Master Bilt BEL-2-30 User manual

ITEM NO. __________________________________________________
PROJECT __________________________________________________
LOCATION _________________________________________________
DATE _________________________ QTY. _______________________
908 Highway 15 North • New Albany, MS 38652
PHONE: [phone] or 662-534-9061 • FAX: [phone] or 662-534-6049 • www.master-bilt.com
CONSTRUCTION
• White painted galvanized steel
cabinet
• Ends must be ordered separately
• 2” foamed-in-place “zero ODP” ure-
thane insulation
• Vertical electronic lighting with T-8
lamps
• Large vinyl cart bumper rail
• Standard cantilever white epoxy-
coated welded wire shelving with
price tag molding
• Shelves rated to support 110 lbs. each
• Pre-wired cabinet-to-cabinet electri-
cal terminal block connectors
• Standard joining kits when
linking together multi-door modules
• Pre-piped drain
DOORS
• Choice of 24” or 30” wide glass
doors
• Self-closing
• Door hinges easily adjustable for
closing tension and leveling
• Standard black door and frame (op-
tional colors available)
FINISH
• Sparkling white polyester enamel
interior and exterior
REFRIGERATION
• All models designed for remote
refrigeration systems
• Refrigerant:
–BEM models: R-22
–BEL models: R-404A
• Factory tested refrigeration system
• Oversized raceway for ease of refrig-
eration piping
• Full length heavy-duty copper tube
evaporator coil
• Choice of electric or hot gas
defrost
• Pre-mounted expansion valve
• Minimum 4” clearance required
between cabinet back and wall with
a 4” open space at top and one or
both ends
• R-factor (insulation efciency
rating): 18.75
• Temperature range:
–BEM models
....................... 34° to 41°F (1°to 5°C)
–BEL models
..................0° to -15°F (18° to -26°C)
WARRANTY
• One year limited parts
FEATURES
BEL-5-30
(shown with
ends installed)
BEM/BEL SERIES
Endless Remote Glass Door
Merchandisers With
Bottom Mounted Coil
OPTIONS
❑ Right or left hand end kits
❑ Custom colors
❑ Insulated and non-insulated
partitions
❑ Stainless steel kickplate
❑ Mounted dial thermometer
❑ Additional cantilever shelves
❑ Solid shelving
❑ Baskets
MEDIUM TEMP MODELS
(24" WIDE DOORS)
❑ BEM-3-24 ❑ BEM-5-24
❑ BEM-4-24 ❑ BEM-6-24
MEDIUM TEMP MODELS
(30" WIDE DOORS)
❑ BEM-2-30 ❑ BEM-4-30
❑ BEM-3-30 ❑ BEM-5-30
LOW TEMP MODELS
(24" WIDE DOORS)
❑ BEL-3-24 ❑ BEL-5-24
❑ BEL-4-24 ❑ BEL-6-24
LOW TEMP MODELS
(30" WIDE DOORS)
❑ BEL-2-30 ❑ BEL-4-30
❑ BEL-3-30 ❑ BEL-5-30

BEM/BEL SERIES
ENDLESS REMOTE GLASS DOOR MERCHANDISERS
WITH BOTTOM MOUNTED COIL
2
TECHNICAL SPECIFICATIONS
MODEL
DIMENSIONS
(in.)
DIMENSIONS
(mm)
NO. OF
DOORS
NO. OF
SHELVES
SHELVING AREA
SQ. FT.
USABLE
CU. FT.
PRODUCT
FACING
SQ. FT.
