1. Safety instructions
READ AND SAVE THESE INSTRUCTIONS
WARNING
This chapter describes important safety and operating instructions for use of a Mac Plus
in residential, vehicle (RV) and marine applications.
General
1 Before using the Mac Plus, read all instructions and cautionary markings on the Mac Plus, the
batteries, and all appropriate sections of the manual.
2 To reduce the risk of electric shock –Do not expose the Mac Plus to rain, snow, spray,
moisture, excessive pollution and condensing circumstances. To reduce risk of fire hazard, do
not cover or obstruct the ventilation openings. Do not install the Mac Plus in a poorly ventilated
room, this may result in overheating.
3 Use of an attachment or spare part not recommended or sold by Mastervolt may result in a risk
of fire, electric shock, or injury to persons.
4 The Mac Plus is designed to be permanently connected to a DC electrical system. Installation
of, and work on the Mac Plus, may be carried out only by a qualified, authorized and trained
technician or electrician, consistent with the locally applicable standards and regulations.
5 Make sure that all wiring is properly installed and in good electrical condition; and that wire size
is large enough for DC ampere rating of the Mac Plus. Check the wiring on a regular base, at
least once a year. Do not use the Mac Plus when the wiring is undersized or damaged and
replace the wiring immediately.
6 Do not operate Mac Plus if it has received a sharp blow, been dropped, or otherwise damaged
in any way; take it to a qualified service technician.
7 Except for the connection compartment, the Mac Plus may not be opened or disassembled.
There are no serviceable parts inside the cabinet. Take it to a qualified, authorized and trained
service technician when service or repair is required. Incorrect reassembly may result in a risk
of electric shock or fire.
8 To reduce risk of electric shock, disconnect the Mac Plus from the DC electrical system before
attempting any maintenance or cleaning. Turning off controls will not reduce this risk.
9 The Mac Plus may not be used by children or by those who cannot read and understand the
manual if they are not supervised by a responsible person who can guarantee that the charger
is being used in a safe manner. Keep the charger away from children.

4
Mac Plus –User and Installation Manual
10 Short circuiting or reversing polarity will lead to serious damage to batteries, Mac Plus, wiring
as well as accessories. Fuses cannot prevent damage caused by reversed polarity and the
warranty will be void.
11 In case of fire, you must use the fire extinguisher which is appropriate for electrical equipment.
12 If applied in a marine application in the United States, external connections to the Mac Plus
shall comply with the United States Coast Guard Electrical Regulations
(33CFR183, Sub part I).
Explosive gases
1 WARNING –RISK OF EXPLOSIVE GASES. WORKING IN VICINITY OF A LEAD-ACID
BATTERY IS DANGEROUS. BATTERIES GENERATE EXPLOSIVE GASES DURING
NORMAL BATTERY OPERATION. FOR THIS REASON, IT IS OF UTMOST IMPORTANCE
THAT EACH TIME BEFORE USING THE Mac Plus, YOU READ THIS MANUAL AND
FOLLOW THE INSTRUCTIONS EXACTLY.
2 To reduce risk of battery explosion, follow these instructions and those published by battery
manufacturer and manufacturer of any equipment you intend to use in vicinity of the battery.
Review cautionary marking on these products.
3 DANGER: To reduce the risk of explosion –Never use the Mac Plus in situations where there
is danger of gas or dust explosion or area in which ignition-protected equipment is required.
Warnings regarding the use of batteries
1 Someone should be within range of your voice or close enough to come to your aid when you
work near a battery.
2 Have plenty of fresh water and soap nearby in case battery acid contacts skin, clothing, or
eyes.
3 Wear complete eye protection and clothing protection. Avoid touching eyes while working near
battery.
4 If battery acid contacts skin or clothing, wash immediately with soap and water. If acid enters
eye, immediately flood eye with running cold water for at least 10 minutes and get medical
attention immediately.
5 NEVER smoke or allow a spark or flame in vicinity of battery or engine.
6 Do not short circuit batteries, as this may result in explosion and fire hazard! Be extra cautious
to reduce risk of dropping a metal tool onto battery. It might spark or short-circuit battery or
other electrical part that may cause explosion.
7 Remove personal metal items such as rings, bracelets, necklaces, and watches when working
with a battery. A battery can produce a short-circuit current high enough to weld a ring or the
like to metal, causing a severe burn.

