MasterForce 241-0948 User manual

1
ROTARY TOOL
241-0948
For questions/comments, technical assistance or repair parts –
Please call toll free: 1-866-349-8665 (M–F 9am–5pm EST)
Or email us at: [e-mail]
OPERATOR’S MANUAL
To Reduce The Risk Of Injury, User Must Read And
Understand Operator’s Manual. Save These Instructions For Future Reference.
CAUTION:
!

2
Front cover ………………………………………………………………………………………..
1
Table of contents ……………………………………………………………………...………....
2
General safety warnings ……………………………………………………………..……….....
3–4
Eye, ear, & lung protection …………………………………………………………………......
3–4
Electrical safety ……………………………………………………………………….………....
4
Power tool safety ……………………………………………………………………...………....
5–6
General warning ………………………………………………………………………………....
5
Work area safety ………………………………………………………….…………..………....
5
Electrical safety ……………………………………………………………………….………....
5
Personal safety ………………………………………………………………………..………....
5–6
Power tool use and care ……………………………………………………………………......
6
Service …………………………………………………………………………………………....
6
Specific safety rules …………………………………………………………………..………....
7
Extension cord safety ……………………………………………………………………………
8
Product specifications ………….………………………………………………………………...
8
Symbols ……………………………………………………………………………………………
9
Know your rotary tool …………………………………………………………………………….
10
Accessories ……………………………………………………………………………………….
11
Accessory description & use …………………………………………………………………….
12–13
Assembly and operating …………………………………………………………………………
14–18
Installing accessory bits ………………………………………………………………………….
14
Removing the 3-jaw chuck and installing a collet ……………………………………………..
14
Installing accessory bit when using the collet nut system ……………………………….......
15
Connecting the flexible shaft to the tool ………………………………………………………..
15
Changing the collet and accessories in the flexible shaft ……………………………………
15–16
Assembling & installing the stand ………………………………………………………………
16
Installing the LED worklight ……………………………………………………………………..
17
Replacing batteries in LED worklight …………………………………………………………..
17
ON/OFF switch ……………………………………………………………………………………
18
Speed control wheel ……………………………………………………………………………..
18
Selecting the proper speed ……………………………………………………………………...
18
Maintenance ………………………………………………………………………………………
19
Exploded view …………………………………………………………………………………....
20
Parts list ………………………………………………………………………………..………....
21
Notes ………………………………………………………………………………………………
22
Warranty ……………………………………………………………………….………………....
23
Back cover ………………………………………………………………………………………..
24
TABLE OF CONTENTS

3
EYE, EAR & LUNG PROTECTION
SAVE THESE INSTRUCTIONS FOR REFERENCE
This instruction manual includes the following:
•General Safety Rules
•Specific Safety Rules and Symbols
•Functional Description
•Assembly
•Operation
•Maintenance
•Accessories
SAVE THESE INSTRUCTIONS FOR REFERENCE
GENERAL SAFETY WARNINGS
WARNING: Before using this tool or any of its accessories, read this
manual and follow all Safety Rules and Operating Instructions. The important
precautions, safeguards and instructions appearing in this manual are not
meant to cover all possible situations. It must be understood that common
sense and caution are factors which cannot be built into the product.
!
!
ALWAYS WEAR EYE PROTECTION THAT CONFORMS WITH CSA
REQUIREMENTS or ANSI SAFETY STANDARD Z87.1
FLYING DEBRIS can cause permanent eye damage. Prescription
eyeglasses ARE NOT a replacement for proper eye protection.
WARNING: Non-compliant eyewear can cause serious injury if
broken during the operation of a power tool.
WARNING: Use hearing protection, particularly during extended
periods of operation of the tool, or if the operation is noisy.
!

