Reset
Clear the Pan / Tilt setting
Switch image effect (OFF / Neg / B&W)
Power
Power Switch
Preset Appoint an ID (0 ~ 9) to save the current
position data
Reset Appoint an ID (0 ~ 9) to delete the
current position data
Zoom-Fast
Adjust image size
Zoom-Slow Fine-tune image size
Po: Change IR remote image with Marshall silkscreen.
CV730-NDI Manual
www.marshall-usa.com19 20

Marshall 21
5.1 Setting Menu
<Remark>Press [Menu] on the remote control to enter the setting menu; the bold underlined
values in the following table are defaults.
1st Level
Major Items
2nd Level
Minor Items
3rd Level
Adjustment Values
Function Descriptions
Exposure
Mode
1. Full Auto
2. Shutter Pri
3. Iris Pri
4. Manual
Exposure mode setting
Exposure
Comp.
On / Off AE Level
Exposure
Comp. Level -5 ~ C~ 5
The value can be
adjusted after Exposure
Comp. is activated
Spot Light On / Off
Spot Light
Position X (0 ~ 6) Y (0 ~ 4)
The value can be
adjusted after Spot
Light is activated
Shutter Pri
60/30
mode
50/25
mode
Adjustable when the
Exposure mode is set
to Shutter Pri
1/10000
1/10000
1/5000
1/5000
1/3000
1/3000
1/2500
1/2500
1/2000
1/1750
1/1500
1/1250
1/1000
1/1000
1/725
1/600
1/500
1/425
1/350
1/300
1/250
1/215
1/180
1/150
1/120
1/120
1/100
1/100
1/90
1/75
1/60
1/50
1/30
1/25
1/15
1/12
2
Marshall 22
1/8
1/6
1/4
1/3
1/2
1/2
1/1
1/1
Iris Pri
1. F1.6
2. F2
3. F2.2
4. F2.7
5. F3.2
6. F3.8
7. F4.5
8. F5.4
9. F6.3
10.F7.8
11.F9
12.F11
13.F13
14.F16
15.F18
16.Off
Adjustable when the
Exposure mode is set
to Iris Pri
Manual Gain
1. 0 dB
2. 3 dB
3. 6 dB
4. 9 dB
5. 12 dB
6. 15 dB
7. 18 dB
8. 21 dB
9. 24 dB
10.27 dB
11.30 dB
12.33 dB
13.36 dB
14.39 dB
15.42 dB
16.45 dB
Adjustable when the
Exposure mode is set
to Manual
Manual Speed
60/30
mode
50/25
mode
Manually set the shutter
1/10000
1/10000
1/5000
1/5000
CV730-NDI Manual
www.marshall-usa.com21 22

Marshall 23
1/3000
1/3000
1/2500
1/2500
1/2000
1/1750
1/1500
1/1250
1/1000
1/1000
1/725
1/600
1/500
1/425
1/350
1/300
1/250
1/215
1/180
1/150
1/120
1/120
1/100
1/100
1/90
1/75
1/60
1/50
1/30
1/25
1/15
1/12
1/8
1/6
1/4
1/3
1/2
1/2
1/1
1/1
Manual Iris
1. F1.6
2. F2
3. F2.2
4. F2.7
5. F3.2
6. F3.8
7. F4.5
8. F5.4
9. F6.3
10.F7.8
11.F9
12.F11
13.F13
14.F16
15.F18
16.Off
Manually set the iris
Marshall 24
Gain Limit
1. 9 dB
2. 12 dB
3. 15 dB
4. 18 dB
5. 21 dB
6. 24 dB
7. 27 dB
8. 30 dB
9. 33 dB
10.36 dB
11.39 dB
12.42 dB
13.45 dB
Max. limit value of
electron gain
Iris Limit
1. F3.2
2. F3.8
3. F4.5
4. F5.4
5. F6.3
6. F7.8
7. F9
8. F11
Max. limit value of iris
WDR
1. Off
2. 1
3. 2
4. 3
White
Balance
Mode
1. Auto
2. Indoor
3. Outdoor
4. One Push WB
5. ATW
6. Manual
7. Sodium Lamp
Select the color
temperature mode
1. 4000k ~ 7000k
2. 3200k
3. 5800k
4. 1700k ~ 10000k
5. 1700k ~ 10000k
6. Custom
7. 2800k
One Push
Trigger
ENTER One push trigger
Manual Red 0 ~ C~ 128
Adjustable when the
white balance mode is
set to Manual
CV730-NDI Manual
www.marshall-usa.com23 24