Mac Plus –User and Installation Manual
5
8 Only use Mac Plus for charging a LEAD-ACID or Mastervolt Li-Ion batteries and the supply of
loads attached to these batteries, in permanent systems. Do not use Mac Plus for charging dry-
cell batteries that are commonly used with home appliances. These batteries may burst and
cause injury to persons and damage to property.
9 NEVER charge a frozen battery.
10 Excessive battery discharge and/or high charging voltages can cause serious damage to
batteries. Do not exceed the recommended limits of discharge level of your batteries.
11 If it is necessary to remove a battery, always remove grounded terminal from battery first. Make
sure all accessories are off, so as not to cause an arc.
12 Be sure that the area around battery is well ventilated while battery is being charged. Refer to
the recommendations of the battery manufacturer.
13 Batteries are heavy! It may become a projectile if it is involved in an accident! Ensure adequate
and sure mounting and always use suitable handling equipment for transportation.
Warning regarding life support applications
Do not use the Mac Plus for applications in any medical equipment intended for use as a
component of a life support system. For this type of use a specific written agreement between the
customer and Mastervolt is required.

6
Mac Plus –User and Installation Manual
2. General information
Liability
Mastervolt can accept no liability for:
•Consequential damage resulting from the use of the Mac Plus.
•Possible errors in the included manual and the consequences of these.
•Use that is inconsistent with the purpose of the product.
Warranty
The correct functioning of this product is subject to warranty. The period and conditions of this
warranty are laid down in Mastervolt Warranty Terms and Conditions and can be downloaded from
www.mastervolt.com/support. For making an appeal on warranty you can contact your supplier
directly, stating your complaint, application, date of purchase and part number / serial number.
Disclaimer
Our products are subject to continual development and improvement. Therefore, additions or modifi-
cations to the products may cause changes to the technical data and functional specifications. No
rights can be derived from this document. Please consult our most current Terms & Conditions of
Sale.
Identification label
Important technical information required for service, maintenance & secondary delivery of parts can
be derived from the identification label.
CAUTION!
Never remove the identification label. This will void the warranty.
Correct disposal of this product
This product is designed and manufactured with high quality materials and components,
which can be recycled and reused. Act according to your local rules and do not dispose
of your old products with your normal household waste. The correct disposal of your old
product will help prevent potential negative consequences to the environment and
human health.

Mac Plus –User and Installation Manual
7
3. Product description
The Mac Plus charger converts a DC (battery) voltage to a regulated DC voltage. It can be used as:
•a 3-Step battery charger or
•a stabilized DC power supply.
The Mac Plus can only be used in installations with a negative ground.
For different system voltages the following models are available.
Overview of the Mac Plus models
Model
Input
Output
Product code
12/12-50
12 V
12 V; 50 A
81205100
12/24-30
12 V
24 V; 30 A
81205300
24/12-50
24 V
12 V; 50 A
81205200
24/24-30
24 V
24 V; 30 A
81205400
Dimensions
146 mm [5.7"]
198 mm [7.8"]
255 mm [10"]
66 mm [2.6"]
165 mm [6.5"]

8
Mac Plus –User and Installation Manual
Front panel
Front panel
1
Status LED
2
+ Output
3
Ground
4
+ Input
5
MasterBus (2x)
6
DIP switch
7
Accessories connector
Pin 1: + battery voltage sense input
Pin 2: - battery voltage sense input
Pin 3: not used
Pin 4: remote switch input
Pin 5-6: battery temperature sensor input
1
2
3
4
5
6
7