NO. OF
INTERIOR
LIGHTS L* D H L* D H
5
SHELVES
WITH
OPTIONAL
6TH SHELF
24" WIDE DOOR MODELS
BEM/BEL-3-24 723/8371/4821/21838 946 2096 3 15 52.9 63.6 59.2 32.5 4
BEM/BEL-4-24 961/8371/4821/22442 946 2096 4 20 70.6 84.8 78.7 43.2 5
BEM/BEL-5-24 1197/8371/4821/23045 946 2096 5 25 88.3 106.0 98.0 53.9 6
BEM/BEL-6-24 1435/8371/4821/23648 946 2096 6 30 105.9 127.2 117.0 64.6 7
30" WIDE DOOR MODELS
BEM/BEL-2-30 62 371/4821/21575 946 2096 2 10 45.5 54.6 50.7 27.9 3
BEM/BEL-3-30 927/16 371/4821/22348 946 2096 3 15 68.3 81.9 75.7 41.6 4
BEM/BEL-4-30 1227/8371/4821/23121 946 2096 4 20 91.0 109.2 100.5 55.3 5
BEM/BEL-5-30 1535/16 371/4821/23894 946 2096 5 25 113.8 136.5 125.4 68.9 6
*Add 2" (51mm) to length for each end or insulated partition.
NOTE: Medium temp units furnished with R-22 expansion valve unless otherwise specied. Low temp units furnished
with R-404A expansion valve unless otherwise specied.
MODEL
120 VOLT - 1 PHASE 230 VOLT - I PHASE
LIGHTS HEATERS FANS FANS DEFROST
MEDIUM TEMP 24" WIDE DOORS
BEM-3-24 2.0 2.7 0.9 N/A N/A
BEM-4-24 2.5 3.5 1.4 N/A N/A
BEM-5-24 3.0 4.3 1.8 N/A N/A
BEM-6-24 3.4 5.1 2.3 N/A N/A
MEDIUM TEMP 30" WIDE DOORS
BEM-2-30 1.5 2.1 0.9 N/A N/A
BEM-3-30 2.0 3.1 1.4 N/A N/A
BEM-4-30 2.5 4.0 1.8 N/A N/A
BEM-5-30 3.0 5.0 2.3 N/A N/A
LOW TEMP 24" WIDE DOORS
BEL-3-24 2.0 5.6 N/A 0.5 9.9
BEL-4-24 2.5 7.4 N/A 0.7 13.1
BEL-5-24 3.0 9.1 N/A 0.9 16.4
BEL-6-24 3.4 10.7 N/A 1.2 19.6
LOW TEMP 30" WIDE DOORS
BEL-2-30 1.5 4.5 N/A 0.5 8.5
BEL-3-30 2.0 6.6 N/A 0.7 12.5
BEL-4-30 2.5 8.7 N/A 0.9 16.8
BEL-5-30 3.0 10.6 N/A 1.2 20.9
MODEL
SHIP WT.
LB/KG
MEDIUM TEMP 24" WIDE DOORS
BEM-3-24 1204/547
BEM-4-24 1490/677
BEM-5-24 1760/800
BEM-6-24 2080/945
MEDIUM TEMP 30" WIDE DOORS
BEM-2-30 984/446
BEM-3-30 1500/682
BEM-4-30 1920/872
BEM-5-30 2340/1064
LOW TEMP 24" WIDE DOORS
BEL-3-24 1150/523
BEL-4-24 1520/691
BEL-5-24 1785/811
BEL-6-24 2100/954
LOW TEMP 30" WIDE DOORS
BEL-2-30 1085/493
BEL-3-30 1500/682
BEL-4-30 1900/864
BEL-5-30 2260/1027
ELECTRICAL SHIPPING WEIGHTS
LISTINGS
HOOKUP
Hardwire, remote refrigeration.

3
MODULES REQUIRED FOR 30" WIDE DOOR LINEUPS & BTU PERFORMANCE DATA
NO. OF
DOORS
MODULES REQUIRED TOTAL OVERALL
LENGTH
WITH ONE PAIR
OF 2" ENDS
+20°F SUCTION MIN.
BTUs (75°F STORE,
55% RH, +35°F AVER-
AGE PRODUCT TEMP.)
-11°F SUCTION MIN.