Marshall 25
Manual Blue 0 ~ C~ 128
Adjustable when the
white balance mode is
set to Manual
Picture effect
1. Off
2. Neg
3. B & W
Sharpness 0 ~ A~ 14
2D NR
1. Off
2. 1
3. 2
4. 3
3D NR
1. Off
2. LOW
3. Typ
4. Max
Image Mode 1. Default
2. Custom
The user may customize
his/her desired image
mode.
Image Mode
Load ENTER
Adjustable when the
Image mode is set to
Custom. After selected,
the corresponding
Image mode
parameters will be read
and applied to Custom
Brightness 0 ~ A~ 15
Adjustable when the
Image mode is set to
Custom
Hue 0 ~ A~ 15
Adjustable when the
Image mode is set to
Custom
Saturation 0 ~ A~ 15
Adjustable when the
Image mode is set to
Custom
Gamma 0 ~ A~ 3
Adjustable when the
Image mode is set to
Custom
Pan Tilt
Zoom
Pan/Tilt Limit On / Off Turn on/off the angle
limit setting
Marshall 26
Pan Right Limit 0 ~ 170 Limit the right angle
Pan Left Limit -170 ~ 0 Limit the left angle
Tilt UP Limit 0 ~ 90 Limit the upward angle
Tilt Down Limit -30 ~ 0 Limit the downward
angle
Pan Flip On / Off Activate the reverse Pan
direction
Tilt Flip On / Off Activate the reverse Tilt
direction
Preset Speed
1. 5 deg/sec
2. 25 deg/sec
3. 50 deg/sec
4. 80 deg/sec
5. 120 deg/sec
6. 160 deg/sec
7. 200 deg/sec
8. 300 deg/sec
Set the rotation speed of
the cradle head when
Preset is executed
PTZ Speed
Comp On / Off
Set the Pan/Tilt moving
speed to vary from the
zoom position
D-Effect Mirror
1. Off
2. MIRROR
3. Flip
4. Mirror + Flip
Set the mode at which
the image is mirror or
flipped
Auto Focus
AF Sensitivity
1. LOW
2. Middle
3. High
For AF triggering speed,
the higher the speed is,
the faster AF is triggered
AF Frame
1. Center Area
2. Full Area
3. Auto
AF frame setting, when
central area was set as
AF frame, focusing will
be on the center of the
screen. When Full
Frame was set as AF
frame, focusing will be
calculated based on the
full screen
CV730-NDI Manual
www.marshall-usa.com25 26

Marshall 27
PTZ Assist On / Off
This function can only be
enabled in the Manual
Focus (MF) mode
When PTZ Assist is
enabled and PTZ control
is in operation, the focus
performs only once upon
immediate execution.
The focus will not be
triggered afterward when
the scene changes
Ethernet
DHCP On / Off
Enable/Disable DHCP
setting using left and
right arrow keys and
press [ENTER] to apply
setting.
IP Address 192.168.100.100
Press [ENTER] to be in
modify mode; select the
item to be modified using
the up and down keys,
and modify the value
using the left and right
keys or the numeric
keys.
Subnet Mask 255.255.255.0
Press [ENTER] to be in
modify mode; select the
item to be modified using
the up and down keys,
and modify the value
using the left and right
keys or the numeric
keys.
Gateway 192.168.100.254
Press [ENTER] to be in
modify mode; select the
item to be modified using
the up and down keys,
and modify the value
using the left and right
keys or the numeric
keys.
Marshall 28
Audio
Audio In Line In/Mic In Set Audio In
Audio Enable On / Off Turn on/off audio output
Audio Volume 0 ~ A~ 10 Volume Setting
System
Prompt On / Off
Turn on/off the prompt
information on the
display
IR Receive On / Off
When it is Off, the
remote control will not be
able to control the
camera. At this moment,
turn off and then turn on
the power to restore
control of the remote
control.
Tally Lamp On / Off
Select to enable or
disable Tally Lamp
function.
Language
English / Chinese
Initial Position Last operation/First
default position
Select the camera lens
to return to the last
operated position or the
first preset position after
POWER ON.
Control Device Encoder / Controller
Control Device setting,
Controller: for joystick
Encoder: for tracking
system
Motionless
Preset On / Off
When the function is
enabled, the screen will
Freeze when Preset is
executed. Freeze will be
released after Preset is
completed.
Control Port RS-232/RS-422
Choose whether the
control interface used is
RS-232 or RS-422
Protocol
VISCA
/ Pelco D
CV730-NDI Manual
www.marshall-usa.com27 28