Mac Plus –User and Installation Manual
9
4. Installation instructions
Installation steps:
1 Place and mount the Mac Plus, see chapter 5
2 Connect the Mac Plus, see chapter 6
3 Configure the Mac Plus, see chapter 10
CAUTION
Read the entire manual before installing the Mac Plus. Keep the manual at a safe location
for future reference.
•Operating temperature range: -20 up to +60 ºC, >40 ºC derating power
[-4 up to +140 ºF, >40 ºF derating power].
•Never use the Mac Plus at a location where there is danger of gas or dust explosions.
•Mount the Mac Plus in such a way that obstruction of the airflow through the heatsink is
prevented. This device requires a minimum of 100 mm (4") of clearance on every side.
•Do not install the Mac Plus in the same compartment as the batteries. Do not mount the Mac
Plus straight above batteries that might release corrosive sulphur fumes.
•Be sure that the output of the supplying source is switched off during installation. Also be sure
that no load is connected to the batteries during installation, to prevent hazardous situations.
•Use cables with an appropriate size, see the following table.
Recommended wire sizes DC input/output
Model
Minimum wire size Input
Minimum wire size Output
12/12-50
16 mm2[AWG 6]
16 mm2[AWG 6]
12/24-30
16 mm2[AWG 6]
10 mm2[AWG 8]
24/12-50
10 mm2[AWG 8]
16 mm2[AWG 6]
24/24-30
10 mm2[AWG 8]
10 mm2[AWG 8]
Min. 3 Nm –max. 5 Nm

10
Mac Plus –User and Installation Manual
5. Placement and mounting
Mount the Mac Plus with four M5 screws (3/16") to a solid flat surface.

Mac Plus –User and Installation Manual
11
6. Connection
•Mac Plus as a battery charger, see installation drawing A.
•Mac Plus as a stabilized DC power supply, see installation drawing B.
•Use properly sized fuses and wiring.
Installation drawing A
Installation drawing B

12
Mac Plus –User and Installation Manual
Remote switch input
The remote switch input (pin 4 of the Accessories connector) can be used to enable and disable the
battery charger. In a vehicle application, it is recommended to connect the engine run signal. This
way, the charger is used when the engine is running and the alternator is charging. The engine run
signal can be provided in different ways. For details contact your vehicle distributor.
The remote input accepts two different enable levels:
•active low, connect to ground (between 0 and 0.5 V)
•active high, connect to + battery voltage (between 3 and 32 V)
Active low means active when input is low. Active high means active when input is high.
The remote switch input configuration can be done by DIP switch (see chapter 7) or by MasterBus
(see chapter 9 and 10).
Battery temperature sensor (included)
By installing the Mastervolt temperature sensor, the charge voltages are automatically adapted for
deviating temperatures.
Figure 1. Temperature compensated charging
When the battery temperature is low, the charge voltage increases. In case the battery temperature
is high, the charge voltage is decreased. Over charge and gassing are prevented this way. This will
extend the life of your battery.
Voltage drop compensation
The Mac Plus can compensate the voltage drop occurring over the output cables. For this purpose,
the Mac Plus is equipped with terminals for voltage sense wires. Use 0,75 mm2 [AWG 18], preferably
red and black wire and protect these with a 2 A fuses slow blow. Pay good attention to the polarity
of the wires.
In order to accurately measure the battery voltage, connect the voltage sense wires as close to the
battery poles as possible. The positive and negative voltage sense wires must be connected. Cable
losses will be compensated up to a maximum of 2.5 V.

Mac Plus –User and Installation Manual
13
7. Configuration –DIP switches
The Mac Plus settings can be adjusted in two ways:
•By means of DIP switches;
•Via the MasterBus network (with a remote-control panel, or a PC with MasterAdjust software
connected via a USB Interface); see chapter 9 and 10.
This chapter only describes the DIP switch settings.
Note: DIP switch settings overrule MasterBus settings. If DIP switches are not in their default
setting, the corresponding MasterBus setting is grayed out.
CAUTION!
Incorrect settings of the Mac Plus can cause serious damage to your batteries and/or the
connected load! Adjustments of settings may be undertaken by authorized personnel only!
Use a small screwdriver to carefully set the required
settings. You may need to remove the MasterBus
cables (or Terminator) to be able to access the DIP
switches.
For an overview of the various DIP switch settings,
see the following three tables, where a 0 indicates
OFF or and a 1 indicates ON or .
DIP switch
MasterBus communication
1
0
Smart on; no MasterBus communication in sleep mode (no load <2mA)
1
MasterBus communication always on (no load 10mA), provided there is enough
input power
DIP switch
Charger on conditions
Typical use
2
3
4
5
0
0
0
0
MasterBus settings apply, see chapter
9 and 10.
Default factory setting:
Remote switch input ‘active high’ and
input voltage greater than enable
voltage setpoint (12.50 V*)
Default factory setting:
Recommended setting for vehicle with
proper engine run signal
0
0
0
1
Always on
(Remote switch input not used)
When the battery charger must be
always active
0
0
1
0
Remote switch input ‘active low’
Enable the battery charger by external
operating signal

