MasterChef 18mcpm20qlh User manual

Planetary Mixer
Instruction manual
18mcpm20qlh, 18mcpm30qlh
Distributed by masterchefpr.com
787788-2264 787 788-2269 787 275-1643

Pack Contents
The following is included:
•Food Mixer •Spiral Dough Hook •Whisk
•Mixing Bowl •Beater •Instruction Manual
General Description
This is a kind of changing speed gear mixer. With its planetary
stirring design, it has a compact structure, high efficiency, power
saving and easy operation. It provides as an ideal assistant to you for
bread and cake making.
Technical Parameters
Name
Power
(KW)
Weight
(LBS)
Speed of Stirring Shaft
(r/min)
Overall Dimensions
(inch)
1st
Speed
2nd
Speed
3rd
Speed
18mcpm20qlh
1.1
180
108
195
355
25" x 23.50" x 35.50"
18mcpm30qlh
1.5
396
91
166
282
28" x 26.50" x 50"

Main External Parts Mixer
①Gear change hand lever
②Stirring shaft
③Mixer
④Stainless barrel
⑤Power switch
⑥Bent lever
⑦Safety guard ( may choose the fitting)
⑧Suppor

Operation Instruction
①Standard power supply v/ HzAc. (Please use a plug
with 3 wide contacts and good grounding.)
②Installation of mixer: Put the stirring shaft 2 in Mixer 3 and rotate
it in clockwise direction.
③Starting procedures: Pull the gear change hand lever 1 to position
1 before starting, then turn on the power switch 5 and set the
speed required. After the mixer is in normal operation, pull the
hand lever 6 to the highest point and lift the support 7 to the
highest position.
④Speed transformation: If you want to change speed, please turn
off the power switch 5 firstly, and then pull the gear change hand
lever 1 to the position required.
⑤Shutting down: when the operation is complete, turn off the
power switch 5 firstly, then pull the gear change hand lever 1 to
position 1, and pull back the hand lever 6 to the lowest point and
finally disconnect power supply.
Accessories and Functions
①Whisk: Used for stirring of liquid material, such as cram and egg.
Recommended speed: mid or high speed.
②Beater: Used for stirring of paste, powder and fragmental
material, such as stuffing and cake dough. Recommended speed:
start with low speed, end with mid speed.
③Spiral dough hook: Used for stirring of sticky material, such as
dough. Recommended speed: low speed.

Notes
①The power socket must be provided with a good ground wire
to guarantee the mixer’s good grounding through it. There will
be an electric shock if no ground wire or an improper
grounding mounted. The ground wire can never be connected
with gas pipe, water pipe, lightning rod or telephone line.
Electric leakage should be checked after installation. Once the
power line damaged, the user must replace them in the special
maintain service company.
②Don’t put your hands into the stirring barrel during operation.
Power supply should be disconnected before the mixer is going
to be installed.
③Don’t operate the mixer beyond the time limit to prevent
reduction of its service life.
④The mixer should be mounted on a stable and clean place.
Keep it away from overheated or overwet places and away
from equipment which has strong electromagnet or can
produce strong electromagnet.
⑤Keep the machine clean constantly. Disconnect power supply
before maintenance. Clean it with a piece of soft and a bit wet
cloth. Don’t clean it with liquid or spraying detergent.
Maintenance
Clean the bowl and stirrer daily or after use to maintain hygiene
standard.
The transmission gear box is greased in factory. Check the
greasing each 6 months. To ass or refill grease, open the top cover,
then fill grease from aperture or replace the grease directly.

Trouble Shooting
Problems
Causes
Solutions
Tool shaft does not
rotate after starting
the machine
Loosen electric wiring
Check electric wiring,
tighten those loose
connects
Oil leakage
The seal rings are
worn out
Replace seal rings
Motor temperature
raised while
reduced output
speed
Too low voltage
Check the power
supply
Overloaded
Reduce load
The sped of mixing is
too high or using a
wrong stirrer
Select a suitable speed
and stirrer
The mixing knocks
with the bowl
The stirrer or bowl is
deformed
Repair or replace the
stirrer or bowl
Abnormal noise and
high temperature
from gearbox
Insufficient lubrication
Add or replace the
grease