4
EYE, EAR & LUNG PROTECTION –cont’d
ELECTRICAL SAFETY
WEAR A DUST MASK THAT IS DESIGNED TO BE USED WHEN
OPERATING A POWER TOOL IN A DUSTY ENVIRONMENT.
WARNING: Dust that is created by power sanding, sawing, grinding,
drilling, and other construction activities may contain chemicals that are
known to cause cancer, birth defects, or other genetic abnormalities. These
chemicals include:
Lead from lead-based paints
Crystalline silica from bricks, cement, and other masonry products
Arsenic and chromium from chemically treated lumber
The level of risk from exposure to these chemicals varies, according to how
often this type of work is performed. In order to reduce exposure to these
chemicals, work in a well-ventilated area, and use approved safety
equipment, such as a dust mask that is specifically designed to filter out
microscopic particles.
!
SAVE THESE INSTRUCTIONS FOR REFERENCE
WARNING: To avoid electrical hazards, fire hazards or damage to
the tool, use proper circuit protection.
This tool is wired at the factory for 120 V AC operation. It must be
connected to a 120 V AC, 15 A circuit that is protected by a time-delayed
fuse or circuit breaker. To avoid shock or fire, replace power cord
immediately if it is worn, cut or damaged in any way.
GENERAL SAFETY WARNINGS

5
WARNING: Read all safety warnings and
all instructions. Failure to follow the warnings
and instructions may result in electric shock, fire
and/or serious injury.
Save all warnings and instructions for future
reference.
Work area safety
Keep work area clean and well lit. Cluttered or
dark areas invite accidents.
Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or
fumes.
Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
Electrical safety
Power tool plugs must match the outlet.
Never modify the plug in any way. Do not
use any adapter plugs with earthed
(grounded) power tools. Unmodified plugs and
matching outlets will reduce risk of electric
shock.
Avoid body contact with earthed or
grounded surfaces such as pipes, radiators,
ranges and refrigerators. There is an
increased risk of electric shock if your body is
earthed or grounded.
Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
Do not abuse the cord. Never use the cord
for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or
entangled cords increase the risk of electric
shock.
When operating a power tool outdoors, use
an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces
the risk of electric shock.
If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD
reduces the risk of electric shock.
Personal safety
Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired
or under the influence of drugs, alcohol or
medication. A moment of inattention while
operating power tools may result in serious
personal injury.
Use personal protective equipment. Always
wear eye protection. Protective equipment
such as dust mask, non-skid safety shoes, hard
hat, or hearing protection used for appropriate
conditions will reduce personal injuries.
Prevent unintentional starting. Ensure the
switch is in the off-position before
connecting to power source and/or battery
pack, picking up or carrying the tool.
Carrying power tools with your finger on the
switch or energizing power tools that have the
switch on invites accidents.
Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key
left attached to a rotating part of the power tool
may result in personal injury.
Do not overreach. Keep proper footing and
balance at all times. This enables better
control of the power tool in unexpected
situations.
POWER TOOL SAFETY
SAVE THESE INSTRUCTIONS FOR REFERENCE
!

6
PERSONAL SAFETY –cont’d
Dress properly. Do not wear loose clothing
or jewelry. Keep your hair, clothing and
gloves away from moving parts. Loose
clothes, jewelry or long hair can be caught in
moving parts.
If devices are provided for the connection of
dust extraction and collection facilities,
ensure these are connected and properly
used. Use of dust collection can reduce dust-
related hazards.
Do not let familiarity gained from frequent
use of tools allow you to become
complacent and ignore tool safety
principles. A careless action can cause severe
injury within a fraction of a second.
Power tool use and care
Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at the
rate for which it was designed.
Do not use the power tool if the switch does
not turn it on and off. Any power tool that
cannot be controlled with the switch is
dangerous and must be repaired.
Disconnect the plug from the power source
and/or the battery pack from the power tool
before making any adjustments, changing
accessories, or storing power tools. Such
preventive safety measures reduce the risk of
starting the power tool accidentally.
Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool. Power tools are
dangerous in the hands of untrained users.
Maintain power tools. Check for
misalignment or binding of moving parts,
breakage of parts and any other condition
that may affect the power tool’s operation. If
damaged, have the power tool repaired
before use. Many accidents are caused by
poorly maintained power tools.
Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to
control.
Use the power tool, accessories and tool bits
etc. in accordance with these instructions,
taking into account the working conditions
and the work to be performed. Use of the
power tool for operations different from those
intended could result in a hazardous situation.
Keep handles and grasping surfaces dry,
clean and free from oil and grease. Slippery
handles and grasping surfaces do not allow for
safe handling and control of the tool in
unexpected situations.
Service
Have your power tool serviced by a qualified
repair person using only identical
replacement parts. This will ensure that the
safety of the power tool is maintained.
POWER TOOL SAFETY
SAVE THESE INSTRUCTIONS FOR REFERENCE

