Masalta MSR58 SERIES User manual

WARNING
!
R
INSTRUCTION MANUAL
SINGLE DRUM VIBRATORY ROLLER
MSR58 SERIES

1
TableofContents
1.SAFETYINFORMATION
1.1General .. ....3
1.2Intended use .. ...3
1.3Unintended use .. ..3
1.4Whoisallowed tooperatethemachine 3
1.5Conversionsand alternationstothe machine ..3
1.6Safetynotesinthe operating and maintenanceinstructions ..3-4
1.7Safetystickerson the machine .. .4
1.8Loading the machine .. 5-6
1.9Starting the machine .. 7
1.10 Driving the machine .. ..8
1.11Parking the machine .. ..9
1.12 Miscellaneous ... ..10
2.OPERATION
2.1Controls ..11
2.2General notes ....12
2.3Checksbeforestarting .....12
2.4Starting the engine ..12-14
2.5Wrong starting .. .14
2.6Adjusting the steeringrod .. ..14
2.7Driving the machine .. .15
2.8Driving the machine withthe backup protection bow .. 15
2.9Switching the vibration on resp. off .. 15-16
2.10 Switching the gravitysprinklersystemon resp. off ..16
2.11Stopping the engine .16-17
2.12 Loading and transport ....17
3. MAINTENANCE
3.1General NotesforMaintenance .18
3.2Fuelsand Lubricants . .18-19
3.3Fuels, Lubricantsand Filling Capacities 19
3.4Running-ininstructions ... .20
3.5Maintenancechart 20
3.6Cleaning machine/engine 21
3.7Cleaning the airfilter ... .21
3.8Checking the engine oillevel ..21
3.9Checking the fuellevel 21-22
3.10 Checking the waterlevel ... 22
3.11Cleaning the cooling finsand the cooling airintakesofengine 22

2
TableofContents
3.12 Checking the engine oil .23
3.13 Cleaning,greasing the spring on the driven system ... ..23
3.14 Cleaning, checking the spark plug ..23-24
3.15 Cleaning the fuelsludge filterspark ... ..24
3.16 Checking the rubberbuffers ... ...24
3.17 Checking the vibration systemV-belt .24-25
3.18 Check, greasethe drive. ..25
3.19 Tensioning, changing V-belt/chain 25
3.20 Changing the airfilter .26
3.21 Checking,adjusting the valveclearance ... .26
3.22 Cleaning the fuelstrainer .. ...27
3.23 Changing oil .. ......27
3.24 Watersprinklersystem,maintenanceincaseoffrost ......28
3.25 Adjusting the scrapers .. .28
3.26 Tighteningtorquesforscrewswithmetricunifiedthread .. ..28
4.TROUBLESHOOTING
4.1General notes ...29
4.2Engine troubleshooting ................29
5.TECHNICALDATA . .30
6. WARRANTY ...... ...31
7. MAINTENANCERECORD ...... .....32
8. ECDECLARATION ......33

3
SAFETYINFORMATION
1.1General
ThisMASALTAmachineisbuiltin accordancewith thelatesttechnicalstandardandthevalid
technicalrules and regulations. However,dangers forpersonsand propertymay arise from
themachineifitis:
lput tounintended use,
loperated byuntrained personnel,
lmodified oraltered inan unprofessionalway,
lthe applicablesafetyregulationsarenot observed.
Each personinvolvedinoperation, maintenance and repairofthemachinemusttherefore
read andapplythese safetyregulations.Ifnecessary thisshouldbeconfirmedbyobtaining
thesignature ofthecustomer.
Furthermorethe following regulationsand instructionsareobviouslyalsovalid:
lallapplicableinstructionsforthe prevention of accidents,
lgenerallyacknowledged safetyand road trafficregulations,
lcountry specificregulations.
1.2Intendeduse
lCompaction ofbituminousmaterials(road layers)
lLight compaction work inearthconstruction (road subbase)
1.3Unintendeduse
Dangersmay, however,arisefromthe machineifit isused byuntrained personnelinan
unprofessionalwayorifitisused forpurposesotherthan thosementioned intheseinstructions.
1.4Whoisallowedtooperatethemachine?
The machine must onlybe operated bytrained and authorized persons,whichareatleast 18
yearsofage.The responsibilitiesforthe operation of themachine aretobe clearlyspecified and
complied with.
Maintenanceand repairsrequireveryspecificknowledge and mustthereforeonlybe carried out
bytrained and qualifiedpersonnel.
1.5Conversionsandalterationstothemachine
Unauthorized conversionstothe machine areprohibitedforsafetyreasons.
Original partsand accessorieshavebeen speciallydesigned forthismachine.Wewishtomake
expresslyclearthatwehavenottested orauthorizedanyoriginal partsorspecialequipmentnot