Warning!
If the equipment is out of function, please make sure that it is
serviced by professional person or please turn to special service point.
ElectricalWiring
This appliance is supplied with a 3 pin, moulded,
BS1363 plug and lead, with a 13 amp fuse as
standard.
The plug is to be connected to a suitable
mains socket. This appliance is wired as
follows:
• Live wire (coloured brown) to terminal marked L
• Neutral wire (coloured blue) to terminal marked N
• Earth wire (coloured green/yellow) to terminal marked E
This appliance must be earthed, using a dedicated
earthing circuit.
If in doubt consult a qualified electrician.
Electrical isolation points must be kept clear of any obstructions. In the event of any
emergency disconnection being required they must be readily accessible.
Compliance
The WEEE logo on this product or its documentation indicates that the
product must not be disposed of as household waste. To help prevent
possible harm to human health and/or the environment, the product
must be disposed of in an approved and environmentally safe recycling
process. For further information on how to dispose of this product
correctly, contact the product supplier, or the local authority responsible
for waste disposal in your area.
parts have undergone strict product testing in order to comply with
regulatorystandardsandspecificationssetbyinternational,independent,and
federal authorities.
products have been approved to carry the following symbol:

Securing pins
Remove the appliance from all packaging.
Fitting/Removing the Bowl
1. Turn Off the appliance.
2. Open the safety guard by turning it to the left
(HLM10 &HLM20) or lifting it above the
mixer (HLM30).
3. Lower the bowl with the bowl handle.
4. Release the locking catches either side of the
bowl.
5. Lift the bowl. The bowl is held in place by two
pins securing the handles to the cradle and a
hole at the back of the appliance which houses
the lug on the bowl lip.
6. Reverse the procedure to fit the bowl.
Changing the Mixer Attachment
1. Turn Off the appliance.
2. Open the safety guard by turning it to the left ( HLM10 & HLM20) or lifting it above the mixer
(HLM30).
3. Lower the bowl with the bowl handle.
4. Push the mixer attachment up and to the left to release it.
5. Insert the desired attachment. Push up and to the right to lock it into place.
6. Raise the bowl.
We recommend the following uses for each attachment:.
Spiral Dough hook
Heavy mixes
dough, pie pastry etc.
Suitable Gears:
1 Slow
Note: Regularly grease the bowl lift mechanism to ensure smooth operation .
Note: Ensure the handle is fully pushed
back and the bowl is completely raised or
the mixer will not work.

Layout of Controls
Gear lever
ON switch
OFF switch
ON button - Press to start the mixer.
OFF button - Press to stop the mixer. Twist clockwise to release and reset HLM30 only).
GEAR LEVER - Use to adjust the speed of the mixer.
Beater
Firm mixes
light pastry, cake/biscuit mix,
icings, fillings and mashed
vegetables
Suitable Gears: 1, 2
Medium
Whisk
Light mixes
whipped cream, mayonnaise, egg
whites, pancakes and soufflés
Suitable Gears: 1, 2, 3
Fast

MixingCapacity
Model
Bowl
Volume
Max Flour
Max Dough
18mcpm20qlh
20Quart
11.00LBS
18.00LBS
18mcpm30qlh
30Quart
16.50LBS
25.00LBS
Changing Mixing Speed
Note: ALWAYS stop the mixer before attempting to change the mixing speed.
With the appliance turned Off:
1. Select the required gear using the gear change lever.
2. Restart the appliance.
OverloadSwitch
The Overload switch is situated at the back of the machine
beside the cable entry. If the appliance becomes too hot the
Overload switch will stop the machine automatically. If
this happens:
1. Turn Off the mixer.
2. Reduce the load in the mixing bowl.
3. Push the Overload switch back in to reset it.
4. Allow the appliance to cool for 20 minutes.
Cleaning, Care & Maintenance
Overload
Switch
• Always turn off the mixer and disconnect from the power supply before cleaning.
• Use warm soapy water to clean the bowl and mixing attachments. Do not use abrasive cleaning
chemicals as these can leave harmful residues.
• Clean the exterior of the appliance with a damp cloth.
• Dry all parts thoroughly after cleaning.
• Do not use jet/pressure washers to clean the appliance.
• Clean the appliance regularly.
Note: In the event of a power cut the Overload switch will cut in to prevent the
appliance from restarting automatically when power is restored.
Note: Always disconnect the Planetary Mixer from the mains powers supply when not
in use.