7
WARNING: Know your rotary tool. Do
not plug the tool into the power source until
you have read and understand this
Instruction Manual. Learn the tool’s
applications and limitations, as well as the
specific potential hazards related to this tool.
Following this rule will reduce the risk of electric
shock, fire, or serious injury.
Always wear eye protection. Any
power tool can throw foreign
objects into your eyes and cause
permanent eye damage.
ALWAYS wear safety goggles (not glasses) that
comply with ANSI safety standard Z87.1.
Everyday glasses have only impact resistant
lenses. They ARE NOT safety glasses.
WARNING: Glasses or goggles not in
compliance with ANSI Z87.1 could cause
serious injury when they break.
Hold tool by insulated gripping surfaces
when performing an operation where the
cutting tool may contact hidden wiring or its
own cord. Contact with a “live” wire will make
exposed metal parts of the tool “live” and shock
the operator.
Always make sure the work surface is free
from nails and other foreign objects. Cutting
into a nail can cause the bit and the tool to jump
and damage the bit.
Never hold the workpiece in one hand and
the tool in the other hand when in use. Never
place the hands near or below the cutting
surface. Clamping the material and guiding the
tool with both hands is much safer.
Never lay workpiece on hard surfaces like
concrete, stone, etc. Protruding cutting bit may
cause the tool to jump
Always wear safety goggles and dust mask.
Use only in well-ventilated area. Using
personal safety devices and working in a safe
environment reduces risk of injury.
After changing the bits and accessories or
making adjustments, make sure the collet
nut and any other adjustment devices are
securely tightened. Loose adjustment devices
will be violently thrown.
Always use the correct collet size. If the collet
size is larger than the accessory shank size it
will not grip the shank properly, leading to
possible injury to the operator or damage to the
tool.
Always check accessory bits, grinding
stones, cut-off wheels etc. for damage
before each use. Damaged accessories can
break during use and cause serious injury.
Never use dull or damaged bits. Sharp bits
must be handled with care. Damaged bits can
snap during use. Dull bits require more force to
push the tool, possibly causing the bit to break.
Never touch the bit during or immediately
after use. After use the bit is too hot to be
touched by bare hands.
SPECIFIC SAFETY RULES
SAVE THESE INSTRUCTIONS FOR REFERENCE
!
!