Marshall 29
Baud Rate 9600/38400
Choose the transmission
speed of the control
signal
VISCA Address 0 ~ 7
The Protocol set to
VISCA allows the
camera ID address to be
assigned. Select 0 for
automation.
PELCO D
Address 1~ 255
The Protocol set to
Pelco D allows the
camera ID address to be
assigned.
Output Mode
1. 3840 x 2160/59.94p
2. 3840 x 2160/50p
3. 3840 x 2160/29.97p
4. 3840 x 2160/25p
5. 1080p/59.94
6. 1080p/50
7. 1080p/29.97
8. 1080p/25
9. 720p/59.94
10. 720p/25
Choose the output
resolution
Factory Reset On / Off Resume the factory
default setting
Status Display the current
setting status
Marshall 30
Chapter 6 Network Function Settings Description
6.1 Connecting Camera to Network
6.1.1 Connecting to Internet
Two common connection methods are shown below
1. Connecting via switch or router
2. To connect directly through network cable, the IP address of the computer should
be changed so that it is on the same network segment as the camera
e.g.: The factory-preset default IP address of camera is 192.168.100.100. The
computer IP address must be set with the same network segment, such as
192.168.100.101, so that the computer can be connected correctly with the camera
Change network settings
Switch or router
Network cable Network cable
Camera
Computer
Camera Computer
Network cable
CV730-NDI Manual
www.marshall-usa.com29 30

Marshall 31
6.1.2 Using the Browser to View the Images
Open the browser, and enter the URL of camera in the IP address bar
e.g.: http://192.168.100.100 (default IP address)
Enter administrator’s account and password
*For the first login, please refer to 6.2.3 User Management Modify the default
password
6.1.3 Using RTSP Player to View the Images
In addition to the browser and VMS, other free software also can be used for RTSP connection, such as
VLC, Quick Time and PotPlayer
RTSP connection address formats are as follows:
RTSP Main Streaming (4K@H.265) => rtsp://camera IP:8554/hevc
RTSP Sub1 Streaming (1080P@H.264) => rtsp://camera IP:8557/h264
RTSP Sub2 Streaming (720P@H.264) => rtsp://camera IP:8556/h264
Example: Open VLC software and enter URL: rtsp://192.168.4.48:8554/hevc
Marshall Network Camera
Account: admin
Password: 9999
Marshall 32
CV730-NDI Manual
www.marshall-usa.com31 32

Marshall 33
6.2 Web Page Function Description
6.2.1 Login Screen
No Item Function Descriptions
1 Username Enter user account (default: admin)
2
Password
Enter user password (default: 9999)
*For the first login, please refer to 6.2.3 User Management Modify the
default password
3 Language selection Currently, the system supports English, Traditional Chinese, and
Simplified Chinese
4 Remember password Save user account name and password to the browser. When you log
in next time, there is no need to re-enter them
5
Login Log into the administrator screen on the website
1
2
3
5
4
1
2
3
4
5
Marshall 34
6.2.2 Viewing In Real Time
No Item Function Descriptions
1
Pan / Tilt setting
Adjust the Pan/Tilt position of the camera screen
2
Preset setting
Select the number first and then select SAVE or LOAD
3
Zoom ratio
Adjust the zoom-in or zoom-out ratio via scroll bar
4
Power button
Turn on or turn off the camera power
3
2
1
4
12
3
4
CV730-NDI
CV730-NDI Manual
www.marshall-usa.com33 34