14
Mac Plus –User and Installation Manual
DIP switch
Charger on conditions
Typical use
2
3
4
5
0
0
1
1
Remote switch input ‘active high’
Enable the battery charger by external
operating signal
0
1
0
0
Remote switch input ‘active low’
and input voltage greater than enable
voltage setpoint (12.50 V*)
Recommended setting for vehicle with
proper engine run signal
0
1
0
1
Remote switch input ‘active high’
and input voltage greater than enable
voltage setpoint (12.50 V*)
Recommended setting for vehicle with
proper engine run signal
0
1
1
0
Input voltage greater than enable
voltage setpoint (13.50 V*)
(Remote switch input not used)
Higher enable voltage setpoint.
Setting for vehicle without engine run
signal
* For a 24 V battery charger, multiply the voltages by two.
DIP switch
Battery type
6
7
8
0
0
0
Follow MasterBus setting, see chapter 9 and 10
Default factory setting: Flooded battery
0
0
1
Flooded
Bulk: 14.25 | Abs: 14.25 | Float: 13.25 V *
0
1
0
Gel
Bulk: 14.25 | Abs: 14.25 | Float: 13.80 V *
0
1
1
AGM
Bulk: 14.25 | Abs: 14.25 | Float: 13.80 V *
1
0
0
Spiral
Bulk: 14.25 | Abs: 14.25 | Float: 13.80 V *
1
0
1
Traction
Bulk: 14.55 | Abs: 14.55 | Float: 13.25 V *
1
1
0
Nicad
Bulk: 14.50 | Abs: 14.50 | Float: 14.50 V *
1
1
1
Constant voltage
13,25 V*
* For a 24 V battery charger, multiply the voltages by two.
Notes: - For Li-Ion see MasterBus settings, chapter 9 and 10.
- The charge specifications are based on Mastervolt batteries. Specifications for a given
chemistry of a different manufacturer may vary. If connecting batteries of a different manu-
facturer, make sure the manufacturer's recommendations are met. Individual adjustments
are possible if in the configuration the battery type "User defined" is selected. User defined
batteries can only be configured through MasterAdjust, see chapter 9 and 10.

Mac Plus –User and Installation Manual
15
8. Operation
Battery charger operation modes
Mode
Explanation
Charging
The Mac Plus is in charging mode if it meets the switch-on
conditions (see DIP switch/MasterBus settings)
Standby
The Mac Plus goes to standby when is does not meet the
switch-on conditions (see DIP switch/MasterBus settings)
Or
Switched off by the on / off button in the MasterBus menu or by
a MasterBus event
Sleep (low no-load power
consumption)
The Mac Plus enters sleep mode when the sleep delay has
passed, to reduce the no-load power consumption
Every 5 seconds, the Mac Plus scans if the configured battery
charger meets the switch-on conditions
Alarm
Possible error, connect MasterBus and analyze the situation
LED indicator
Use the following table to understand the meaning of the LED signals.
LED color
LED indication
Meaning
What to do?
Green
Solid
Charging
Normal operation
Green
Slow blinking
Sleep
Normal operation
Blue
Solid
Standby
Normal operation
Red-Blue
Fast blinking
Software update
Normal operation
Red
Solid
Possible error
Connect to MasterBus and
analyze the situation

16
Mac Plus –User and Installation Manual
9. MasterBus
What is MasterBus
All devices that are suitable for MasterBus are marked by the MasterBus symbol
MasterBus is a fully decentralized data network for communication between the
different Mastervolt system devices. It is a CAN-bus based communication network
which has proven itself as a reliable bus-system in automotive applications. MasterBus is used as
power management system for all connected devices, such as the inverter, battery charger,
generator and many more. This gives the possibility for communication between the connected
devices, for instance to start the generator when the batteries are low.
MasterBus reduces complexity of electrical systems by using UTP patch cables. All system
components are simply chained together. Therefore, each device is equipped with two MasterBus
data ports. When two or more devices are connected to each other through these data ports, they
form a local data network, called the MasterBus. The results are a reduction of material costs as
only a few electrical cables are needed and less installation time.
For central monitoring and control of the connected devices Mastervolt offers a wide range of panels
which show full status information of your electrical system at a glance and a push of a button. See
www.mastervolt.com for all available options.
New devices can be added to the existing network in a very easy way by just extending the network.
This gives the MasterBus network a high degree of flexibility for extended system configuration, not
only today, but in the future as well!
Mastervolt also offers several interfaces, making even non-MasterBus devices suitable to operate in
the MasterBus network.
How to set up a MasterBus network
Each device that is suitable for the MasterBus network is equipped with two data ports. When two or
more devices are connected to each other through these ports, they form a local data network,
called the MasterBus. Keep the following rules in mind:
˗Connections between the devices are made by standard MasterBus cables (straight UTP).
Mastervolt can supply these cables.
˗As with all high-speed data networks, MasterBus needs a terminating device on both ends of
the network.
˗Up to 63 MasterBus devices can be connected together.
˗The electric power for the network comes from the connected devices. At least one device in
the network should have powering capabilities (see specifications). One powering device can
power up to three non-powering devices. As all powering devices are galvanically isolated,
multiple powering devices are allowed. Spread the powering devices over the network.
˗Do not make ring networks.
˗Do not make T-connections in the network.
For more details on networks, please contact your Mastervolt supplier.

Mac Plus –User and Installation Manual
17
10. MasterBus on the Mac Plus
Monitoring
Value
Meaning
Default
Adjustable range
Status
Device state
Shows the actual operation mode:
Standby / Charging / Alarm / Off
(read only)
Charge state
State of charge algorithm: Off / Bulk /
Absorption / Float / Constant voltage
(read only)
Standby
Button to toggle the device state.
Note: in the standby mode, the Mac Plus
can be switched on again automatically.
This happens, for example, after a restart.
On
On, Off
General
Input voltage
Voltage at the input
(read only)
Input current
Current of the input
(read only)
Output voltage
Voltage at the output
(read only)
Output current
Current of the output
(read only)
Bat. volt sense
Battery voltage measured by the battery
voltage sensor. If the Shunt device function
is enabled for a MasterShunt (MSH) or an
MLI Ultra (BAT): voltage measured by the
MasterShunt / MLI Ultra.
(read only)
Remote sw.
input
Remote input signal detected. Only
applicable when Remote input mode is
active low or active high configured.
(read only)
Temperatures
Device
Device temperature
(read only)
Battery
Actual battery temperature measured by the
Battery temperature sensor.
If no battery temperature sensor is used or
when Battery is set to “Li-Ion”: “---“ is
shown.
(read only)
Alarm
Value
Meaning
Alarm status
Temperature high
Internal temperature is too high
Bat. temp. high
Battery temperature is too high (> 55 ºC [131 ºF])

18
Mac Plus –User and Installation Manual
Value
Meaning
Bat. temp. low
Battery temperature is too low (< -20 ºC [-4 ºF])
Input high
Input voltage is too high
Input low
Input voltage is too low
Output high
Output voltage is too high
Output low
Output voltage is too low
OVP/OCP
Over Voltage Protection or Over Current Protection shutdown
HW fault
Internal hardware error
Cable loss high
Cable loss is too high (>2.5 V)
Shunt mismatch
(available in upcoming
software update)
Setting for nominal voltage (12 or 24 V) at the MasterShunt or the nominal
voltage of the MLi Ultra battery differs from nominal output voltage of the
Mac Plus, Check battery voltage and settings of the MasterShunt or voltage
of the MLI-Ultra battery.
Configuration
Value
Meaning
Factory setting
Adjustable range
Device
Language
Language that is displayed on a
monitoring device connected to
the MasterBus
English
EN, NL, DE, FR,
ES, IT, NO, SV, FI,
DA
Name
Device name (user defined). The
device will be represented by this
name throughout the MasterBus
network
Plus 12/12
Plus 12/24
Plus 24/12
Plus 24/24
0-12 chars
Back to default
Button to reset the Mac Plus to
default settings
Remote sw.
input
Mode
Active low: active when the input
voltage is 0 - 0.5 V
Active high: active when the input
voltage is 3 - 32 V
Not used: always active
Active high
Not used, Active
low, Active high
Input threshold
Enabled
Enabled: input voltage thresholds
are active
Disabled: input voltage thresholds
are not active
Enabled
Enabled, Disabled
Enable voltage
Enable input voltage
12.50 / 25.00 V
8-16 / 16-32 V