PARTS of 18mcpm20qlh
SERIAL
NO.
PART
NO.
PART NAME
SERIAL
NO.
PART
NO.
PART NAME
1
20-1
Wire whip
46
20-46
Bushing
2
20-2
Spiral dough hook
47
20-47
Oil seal
3
20-3
Flat Beater
48
20-48
Fore lump
4
20-4
Safety guard
49
20-49
Support
5
20-5
Bowl
50
20-50
Base
6
30-7
Adjusting screw
51
20-51
Nut
7
30-8
Spring
52
20-52
Bearing
8
30-9
Fork pin
53
20-53
Gear shaft
9
20-9
Shifting yoke
54
20-54
Flat key
10
30-11
Eccentric mounting
55
20-55
Circlip for shaft
11
30-12
Handle seat
56
20-56
Gear
12
20-12
Handle seat cover
57
20-57
Bushing
13
20-13
Handle spindle
58
20-58
Gear
14
20-14
Speed handle
59
20-59
Cap
15
20-15
Gear-case gland
60
20-60
Worm
16
20-16
Nut
61
20-61
Oil seal
17
20-17
Pressing plate
62
10-17
Green button
18
30-35
Rubber cover
63
10-16
Red button
19
20-19
Super machine parts
64
20-64
Brand
20
20-20
Declutch shift shaft
66
20-66
Flat key
21
20-21
Spring washer
67
20-67
Worm gear shaft
22
20-22
Nut
68
20-68
Worm gear
23
20-23
Main shaft
69
20-69
Motor (with tool)
24
20-24
Gear + Motor box
70
20-70
Back housing
25
20-25
Lid for attachment hub
72
20-72
Handle
26
20-26
Inner gear
73
20-73
Crank lever
27
20-27
planet gear
74
20-74
Connecting rod
28
20-28
Moving frame
75
20-75
Stud
29
30-36
Bearing
76
20-76
Shutter
30
20-30
Oil seal
77
20-77
Flat washer
31
20-31
Working shaft
78
20-78
Compression spring
32
20-32
Retainer pin
79
20-79
Micro switch
33
20-33
Spring washer
80
20-80
Overload switch
34
20-34
Pressing plate
81
20-81
Power cord
35
20-35
Transmission shaft support
82
20-82
Waterproof Joint
36
30-53
Bearing
83
20-83
Contact switch
37
20-37
Cap for main shaft
84
20-84
Capacitor 1 (running capacitor)
38
20-38
Circlip for shaft
85
20-85
Capacitor 2 (starting capacitor)
39
20-39
Bevel gear
86
20-86
Attachment hub
40
20-40
Gear
87
20-87
Plum wrench
41
30-40
Gear shaft sleeve
88
20-88
Circlip
42
20-42
Claw clutch
89
20-89
Gear
43
20-43
Gear
90
20-90
Timer
44
20-44
Gasket
91
20-91
Timer knob
45
30-26
Bearing

PARTS of 18mcpm30qlh
SERIAL
NO.
PART
NO.
PART NAME
SERIAL
NO.
PART
NO.
PART NAME
1
30-1
Hook
51
30-51
Nut
2
30-2
Beater
52
30-52
Base
3
30-3
Wire whip
53
30-53
Bearing
4
30-4
Safety guard
54
30-54
Transmission shaft support
5
30-5
Bowl
55
30-55
Flat key
6
30-6
Top cover
56
30-56
Circlip for shaft
7
30-7
Adjustig screw
57
30-57
Gear
8
30-8
Spring
58
30-58
Gear shaft sleeve
9
30-9
Fork pin
59
30-59
Gear box
10
30-10
Shifting yoke
60
30-60
Worm
11
30-11
Eccentric mounting
61
30-61
Brand
12
30-12
Handle seat
62
30-62
Motor box
13
30-13
Handle spindle
63
30-63
Back cover
14
30-14
Handle set
64
30-64
Inner gear
15
30-15
Handle cover
65
30-65
Switch shaft
16
30-16
Speed handle
66
30-66
Seal ring
17
30-17
Lid for attachment hub
67
30-67
Gear shaft
18
30-18
Attachment hub
68
30-68
Gear
19
30-19
Plum wrench
69
30-69
Bushing
20
30-20
Circlip
70
30-70
Worm wheel
21
30-21
Gear
71
30-71
Gear
22
30-22
Hood ring
72
30-72
Gasket
23
30-23
Circlip for shaft
73
30-73
Cap fo gear shaft
24
30-24
Planet gear
74
30-74
Nut
25
30-25
Moving frame
75
30-75
Spring washer
26
30-26
Bearing
76
30-76
Bearing
27
30-27
Oil seal
77
30-77
Worm-wheel shaft
28
30-28
Retainer pin
78
30-78
Flat key
29
30-29
Working shaft
79
30-79
Circlip for shaft
30
30-30
Declutch shift shaft
80
30-80
Circlip for shaft
31
30-31
Spring washer
81
30-81
Cap for worm-wheel shaft
32
30-32
Main shaft
82
30-82
Motor (with tool)
33
30-33
Nut
83
30-83
Stop block
34
30-34
Valve cap for main shaft
84
10-17
Green button
35
30-35
Rubber cover
85
10-16
Red button
36
30-36
Bearing
86
30-86
Crank lever
37
30-37
Cap for main shaft
87
30-87
Handle
38
30-38
Super machine parts
88
30-88
Connecting rod
38-1
30-38-1
Super machine parts
89
30-89
Flat wahser
38-2
30-38-2
Gear
90
30-90
Compression spring
38-3
30-38-3
Pin roller
92
30-92
Micro switch
38-4
30-38-4
Spring
93
30-93
Overload switch
39
30-39
Bevel gear
94
30-94
Power cord
40
30-40
Gear shaft sleeve
95
30-95
Waterproof joint
41
30-41
Claw clutch
96
30-96
Contact switch
42
30-42
Gear
97
30-97
Capacitor 1 (running capacitor)
43
30-43
Gasket
98
30-98
Capacitor 2 (starting capacitor)
44
30-44
Bearing
99
30-99
Switch gasket
45
30-45
Bushing
100
30-100
Switch compression spring
46
30-46
Oil seal
101
30-101
Split washer
47
30-47
Stud
102
30-102
Left guard
48
30-48
Bowl hold kits
103
30-103
Right guard
49
30-49
Support
104
30-104
Timer
50
30-50
Spring washer
105
30-105
Timer knob