BTUs (75°F STORE,
55% RH, -3°F AVERAGE
PRODUCT TEMP.)
-18°F SUCTION MIN.
BTUs (75°F STORE,
55% RH, -12°F AVER-
AGE PRODUCT TEMP.)
2
DOOR
3
DOOR
4
DOOR
5
DOOR
2 1 66" 2800 3300 3550
3 1 961/2" 3750 4750 5125
4 1 1267/8" 4600 6150 6550
5 1 1573/8" 5750 7625 8300
6 2 189" 6900 9150 9960
7 1 1 2193/8" 8050 10,675 11,620
8 1 1 2497/8" 9200 12,200 13,280
9 1 1 2801/4" 10,350 13,725 14,940
10 2 3103/4" 11,500 15,250 16,600
11 2 1 3423/8" 12,650 16,775 18,260
12 1 2 3723/4" 13,800 18,300 19,920
13 1 2 4031/4" 14,950 19,825 21,580
14 1 2 4335/8" 16,100 21,350 23,240
15 3 4641/8" 17,250 22,875 24,900
16 2 2 4953/4" 18,400 24,400 26,560
17 1 3 5261/8" 19,550 25,925 28,220
18 1 3 5565/8" 20,700 27,450 29,880
19 1 3 587" 21,850 28,975 31,540
20 4 6171/2" 23,000 30,500 33,200
21 2 3 6491/8" 24,150 32,025 34,860
22 1 4 6791/2" 25,300 33,550 36,520
23 1 4 710" 26,450 35,075 38,180
24 1 4 7403/8" 27,600 36,600 39,840
25 5 7707/8" 28,750 38,125 41,500
MODULES REQUIRED FOR 24" WIDE DOOR LINEUPS & BTU PERFORMANCE DATA
NO. OF
DOORS
MODULES REQUIRED TOTAL OVERALL
LENGTH
WITH ONE PAIR
OF 2" ENDS
+20°F SUCTION MIN.
BTUs (75°F STORE,
55% RH, +35°F AVER-
AGE PRODUCT TEMP.)
-11°F SUCTION MIN.
BTUs (75°F STORE,
55% RH, -3°F AVERAGE
PRODUCT TEMP.)
-18°F SUCTION MIN.
BTUs (75°F STORE,
55% RH, -12°F AVER-
AGE PRODUCT TEMP.)
3
DOOR
4
DOOR
5
DOOR
6
DOOR
3 1 763/8" 3750 4750 5125
4 1 1001/8" 4600 6150 6550
5 1 1237/8" 5750 7625 8300
6 1 1475/8" 6900 9150 9960
7 1 1 1721/2" 8050 10,675 11,620
8 2 1961/4" 9200 12,200 13,280
9 1 1 220" 10,350 13,725 14,940
10 2 2433/4" 11,500 15,250 16,600
11 1 1 2671/2" 12,650 16,775 18,260
12 2 2911/4" 13,800 18,300 19,920
13 2 1 3161/8" 14,950 19,825 21,580
14 2 1 3397/8" 16,100 21,350 23,240
15 3 3635/8" 17,250 22,875 24,900
16 4 3881/2" 18,400 24,400 26,560
17 1 2 4111/8" 19,550 25,925 28,220
18 3 4347/8" 20,700 27,450 29,880
19 1 3 4593/4" 21,850 28,975 31,540
20 4 4831/2" 23,000 30,500 33,200
21 1 3 5071/4" 24,150 32,025 34,860
22 1 3 531" 25,300 33,550 36,520
23 1 3 5543/4" 26,450 35,075 38,180
24 4 5781/2" 27,600 36,600 39,840
25 5 6033/8" 28,750 38,125 41,500

4
TECHNICAL DRAWINGS
ELEVATION VIEW
PLAN VIEW
SIDE VIEW

5
BEM/BEL SERIES
ENDLESS REMOTE GLASS DOOR MERCHANDISERS
WITH BOTTOM MOUNTED COIL
REQUIRED CONDENSING UNITS
NO. OF
DOORS
+35°F AVERAGE PRODUCT TEMP.
+20°F SUCTION
75°F AIR CONDITIONED STORE
55% RELATIVE HUMIDITY
-3°F AVERAGE PRODUCT TEMP.
-11°F SUCTION
75°F AIR CONDITIONED STORE
55% RELATIVE HUMIDITY
-12°F AVERAGE PRODUCT TEMP.
-18°F SUCTION
75°F AIR CONDITIONED STORE
55% RELATIVE HUMIDITY
COND. UNIT REQUIRED FOR AIR
TEMP. ENTERING CONDENSER*
COND. UNIT REQUIRED FOR AIR
TEMP. ENTERING CONDENSER*
COND. UNIT REQUIRED FOR AIR
TEMP. ENTERING CONDENSER*
90°F 100°F 110°F 90°F 100°F 110°F 90°F 100°F 110°F
2
MHHX0061B MHHX0061B MHHX0061B MHLZ0071 MHLZ0071 MHLZ0071 MHLZ0091 MHLZ0091 MHLZ0091
3
MHHX0061B MHHX0061B MHHX0061B MHLZ0071 MHLZ0091 MHLZ0091 MHLZ0091 MHLZ0121 MHLZ0121
4
MHHX0061B MHHX0081B MHHX0081B MHLZ0091 MHLZ0091 MHLZ0121 MHLZ0121 MHLZ0121 MHLZ0121
5
MHHX0081B MHHX0081B MHHX0111 MHLZ0091 MHLZ0121 MHLZ0121 MHLZ0121 MCLZ0141 MCLZ0171
6 MHHX0111 MHHX0111 MHHX0111 MHLZ0121 MHLZ0121 MCLZ0141 MCLZ0141 MCLZ0171 MDLZ0201
7 MHHX0111 MHHX0111 MHHX0151 MHLZ0121 MCLZ0141 MCLZ0171 MCLZ0171 MDLZ0201 MDLZ0201
8 MHHX0151 MHHX0151 MHHX0151 MCLZ0141 MCLZ0171 MCLZ0171 MDLZ0201 MDLZ0201 MDLZ0231
9 MHHX0151 MHHX0151 MHHX0191 MCLZ0171 MCLZ0171 MDLZ0201 MDLZ0231 MDLZ0231 MDLZ0291
10 MHHX0151 MHHX0191 MHHX0191 MCLZ0171 MDLZ0201 MDLZ0231 MDLZ0231 MDLZ0291 MDLZ0291
11 MHHX0191 MHHX0191 MHHX0221 MDLZ0201 MDLZ0231 MDLZ0231 MDLZ0291 MDLZ0291 MDLZ0331
12 MHHX0191 MHHX0221 MHHX0221 MDLZ0231 MDLZ0231 MDLZ0291 MDLZ0291 MDLZ0291 MDLZ0331
13 MHHX0191 MHHX0221 MHHX0251 MDLZ0231 MDLZ0291 MDLZ0291 MDLZ0291 MDLZ0331 BCLZ0750
14 MHHX0221 MHHX0251 MHHX0251 MDLZ0291 MDLZ0291 MDLZ0291 MDLZ0331 BCLZ0750 BCLZ1000
15 MHHX0251 MHHX0251 MHHX0301 MDLZ0291 MDLZ0291 MDLZ0331 BCLZ0750 BCLZ0750 BCLZ1000
16 MHHX0251 MHHX0251 MHHX0301 MDLZ0291 MDLZ0331 BCLZ0750 BCLZ0750 BCLZ1000 BCLZ1000
17 MHHX0251 MHHX0301 MHHX0351 MDLZ0291 MDLZ0331 BCLZ0750 BCLZ1000 BCLZ1000 BCLZ1000
18 MHHX0301 MHHX0301 MHHX0351 MDLZ0331 BCLZ0750 BCLZ1000 BCLZ1000 BCLZ1000 BCLZ1000
19 MHHX0301 MHHX0351 MHHX0351 BCLZ0750 BCLZ0750 BCLZ1000 BCLZ1000 BCLZ1000 BCLZ1000
20 MHHX0301 MHHX0351 MHHX0441 BCLZ0750 BCLZ1000 BCLZ1000 BCLZ1000 BCLZ1000 BCLZ1500
21 MHHX0351 MHHX0351 MHHX0441 BCLZ0750 BCLZ1000 BCLZ1000 BCLZ1000 BCLZ1000 BCLZ1500
22 MHHX0351 MHHX0441 MHHX0441 BCLZ1000 BCLZ1000 BCLZ1000 BCLZ1000 BCLZ1500 BCLZ1500
23 MHHX0351 MHHX0441 MHHX0441 BCLZ1000 BCLZ1000 BCLZ1000 BCLZ1000 BCLZ1500 BCLZ1500
24 MHHX0441 MHHX0441 MHHX0441 BCLZ1000 BCLZ1000 BCLZ1000 BCLZ1500 BCLZ1500 BCLZ1500
25 MHHX0441 MHHX0441 MHHX0501 BCLZ1000 BCLZ1000 BCLZ1000 BCLZ1500 BCLZ1500 BCLZ1500