8
WARNING: Keep the extension cord
clear of the working area. Position the cord so
it will not get caught on the workpiece, tools or
any other obstructions while you are working
with the power tool.
Make sure any extension cord used with this
tool is in good condition. When using an
extension cord, be sure to use one of heavy
enough gauge to carry the current the tool will
draw. An undersized cord will cause a drop in
line voltage resulting in loss of power and
overheating.
The table to the right shows the correct size to
use according to cord length and nameplate
ampere rating. If in doubt, use the next heavier
gauge. The smaller the gauge number the
heavier the cord.
Be sure your extension cord is properly wired
and in good condition. Always replace a
damaged extension cord or have it repaired by a
qualified electrician before using it. Protect your
extension cord from sharp objects, excessive
heat and damp or wet areas.
Use a separate electrical circuit for your power
tools. This circuit must not be less than 14
gauge wire and should be protected with either
a 15 A time delayed fuse or circuit breaker.
Before connecting the power tool to the power
source, make sure the switch is in the OFF
position and the power source is the same as
indicated on the nameplate. Running at lower
voltage will damage the motor.
MINIMUM GAUGE (AWG)
EXTENSION CORDS (120 V use only)
Amperage
rating
Total length
More
than
Not
more
than
25'
(7.5 m)
50'
(15 m)
100'
(30 m)
150'
(45 m)
0
6
18
16
16
14
6
10
18
16
14
12
10
12
16
16
14
12
12
16
14
12
Not Applicable
EXTENSION CORD SAFETY
!
SAVE THESE INSTRUCTIONS FOR REFERENCE
Rating:
120 V, 60 Hz AC
Amperes:
1.6 Amp
RPM:
5,000–35,000 RPM (no load)
Chuck type:
3-jaw
Chuck capacity:
1/16” to 1/8”
Weight:
1 lb 6 oz (0.62 kg)
For questions / comments, technical assistance or repair parts –
Please Call Toll Free at: 1-866-349-8665 (M–F 9am –5pm EST)
Or email us at: custom[email protected]
PRODUCT SPECIFICATIONS

9
V
Volts
A
Amperes
Hz
Hertz
W
Watts
kW
Kilowatts
Microfarads
L
Litres
kg
Kilograms
H
Hours
N/cm2
Newtons per square
centimetre
Pa
Pascals
OPM
Oscillations per minute
Min
Minutes
S
Seconds
or a.c.
Alternating current
Three-phase alternating
current
Three-phase alternating
current with neutral
Read all safety warnings
and instructions
Direct current
No load speed
Alternating or direct
current
Class II construction
Splash-proof
construction
Watertight construction
Protective grounding at
grounding terminal,
Class I tools
Revolutions or
reciprocations per
minute
Diameter
Off position
Directional arrow
Warning symbol
Wear your safety
glasses
Wear dust mask
Wear hearing protection
SYMBOLS
WARNING: Some of the following symbols may appear on the rotary tool. Study
these symbols and learn their meaning. Proper interpretation of these symbols will
allow for more efficient and safer operation of this tool.
!
This symbol designates that this tool is listed
with U.S. requirements by TÜV Rheinland.
Conforms to UL Std. 60745-1 and 60745-2-23.
Certified to CAN/CSA-C22.2 No. 60745-1 and
60745-2-23.
JD3317U

10
Flexible shaft
ON/OFF
switch
Hanging
loop
Air vents
Spindle lock
button
3-Jaw
Chuck
Umbrella
nut
Speed control
Motor brush
cap
KNOW YOUR ROTARY TOOL
110 pc
accessory kit
Table clamp &
hanger
1/8”, 3/32”, 1/16”
Collets
Collet wrench
Collet nut

11
ACCESSORIES
Illustration
Description
Size/Shape
Qty
Brass brush
1/4” Axial
1
Bristle brush
7/8” Radial
1
Brass brush
7/8” Radial
1
Bristle brush
1/4” Axial
1
Felt polishing wheel
1/2”
3
Felt polishing wheel
1”
3
Felt polishing tip
3/8”
3
Mandrel for felt
wheel
1/8”
1
Sanding band
1/2”
18
Drum sander with
1/8” shank
1/2” Diameter
1
Diamond ball
5/64” Ball
1
Diamond bit cylinder
Cylinder
1
Diamond taper
5/64” Taper
1
Multi-purpose bit
1/8” Cylinder
3
Screw mandrel
1/8”
1
Screw mandrel
3/32”
1
Heavy duty cut-off
wheel
15/16” x 0.031
Thick
23
Dressing stone
3/8” x 3/8” x 1”
1
Sanding disc
3/4” Circular
35
Various grinding
stones
Assorted
10

