MPTL36A 1 Rev. 01/04/05
MPTL36A
3.6v Pocket Style
Screwdriver
• Operating Instructions
• Warning Information
• Parts Breakdown
Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20cm
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55 lbs.
Voltage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . DC 3.6V
Free Speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . 230 RPM
Charging Time . . . . . . . . . . . . . . . . . . . . . 2 Hour Adapter
Max. Torque . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 in/lbs
*This tool has an auto spindle lock gear structure.
SPECIFICATIONS
Some dust created by power sanding, sawing, grinding, drilling, and other
construction activities contains chemicals known to cause cancer, birth
defects or other reproductive harm. Some examples of these chemicals are:
• lead from lead-based paints,
• crystalline silica from bricks and cement
and other masonry products, and
• arsenic and chromium from
chemically-treated lumber.
Your risk from these exposures varies, depending on how often you do this
type of work. To reduce your exposure to these chemicals: work in a well
ventilated area, and work with approved safety equipment, such as those
dust masks that are specially designed to filter out microscopic particles.
ALWAYS READ
INSTRUCTIONS
BEFORE USING
POWER TOOLS
ALWAYS WEAR
SAFETY GOGGLES
™
FULLY CHARGE BATTERY 5-8
HOURS BEFORE INITIAL USE.
DRAIN BATTERY COMPLETELY
BEFORE RECHARGING.
FOR MAXIMUM BATTERY LIFE:
ALWAYS DRAIN AND CHARGE
COMPLETELY.
IMPORTANT

MPTL36A 2 Rev. 01/04/05
FAILURE TO OBSERVE THESE WARNINGS COULD RESULT IN INJURY.
This Instruction Manual Contains Important Safety
Information.
Read THIS INSTRUCTION MANUAL
Carefully and understand ALL INFOR-
MATION Before Operating THIS Tool.
• Keep these instructions in a safe
accessible place.
• Always wear impact-resistant eye and face protection
when operating or performing maintenance on this
tool.
• Do not use tool to pry.
• This tool is not recommended for use near or in
water.
• When battery is not in use, keep it away from other
objects.
• Store idle tools out of reach of children.
• Keep the tool in efficient operating condition.
• Place the tool on the work before starting the tool. Do
not point or indulge in any horseplay with this tool.
• Keep body working stance balanced and firm. Do
not overreach when operating the tool.
• Anticipate and be alert for sudden changes in motion
during start up and operation of any power tool.
• Tool shaft may continue to rotate briefly after throttle
is released. Avoid direct contact with
accessories during and after use.
• Keep away from rotating end of tool.
Do not wear jewelry or loose clothing.
Secure long hair.
• Drill bits can bind suddenly and cause rotation of the
work piece or tool, causing injury to arms and/or
shoulders. Always use sharp bits. Use less downward
pressure at breakthrough.
• Do not lubricate tools with flammable or volatile
liquids such as kerosene, diesel or jet fuel.
• Do not force tool beyond its rated capacity.
• Do not remove any labels. Replace damaged labels.
• Use accessories recommended by Matco Tools.
Safety rules for charging the battery:
• Continuous charging for extended periods (several
days or weeks at a time) is harmful to the battery.
• Do not charge battery cartridge when temperature is
below 50°F (10°C) or above 104°F (40°C).
• Do not store the machine and battery cartridge
in locations where the temperature may reach or
exceed 122°F (50°C).
• Do not incinerate the battery cartridge even if it
is severely damaged or completely worn out. The
battery cartridge can explode in a fire.
• The battery must be placed in a well-ventilated area
during charging.
• Caution: charge only specific type rechargeable
batteries.
• Do not disassemble battery pack.

MPTL36A 3 Rev. 01/04/05
™
MPTL36A
3.6 v Pocket Style Screwdriver
Battery Installation:
To remove the battery, push the button on the battery
pack and pull the battery to remove the battery
from the unit.
Keep connected
for 2 hours
until battery
is completely
charged.
To install the battery, push
the battery into the unit until
the battery release button clicks into
place.
Drain battery completely before recharging and
charge to full capacity (5-8 hours) every time to
maintain maximum battery life.
Forward/Reverse Switch:
The spindle is locked in place when the switch is in
the center or off position or at any time the tool is
not operating. The switch can be activated in the
direction desired. The switch will automatically return
to the center off position when pressure is released.
View of the major components:
1. Bit Holder Socket
2. Front Cover
3. Main Housing
4. Forward/Reverse
Switch
5. Battery Pack
6. Recharging
Receptacle
7. Adaptor
Charging and Installation:
• Insert the charger plug into the receptacle of the
screwdriver and plug of the adaptor into a wall
socket.
• Remember to remove the plug from the wall after the
battery is charged.
Inserting Accessories:
• Hold the unit in one hand.
• Push the sleeve forward.
• Insert the shank of the accessory in to the holder.
• Release the sleeve.

MPTL36A 4 Rev. 01/04/05
Matco warrants this tool for a period of 90 days from original purchase. We will replace any MPTL36A covered
under this warranty which proves to be defective in material or workmanship during the warranty period.
In order to have your tool replaced, return the tool to the Matco Authorized Warranty Center listed below, freight
prepaid. Please include your name and address, evidence of the purchase date, and description of the suspected
defect. The tool will be inspected and if any part or parts are found to be defective in material or workmanship, the
tool will be replaced free of charge and returned to you freight prepaid. This warranty does not cover damage to
equipment or tools arising from alteration, abuse, misuse, damage and does not cover any repairs or replacement
made by anyone other than Matco or its authorized service center. The foregoing obligation is Matco's sole
liability under this or any implied warranty and under no circumstances shall we be liable for any incidental or
consequential damages.
Note: Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitation or exclusion may not apply to you.
This warranty gives you specific legal rights and you may also have other rights which vary from state to state.
AIR & HYDRAULIC SERVICE
315 Hawkins Rd.
Travelers Rest, SC 29690
[phone]
™
Model# MPTL36A Limited Warranty:
