Master Bilt Sliding Glass Door Merchandise SMB-430 User manual

ITEM NO. ______________________________________________________
PROJECT ______________________________________________________
LOCATION _____________________________________________________
DATE _________________________ QTY. ___________________________
908 Highway 15 North • New Albany, MS 38652
PHONE: [phone] or 662-534-9061 • FAX: [phone] or 662-534-6049 • www.master-bilt.com
CONSTRUCTION
• 24 gauge painted steel
interior and exterior
• Low prole evaporator coil with
horizontal, forced air system
• Four white epoxy-coated, heavy-
duty, welded wire shelves per
door
• Shelves adjustable in 1/2"
increments
• Dual overhead, high output
uorescent lamps
• Independent on/off light switch
• 8 foot cord with molded plug
(excluding SMB-870)
• 2" foamed-in-place “zero ODP”
urethane insulation
FINISH
• Sparkling white polyester
enamel interior and exterior
DOORS
• Sliding, dual pane, tempered
glass doors
• Self-closing with cord and sash
system
• Extruded aluminum frame doors
• Stainless steel, ball-bearing door
rollers and tracks
• Full length easy-grip door
handles
REFRIGERATION
• Self-contained, bottom mount,
slide-out refrigeration system
• Electric condensate evaporator
• Minimum 4" clearance required
between cabinet back and wall
• Refrigerant: R-134a
• Temperature range:
34° to 41°F (1° to 5°C)
• R-factor (insulation efciency
rating): 17.24
WARRANTY
• Standard limited three year
extended compressor and two
year limited parts and labor
FEATURES
SMB-430
SMB SERIES
Sliding Glass Door
Merchandisers
OPTIONS
❑ Casters
❑ Door lock
❑ Extra shelves
MODELS
❑ SMB-430
❑ SMB-580
❑ SMB-870

NOTE: Cabinet designed for optimum performance in air-conditioned area at 75°F ambient and 55% relative humidity.
All specications subject to change without notice.
908 Highway 15 North • New Albany, MS 38652
PHONE: [phone] or 662-534-9061 • FAX: [phone] or 662-534-6049 • www.master-bilt.com
SMB SERIES
SLIDING GLASS DOOR MERCHANDISERS
TECHNICAL SPECIFICATIONS
LISTINGS
HOOKUP
BID SPECIFICATIONS
Item no. SMB- _______________
Provide_______________( ) Sliding
Glass Door Merchandiser(s), Master-Bilt
model no. SMB-__________.
Merchandiser to have stainless steel,
ball-bearing door rollers and tracks and an
270-6/10-web
©Master-Bilt Products division of Standex International, Inc. All rights reserved. Printed in U.S.A.
SMB-430 and SMB-580 via plug in, 8 foot
long, exible three wire 14/3 cord with
molded plug. SMB-870 is a 115/60/1 hardwire
with a maximum 30 amp fuse.
PLAN VIEW SIDE VIEW ELEVATION VIEW
independent on/off light switch. Cabinet
to be provided with electric condensate
evaporator and dual overhead high output
uorescent lamps. Provide SMB-430 and
SMB-580 with eight foot cord and molded
plug.
Merchandiser to have standard limited
three year extended compressor warranty
and two year limited parts and labor war-
ranty.
Merchandiser to be UL and C-UL listed as
well as UL EPH classied.
NEMA 5-20P
MODEL
DIMENSIONS
(in.)
DIMENSIONS
(mm)
VOLTS AMPS
UNIT
H.P.
NO. OF
DOORS
NO. OF
SHELVES
STANDARD
SHELF SIZE
(in inches)
CAP.
CU.
FT.
SHIP
CU.
FT.
SHIP
WT.
LB/KGL D H L D H
SMB-430 53 321/4761/21346 819 1930 115 15.0 1/2 2 8 221/4 x 233/843.0 103.0 615/280
SMB-580 70 321/4761/21778 819 1930 115 15.0 1/2 2 8 221/4 x 317/858.0 147.0 900/409
SMB-870 1023/4321/4761/22610 819 1930 115 22.5 3/4 4 16 221/4 x 233/887.0 210.0 1115/507