Marshall 35
6.2.3 Account Management
No
Item
Function Descriptions
1
Add user account
Enter a user name and password to add a new user
2 Permission setting
Set the new account management permissions
User Type
Admin
Operator
Viewer
View images
V
V
V
Settings
V
V
X
Account
management
V X X
3
Applying setting
Add the newly created user to the list of account
4 List of accounts Edit: Modify the user password and permissions
Delete: Delete the user account
1
2
3
4
1
2
3
4
CV730-NDI
Marshall 36
6.2.4 Setting - System Setting
No
Item
Function Descriptions
1 Resolution
Set the resolution of the camera, resolutions supported by the camera
are as follows:
3840 x 2160 59.94 / 50 / 29.97 / 25 fps
1080P 59.94 / 50 / 29.97 / 25 fps
720P 59.94 / 50
After switching to the resolution, the camera will restart. Please refresh
the browser
2 HDMI YUV
Select YUV422 or YUV420 (This function is only available for these two
resolutions, 3840 x 2160/59.94p and 3840 x 2160/50p and remains in
display mode for all other resolutions)
3
Apply
After the setting has been modified, select this button to apply the setting
1
2
3
1
2
3
CV730-NDI
CV730-NDI Manual
www.marshall-usa.com35 36

Marshall 37
6.2.5 Setting – Video
No Item Function Descriptions
1 Camera name
Modify the camera name
Camera names are limited to 1 - 12 characters
Please use a camera name by mixing uppercase and lowercase
letters or numbers. Do not use “/” and “space” or special symbols
2 Camera Location
Modify the location of the camera, such as Meeting Room 1
Camera location is limited to 1 - 12 characters
Please use a camera name by mixing uppercase and lowercase
letters or numbers. Do not use “/” and “space” or special symbols
3 Streaming 1/Streaming
2/Streaming 3
CV730-NDI supports 3 streaming outputs. Please refer to 6.2.5.1
Streaming Parameter Setting for relevant settings
4
Open Streaming
Confirm whether or not the streaming function is opened
5 Force I Frame
Check this item to insert IDR frame into specified series flow and apply
its setting. User’s setting will be reserved and displayed in GUI
interface
6.2.5.1 Streaming parameter setting
Function Streaming 1 Streaming 2 Streaming 3
Encode Format H.265 H.264
Resolution 4K /1080P / 720P 1080P/720P 640 x 360
Frame Rate Setting according to the supported resolution
Bit Rate (kbps)
Range 2,000 ~ 20,000 2,000 ~ 20,000 512 ~ 5,000
Factory
Default
7,000 7,000 1,000
Rate Control CBR / VBR
IP Ratio Setting according to the supported resolution
1
2
3
4
5
1
2
3
4
5
CV730-NDI
Marshall 38
6.2.6 Setting – Camera
No Item Function Descriptions
1
Zoom ratio
Adjust the zoom-in or zoom-out ratio via scroll bar
2 Exposure
Mode: Select exposure mode (Automatic/Shutter Priority/Aperture
Priority/Manual)
Exposure Comp. Level: Select exposure compensation level
Gain: The gain limit is adjustable when the exposure mode is set to
“Manual”
Iris: The size of aperture is adjustable when the exposure mode is
set to “Manual” or “Aperture Priority”
WDR: Set the level of wide dynamic range (WDR) in order to obtain
better images
Shutter Speed: The shutter speed is adjustable when the exposure
mode is set to “Manual” or “Shutter Priority”
5
4
3
2
1
1
2 3 4 5
CV730-NDI
CV730-NDI Manual
www.marshall-usa.com37 38