4
SAFETYINFORMATION
supplied byus.The installation and/oruseofsuchproductscan impairthe activeand/orpassive
drivingsafety.The manufacturerexpresslyexcludesanyliabilityfordamage resulting fromthe useof
non-original partsoraccessories.
1.6Safetynotes intheoperatingandmaintenance instructions:
!Danger
Sectionsmarked likethispoint out possible dangers forpersons.
!Caution
Sectionsmarked likethispoint out possible dangers forthe machine orforpartsofthe machine.
iNote
Sectionsmarked likethisprovide technical information concerning the optimal economicaluseofthe
machine.
1.7Safetystickersonthemachine
Keep safetystickersingood condition and legibleand followtheirmeaning.
Replacedamaged and illegiblesafetystickers.

5
SAFETYINFORMATION
MASALTAmachinesuseinternationalpictoriallabelswhereneeded.Theselabelsaredescribed
below:
Label Meaning
DANGER!
Enginesemitcarbon monoxide;operateonlyin
well-ventilatearea. Read the Operation Manual for
machine information.No sparks, flames, orburning
objectsnearthe machine. Shutoff the engine before
refueling. Useonlyclean, filtered unleaded gasoline.
WARNING!
Alwayswearhearing and eyeprotection when
operating thismachine.
CAUTION!
Read and understand the supplied OperationManual
beforeoperating themachine.Failuretodo so
increasethe riskofinjurytoyourself orothers.
CAUTION！
Lifting point.
CAUTION！

6
SAFETYINFORMATION
Label Meaning
WARNING!
Hot surface!
WARNING!
Gontroll oftraveling and vibration.
Guaranteed sound powerlevelindB(A).
Anameplatelisting the modelnumberand serial
numberisattached toeachunit. Pleaserecordthe
information found on thisplatesoitwillbe availableif
the nameplatelost ordamaged.When requesting
serviceinformation,the serial numbershouldbe
specified of the unit.

7
SAFETYINFORMATION
1.8Loadingthemachine
Useonlystrong and stableloadingramps.The rampinclinationmust be lowerthan the gradabilityof
the machine.
Securethe machine against turning overorslipping off.
Securethe machine on the transportvehicleagainst rolling, slipping and turning over.
Personsarehighlyendangered when
lstepping orstanding underloadsbeing lifted
ltheyremaininthe driverange ofthe machine duringan ongoing demonstration and during
loading.
The machine must not swing about when being lifted.
Securethe machine on the transportvehicleagainst rolling, slipping and turning over.
1.9Startingthemachine
Before starting
Familiarizeyourself withthe equipment,the controlelements,the working principlesofthe machine
and the area whereyou will be working.
Useyourprotectiveoutfit (hardhat, safetybootsetc.).
lCheck beforestarting themachinewhether:
lpersonsorobstaclesarebeside orunderthe machine
lthe machine isfree of oilyand combustiblematerial
lallhandlesarefree of grease, oils,fuels,dirt,snowandice
lthe machine showsanyobviousfaults
lallguardsand protectivedevicesareproperlyfastened
lsteering, brakesand controlelementsareingood working order.
Do not start the machine if anygauges, control lightsorcontrol elementsaredefective.
Do not takeanylooseobjectswithyou orsecurethemtothe machine.
Useonlymachinesthat havebeen properlyserviced according toschedule.
Starting
lTakeacorrectposition tothe machine tostartthe engineand holdthe crankhandlecorrectly.
lDo not useanystarting aidssuchasStart Pilotorether.
Startingin closedrooms
Exhaustfumesarehighlydangerous!Alwaysensureanadequatesupplyoffreshairwhen starting in
closed rooms!