Ⅰ . Introduction
These Meat grinders are state-of-the-art machines elaborately designed and
manufactured by our company. They possess the following notable advantages:
1. Totally-enclosed gear driving, compact structure and stable operation.
2. Hygienic food processing is our main goal. In fact, the food-contacting
components and the bodies of meat grinders are all made ofpremium stainless
steel. They feature easy cleaning, smooth lines and elegant appearance without
gap hiding contaminants and sharp edge hurting operators.
3. This Meat grinders to facilitate installation and
maintenance. 4. Large meat grinding capacity and high
productivity.
Ⅱ . Main technical parameters:
TYPE
LENGTH
WIDTH
HEIGHT
NET
WEIGHT
GROSS
WEIGHT
MG-TC22
14Inch
10Inch
11 Inch
10 LBS
11 LBS
MG-12
14 Inch
10 Inch
13 Inch
14.50 LBS
15.50 LBS
VS-V12H-AE
20 Inch
11 Inch
10 Inch
22 LBS
24.30 LBS
Ⅲ . Operations
1. Detach and clean the meat-grinding components with clear water, then assemble
it sequentially and lock the handle.
2. Take off the cover and locking bolt, and then fit on the meat grinder
(attachment hub) to the mixer. Tight up the locking bolt.

3. Cut the stuff into pieces of meat whose sizes are similar to that of the feeding inlet
after its skin and bone removed.
4. Feed the stuff into the grinding cavity with the feeding bar. Do not replace the bar
with other tools.
5. Upon completion, detach and clean the meat-grinding components etc.
immediately to prevent bacteria growth.
6. If the discharge is not smooth or the stuff becomes pasty, the reason may be:
1. The locking of the front nut is not tight enough, resulting in poor contact
between the grinding blade and the discharge plate. Readjust the nut.
2. The grinding plate is blocked. Clean it.
3. The grinding blade is too blunt. Sharpen or replace it.
IV. Maintenance
1. Clean the machine thoroughly upon every operation. Wipe the body with just a
piece of wet cloth.
2. Oil the gear cavity on a regular basis. Lubricate the gear and shaft bearing
about half a year with around 0. lkg of lubricant.
3. Protect the grinding blade from damage. If necessary, sharpen orreplace it.
Warning: Do not wash the machine with water directly.

V. Expoded diagram and spare parts list
1. MG-TC22
SN
NAME
QUANTITY
1
Copper bush
2
2
Grinder Head
1
3
Nylon washer
1
4
Bearing
1
5
Propeller
1
6
Shaft pin of propeller
1
7
Knife
1
8
Pressure plate
1
9
Funnel
1
10
Trefoil nut
1
11
Locking bolt
1
12
Stuff tray
1
13
Pusher
1

2. MG-12
SN
NAME
QUANTITY
1
Grinder Head
1
2
Propeller
1
3
Knife
1
4
Pressure plate
1
5
Trefoil nut
1
6
Stuff tray
1
7
Pusher
1

3. VS-V12H-AE
SN
NAME
QUANTITY
SN
NAME
QUANTITY
1
pushing rod
1
13
transmission shaft
1
2
The plastic handle
1
14
The shaft sleeve
1
3
scraping wings
1
15
washer
1
4
front cover
1
16
back over
1
5
fixed pin
1
17
plastic screws
1
6
ball screw
2
18
Locking hook
1
7
lead screw
1
19
lock pin
1
8
Front cover dowel
2
20
Bearing
2
9
knife
2
21
bushing
1
10
1
The blade flange
1
22
support sleeve
1
11
screw
1
23
locating pin
1
12
locating pin
1
24
flange
1
13
transmission shaft
1
25
Shred plate(6MM)
1
14
The shaft sleeve
1
26
Shred plate(8MM)
1
The above diagram is only for reference and subject to change without prior notice.

Declaration of conformity
Equipment Type
Certificate
Planetary Mixer