12
Accessory Description
Accessory Use
Cut-off wheel
Ideal for cutting, grooving and trimming all kinds of
materials—including metal, wood and ceramics. You
can use it to cut screws and rusted bolts, make slots in
screw heads, trim castings and more.
Felt polishing wheel
Ideal for polishing most metal surfaces and plastics. Can
be used with polishing compound.
Mandrel for felt wheels
Use with felt polishing wheels.
Sanding band for use with drum
sander
For rough shaping and smoothing wood and fiberglass;
removing rust from metal surfaces; shaping rubber
surfaces. Sanding bands are easily replaceable on
drums.
Drum sander
For use with sanding bands
Screw mandrel
Use with sanding discs, polishing, grinding and cut-off
wheels.
Aluminum oxide grinding stones &
wheels (pink)
Use on metals, castings, welded joints, rivets and rust.
Ideal for sharpening, de-burring, rust removal and
general-purpose grinding of most materials.
Silicon carbide grinding stones &
wheels (green)
Designed to work well on stone, glass, ceramics,
porcelain and non-ferrous metals.
Bristle brush
Use for light de-burring, cleaning and polishing of
silverware, jewelry and other precious metals. Can be
used with polishing compound.
Brass brush
Brass brushes are non-sparking and softer than steel.
They will not scratch soft metals like gold, copper, brass,
etc.
Diamond point
Great for cutting, sawing and carving of hard materials
such as marble, concrete, brick, porcelain, ceramics,
hard epoxy and soft and hard wood.
Dressing stone
Cleans grinding wheels and stones. Shapes or reshapes
stones for desired applications.
Collet
For use with accessories.
Collet wrench
For tightening & loosening collet nut, screw of drum
sanders
ACCESSORY DESCRIPTION & USE
There are many different types of accessories that can be used with this rotary tool. The following
charts identify the most popular accessories and their uses.
NOTE: Please see the accessory case contents on Page 11 to identify the accessories that are
included with this rotary tool.

13
Accessory Description
Accessory Use
Multi-purpose drill bit
Cuts wood, plastic, fiberglass, drywall, laminate and
aluminum and vinyl siding.
Stainless steel brush
Stainless steel brushes do not cause "after-rust" when
used on corrosive-resistant materials like pewter,
aluminum and stainless steel.
Cloth wheel
Use for polishing metal & plastics.
Can be used with polishing compound.
Rubber polishing wheel
Use for removing small scratches and for polishing
ferrous metals
Drill bit
Use for drilling in wood, plastic and soft metals
Cutting bit
Use for cutting wood, plastic, fiberglass, aluminum,
drywall and vinyl siding
Grinding disc
Use for grinding metals, welds, rivets, rust etc.
Grinding compound
Use with grinding stones and discs to increase the rate
of material removal
Cutting guide
Use with cutting bit for precise cutting control.
To install the cutting guide on the rotary tool, remove the
umbrella nut from the tool and thread the cutting guide
onto the exposed threads. To adjust the cutting depth,
loosen the thumb screw on the cutting guide and slide
the guide to the correct depth. Retighten the thumb
screw.
NOTE: This rotary tool will accept all 1/8", 3/32" and 1/16" shanked accessories offered by
leading brands, however, attachments such as drill press stands etc. may not be compatible.
ACCESSORY DESCRIPTION & USE

