Masport FireGenie FG37-NG Quick start guide

Freestanding Gas Stove
Owners &
Installation
Manual
LISTINGSANDCODEAPPROVALS
These gas appliances have been
tested in accordance with AG 103,
NZS5262andhavebeencertifiedby
the Australian Gas Association for
installation and operation as
described in these Installation and
Operating Instructions.
Your unit should be serviced
annually by an authorised service
person.
918-363
Models: FG37-NG
FG37-LPG
PLEASEKEEPTHESEINSTRUCTIONS
FORFUTUREREFERENCE
Head Office - New Zealand
1-37 Mt Wellington Hwy.Panmure,
P.O. Box 14349
Auckland 6.
Australia
P.O. Box 533
Braeside, Victoria, 3195
WARNING:
Improper installation, adjustment,
alteration, service or maintenance can
cause injury or property damage. Refer to
this manual. For assistance or additional
informationconsultanauthorisedinstaller,
service agency or the gas supplier.
FORYOURSAFETY
Do not store or use gasoline or other
flammablevapoursandliquidsinthevicinity
of this or any other appliance.
Installation and service must be performed
byan authorisedinstaller,serviceagencyor
the gas supplier.
FORYOURSAFETY
What to do if you smell gas:
Donottry to light any appli-
ance
Do not touch any electrical
switch: do not use any
phone in your building.
Immediately call your gas
supplierfromaneighbour's
phone. Follow the gas sup-
plier'sinstructions.
If you cannot reach your
gas supplier, call the fire
department.
01/06/05

2FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater
To the New Owner:
Congratulations! Youaretheownerofastate-of-the-artMasportRearFluedRoomSealedFreestandingGasStovebyFPI
FireplaceProductsInternational.TheMasportGasSeriesofhandcraftedapplianceshasbeendesignedtoprovideyouwith
all thewarmthandcharmofawoodstove,attheflickofaswitch. ThemodelsFG37-NG,andF37-LPGofthisserieshas
beenapprovedbyWarnockHerseyforbothsafetyandefficiency.Asitalsobearsourownmark,itpromisestoprovideyou
witheconomy,comfortandsecurityformanytroublefreeyearstofollow. Pleasetakeamomentnowtoacquaintyourself
withthese instructionsand themany features ofyour MasportRear FluedRoom Sealed FreestandingGas Stove.

FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater 3
TABLE OF CONTENTS
Page Page
OperatingInstructions
OperatingInstructions ............................................... 19
LightingProcedure .................................................... 19
Resettingthe Unit ..................................................... 19
ShutdownProcedure ................................................. 19
First Fire ................................................................... 19
FanOperation ........................................................... 19
AdjustingFlameHeights ........................................... 19
NormalOperatingSoundsofGasAppliances............ 20
SummaryofControls ................................................ 20
Pilot Adjustment ....................................................... 20
CopyofLighting PlateInstructions ............................ 21
Maintenance
MaintenanceInstructions .......................................... 22
GoldPlatedDoors..................................................... 22
LatchAdjustment...................................................... 23
LogReplacement ...................................................... 23
GlassReplacement................................................... 23
FanMaintenance ...................................................... 24
RemovingValve......................................................... 25
PartsList
ReplacementParts List............................................. 26
Warranty
Warranty ................................................................... 31
Specificationsdiagram ................................................ 2
DataPlate................................................................... 4
Installation
Specifications ............................................................. 5
BeforeYouStart ......................................................... 5
GeneralSafetyInformation .......................................... 5
InstallationChecklist ................................................... 6
ClearancestoCombustibles ....................................... 6
LocatingYourMASPORTGasStove .......................... 6
CombustionandVentilationAir ................................... 6
ExteriorFlueTerminalLocations ................................. 7
FluingInstallationPrecautions..................................... 8
SafetyPrecautionsfortheInstaller.............................. 8
PlanningYourFluingInstallation ................................. 8
FluingArrangements-VerticalTerminations ............... 9
Flue Restrictor Position............................................... 9
Fluing:ResidentialandManufactured
Homes/MobileHomesInstallation....................... 10
HorizontalInstallations .............................................. 10
VerticalTerminationwithCo-linear FlexSystem ....... 12
GasConnection ........................................................ 12
System Data Chart - FG37........................................ 12
ConversionfromNGtoLPG ...................................... 13
AerationAdjustment.................................................. 15
LogInstallation.......................................................... 15
DoorInstallation ........................................................ 16
GasPipePressure Testing ....................................... 17
ValveDescription ...................................................... 17
LouvreInstallation...................................................... 17
OptionalRemoteControlInstallation ......................... 18
FinalCheck............................................................... 18
WiringDiagram ......................................................... 18

4FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater
This is a copy of the label that accompanies
eachMASPORTRearFluedRoomSealedFree-
standing Gas Stove. We have printed a copy of
DATA PLATE
the contents here for your review. The data
plate is located on the inside of the drop down
pedestal door.
NOTE: Masport units are constantly being im-
proved. Check the label on the unit and if there
isadifference,thelabelontheunitisthecorrect
one.
(AustraliaOnly)
Gas Type NG LPG
Model
Gas Consumption 31.7 . 31 .
Manifold Pressure 0.89
Injector Size 1x 1x 52
FG37-NG FG37-LPG
mj mj
kPa kPa
##
2.55
37
Electrical: 240VAC 50Hz 1.0 amp max.
Serial
Number
918-364
Model
N2134
Masport Gas Fireplace
2.64mm 1.61mm
AGA Approval number to
Code AG103 6240 6240
281
To be installed by an
authorised person in
accordance with
installation instructions
provided with the appliance
Masport Ltd.
1-37 Mt. Wellington H/Way
Auckland 6
New Zealand
Masport Pty. Ltd.
PO Box 533
Braeside, Victoria. 3195
Distributed by:

FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater 5
INSTALLATION AND REPAIRS
SHOULDBEDONEBYANAUTHOR-
IZEDSERVICEPERSON.THISAP-
PLIANCESHOULDBEINSTALLED,
REPAIRED, INSPECTED BEFORE
USEANDATLEASTANNUALLYBY
AN AUTHORIZED SERVICE PER-
SON. MORE FREQUENT CLEAN-
ING MAY BE REQUIRED DUE TO
EXCESSIVELINTFROMCARPET-
ING,ETC. ITISIMPERATIVETHAT
THE CONTROL COMPARTMENT,
BURNERSANDCIRCULATINGAIR
PASSAGEWAYS OF THE APPLI-
ANCEBEKEPTCLEAN.
IMPORTANT:
SAVE THESE
INSTRUCTIONS
TheMASPORTRearFluedRoomSealedFree-
standingGasStovemustbeinstalledinaccord-
ance AG601 and NZS 5261 and with these
instructions. Carefully read all the instructions
inthismanualfirst.Consultthebuildingauthority
having jurisdiction to determine the need for a
permit prior to starting the installation.
Note: Failure to follow the instructions
could cause a malfunction of the
heater which could result in death,
serious bodily injury, and/or prop-
erty damage. Failure to follow these
instructions may also void your
fire insurance and/or warranty.
SPECIFICATIONS
Fuels: FG37-NG is approved for use with
NG.
FG37-LPG is approved for use with
liquefied petroleum gases (LPG).
Electrical: 240 V A.C. system.
Circulation Fan: Two Speed
Log Sets: Ceramic fibre, 7 per set.
Flue System:
Axial (6-5/8" (168mm) outer / 4"
(102mm) inner liner) rigid flue and
Riser Vent Terminal.
BEFORE YOU START
Safeinstallationandoperationof thisappliance
requires common sense, however, please be
aware of the following:
INSTALLATION
4) We recommend that you plan your installa-
tion on paper using exact measurements
for clearances and floor protection before
actually installing this appliance. Have an
authorized building inspector review your
plans before installation.
GENERAL SAFETY
INFORMATION
1) The appliance shall be installed in accord-
ance with the manufacturer's installation
instructions, local gas fitting regulations,
municipalbuilding codes, watersupplyreg-
ulations, electrical wiring regulations, with
AG 601 (AGA gas installation code) NZS
5261 (New Zealand)
2) Installation and repair should be done
ONLY by an authorised person.
3) DONOTCONNECTTOMASONARYFLUE.
4) This appliance must be connected to
the specified flue and termination cap
to the outside of the building enve-
lope. Never flue to another room or
inside a building. Make sure that the
flue is fitted as per Flueing instruc-
tions.
5) Inspect the flueing system annually for
blockage and any signs of deterioration.
6) Flueingterminalsshallnotberecessedinto
a wall or siding.
7) Any safety glass removed for servicing
must be replaced prior to operating the
appliance.
8) To prevent injury, do not allow anyone who
is unfamiliar with the operation to use the
fireplace.
9) Wear gloves and safety glasses for pro-
tection while doing required maintenance.
10)Be aware of electrical wiring locations in
walls and ceilings when cutting holes for
termination.
11)Under no circumstances should this appli-
ance be modified. Parts that have to be
removed for servicing should be replaced
prior to operating this appliance.
12)Installationandanyrepairstothisappliance
should be done by an authorised service
person. An authorised service person
should be called to inspect this appliance
annually. Make it a practice to have all of
your gas appliances checked annually.
13)Do not slam shut or strike the glass door.
DUE TO HIGH TEMPERATURES,
THEAPPLIANCESHOULDBE LO-
CATED OUT OF TRAFFIC AND
AWAY FROM FURNITURE AND
DRAPERIES.
WARNING: FAILURE TO INSTALL
THIS APPLIANCE CORRECTLY
WILLVOIDYOURWARRANTYAND
MAY CAUSE A SERIOUS HOUSE
FIRE.
CHILDRENANDADULTSSHOULD
BEALERTEDTOTHEHAZARDSOF
HIGHSURFACETEMPERATURES,
ESPECIALLY THE FIREPLACE
GLASS,ANDSHOULDSTAYAWAY
TO AVOID BURNS OR CLOTHING
IGNITION.
YOUNG CHILDREN SHOULD BE
CAREFULLY SUPERVISEDWHEN
THEYAREINTHESAMEROOMAS
THEAPPLIANCE.
CLOTHING OR OTHER FLAMMA-
BLE MATERIAL SHOULD NOT BE
PLACEDONORNEARTHEAPPLI-
ANCE.
1) Provide adequate clearances for servic-
ing, proper operation and around the air
openings into the combustion chamber.
2) The appliance must be installed on a flat,
solid, continuous surface (e.g. wood, met-
al,concrete). Thismaybethe floor, oritcan
be raised up on a platform to enhance its
visual impact. The appliance may be in-
stalled on carpeting, tile, wood flooring or
other combustible material, because the
appliance's metal pedestal base extends
the full width and depth of the appliance.
The MASPORT Rear Flued Room Sealed
Freestanding Gas Stove can be installed in
a wide variety of ways and will fit nearly
any room layout. It may be installed in a
recessedposition,framedoutintotheroom,
or across a corner.
3) The MASPORT Rear Flued Room Sealed
Freestanding Gas Stove is approved for
manufactured home installations, see pag-
es6to9fortherequiredfluearrangements.
If installed into a manufactured home the
unit must be bolted down to the floor.

6FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater
14)Under no circumstances should any solid
fuels (wood, paper, cardboard, coal, etc.)
be used in this appliance.
15)The appliance area must be kept clear and
free of combustible materials, (gases and
other flammable vapours and liquids).
INSTALLATION
CHECKLIST
1) Check Clearances to Combustibles (page
6), location of unit (page 6) and fluing
requirements (pages 6-9).
2) Install fluing: Check all fluing requirements,
pages 8-12.
3) Make gas connections, page 12. Test the
pilot. Must be as per diagram, pages 15 &
22.
4) Ifnecessary,convertfromNGtoLPG(page
13).
5) Install log set, page 15.
6) Install Front Door Front, page 16.
7) Test Gas Pressure, page 17.
8) Install Louvres, page 17.
9) Install optional Remote Control, page 18.
10)Final check, page 18.
Before leaving this unit with the customer, the
installer must ensure that the appliance is firing
correctly and operation fully explained to
customer.
This includes:
1) Clocking the appliance to ensure the cor-
rect firing rate (rate noted on label) after
burning appliance for 15 minutes.
2) If required, adjusting the primary air to
ensurethattheflamedoesnotcarbon.First
allow the unit to burn for 15-20 min. to
stabilize.
CAUTION: Any alteration to the product
that causes sooting or carboning that
results in damage is not the responsibil-
ity of the manufacturer.
LOCATING YOUR
MASPORT GAS STOVE
When selecting a location for your stove, en-
surethattheclearanceslistedabovearemetas
well as ensuring that there is adequate acces-
sibility for servicing and proper operation.
For Flu Termination requirements, see page 7.
This appliance is Listed for bedroom installa-
tions when used with a Listed Millivolt Thermo-
stat. Some areas may have further require-
ments, check local codes before installation.
Thisapplianceis Listed for Alcove installations,
maintain minimum Alcove clearances as fol-
lows,minimumceilingheightof1.7m, minimum
width of 1.0m and a maximum depth of 0.9m.
INSTALLATION
Use the minimum clearances shown in the
diagrams below:
FG37-NG & FG37-LPG Clearances
A Side Wall to Unit 190mm
B Back Wall to Unit 76mm
E Side Wall to Unit 114mm
FG37-NG & FG37-LPG
Reference Dimensions
C Floor to Flue Centerline 635mm
D Side Wall to Flue Centerline 521mm
A) Cross Corner
B) Flush with Wall/Alcove
C) Flat on Wall Corner
D) Flat on Wall
CLEARANCES TO
COMBUSTIBLES
The clearances listed are MINIMUM distances.
Measure the clearance to both the appliance
and the chimney connector. The farthest
distance is correct if the two clearances
do not coincide. For example, if the appliance
issetasindicated inoneofthediagrams butthe
connector is too close, move the stove until the
correct clearance to the connector is obtained.
This appliance may be installed only with the
clearances as shown in the situations pictured.
Do not combine clearances from one type
of installation with another in order to
achieve closer clearances.
Thisunitcanbeinstalled onasolid combustible
surface like a wood floor. This unit can also be
installed directly on carpeting or vinyl when the
bottom pedestal cover plate (provided with unit
) is installed.
COMBUSTION AND
VENTILATION AIR
Thecombustionairfrom thisapplianceis drawn
from outside the building through the outer flue.
Extra provision for combustion air inside
the room is not required.
Minimum ceiling height
is 914 mm from top of
unit.

FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater 7
INSTALLATION
EXTERIOR FLUE TERMINATION LOCATIONS
Minimum clearances required for balanced flue terminals or
the flue terminals of outdoor appliances
according to AG 601 (AGA gas installation code) or NZS 5261 (New Zealand)
Minimum
Clearance (mm)
a Below eaves, balconies or other projections:
- Appliances up to 50 MJ/h input 300
- Appliances over 50 MJ/h input 500
b From the ground or above a balcony 300
c From a return wall or external corner 500
d From a gas meter (M) 1000
e From an electricity meter or fuse box (P) 500
f From a drain or soil pipe 150
g Horizontal from any building structure (unless appliance is approved
for closer installation) or obstruction facing a terminal 500
h From any other flue terminal, cowl or combustion air intake 500
j Horizontally from an openable window, door, or non-mechanical air inlet, or
any other opening into a building, with the exception of sub-floor ventilation
(see also Note (I)):
- Appliances up to 150 MJ/h input 500
- Appliances over 150 MJ/h input 1500
k Vertically below an openable window, door, or non-mechanical air inlet,
or any other opening into a building, with the exception of sub-floor ventilation
(see also Note (I)): see table below
Clearance 'k' in mm
Space Heaters All Other Appliances
Up to 50 MJ/h Up to 50 MJ/h input Over 50 MJ/h input Over 150 MJ/h input
input to 150 MJ/h input
150 500 1000 1500
NOTES:
(I) For mechanical air inlets, including spa blowers, the clearance 'j' and 'k' shall be 1500 mm in all cases.
(II) All distances shall be measured vertically or horizontally along the wall to a point in line with the nearest
par to of the terminal.
(III) Prohibited area below electricity meter or fuse box extends to ground level.
(IV)A flue terminal of this type shall not be located under a roofed area unless the roofed area is fully open on
at least two sides and a free flow of air at the appliance is achieved.

8FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater
PLANNING YOUR FLUING INSTALLATION
INSTALLATION
FLUING
TheMasportRoom SealedSystem(Horizontal
TerminationKit(946-110)andtheVertical Ter-
mination with the Co-linear Flex System in
combinationwiththeMASPORTRoomSealed-
RearFreestanding Gas Stoves(FG37-NGand
FG37-LPG) have been approved and listed as
Room Sealed heater systems by Australian
Gas Association.
The Horiz. Termination Kit (946-110) includes
everything required for a straight through the
wallinstallation,oradda45oelbowfor a corner
installation.
IMPORTANT
Read all instructions carefully before starting
the installation. Failure to follow these instruc-
tions may create a fire or other safety hazard,
andwillvoid the warranty. Be sure tocheckthe
fluing and clearance to combustible require-
ments on pages 6 to 9. Consult your local
building codes before beginning installation.
The location of the termination cap must con-
form to the requirements in the Exterior Flue
Terminal Locations diagram on page 7.
FLUING
INSTALLATION
PRECAUTIONS
The Masport Room Sealed System and the
Vertical Termination with the Co-linear Flex
System are engineered products that have
been designed and tested for use with the
FG37-NG, and FG37-LPG. The Masport war-
ranty will be voided and serious fire, health or
other safety hazards may result from any of the
following actions:
1) Installation of any damaged Room Sealed
component
2) Unauthorized modification of the Room
Sealed System
3) Installationofany componentpartnotman-
ufactured or approved by Masport Indus-
tries Ltd.
4) Installation other than as instructed by
Masport Industries Ltd.
Warning:Alwaysmaintainrequired
clearances (air spaces) to nearby
combustibles to prevent a fire haz-
ard.Donot fill air spaces withinsu-
lation.
Theminimumclearancerequirementsbetween
the outer wall of the flue pipe and nearby
combustible surfaces is 30mm. Be sure to
check the flue termination clearance require-
ments from decks, windows, soffits, gas reg-
ulators, air supply inlets and public walkways
asspecifiedonpage7andinyourlocalbuilding
codes.
The gas appliance and flue system
mustbeflueddirectlytotheoutside
of the building, and never be at-
tached to a chimney serving a sep-
arate solid fuel or gas-burning ap-
pliance.
Each Room Sealed gas appliance must use its
own separate flue system. Common flue sys-
tems are prohibited.
SAFETY
PRECAUTIONS FOR
THE INSTALLER
1) Wear gloves and safety glasses for pro-
tection.
2) Exercise extreme caution when using lad-
ders or on roof tops.
3) Be aware of electrical wiring locations in
walls and ceilings.
See page 7 for Exterior Flue Termination
requirements.
When planning your installation, it will be nec-
essary to select the proper length of flue pipe
for your particular requirements. Determine the
minimum clearance to combustibles from the
rear of the unit to the wall. It is also important to
note the wall thickness. Before cutting the flue
hole through the wall ensure that ALL flue and
terminationclearances(seepage7)willbemet.
*If this is an outside corner, the minimum distance between the flue and the outside corner
is 12" (30cm). See "F" on the diagram on page 7.
NOTE: Ensure compliance with the outside
flue terminal location before cutting hole as
both dimensions must be met.
Forcornerinstallation,Restrictormust
be set at 1-1/4" (32mm) open. For straight rear installation, Restric- tormustbesetat1-1/8"(29mm)open.

FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater 9
INSTALLATION
FLUING ARRANGEMENTS - VERTICAL TERMINATIONS
FOR BOTH RESIDENTIAL & MANUFACTURED HOMES/MOBILE HOMES
Offset to Vertical Terminations
If connecting to a Dura-Vent sys-
tem, the Adapter to Dura-Vent #
640-994 is required.
Vertical Terminations
with Co-linear Flex System
The shaded area in the diagram shows the allowable vertical
terminations installed in a masonry chimney. All vertical flue
installations require the Flue Restrictor to be set to 32mm open. All
Vertical Flue Terminals must be Simpson Dura Vent (Abey Australia)
DV 980 MAS (Australian Modified.)
Vertical Terminations
using Dura-Vent Fluing System
The shaded areas in the two diagrams below show all allowable
combinations of straight vertical and offset to vertical runs with
vertical terminations. Maximum one 90oelbow. All vertical and
offset to vertical flue installations require Flue Restrictor to be set to 32mm
open. If the flue is ENCLOSED in a chase (min. size 229mm x 229mm)
maintain a 32mm clearance to combustibles. All Vertical Flue Terminals
must be Simpson Dura Vent (Abey Australia) DV 980 MAS (Australian
Modified.)
Straight Vertical Terminations
FlueRestrictorPosition
Vent Restrictor
Vent
Restrictor
Plate
Vent Restrictor
(fully open)
Vent
Restrictor
Plate
44.5mm 44.5mm 32mm 32mm
To set the Flue restriction
asindicatedinthediagram,
simply loosen the screws
and push the flue restrictor
platetothecorrectposition.
Tighten the screws.
216mm
9.1m Max.
3.2m Min.
1
1
1
2
4
5
6
7
8
2
1
3
9
Horizontal Distance (meters)
Vertical Height (meters)

10 FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater
Pipe Length (max. 457mm)
Part #946-201 (168mm Dia)
#946-207 (102mm Dia.)
Decorative
Wall Trim
Part #640-545
Astro Riser Vent
Terminal
Part# 946-584
Wall Thimble
Part # 946-202
(required in
timber walls)
o
INSTALLATION
Diagram 2
HORIZONTAL INSTALLATIONS
Diagram 1
*Dia 2: Local codes or regulations may require
different clearances.
RESIDENTIAL AND MANUFACTURED HOMES/
MOBILE HOMES INSTALLATIONS
You will require the following components with your new Masport Rear Flued Room Sealed Freestanding Gas Stove. Please review your product
to make sure you have everything you need. In the event that you are missing any part, contact your dealer.
Note: These are the minimum pieces required.
Other parts may be required for your particular installation.
Minimum components for a Horizontal Installation:
946-110 Horizontal Termination Kit which includes:
1 946-201 6-5/8" dia. x 18" (168mm dia. x 457mm) Black Pipe
1 946-207 4" dia. x 18" (102mm dia. x 457mm) Aluminum Flue
1 946-584 Astro Riser Vent Terminal
1 946-202 Wall Penetration Heat Shield for Heat Sensitive walls
(Wall Thimble) (2 pcs)
1 640-545 Decorative Wall Trim (Black)
1 948-128 TubeMill-Pac
Screws
Optional Components:
946-204 45oElbow - 6-5/8" (168mm) Black pipe
and 4" (102mm) Aluminum Flue
946-205 Vinyl Siding Shield for Riser Vent
Terminal
946-208/P Flue Guard
940 Square Wall Thimble Cover*
942 WallPenetration
HeatShield*
* Simpson Dura-Vent components
1) Set the unit in its desired location. Check to
determine if wall studs are in the way when
the fluing system is attached. If this is the
case, you may want to adjust the location
of the unit.
2) Assemble the desired combination of pipe
and elbow to the appliance adapter with
pipe seams oriented down. Offset the pipe
seams as double seams in one place will
cause the outer pipe to take an oval shape.
Kit comes complete with 18" (457mm) of
straight flue - 6-5/8" (168mm) dia. black
outer pipe and 4" (102mm) dia. inner flue.
3) Withthepipeattachedtothestove,slidethe
stove into its correct location, and mark the
wall for a 9-1/2" (241mm) (inside dimen-
sions) round hole. The center of the round
holeshouldlineupwiththecenterlineof the
horizontalpipe, as shown in diagram 1. Cut
and frame the 9-1/2 (241mm) round hole in
the exterior wall where the flue will be
terminated. If the wall being penetrated is
constructed of non-combustible material,
i.e.masonryblockorconcrete,a 7"(178mm)
diameter hole is acceptable.
Note:
a) The horizontal run of flue should have
a 1/4 inch (6mm) rise for every 1 foot
(305mm) of run towards the termina-
tion. Never allow the flue to run down-
ward. This could cause high tempera-
tures and may present the possibility of
a fire.
b) Thelocation of the horizontal fluetermi-
nation on an exterior wall must meet all
local and national building codes, and
must not be blocked or obstructed. For
External Flue Terminal Locations, see
diagram on page 7.
c) Snorkel Terminations:
For installations requiring a vertical rise
on the exterior of the building, Astro
Riser Vent Terminations as shown in
Dia. 2 is available. Follow the same
installation procedures as used for
standard Horizontal Termination.
NEVER install the Astro Riser vent up-
side down.

FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater 11
Diagram 5
Diagram 4
Below Grade Snorkel Installation
IftheSnorkelTerminationmustbeinstalled
below grade, i.e. basement application,
proper drainage must be provided to pre-
vent water from entering the Snorkel Ter-
mination. Refer to Dura-Vent Installation
instructions for details.. Do not attempt to
enclose the Snorkel within the wall, or any
other type of enclosure.
4) Installwallpenetration heat shield in thecenter
of the 9-1/2" (241mm) round hole and attach
with wood screws. The four wood screws
provided should be replaced with appropriate
fasteners for stucco, brick, concrete, or other
types of sidings. Dia. 3.
NOTE: For Snorkel terminations in ABOVE
grade installations, follow national or
local code requirements.
Diagram 3
5) If installing termination on a siding covered
wall, a vinyl siding standoff or furring strips
must be used to ensure that the termination is
not recessed into the siding. Dia. 3.
6) Take the Riser Vent terminal and separate the
Backing Plate from the Riser Vent Front by
removing 8 screws as shown in diagram 4.
7) Install the Backing Plate into the wall
penetration heat shield and attach us-
ing 4 screws. Dia. 4.
8) Connect all pipe sections to unit and
install into wall:
a) Measure pipe length required and
cut to length. Hint: use the cut end
of the 6-5/8" (168mm) dia. outer
pipe at the flue terminal end.
b) Push the pipe sections completely
together,theminimumpipeoverlap
is 1-1/4" (32mm). Secure all outer
pipe joints by using at least two
screws. Locate the screws at the
bottomofthepipesothatthescrew
headsarehiddenonthefinalinstal-
lation. Apply sealant "Mill-Pac" to
inner pipe and high temp silicone
sealantor"Mill-Pac"toouterpipeon
every joint.
Hint: Apply sealant to female end.
c) Before connecting the flue pipe to
the fluetermination,slidetheblack
decorative wall thimble cover over
the flue pipe, then slide the Wall
PenetrationHeatShield(Part#946-
202) over the flue pipe. Dia. 3.
d) Slidetheapplianceandflueassem-
bly towards the wall carefully in-
serting the flue pipe into the riser
vent terminal assembly. It is impor-
tant that the flue pipe extends into
the Riser Vent Backing Plate a suf-
ficient distance so as to result in a
minimum pipe overlap of
1-1/4 inches (32mm). Secure the
connection between the flue pipe
and the flue cap by attaching the
two sheet metal strips extending
from the Riser Vent Backing Plate
into the outer wall of the flue pipe.
Use two aluminum screws provid-
ed to connect the strips to the pipe
section. Bend any remaining por-
tion of the sheet metal strip back
towards the flue cap and cut off
any excess, it will be concealed by
the decorative wall thimble cover.
See diagram 5.
8) Slide the decorative wall thimble up to the
wall surface being careful not to scratch
the paint. See diagram 5.
9) Back outside: Apply sealant to the 4"
(102mm)innerflueand slide the Riser Vent
FrontintotheBackingPlateandfastenwith
8 screws.
IMPORTANT:
When connecting the pipe to the Riser
Vent, apply Mill-Pac to the inner pipe
on the Riser Vent Terminal, around
the bead. Ensure that the flue pipe is
INSTALLATION
pushed past the bead for a secure fit.
10)Seal around the outer edge of the Riser
Vent Backing Plate.

12 FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater
System Data - FG37
Burner Inlet Orifice Sizes:
NG #37
LPG #52
Max. Input Rating 31.7mj
Min. Input Rating 16mj
Supply Pressure
NG min.1.13kPa
LPG min.2.75kPa
Manifold Pressure
NG .89kPa
LPG 2.55kPa
GAS CONNECTION
Thegasconnectionisa1/2"(13mm)NPTMale
Thread. Copper can be used or other con-
nections approved by AG 604.
When using copper or flex connectors use
only approved fittings. Always provide a union
sothat gaslinescan beeasilydisconnectedfor
burner and/or valve servicing. Flare nuts for
copper lines are usually considered to meet
this requirement.
Important: Always check for gas leaks
with a soap and water solution or gas
leak detector. Do not use open flame for
leak testing.
Note: Prior to any pressure testing of
thegassupplypipingsystemthat
exceeds test pressures of 3.45
kPa, this appliance must be dis-
connected from the piping sys-
tem. Iftestpressuresequaltoor
less than 3.45 kPa are used then
this appliance must be isolated
from the piping system by clos-
ingitsindividualmanualshut-off
valveduringthetesting.
VERTICAL TERMINATION WITH
CO-LINEAR FLEX SYSTEM
THEAPPLIANCEMUSTNOTBECONNECTEDTOACHIMNEYFLUESERVING
ASEPARATESOLIDFUELBURNINGAPPLIANCE.
This appliance is designed to be attached to two 3" (76mm) co-linear aluminium flex running the
fulllengthofthechimney.SeetheFluingArrangementschartonpage9forminimumandmaximum
flue lengths. See chart below for minimum distances from roof. Periodically check that the flue
is unrestricted.
Masonry chimneys may take various contours which the flexible liner will accommodate.
However, keep the flexible liner as straight as possible, avoid unnecessary bending.
The Air Intake pipe must be attached to the inlet air collar of the termination cap.
Required Parts:
Part # Description
946-529 Co-linear DV Vertical Termination Cap
948-305 3" Flex - 35 ft.
640-994 FG37 Dura-Vent Adapter
946-563 Co-Axial to Co-Linear Adapter Kit
which contains the following:
Co-linear Flex Adapter (270-585)
Outer Pipe (946-257)
Inner Pipe Adapter (946-219)
Approved Caps
980 Vertical Termination Cap
923GK 3" (76mm) Co-linear Adapter
with flashing
923GK 3" (76mm) Co-linear Adapter
with flashing
INSTALLATION

FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater 13
INSTALLATION
Conversion Kit for NG to LPG Model #516-969
THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER IF IN DOUBT DO NOT DO THIS CONVERSION!!
Burner Orifice
Conversion Kit 516-969 Contains:
Qty. Part # Description
1 904-390 Burner Orifice #52
1 908-528 Red"LPG"label
2 908-255 Label "Converted to LPG"
1 918-334 Instruction Sheet
1 910-920 Pilot Orifice
1) Shut off the gas supply and unplug the
power cord.
2) Open the front door and carefully remove
the logs and lava rock.
3) Remove burner.
4) Remove burner orifice with a 1/2" (13mm)
wrench and discard. Use a wrench to hold
on to the elbow behind the orifice.
5) Reinstall new burner orifice LPG stamped
#52 and tighten.
18)Stick the conversion label "This unit has
been converted to LPG" on the control box
cover.
19)Reverse steps 16, 15 & 12.
Jumper Location
Jumper
8) Remove the NG orifice and replace it with
the LPG orifice.
9) Install the pilot tube to the pilot assembly.
10)Placethepilotassemblyoverthepilotextru-
sion tube and secure it with 2 screws.
11)Adjust the burner areation setting to fully
open and install the burner.
12)Removethepedestalbackcoverbyremov-
ing the 4 Philips screws.
Pilot Tube
7) Lift the pilot assembly and remove the pilot
tube using an 11mm wrench.
6) Remove the 2 screws which hold the pilot.
Pilot
Orifice Pilot Assembly
Pilot
Extrusion
Tube
13)Stick the conversion label "This unit has
been converted to LPG" over top of the
serial number decal.
14)Replace the yellow "NG" label with the red
"LPG"label.
15)Carefully pull out the control box.
Note: The control box is held in place by
velcro.
16)Remove the control box cover by undoing
the 3 screws. Maneuver through antenna.
Control Box
Cover
Antenna
17)Remove the jumper using a plier.
20)Open the bottom door and remove the front
panel by undoing the 6 screws.

14 FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater
InstallerNotice:
Theseinstructionsmustbeleftwith
the appliance.
Minimum pressure: Remove one of the
cables connected to the electric modulator.
Keeping the nut (B) blocked, screw in the
screw (C) to increase the pressure and
screw it out to decrease it. Use a screw-
driver 6 x 1 blade.
NOTE: The outlet pressure must be set to
minimum0.74kPa.
After carrying out all adjustments, block
the setting screws with paint, taking care
not to obstruct the breather orifice of the
pressure.
Put back the modulator plastic cap.
WARNING: To ensure the correct opera-
tionofthemodulatoritisnecessarythatthe
plastic cap (A) is returned to its original
location.
23)At the end of all setting and adjustment
operations, check electrical insulation and
gas leaks.
24)Reverse step 20.
25)Check operation of fan and flame control.
26)Check for proper flame appearance and
glow on logs.
Cable
Electric
Modulator
22) Adjusting the Outlet Pressure
All the adjustments must be carried out
in the following order:
Removethemodulatorplasticcap(A) using
needle nose pliers.
Maximumpressure: TurntheunitONto its
highest input rating. Screw in the nut (B) to
increase the outlet pressure and screw it
out to decrease it. Use a 10 mm wrench.
NOTE: The outlet pressure must be set to
maximum2.65kPa.
21)Turn on the gas supply and plug in the
power cord.
C
BA
INSTALLATION

FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater 15
INSTALLATION
C)02-44
AERATION
ADJUSTMENT
The burner aeration is factory set but may need
adjusting due to either the local gas supply, air
supply or altitude.
NG: 10mm open
LPG: 10mm open
The aeration adjustment gears are located on
the right side of the burner box and can be
accessed from the side or from the front when
the louvres are removed.
To adjust the aeration: use the allen key to turn
the turning gear which will adjust the air shut-
ter.Opentheairshutterforablueflameorclose
it for a yellower flame. This adjustment is
performed by an authorized installer. The fac-
tory setting should be sufficient for most instal-
lations.
Clockwise to open,
counter-clockwise to close.
Caution: Carbon will be produced if the air
shutter is closed too much.
Note: Any damage due to carboning re-
sulting from improperly setting
the aeration controls is NOT cov-
ered under warranty.
LOG SET
INSTALLATION
Read the instructions below carefully
and refer to the diagrams. If logs are
broken do not use the unit until they are
replaced. Broken logs can interfere with
the pilot operation.
The gas log kit contains the following:
a) 02-65 Rear Log
b) 02-56 Middle Left Log
c) 02-44 Front Left Log
d) 02-46 Left Top Log
e) 02-45 Front Right Log
f) 02-47 Center Log
g) 02-48 MiddleRightLog
h) Embers
i) Lava
Note: Install Optional Brick Panels prior
to installing logs.
Embers Embers
The "02" refer numbers (i.e. 02-65) are
molded into the rear of each log.
1) Carefully remove the logs from the box and
unwrap them. The logs are fragile, handle
with care - do not force into position.
2) Sprinkle the embers on the left and right
sides of the firebox base.
Pins on Rear Log Support
A)02-65
B)02-56
3) Place Rear Log A)02-65 on the two pins on
the rear log support.
4) Place the Middle Left Log B)02-56 on the
two pins as shown.
5) Sprinkle some lava rock just in front of B)
02-56 on the burner holes.
lava rock
B)02-56
6) Place Front Left Log C)02-44 onto the 2
front pins as shown.