*Condensing unit and line size based on 100' line run.
See the Master-Bilt Condensing Unit & Refrigeration Systems I/O Manual for other conditions.
For other than high capacity condensing units, consult factory.
Use this chart to determine the correct condensing unit for your endless lineup.
Unless already indicated, add sufx "B" for one phase or "C" for three phase model.

BID SPECIFICATIONS
NOTE: Cabinet designed for optimum performance in air-conditioned area at 75°F ambient and 55% relative humidity.
All specications subject to change without notice.
Item no. BEM-_______ and/or BEL-
_______.
Provide__________( ) End-
less Remote Glass Door Merchan-
disers - Bottom Mounted model
no. BEM-_______ and/or BEL-
_______.
Merchandiser to be constructed
of white painted galvanized steel
with 2" foamed-in-place “zero
ODP” urethane insulation. Mer-
chandiser designed to be used
as either a stand-alone unit or
combined in a modular endless
design.
Merchandiser to be provided
with vertical electronic lighting
with T-8 lamps, a large vinyl cart
bumper rail and a pre-piped drain.
Standard shelving will be
908 Highway 15 North • New Albany, MS 38652
PHONE: [phone] or 662-534-9061 • FAX: [phone] or 662-534-6049 • www.master-bilt.com
cantilever white epoxy-coated
welded wire with price tag mold-
ing. Five shelves per door will be
provided.
Joining kits are supplied for
linking together multi-door
modules. Merchandiser also to
contain pre-wired cabinet-to-
cabinet electrical terminal block
connectors.
Glass doors will be supplied
with self-closing door hinge and
easy provision for easy adjust-
ment of torsion and leveling.
Merchandiser supplied with ei-
ther 24" or 30" wide glass doors.
Door and frame provided in
standard black nish with op-
tional colors available.
The refrigeration system will be
remote and will contain a full-
length heavy-duty copper tube
evaporator coil and pre-mounted
expansion valve. There will also
be a choice of electric or hot
gas defrost. Additionally, mer-
chandiser will be supplied with
an oversized raceway for ease of
refrigeration piping. BEM models
will use R-22 refrigerant while
BEL models will use R-404A.
Temperature ranges will be:
• BEM models: 34° to 41°F (1°to
5°C)
• BEL models: 0° to -15°F (18° to
-26°C)
Merchandiser to be provided
with one year limited parts war-
ranty.
1259-7/09-web
©Master-Bilt Products division of Standex International, Inc. All rights reserved. Printed in U.S.A.