14
INSTALLING ACCESSORY BITS
1. Turn the switch OFF and disconnect the tool
from the power source.
2. Depress the spindle lock button (1) and
slowly turn the 3-jaw chuck collet nut (2) until
the spindle lock button locks the spindle
(Fig. 1).
3. While holding the spindle lock button down,
turn the 3-jaw chuck collet nut counter
clockwise until the 3-jaw chuck jaws open far
enough to allow the accessory bit shank (3) to
be inserted into the 3-jaw chuck.
4. Insert accessory shank into the 3-jaw chuck.
NOTE: Insert accessory shank at least 3/4"
into the 3-jaw chuck.
5. Press the spindle lock button and engage it in
the spindle. While holding the spindle lock
button down, hand-tighten the 3-jaw chuck by
turning it clockwise.
NOTE: Do not use pliers to tighten the collet
nut. Use the small wrench (4) supplied. Over
tightening will cause damage to the tool.
6. Pull on the accessory to ensure it is securely
in place.
REMOVING THE 3-JAW CHUCK AND
INSTALLING A COLLET
In some instances you may wish to remove the
3-jaw chuck and use the collet nut system to
hold the accessory bit. Collet sizes can be 1/8",
3/32" and 1/16". It is important to ensure that the
collet size matches the accessory.
NOTE: This tool includes the most commonly
used collets: 1/8", 3/32" and 1/16".
WARNING: Using a collet that is too
large for the accessory will result in the
accessory possibly being thrown from the
tool causing serious injury.
1. Turn the tool switch OFF and remove the plug
from the power source.
2. Depress the spindle lock button (1) and
slowly turn the 3-jaw chuck (2) until the
spindle lock button locks the spindle (3) (Fig.
2).
3. While holding the spindle lock button down,
turn the 3-jaw chuck counter clockwise until
both the 3-jaw chuck collet nut and the jaw
assembly are removed from the spindle.
4. Insert the appropriate sized collet (4) into the
spindle and thread the collet nut (5) onto the
spindle by turning it clockwise while holding
the spindle lock button down.
NOTES:
a) The collet nut is supplied with the tool.
b) Do not tighten the collet nut without an
accessory bit installed in the collet. You will
damage the collet.
ASSEMBLY AND OPERATINGASSEMBLY AND OPERATING
!
Fig. 1
1
23 4
1
23
4
5
Fig. 2

15
INSTALLING ACCESSORY BIT WHEN USING
THE COLLET NUT SYSTEM
1. Turn the switch to the OFF position, and
disconnect the plug from the power source.
2. Depress the spindle lock button (1), and
slowly turn the collet nut (2) until the spindle
lock button locks the spindle in place (Fig. 3).
3. Hold the spindle lock button down, and turn
the collet nut counter clockwise until the collet
is loose inside the collet nut.
4. Insert the shank of the accessory (3) into
collet at least 3/4”.
NOTE: Verify that the proper collet is used
for the accessory. If the collet is too large,
replace it with the next smaller size.
5. Press the spindle lock button, and engage it
in the spindle. While holding the spindle lock
button down, turn the collet nut clockwise by
hand to tighten it.
NOTE: Do not use pliers to tighten the collet
nut. Use the collet wrench (4) that is provided
with the tool. Over-tightening the collet will
damage the tool.
6. Pull on the accessory to verify that it is held
securely in position.
CONNECTING THE FLEXIBLE SHAFT TO
THE TOOL
WARNING: Do not bend the flexible shaft
to a radius of less than 6” (15.2 cm) when using
it with the rotary tool. Store the flexible shaft
carefully when it is not in use, avoiding sharp
bends.
1. Lock the spindle using the spindle lock button
(1) open the 3-jaw chuck (2) as shown in
Fig. 1.
2. Insert the drive shaft (3) into the 3-jaw
chuck as far as it will go.
3. Tighten the 3-jaw chuck onto the drive
shaft as shown in Fig. 1.
NOTES:
a) Do not overtighten the 3-jaw chuck
b) The flex shaft can also be attached to
the tool using a 1/8" collet and collet nut.
Install the collet and collet nut as shown in
Fig. 2.
CHANGING THE COLLET AND
ACCESSORIES IN THE FLEXIBLE SHAFT
To change the collet or to install an accessory
bit in the flexible shaft, refer to the steps listed in
the sections entitled “Removing the 3-jaw chuck
and installing a collet”(Fig. 2) and “Installing
accessory bit when using the collet system”
(Fig. 3).
NOTE: You cannot use the 3-jaw chuck with the
flexible shaft.
To lock the shaft in place while loosening or
tightening the collet nut, press the spindle
locking button (1) and rotate the collet nut until
the locking button locks the shaft (Fig. 5). Use
the collet wrench to loosen or tighten the collet
nut.
NOTES:
a) Do not attempt to loosen or tighten the collet
without locking the shaft as described above.
Doing so will damage the flexible shaft.
b) Do not over-tighten the collet nut.
ASSEMBLY AND OPERATING
!
1
2
34
Fig. 3
Fig. 4
1
2
3

