Masterlock 8184D User manual

Master Lock Bike
U-Lock Mounting Instructions

Mounting Instructions
Displayed: Model No. 8184D with Carrier Bracket
Multi-Purpose Fixed Bracket Mounting Instructions
•Your standard Master Lock Bike U-Lock should include the following contents:
(4) screws with 2 bolts
(1) wing nut
(2) Keys
U-Lock
Carrier Bracket

Mounting Instructions
Multi-Purpose Fixed Bracket Mounting Instructions
Bracket Insert
Step 1: Remove carrier bracket from U-Lock Step 2: Remove bracket insert

Mounting Instructions
Multi-Purpose Fixed Bracket Mounting Instructions
Step 3: Insert the smaller circumference
portion of the carrier bracket into the U-
Lock. Bracket should fit snuggly on U-Lock
Step 4: Carrier should resemble picture
below
Bracket Insert

Mounting Instructions
Multi-Purpose Fixed Bracket Mounting Instructions
Step 5a: Mount carrier bracket to your bike
frame and utilize the bracket insert for
different size frames
Step 5b: To adjust the carrier bracket
position, remove screw indicated below.
Once screw is removed, adjust to your
preference and tighten the screw
*Not featured on all brackets
Step 6: Insert screws and bolts in remaining holes to secure the U-Lock to your bike. Use the
appropriate length screws to secure the bottom of the carrier bracket.
Bottom of
carrier bracket
Bracket Insert

Mounting Instructions
Multi-Purpose Fixed Bracket Mounting Instructions
Optional Step 7: An additional screw or wing nut (pictured on slide 2) may be used to provide
added security on the upper portion of the carrier bracket
location for optional screw or wing nut tightened wing nut for added security