Mac Plus –User and Installation Manual
19
Value
Meaning
Factory setting
Adjustable range
Enable delay
Enable delay
2 s
0-300 s
Disable voltage
Disable input voltage
12.00 / 24.00 V
8-16 / 16-32 V
Disable delay
Disable delay
300 s
0-300 s
Instant disable
Disable input voltage, no delay
11.00 V
8-16 / 16-32 V
Sleep delay
Delay before the Mac Plus
switches to sleep mode
300 s
0-3600 s
Charger
Battery type
Selection of pre-set charge
algorithm. Individual adjustments
are only possible if “User defined”
is selected here.
Flooded
Flooded, Gel, AGM,
Spiral, Li-Ion,
Traction, NiCad,
Constant voltage,
User defined,
Max output (limit)
Maximum output (charge) current
50 A
30 A
0-50 A
0-30 A
Max input (limit)
Maximum input current
50 A
30 A
0-50 A
0-30 A
Current ramp up
Charge current ramp up after
enabling the charger.
5 A/s
0-50 A/s
Temp.
compensate
Temperature compensation for
charge voltage
-0.030 V/°C
-0.060 V/°C
-0.1 - +0.1 V
Shunt
Shunt device
(available in
upcoming software
update)
Selection of the shunt device to
which the Mac Plus is connected.
This can either be a MasterShunt
(MSH) or an MLI-Ultra battery
(BAT). Enabling this function
allows to:
- Compensate the charge voltage
for cable losses;
- Adjust the actual Charge state
based on the state of charge of
the battery;
- Compensate the charge voltage
for deviating battery temperatures
(MasterShunt only).
No connection
No connection,
MSH+Product
Name,
BAT+Product
Name
Bulk
Bulk voltage
Bulk voltage
14.25 / 28.50 V
8-15 / 16-30 V
Max. bulk time
Maximum bulk time
480 min
0-1440 min
Min. bulk time
Minimum bulk time
120 s
0-240 s

20
Mac Plus –User and Installation Manual
Value
Meaning
Factory setting
Adjustable range
Start bulk time
Start bulk timer
13.25 V
8-15 / 16-30 V
Bulk ret. volt
Return to bulk voltage
12.80 / 25.60 V
8-15 / 16-30 V
Bulk return time
Return to bulk time delay
30 s
0-240 s
Absorption
Abs. voltage
Absorption voltage
14.25 / 28.50 V
8-15 / 16-30 V
Max absorp. time
Maximum absorption time
240 min
0-1440 min
Min absorp. time
Minimum absorption time
15 min
0-240 min
Return amps
Return amps (% of maximum
charge current)
6 % or
10 %
0-50 %
Float
Float voltage
Float voltage
13.25 / 26,50 V
8-15 / 16-30 V
Constant
voltage
Constant voltage
Constant output voltage
13.25 / 26.50 V
8-15 / 16-30 V
Input alarm
High alarm on
High input voltage alarm on
16.00 / 32.00 V
8-16 / 16-32 V
High alarm off
High input voltage alarm off
15.50 / 31.00 V
8-16 / 16-32 V
Low alarm off
Low input voltage alarm off
11.00 / 22.00 V
8-16 / 16-32 V
Low alarm on
Low input voltage alarm on
10.00 / 20.00 V
8-16 / 16-32 V
Low alarm delay
Low input alarm delay time
5 s
0-300 s
Output alarm
High alarm on
High output voltage alarm on
15.25 / 30.50 V
8-16 / 16-32 V
High alarm off
High output voltage alarm off
14.75 / 29.50 V
8-16 / 16-32 V
Low alarm off
High output voltage alarm off
11.00 / 22.00 V
8-16 / 16-32 V
Low alarm on
High output voltage alarm on
10.00 / 20.00 V
8-16 / 16-32 V
Low alarm delay
Low output alarm delay time
30 s
0-300 s
DIP switch
12345678
DIP switch state 0=off, 1=on
0
0,1