16
CHANGING THE COLLET AND
ACCESSORIES IN THE FLEXIBLE SHAFT –
cont’d
ASSEMBLING & INSTALLING THE STAND
The C-clamp that holds the hang bar rod can be
mounted either horizontally or vertically
(Fig. 6a & 6b).
1. To open the clamp (1), pull back on the quick
release lever (2) and pull outward on the
clamp knob (3).
2. Clamp the C-clamp onto a work table
(horizontal surface) or other appropriate
vertical surface by pushing inward on the
clamp knob and the quick release lever.
Complete the tightening process by turning
the clamp knob clockwise (Fig. 6a & 6b).
NOTE: Do not over tighten to avoid breaking
the clamp.
3. Thread screw (3) in the bottom of the hang
bar rod (4) into the appropriate mounting hole
(5) in the C-clamp (Fig. 7).
NOTE: Do not over tighten. Hand-tighten
only.
4. Loosen hang bar sections (6) by turning them
counter-clockwise.
5. Pull out each hang bar section approximately
5” and lock into place by turning them
clockwise.
NOTE: Do not over tighten. You will damage
the locking mechanism.
6. Insert the rotary tool hanger (7) into the top of
the hang bar rod.
7. Using the hang loop on the rotary tool (8)
hang rotary tool from the stand (Fig. 8).
ASSEMBLY AND OPERATING
Fig. 6a
Fig. 6b
Fig. 7
Fig. 5
1
Fig. 8
8

17
INSTALLING THE LED WORK LIGHT
1. Remove the standard umbrella nut from the
tool (1) by turning it counter clockwise
(Fig. 9).
2. Place the worklight mounting hole (2) onto the
threaded end of the tool housing (3).
3. Thread the worklight mounting umbrella nut
(4) clockwise onto the threaded end of the
tool.
NOTE: Hand tighten only.
4. To turn the LED light ON, move the switch
button (5) to the right. To turn the LED light
OFF, move the switch button to the left.
REPLACING BATTERIES IN LED
WORKLIGHT
1. Remove the worklight from the tool.
2. Remove the LED module screw (1) using a
small screwdriver (Fig. 10).
3. Lift upward on the front of the LED module (2)
and remove it from the LED worklight housing
(3).
4. While holding the LED module in one hand,
use a small screwdriver to push the two
button cells (4) out of the LED module
(Fig. 11).
NOTE: The button cells can only be removed
from one side of the LED module.
5. Install two new CR927 button cells (5) to
replace the button cells that have been
removed (Fig 12).
NOTES:
a. Make sure the "–" (small side) of the button
cells are facing upward.
b. Make sure the switch actuator (6) is still on
the switch button and tilted away from the
switch.
6. Reinstall the LED module into the LED
worklight housing.
NOTE: When placing the LED module back
into the LED worklight housing, tilt the module
to feed the switch actuator through the slot in
the top of the worklight housing.
7. When the LED module is properly reinstalled
into the LED worklight housing, fasten it in
place with the screw that was removed.
ASSEMBLY AND OPERATING
1
2
3
4
5
Fig. 9
12
3
Fig. 10
Fig. 11
4
Fig. 12
5
6