8
SAFETYINFORMATION
1.10 Drivingthemachine
Personsinthedanger zone
Beforestarting towork,even aftershortbreaks,check,ifthereareanypersonsorobstructionsinthe
working range ofthe machine.
Ifnecessary givewarning signals.Stop work immediatelyifpersonsremaininthe dangerzone
despitethe warning.
Driving
Do not usethe machine totransport persons.
Change the traveldirectiononlywhilethemachine isstanding.
Movethe travelcontrolleverslowlytostart and stop themachine.
Alwaysguide themachine sothatyou donothityourhandsagainstsolidobstructions.Dangerof
injury!
Guide and operatethe machine onlyfromthe predetermined operating side
Keep awayfromedgesand slopes.
Stop the machine if you noticeunusualnoisesorthe development of smoke. Investigatethe cause
and havethefault corrected.
Alwaysletloaded transportvehiclespass.
Drivingon slopes andgradients
Do not driveup and downinclineswhicharesteeperthan the maximumgradabilityof the machine.
Alwaysdriveextremelycarefullyon slopesand alwaysdirectlyup ordownthe slope.Alwaysshiftto
the lowerspeed range when approaching the slope.
The steering rod must alwayspoint uphill when driving up ordownslopes.
Wet and loosesoilsreducethe ground adhesion ofthe machine on slopesand gradients
considerably. Higherriskofaccidents!
Whendrivingin traffic
Matchthe travelspeed tothe working conditions.
Alwaysletloaded transportvehiclespass.
Keep awayfromedgesand slopes.
Check theeffectofvibration
Whencompactingwithvibration check the effect of the vibration on nearbybuildingsand
underground supplylines(gas, water, sewageand electricity),stop vibratory compaction
immediatelyif required.

9
SAFETYINFORMATION
Do notvibrateon hard(frozen,concrete)ground.
Riskofbearingdamage!
1.11Parking themachine
Park the machine on ground asleveland firmaspossible.
Beforeleaving the machine:
lset the control levertoneutral position
lapplythe parking brake
lshut the engine downand pull the ignition keyout
Do not usethe decompression levertoshut the engine down.
Mark parked machines, whichcouldbe an obstruction,withaclearlyvisiblesign.
Parkingon slopes andgradients
Park themachine transversetothe slope orsecurethe machine againstrolling.Placemetal chocks
underthe drums.
1.12 Miscellaneous
Filling thefueltank
Refuelonlywiththe engine shut down.
Do not refuel inclosed rooms.
No open fire,do not smoke.
Do not spillanyfuel. Catchrunning out fuel,do notletitseep intothe ground.
Maintenance
Maintenancework must onlybecarried out byqualified and authorized personnel.
Keep unauthorized personsawayfromthe machine.
Do not performmaintenancework whilethe machine isdriving orthe engine isrunning.
Park the machine on leveland firmground.
Pullthe ignition switchout.
Workingonhydrauliclines
Depressurizehydrauliclinesbeforestarting towork.Hydraulicoilescaping underpressurecan
penetratethe skinand causeseriousinjuries.Consultadoctorimmediatelyifyou areinjured by
pressurized oil, asotherwiseseriousinfectionsmaydevelop.
Do not stand infrontof orbehind the drumswhen adjusting the hydraulicsystem.
Do not change the setting ofpressurereliefvalves.
Drainhydraulicoilat operating temperature-dangerofscalding!
Catchrunning outhydraulicoiland disposeofenvironmentally.
Alwayscatchbiodegradablehydraulicoilsinaseparatecontainerand disposeofseparately.