16 FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater
Diagram 2
Diagram 3
4) The latches should already be at the
proper setting. If they are too hard or too
easy to close, you may want to adjust
them by loosening the locking nut and
turning the latch catch. See diagram 3.
5) Remove the blue plastic protective coat-
ing from the glass.
6) Test the seal around the door by placing
apieceofpaperbetween the unit and the
door, close the door and try to pull the
paper out. If it slips out easily, then the
door is not properly sealed. Tighten or
loosenthe latchbyturning thelatchcatch
inward or outward. See diagram 3.
Note: The door latch may require ad-
justment as the door gasket ma-
terial compresses after a few
fires and after glass replace-
ment. Turn the latch catch in-
ward or outward.
Diagram 1
DOOR INSTALLATION
(Packaged Separately)
1) Open the two side panels.
2) Slide the door
onto the two
hingepins mak-
ing sure the
two pieces are
flush together.
See diagram
Cutout
Pin Notch
D)02-46
B)02-56
A)02-65
E)02-45
Bracket
A)02-65
The bottom right edge of Log G)02-48 must
sit snugly against the bracket
Side View
G)02-48
E)02-45
F)02-47
1.
3) Close the door. The
latch plate must be
centered around the
alignment pin. See dia-
gram 2. If the latch plate
interferes with the cor-
ner of the stove you may
want to angle the plate
slightly so the door clos-
es easier.
7) Place the Left Top Log D)02-46 on the pin
on Log B)02-56 and on top of the cutout on
Log A)02-65.
E)02-45
C)02-44
8) Place Front Right Log E)02-45 on the two
pins as shown.
9) Place thelavarockintheareabetweenthe
left and right logs, leaving a space in the
middle for log (F) 02-47.
CutoutNotch
F)02-47
E)02-45
10)Place the notch in Center Log F)02-47 over
Log E)02-45 and across the cutout on Log
A)02-65.
11)Position notch in Front Right Log G)02-48 on
Log F)02-47 and push the bottom right edge
against the bracket on the burner tray.
G)02-48
12)Test fire to ensure proper light off (make sure
flame flows smoothly from one end of burner
to the other. If there is any flame hesitation,
checkthatareaforanyblockageoftheburner
port.
F)02-47
E)02-45
A)02-65
G)02-48
D)02-46
B)02-56
C)02-44
INSTALLATION

FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater 17
INSTALLATION
LOUVRE
INSTALLATION
Attachthetop&bottomlouvrestothesidestove
panel using 2 screws per side.
GAS PIPE PRESSURE
TESTING
The appliance must be isolated from the gas
supply piping system by closing its individual
manual shut-off valve during any pressure
testing of the gas supply piping system at test
pressures equal to or less than 1/2 psig. (3.45
kPa). Disconnect piping from valve at pres-
sures over 3.45 kPa.
The manifold pressure is controlled by a regu-
lator built into the gas control, and should be
checked at the pressure test point.
Note: To properly check gas pressure,
both inlet and manifold pressures
should be checked using the valve
pressure ports on the valve.
1) Makesurethevalveisinthe"OFF"position.
2) Loosen the "IN" and/or "OUT" pressure
tap(s), turning counterclockwise with a 1/
8" wide flat screwdriver.
3) Attach manometer to "IN" and/or "OUT"
pressure tap(s) using a 5/16" (8mm) ID
hose.
4) Light the pilot and turn the valve to "ON"
position. Read manometer.
5) The pressure check should be carried out
with the unit burning and the setting should
be within the limits specified on the safety
label.
6) When finished reading manometer, turn off
the gas valve, disconnect the hose and
tighten the screw (clockwise) with a 1/8"
flat screwdriver. Note: Screw should be
snug, but do not over tighten
S.I.T. Valve Description
1) On-Off Solenoid Valve EV1
2) On-Off Solenoid Valve EV2
3) Inlet Pressure Test Point
4) Outlet Pressure Test Point
5) Connection for Pressure Regulator/Com-
bustion Chamber Compensation
6) Pressure Regulator for Minimum and Max-
imum Outlet Pressure
7) Gas Outlet Pressure Electric Modulator
8) PilotOutlet
9) Main Gas Outlet
10)Side Outlet

18 FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater
FINAL CHECK
Before leaving this unit with the customer, the
installer must ensure that the appliance is firing
correctly. This includes:
1) Clocking the appliance to ensure the cor-
rect firing rate (rate noted on label) at 15
minutes.
2) If required, adjusting the primary air to
ensurethattheflamedoesnotcarbon.First
allowthe unittoburn for 15min.to stabilize.
CAUTION
Any alteration to the product that causes
sooting or carboning that results in dam-
age to the exterior facia is not the respon-
sibility of the manufacturer.
INSTALLATION
WIRING
CAUTION: Labelall wires prior to
disconnectionwhenservicingcon-
trols. Wiring errors can cause im-
proper and dangerous operation.
WARNING:ElectricalGroundingInstructions
Thisapplianceisequippedwithathreepronged(grounding) plug for yourprotectionagainstshockhazardandshouldbe
pluggeddirectlyintoaproperlygroundedthree-prongreceptacle.Donotcutorremovethegroundingprongfromthisplug.
Thisheaterdoesnotrequirea240VA.C.supply
for the gas control to operate. A 240V A.C.
power supply is needed for the fan/blower
operation.
Caution: Ensure that the wires do
not touch any hot surfaces and are
away from sharp edges.
OPTIONAL
REMOTE CONTROL
Use the Masport Remote Control Kit approved for
this unit. Use of other systems may void your
warranty.
The remote control kit comes with a hand held
transmitter and a wall mounting plate.
1) Choose a convenient location to mount the
hand held transmitter, protection from extreme
heat is very important.
The remote can also be used as a wall thermostat.
PILOT
FLAME SENSOR
SPARK IGNITOR
TO SIT 845 VALVE
BLUE (NEUTRAL)
BROWN (ACTIVE)
GREEN
BLUE
BLACK
RED
WHITE
FAN
VIOLET
LOW SPEED
HIGH SPEED
BROWN
VIOLET
VIOLET
YELLOW
2
JUMPER
RESET SWITCH (NC)
YELLOW
11112
10 897 564
BLACK
BLACK
231
ORANGE
ORANGE
ORANGE
ORANGE
MODULE - GROUND
MODULE - FLAME
MODULE - SPARK
GREEN
RED
RED
IGNITION MODULE: S.I.T. #0.537.201
VALVE:- S.I.T. SIGMA 845
ON/OFF
FAN
FLAME
+-
+-
BLUE COVER
MANUAL CONTROL
MED
FAN
NEUTRAL
NEUTRAL
Electronic Control Module
ACTIVE
LOW
THERM
HIGH
TH2
TH1
MOD1
MOD2
GND
GND
GND
GND

FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater 19
OPERATING INSTRUCTIONS
FIRST FIRE
TheFIRSTFIREinyourheaterispartofthepaint
curing process. To ensure that the paint is
properly cured, it is recommended that you
burn your fireplace for at least four (4) hours
the first time you use it with the fan on.
When first operated, the unit will release an
odour caused by the curing of the paint and the
burningoffof any oils remaining from manufac-
turing.Smokedetectorsinthehousemaygooff
at this time. Open a few windows to ventilate
the room for a couple of hours. The glass may
require cleaning.
NOTE: The main burner will always start on
"HIGH"andresumeit'slastsettingafter
20 seconds of operation.
NOTE: When the glass is cold and the appli-
ance is lit, it may cause condensation
and fog the glass. This condensation is
normal and will disappear in a few
minutes as the glass heats up.
DONOTATTEMPTTOCLEANTHEGLASS
WHILEITISSTILLHOT!
DONOTBURNTHEAPPLIANCEWITH-
OUTTHEGLASSFRONTINPLACE.
OPERATING
INSTRUCTIONS
Before operating this appliance, proceed
through the following check list.
1) Read and understand these Instructions
before operating this appliance.
2) Check to see that all wiring is correct and
enclosed to prevent possible shock.
3) Check to ensure there are no gas leaks.
4) Make sure the three pieces of door glass
are properly positioned. Never operate the
appliance with any of the glass removed or
with the door open.
5) Verify that all flueing and the cap is unob-
structed.
6) Verify log placement.
LIGHTING
INSTRUCTIONS
1) Plug the power cord into a power outlet.
2) Pressandrelease theON/OFFbuttononce
to start the unit.
3) After approximately 3 seconds the spark
ignition system will spark for 40 seconds to
light the main burner.
4) If the main burner does not light, reset the
unit.
RESETTING
THE UNIT
1) Open the pedestal door on the unit.
2) Press the reset button for approximately 3
seconds and release. The reset button is
located on the unit's control panel.
3) Wait for approximately 3 seconds and the
pilotsparks canbeheardand seen.Itwould
take 2 to 3 seconds for the flame to be lit.
SHUTDOWN
INSTRUCTIONS
1) Press the ON/OFF button once.
2) Turn off all electric power to the appliance
if service is to be performed.
FAN OPERATION
Set the fan speed on the control panel located
in behind the pedestal door to adjust fan to the
desired speed.
ADJUSTING FLAME
HEIGHT
There are six flame settings that can be adjust-
ed by pressing and releasing the plus (+) and
minus (-) FLAME button.
The FLAME setting button is located on the
control panel in behind the pedestal door.
Pressing and releasing the plus (+) FAN button
will change the fan speed as follows:
OFF-> LOW->MEDIUM-> HIGH->OFF,etc.
Pressingandreleasingtheminus(-)FANbutton
will be the reverse of the above.
Control Panel

20 FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater
NORMAL OPERATING
SOUNDS OF
GAS APPLIANCES
It is possible that you will hear some sounds
from your gas appliance. This is perfectly nor-
malduetothefactthattherearevariousgauges
and types of steel used within your appliance.
Listed below are some examples. All are nor-
mal operating sounds and should not be
considered as defects in your appliance.
Blower:
Masport gas appliances use high tech blowers
to push heated air farther into the room. It is not
unusual for the fan to make a "whirring" sound
when ON. This sound will increase or decrease
in volume depending on the speed setting of
your fan speed control.
Burner Tray:
The burner tray is positioned directly under the
burner tube(s) and logs and is made of a
different gauge material from the rest of the
firebox and body. Therefore, the varying thick-
nesses of steel will expand and contract at
slightly different rates which can cause "tick-
ing" and "cracking" sounds. You should also be
aware that as there are temperature changes
within the unit these sounds will likely re-occur.
Again, this is normal for steel fireboxes.
Gas Control Valve:
As the gas control valve turns ON and OFF, a
dullclickingsoundmaybeaudible,thisisnormal
operation of a gas regulator or valve.
Unit Body/Firebox:
Different types and thicknesses of steel will
expand and contract at different rates resulting
in some "cracking" and "ticking" sounds will be
heard throughout the cycling process.
SUMMARY OF
CONTROLS
On/Off Button:
If the unit is switched off, pressing and releas-
ing this button once will switch the unit on. The
unit will resume its last settings.
If the unit is switched on, pressing and releas-
ing this button once will switch the unit off.
Flame:
Increase - If the unit is switched on, pressing
andreleasingtheflameplus(+)buttononcewill
increase the flame height to the next available
high setting.
Decrease - If the unit is switched on, pressing
and releasing the flame minus (-) button once
will decrease the flame height to the next
available low setting.
Fan:
Increase - If the unit is switched on, pressing
and releasing the fan plus (+) button once will
increase the fan speed to the next available
high setting.
Decrease - If the unit is switched on, pressing
and releasing the fan minus (-) button once will
decrease the fan speed to the next available
low setting.
PILOT ADJUSTMENT
Periodically check the pilot flames. The correct
flame pattern has 3 strong blue flames.
One flowing around the thermocouple, the sec-
ond flowing across the rear of the burner (it
does not have to be touching the burner) and
the third flame flowing tangent to the spark
ignitor.
NOTE: If you have an incorrect flame
pattern, contact your Masport dealer for
further instructions.
Rear of Burner
Front of Burner
An incorrect flame pattern will have small,
probably yellow flames, not coming into
proper contact with the rear of the burner or
thermopile.
Rear of Burner
Front of Burner
OPERATING INSTRUCTIONS