18
ON/OFF SWITCH
To turn the switch (1) ON, slide it forward
(Fig. 13). To turn the switch OFF, slide it back
toward the rear of the tool.
SPEED CONTROL WHEEL
The speed control wheel (1) is located at the
rear of the tool (Fig. 14). Speeds from 5,000 to
35,000 RPM can be set by rotating the speed
control wheel to show the desired speed (in
thousands RPM).
SELECTING THE PROPER SPEED
The different types of operations that can be
performed require that the rotary tool be used at
different speeds. The following chart outlines
some of the basic speed settings:
OPERATION
SPEED
(RPM)
Sanding
13,000
Cutting metal
35,000
Sanding wood
13,000
Cutting hard metal
29,000
Engraving metal
27,000
Sawing
25,000
De-burring
19,000
Drilling holes
17,000
Removing rust
13,000
Sharpening
9,000
Polishing
9,000
ASSEMBLY AND OPERATING
Fig. 14
1
For safety reasons, the operator must
read the sections of this Owner’s
Manual entitled "GENERAL SAFETY
WARNINGS", "POWER TOOL
SAFETY", "SPECIFIC SAFETY RULES",
"EXTENSION CORD SAFETY" and
"SYMBOLS" before using this rotary
tool.
Verify the following every time the
rotary tool is used:
1. Safety glasses, safety goggles, or
face shield are being worn.
2. Hearing protection is being worn.
3. Accessory is in good condition
and not damaged in any way.
4. Workpiece is properly secured.
Failure to observe these safety rules
will significantly increase the risk of
injury.
!
WARNING
Fig. 13
1

19
WARNING: When servicing, use only
identical replacement parts. The use of any
other part may create a hazard or damage the
rotary tool.
Do not abuse power tools. Abusive practices
can damage the tool and the workpiece.
WARNING: Do not attempt to modify this
rotary tool or to create accessories. Any such
alteration or modification is considered to be
misuse, and could result in a hazardous
condition that may lead to serious injury. Doing
so will also void the warranty.
CLEANING
Do not use solvents to clean plastic parts. Many
plastics are susceptible to damage from various
types of commercial solvents. Use a clean cloth
to remove dirt, dust, oil, grease, etc.
WARNING: Do not allow brake fluids,
gasoline, petroleum-based products, penetrating
oils, etc. to come into contact with plastic parts.
These substances contain chemicals that can
damage, weaken, or destroy plastic.
Power tools are subjected to accelerated wear
and possible premature failure when they are
used on fiberglass boats and sports cars,
wallboard, spackling compounds, or plaster. The
chips and grindings from these materials are
extremely abrasive to some parts of power
tools, including bearings, brushes, commutators,
etc. Therefore, it is recommended that this tool
not be used for extended work on any fiberglass
material, wallboard, spackling compound, or
plaster. If this rotary tool is used on these
materials for an extended period, it must be
cleaned frequently by blowing it out with an air
jet.
WARNING: Wear safety goggles or
safety glasses that have side shields whenever
performing any operation with a rotary tool. It is
also critical to wear safety goggles or safety
glasses that have side shields, as well as a dust
mask, when blowing dust out of the tool using
an air jet. Failure to observe these safety
precautions could result in permanent eye or
lung damage.
LUBRICATION
All of the bearings in this rotary tool have been
lubricated with a sufficient quantity of high-grade
lubricant for the life of the tool under normal
conditions. No further lubrication is required.
REPLACING MOTOR BRUSHES
The carbon motor brushes will wear down and
require replacing. The time intervals between
replacements will vary depending upon the type
of materials being cut and the hours of use. It is
recommended that the brushes be checked
after each 10 hours of use. When the length of
the carbon brush reaches 1/4" (6.35 mm), the
brushes should be replaced.
1. Remove the motor brush caps (1) with a
small slot screwdriver by turning them counter
clockwise (Fig. 12).
2. Remove the brush & spring assemblies (2).
3. Insert new brush & spring assemblies.
4. Reinstall the brush caps.
NOTE: Make sure the brush caps are not
cross threaded and do not over tighten.
MAINTENANCE
!
!
!
!
Fig. 12
1
122

20
EXPLODED VIEW
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
1
28
29
30
31
32
33
34
LED Work Light