10
SAFETYINFORMATION
Do not start the engineafterdraining the hydraulicoil.
Check all connectionsand fittingsforleakagesafterall workiscompleted (withthesystem
still depressurized!).
Workingon theengine
Drainthe engine oilat operating temperaturedangerof scalding!
Wipeoffspilled oil,catchrunning outoiland disposeofenvironmentally.
Storeused filtersand otheroilymaterialsinaspeciallymarked containerand disposeof
environmentally.
Workingon thefuel system
No open fire,do not smoke,do not spillanyfuel.
Catchrunning out fuel, do not letitseep intothe ground and disposeofenvironmentally.
Water sprinkler system
Inthe eventoffrost the watersprinklersystemmust bedrained orfilledwithan anti-freezemixture.
Cleaning
Do not clean the machine whilethe engine isrunning.
Neverusepetrol oranyotherhighlyinflammablesubstancesforcleaning purposes.
Whenusing steamcleaning equipmentdonotsubjectelectricalpartsand insulatingmaterialstothe
directwaterjetorcoverthembeforehand.
Do not guide the waterjetdirectlyintothe exhaust.
Do notguide the cleaning jetdirectlyintothe oilbathairfilterorintothe opening forthe crankhandle.
After completingmaintenance
Reinstall allguardsand protectivedevicesaftercompleting maintenance.
Repair
Attachawarning tag tothe steering rod if themachine isdefective.
Repairsmustonlybe carriedoutbyqualifiedand authorized personnel.Alwaysfollowthe repair
instructions.

11
OPERATION
2.1Controls
Ref. Description Ref. Description
1 LeverforOperator 7 WaterTankDraining
2 LeverforVibration 8 LiftingHole(four)
3 LeverforAdjustingHandleHeight 9 Bolt,SideProtectiveCover
4 FuelTankfilling 10 Bolt,UpperProtectiveCover
5 LiftingHook 11 Bolt,Scraperadjustment
6 WaterTankFilling
1 2 3
4 5 6
7
8
9
10
11

12
OPERATION
2.2Generalnotes
Pleaseread section 3Indicatorsand Control
Elementsthoroughlybeforeoperating the
machine if you arenotyetfullyfamiliarwiththe
indicatorsand controlelementsofthe machine.
2.3Checksbeforestarting
Pleaseobservethe safetyregulationsinsection
2oftheseoperating and maintenance
instructions.
Referalsotothe detailed description under
maintenance
lTop up missing fuelsand lubricant
according tothe maintenanceinstructions.
lPark the machine on ground aslevelas
possible.
lCheck fueltankand fuellinesforleakages.
lCheck the conditionofengineand
machine.
lCheck allscrewed connectionsfortightfit.
lNeutralposition of the travel controllever
(the vibratory rollermust not move
forwardsorreversewhen the travel control
leverisincenterposition).
lCheck the fuellever. Useonlystandard
grade petrolorunleaded standardgrade
petrol.
lCheck the waterlevelforthe water
sprinklersystem.
lCheck the engine oillevel.
lCheck the scrapers, adjust if necessary.
2.3Starting theengine
!Caution
Theengineisprovidedwithalowoil level
safetydevice. Theenginecannotbestarted
iftheoillevelistoolow.
Fig. 1
lMovethe throttlelever1(Fig.1)to
position "I"(detent).
Fig. 2
lOpen the fuelvalve1(Fig.2)byturning it
indirection of arrowtothe end stop.
Warmengineorwarmambient
temperature
2
1
2
1

13
OPERATION
Fig. 3.
lDo not operatethe lever2(Fig.3)forthe
chokeasshown in.Ifnecessary movethe
lever(2)tomiddleposition according tothe
engine temperatureresp. the ambient
temperature.
Coldengineorcoldambient
temperature
Fig. 4
lPushthe lever2(Fig. 4)forthe chokein
direction ofarrowtothe end stop and close
the choke.
iNote
The chokeisin operating position when it isnot
operated.
Starting theengine
Fig. 5
lTurnthe ignition switch3(Fig. 5)to
position "ON".
Fig. 6
lPullthe starterhandle(Fig.6)lightlyuntil
resistanceisnoticed (compression), then
pullthe starterhandlewithforce. Do not
pullit completelyout.
lGuide the starterrope back byhand.
iNote
Do notletthe starterhandle hitback againstthe
engine.
lRepeat the starting procedureifthe engine
doesnot startatthe firsttime.
lIfthe engine iscold closethe chokeagain
and repeat the starting procedure.
Fig. 7
lOpen the lever2(Fig.7)of the chokein
direction of arrowoncethe engine has
warmed up.
lLet the engine warmup for1-2minutes.
2
2

