Maruson PRO-400A LCD User manual

Front Panel—
1. LCD Back-Light
2. Power “ON/OFF” Switch
Back Panel—
1. USB Port
2. Modem/Phone Line Surge Protection
3. Battery Backup Outlets
4. Surge protected outlets
5. AC input
6.
*
Circuit breakerz
IEC×3 for 220/230/240V
NITUO
2
2
34
5
6
1
1
Inspection
Remove the UPS from its packaging and inspect it
for damage that may have occurred during shipping.
If any damage is discovered, repack the unit and
return it to the place of purchase.
Placement
Charging
Install the UPS unit in any protected environment
that provides adequate airflow around the unit, and
is free from excessive dust, corrosive fumes and
conductive contaminants. Do not operate your UPS
in an environment where the ambient temperature
or humidity is high. On the other hand, place the
UPS unit away from monitor at least 20cm to avoid
interference.
This unit is shipped from the factory with its internal
battery fully charged. however, some energy may be
lost during shipping so the battery should be
recharged before using it. Plug the unit into an
appropriate power supply and allow the UPS to
charge fully by leaving it plugged in for 8 hours.
Connect one computer-related device into each of
the power receptacles supplied on the back of the
UPS (maximum of three devices).
To turn on the UPS unit, press the power switch lightly.
To turn off the UPS unit, press the power switch again
(When Swith ON，The LED lighting.).
The LED will always turns on when UPS works,
including in off charging mode and fault mode.
When LCD start to work, it will display all information
for 3s
Plug incoming internet line into the “In” socket at the
back of the UPS. Use one more Internet line cable
and plug one end of the Internet line cable to the
“Out” socket at the back of the UPS. Plug the other
end to the modem input socket as shown.
Computer Connection
Modem/Phoneline Connection
Turn On/Off
LCD Display Specification
1).When in normal mode, it will display as below.
2).When in AVR mode, it will display as below. And the
mark will flicker every 1second.
3).When in battery mode, it will display as below.
And the mark will flicker every 1second.
Note: If I/P-V<40V，input voltage will display “000”
4).When in off charging mode, it will display as below.
Note: the output voltage always is displayed as “000”
in off charging
mode.
5).When in fault mode, it will display as below. “FAULT”
character and
the reason of fault only.
Note: the fault code will be showed in fault mode.
6).Load level definition:
Load LEVEL Load bar Indication
0%~25%
25%~50%
50%~75%
75%~100%
7).Battery capacity definition:
Battery voltage ≤11V
11V≤Battery voltage ≤11.5V
11.5V≤Battery voltage≤12.5V
Battery voltage ≥12.5V
8).When over load, the mark will flicker every
1second.
1second.
9).When battery low, the mark
will flicker every
5
4
6
7
3
2
1
UPS System Description
LONG 202-719-4978

-- WinPower --
WinPower is a brand new UPS monitoring software, which provides
user-friendly interface to monitor and control your UPS. This unique
software provides safely auto shutdown for multi-computer systems while
power failure. With this software, users can monitor and control any UPS
on the same LAN no matter how far from the UPS
Installation procedure:
1. Go to the website:
http://www.ups-software-download.com/winpower.htm
2. Choose the operation system you need and follow the instruction
described on the website to download the software.
3. When downloading all required files from the internet, enter the serial
No: 511C1-01220-0100-478DF2A to install the software.
When your computer restarts, the WinPower software will appear as a
green plug icon located in the system tray, near the clock.
Use the table below to solve minor UPS installation or operation
problems. If any abnormal situations occur that are not listed
above,please call service people immediately.
Symptom Possible Cause Remedy
1. Missing battery. 1. Charge battery up to 8
hours.
2. Battery defect. 2. Replace with the same type
of battery.
No LED display on
the front panel.
3.When the Input cord
isn’t electvified and
Power switch is not
pressed.
3. Press the power switch
again or elecerity the Input
cord
Alarm buzzer
beeps continuously
when AC supply is
normal.
Overload of the UPS. Verify that the load matches
the UPS capability specified in
the specs.
1. Overload of the UPS. 1. Remove some noncritical
load.
2. Battery voltage is too
low.
2. Charge battery 8hours or
more.
When power
failure, back-up
time is shorten.
3. Battery defect due to
high temperature
operation environment,
or improper operation
to battery.
3. Replace with the same type
of battery.
1. Software is not
installed well.
1. Check the setting of the
software .
Communication
lost between UPS
and computer. 2. Cable is not properly
connected.
2. Make sure both ends of the
USB cable is connected
and recheck settings.
1. Circuit breaker is
broken.
