FEATURES
CONSTRUCTION
• Seamless stainless steel top
• 24 gauge painted textured
galvanized steel cabinet
• Galvanized steel interior
• Equipped with leveling legs to
correct for unlevel ooring
situations
• Floor drain with garden hose
tting
• Galvanized steel inner liner with
cold wall evaporator
• Anti-condensate heaters under
stainless top cap
• 21/4" foamed-in-place “zero
ODP” urethane insulation
LIDS
• Stainless steel
• Hinged with handles
• Gasket
REFRIGERATION
• Refrigerant:
DC-12D ..........................R-404A
All other models ............ R-134a
• Self-contained, factory tested
refrigeration system
• Force draft hermetic condensing
unit (semi-hermetic unit on DC-
12D with wire and tube con-
denser for low maintenance)
• Minimum 4" clearance required
between cabinet back and wall
• Temperature range:
10° to -10°F (-12° to -23°C)
• R-factor (insulation efciency
rating): 19.40
WARRANTY
• Standard limited three year
extended compressor and two
year limited parts and labor
FEATURES
DC-2S
DC SERIES
Conventional
Ice Cream Storage/Dipping
Cabinets
OPTIONS
❑ Add sufx “SE” for all-
stainless exterior
❑ Custom colors
❑ Lid locks
❑ Legs
❑ Casters
❑ Additional lids
❑ Load level shelves
❑ Dipper well
MODELS
❑ DC-2S ❑ DC-8D
❑ DC-4S ❑ DC-10D
❑ DC-4D ❑ DC-12D
❑ DC-6D
C-UL listing for
all models
except
DC-12D.
DC-8D
Standard
white
Black also
available
NEW
STANDARD TEXTURED EXTERIOR

NOTE: Cabinet designed for optimum performance in air-conditioned area at 75°F ambient and 55% relative humidity.
All specications subject to change without notice.
908 Highway 15 North • New Albany, MS 38652
PHONE: [phone] or 662-534-9061 • FAX: [phone] or 662-534-6049 • www.master-bilt.com
DC SERIES
CONVENTIONAL ICE CREAM STORAGE/DIPPING CABINETS
TECHNICAL SPECIFICATIONS
LISTINGS
HOOKUP
BID SPECIFICATIONS
Item no. DC-_______________
Provide_____________( ) Conventional
Ice Cream Storage/Dipping Cabinet(s),
Master-Bilt model DC-________.
Cabinet will feature textured nish on
exterior with galvanized steel interior.
Cabinet to have ip lids, seamless stainless
steel top, 24 gauge steel walls, galvanized
steel inner liner with cold wall evapora-
287-7/11-web
©Master-Bilt Products division of Standex International, Inc. All rights reserved. Printed in U.S.A.
Via plug in, 9 foot long, exible 3 wire 14/3
cord with molded plug. Ten amp 115V service
is recommended.
PLAN VIEW SIDE VIEW ELEVATION VIEW
tor, anti-condensate heaters under stain-
less steel top, 21/4" foamed-in-place “zero
ODP” urethane insulation and baked-on
polyester enamel nish. Standard leveling
legs provided to correct for unlevel ooring
situations.
The refrigeration system will be self-
contained. DC-12D will contain R-404A re-
frigerant and all other models will contain
R-134a. The temperature range will be 10°
to -10°F (-12° to -23°C).
Cabinet to have standard limited three
year extended compressor warranty and two
year limited parts and labor warranty.
Cabinet to be UL, C-UL (on all except
DC-12D) and NSF listed.
NEMA 5-15P
MODEL
DIMENSIONS
(in.)
DIMENSIONS
(mm)
VOLTS AMPS
UNIT
H.P.
CAN CAP.
DISPLAY/
STORAGE*
CAP.
CU. FT.
SHIP
CU. FT.
SHIP
WT.
LB/KGL D H L D H
DC-2S 317/8211/8341/8810 537 867 115 5.7 1/4 3/1 5.2 19.0 195/89
DC-4S 54 211/8341/81372 537 867 115 5.7 1/4 6/4 11.0 36.0 280/127
DC-4D 305/8301/8341/8778 765 867 115 5.7 1/4 5/2 7.6 27.0 220/100
DC-6D 43 301/8341/81092 765 867 115 5.7 1/4 8/5 12.5 39.0 275/125
DC-8D 54 301/8341/81372 765 867 115 7.3 1/3 11/8 17.3 47.0 365/164
DC-10D 665/8301/8341/81692 765 867 115 7.3 1/3 14/11 22.0 59.0 430/195
DC-12D 845/8301/8341/82149 765 867 115 7.5 1/3** 18/15 29.1 71.0 490/223
*Capacity in 3 gal. cans **Semi-hermetic compressor
C-UL listing for all models except DC-12D.