14
OPERATION
!Caution
Thechoke mustalwaysbeopenduring
operation,otherwisethefuel consumption
willbeexcessivelyhighortheenginemay
bedamaged.
Fig.8
lSetthe throttlelever1(Fig.8)toposition
"MIN"(idlingspeed).Thisshouldalsobe
done forshortbreaks.Thispreventsthe
centrifugalclutchfromslipping.
2.4Wrong starting
Engine sucked too muchfuel
iNote
Ifthe chokeisclosed and the starterrope is
pulled too often,the engine will suck too much
fuel and will thereforenot start.
Remedy
lClosethe fuel valve.
lOpen the choke.
lSet the throttlelevertofullspeed position.
lOperatethe starteruntilthe engine starts.
iNote
Ifthe engine doesnotstartafter10 to20times
then
lopen the choke.
lSet the throttle levertofull speed position.
lPull the spark plug socket off.
lUnscrewthe spark plug.
lOperatethe starterseveral times.
lDry thespark plug withadryand clean
clothorwithcompressed air.Clean itwith
awirebrush.
lScrew the sparkplug back inand pushthe
spark plug socket back on.
lRepeat the starting procedure.
2.5Adjusting thesteering rod
iNote
Toachievean optimal working position, the
steering rod needstobe adjusted tothe sizeof
the operator.
Fig. 9
lLoosen the T-bar1(Fig.9)and adjustthe
steering rod tooperating position.
lRetighten the T-bar.
2.6Driving themachine
!Danger
Soil conditionsand weather influences
impairthegradeabilityofthemachine.
Do notdrive on gradientsexceedingthe
maximumgradeabilityofthemachine!
Make sure thatyourdrive rangeisfree of
obstaclesand dangers.
1
MIN
1

15
OPERATION
Danger whenreversing.
lChokeon engine isopen.
Fig. 10
lThrottlelever1(Fig.10)inposition "I"
(detentfortravelposition).
lChoosethe desired travel direction by
meansofthetravelcontrol lever(2).
Position "A"=forward(infinitely)
Position "B"=reverse(infinitely).
!Danger
Operatethetravel control lever onlyslowly,
asotherwisethemachinewilldrivejerkily
and thesteeringrodwillhitupordown.
lWhen releasing the travel control leverit
will slowlyreturnto"0"-position.The
machine isbraked automatically.
2.7Driving themachinewiththebackup
protection bow
Fig. 11
lIfthe operatorispressed against an
obstacleduring reversetravel, the backup
protection bow2(Fig.11)isforced to
forwardstravel.
!Danger
Do notusethe machine ifthe safetycontrol is
defective.
2.8Switching thevibration on resp. off
iNote
Vibration atstandstill causestransverserutsin
the surface,therefore:
Switchthevibration on onlywhen themachine
drives.
Switchthe vibration offbeforethe machine
stops.
!Caution
Never switchthevibrationonwhen the
machineisonhard(frozen,concrete)
ground.
Possiblebearing failures!
1
2
2
A
B
2
1

16
OPERATION
Switchingthevibrationon
2.9Switching thegravitysprinkler
systemon resp. off
Fig. 12
lSet the throttlelever1(Fig. 12)toposition
"I"or"MIN".The vibration stopsaftera
short time.
lDrivethe machine forwardsorreverse.
lSet the throttlelever1(Fig. 12)toposition
"II",vibration.
Fig. 14
Switchingthevibration off
Fig13
lSet the throttlelever1(Fig.13)toposition
“I”or “MIN”.The vibrationstopsaftera
short time.
iNote
Forshortbreaks always set the throttle leverto
position "MIN"(idling speed).
Fig. 15
Position "I"=sprinklersystemswitched on
Position "II"=sprinklersystemswitched off
2.10Stopping theengine
!Danger
When parking on aslope placeasuitable chock
in front oforbehind the drum.
A
B
MIN
Ⅱ
1
1