1. Reset the circuit breaker..Mains normal but
LCD display
Battery mode. 2. Power cord is loose. 2. Reconnect the power cord
properly.
MODEL PRO-400A LCD PRO-600A LCD PRO-800A LCD
CAPACITY VA/W 400/240 600/360 800/480
Voltage Range 89-145VAC/162~290VAC
INPUT Frequency 50Hz/60Hz (Auto-Sensing)
Voltage 110/120/220/230/240VAC
Voltage Regulation +/- 10%(Battery Mode)
zH06/zH05ycneuqerF
Frequency
Regulation +/-1 Hz(Battery Mode)
OUTPUT
Output Waveform Modified Sine-wave
Battery Type 12V/4.5Ah 12/7Ah 12V/9Ah
Back up Time Up to 12 mins Up to 22 mins Up to 30 mins
BATTERY
Recharge Time 8 Hours to 90% after complete discharge
TRANSFER TIME xamsm01,lacipytsm6-2lacipyT
The LCD will always turn on when UPS work,
INDICATOR LCD Display Models Including in off charging mode and fault mode
Backup Mode Sounding every 10 seconds
dnoces1yrevegnidnuoSwoLyrettaB
sdnoces5.0yrevegnidnuoSdaolrevO
Battery replace Sounding every 2 seconds
AUDIBLE ALARM
gnidnuossuounitnoCtluaF
Buck/boost with
>70% SPS load
Sounding every 0.5sec. after 25min.
And fault after 30 mins
PROTECTION Full Protection Discharge,Overcharge short circuit
and Overload Protection
PHYSICAL Dimension (DxWxH) 330 x 100 x 140mm/12.9 x 3.9 x5.5 inch
WEIGHT Net Weight 4.4Kg/9.7lb 5.4Kg/11.9lb 6.1Kg/13.4lb
Operating
Environment 0- 40°C, 0-90 % Relative Humidity (non-condensing)
ENVIRONMENT
Bd04nahtsseLleveLesioN
INTERFACE For Windows Family, Mac, Linux Family,
and Unix Based Famillies
USB
(Software included)
Software Installation
This UPS utilizes voltages that may be hazardous. Do not attempt to disassemble the unit. The unit contains no user serviceable parts.
Only factory service personnel may perform repairs.
Internal battery voltage is 12Vdc. Sealed, lead-acid, 6 cells battery.
Connection to any other type of receptacle other than a two-pole, three-wire grounding receptacle may result in s shock hazard as well
as violate local electrical codes.
In the event of an emergency, turn the power switch to the “off” position and disconnect the power cord form the AC power supply to
properly disable the UPS
Do not allow any liquids or any foreign object to enter the UPS. Do not place beverages or any other liquid-containing vessels on or near
the unit.
Do not plug the UPS input into its own output.
Do not attach a power strip or surge suppressor to the UPS.
To reduce the risk of overheating the UPS, do not cover the UPS’ cooling vents and avoid exposing the unit to direct sunlight or installing the
unit near heat emitting appliances such as space heaters or furnaces.
Do not attach non-computer-related items, such as medical equipment, life-support equipment, microwave ovens, or vacuum cleaners to UPS.
Unplug the UPS prior to cleaning and do not use liquid or spray detergent.
Do not dispose of battery or batteries in a fire. The battery may explode.
Do not open or mutilate the battery or batteries. Released electrolyte is harmful to the skin and eyes. It may be toxic.
Servicing of batteries should be performed or supervised by personnel knowledgeable of batteries and the required precautions.
Keep unauthorized personnel away from batteries.
When replacing batteries, replace with the same number of the sealed lead-acid batteries.
This pluggable type A equipment with battery already installed by the supplier is operator installable and may be operated by laymen.
During the installation of this equipment it should be assured that the sum of the leakage currents of the UPS and the connected
loads does not exceed 3.5mA.
The mains socket outlet that supplies the UPS shall be installed near the UPS and shall be easily accessible.
A battery can present a risk of electrical shock and high short circuit current. The following precautions should be observed when working
on batteries :
1) Remove watches, rings, or other metal objects from the hand.
2) Use tools with insulated handles.
3) Wear rubber gloves and boots.
4) Do not lay tools or metal parts on the top of batteries.
5) Disconnect charging source prior to connecting or disconnecting batteries terminal.
This unit intended for installation in a controlled environment (temperature controlled, indoor area free of conductive contaminants).
Avoid installing the UPS in locations where there is standing or running water, or excessive humidity.
All trade names are registered trademarks of respective manufacturers listed.
Specifications may change without notification.
