Martin Yale PL18M User manual

Blade Changing
Guide
Provided By
http://www.MyBinding.com
http://www.MyBindingBlog.com
Intimus PL18M
Guillotine Cutter

1
Blade Handle
Clamp
PL18M Blade Change Instructions
Warning: this procedure is intended for a qualified equipment
technician. It is not recommended for non-qualified personnel
to service this unit. This unit contains an extremely sharp
cutting blade which could cause severe personal injury if
improperly handled. Technical Support for this product can be
reached at 800-225-5644. Additional instructions for this
machine are available at www.martinyalesupport.com.
Tools Needed
3 mm Allen Wrench (Removal of Shroud and Clamp)
5 mm Allen Wrench (Removal of Blade from Carriage)
Phillips Screw Driver (Removal of Blade Handle)
Removal of Blade Handle, Clamp and Shroud
1. Remove handle from unit by taking out (3) phillips head
screws from both front and back side. See Photo 1 (Next
page). Once screws are removed, pull handle up and off
mounting stem.
Shroud

2
2. Remove shroud by taking out (3) 3mm Allen screws from
shroud. See photo 2. Shroud cannot be removed before
handle .
3. Remove plexi-glass clamp/guard by taking out (4) 3mm
Allen screws from left and right side. A metal bracket
under each side of the clamp may separate when this is
performed. See Photo 3.
Step 1--Handle Front Step 1--Handle Rear
PHOTO 1
Shroud Screw--Clamp
Side
Shroud Screw—Blade
Side, Another on
opposite side!
PHOTO 2

3
1. Once clamp, shroud and handle are removed position
blade handle so that both of the outer mounting screws are
in sight. Remove each outer screw with 5mm Allen
wrench. See Photo 4 on next page. Once outer screws are
removed, reposition handle as necessary to remove
remaining (5) Allen screws. Once screws are removed,
blade will drop to cutting stick.
2. Once blade is dislodged from carriage, carefully slide the
blade out of the handle side of the unit (right side). It’s
recommended that something be inserted into blade hole
to pull blade out. Do not use hands. See photo 5 on next
page. The blade is easy to damage. Take extra caution to
not chip.
3. While blade is removed, turn the cutting stick by pulling
out of right side and rotating. See Photo 6.
4. Reassemble machine by reversing steps. Be careful when
reinserting the blade. It has a keyed fit to the blade
carriage and the carriage should not be forced down. The
downward motion should be smooth. Realign and reinstall
(7) 5mm Allen screws. Test for cut. If additional
Clamp Removal--2 Screws at each
end of clamp
PHOTO 3
Removal Of Blade

4
instructions are needed please contact Martin Yale
Industries, Inc. at 800-225-5644, or [email protected].
Photo 1-Blade handle must be
properly positioned to get access to
the outer Allen screws.
Do nut use hands to pull blade out.
Insert a small tool into blade hole
and pull.
A severe groove in cutting stick can keep even a
sharp blade from going all the way through the
stack
PHOTO 4 PHOTO 5
PHOTO 6