17
OPERATION
Fig. 16
lReleasethe travelcontrollever2(Fig.16)
slowly.
lSet the throttlelever(1)to"MIN"
(idling speed)and letthe engineidlefora
whilefortemperatureequalization.
Fig. 17
lSwitchthe ignition switch(Fig. 17)to
position "OFF",the engine willstop.
Fig. 18
lClosethe fuelvalve1(Fig.18)indirection
of arrow.
2.11Loading andtransport
Fig. 19
lLoading the machine. If necessary foldthe
steering rod up.
lForloading attachthe lifting tackletothe
lifting hookson the frame.
Forweights referto thetechnicaldata.
!Danger
Lash themachinedown,so thatitis
securedagainstrolling, slippingandturning
over.
Forloading, lashingand liftingusealways
shacklesattheliftingpoints.
When lifting themachinedonotstep under
loadsbeing lifted.
2
2
MIN

18
MAINTENANCE
3.1GeneralNotesforMaintenance
Makesurethat the respectivesafety
regulationsarefollowed during the
maintenance, especiallythe safetyregulations
stated insection 2of theseoperating,
maintenanceand repairinstructions.
Propermaintenanceofthe vibratory plate
ensuresamuchhigherfunctional safetyand
increasesthe
lifetimeofimportantparts.The necessary
maintenanceeffortsarebyno means
proportionaltothe
damagesthatmayoccurbynon-observance.
lClean the vibratoryplateand the engine
thoroughlybeforestartingmaintenance
work.
lPlacethe vibratory plateonan even
surfaceformaintenance.
lPerformmaintenanceonlywhen the
engine isturned off.
lCatchrunning outoilsand fuel inaway
harmless tothe environmentand do not
allowthemtoseep intothe ground or
sewagesystem.Disposeofoilsand fuelin
awayharmless tothe environment.
Frequentcausesoffailures
lFaultyoperation
lIncorrect, insufficientmaintenance.
3.2Fuelsand Lubricants
Engineoil
During operationinwinterusewinterengineoil!
Toensureareliablecoldstart, it isimportantto
choosethe viscosity(SAE-class)of the engine
oilaccordingtothe surrounding temperatures.
During operation inwinterunder-10 °C(14 °F),
the oilchange intervalsmust be shortened.
Too viscouslubrication oilwill causedifficulties
whenstarting,forthisreason the temperature
during the engine startinwinterisdecisivefor
the viscositychoice.
Oilviscosity
Becauselubricant oilchangesitsviscositywith
the temperature,the surrounding temperature
at
the operating area of the engine isdecisivefor
the choiceofthe viscosityclass (SAE-class)
(see diagram).
Ifthe temperatureoccasionallyfallsbelowthe
limit(e.g.the useof SAE15W/40 up to-15 °C),
the coldstart abilitycouldbe impaired,although
thisdoesnot lead toanyengine damage.
Temperaturedependent oilchangescan be
avoided byusing multigrade oils.The following
mentioned oil change intervalsarealsovalidfor
multigrade oils.
Fig. 21

19
MAINTENANCE
Regular lubricantoilchange
The longest permitted lengthoftimeforthe lubricant oilfilling is1year.
3.3Fuels, Lubricantsand Filling Capacities
Assemblies
Fuels,Lubricants
Summer Winter
Approx.quantity
Attention
Observelevel marks
Engine
-Airfilter
-Fuel
BDU+Reducer
spring,
drivechain
Engine oil API: CD/SEbzw. CD/SF
SAE 10W/40
(-20°Cto+30°C)
(-4°Fto+86°F)
SAE 15W/40
(-10°Cto+40°C)
(+14°Fto+104°F)
SAE 30
(+5°Cto+30°C)
(+41°Fto+86°F)
SAE 40
(+25°Cto+40°C)
(+77°Fto+104°F)
asengine oil
Petrol (unleaded orstandardgrade)
ATF
Grease
ca. 0,6l
(0.16 USgal)
asrequired
2,5l(0.66 USgal)
Asrequired
SAE 10 W
(-5°Cto-30°C)
(+23°Fto-22°F)
SAE 20W/20
(+10°Cto-10°C)
(+50°Fto+14°F)
