Matco Tools MST5907 User manual

MST5907
WARNING:
Read all instructions and warnings before using this product. Failure to do so can
lead to damage to the tool, personal injury, or possibly death.
WARNINGS:
• DO NOT USE WITH AN IMPACT WRENCH LARGERTHAN 1/2” DRIVE.
Doing so will void the product warranty immediately.
• Hammering on this tool will void the product warranty.
• Always be aware of your surroundings when using this tool.
• Always be sure to inspect the tool for damage or signs of stress before
each use.
• Only use when you have equipped yourself with proper safety gear.This
pertains to the user and others in the same area of operation.
• Be sure to keep any loose items away from the tool during use, including but
not limited to jewelry and clothing.
• Do not use this tool confined or unclean areas.
• Keep tool lubricated, especially where the force screw rotates in the puller
cup.Recommended lubricants are SAE 30 and EP moly grease.
www.matcotools.com

MST5907
INSTRUCTIONS:
1. Remove bearing cup bolts and bolt keepers
2. Adjust the puller cup to allow it to accept the yoke.
3. Turn the center screw assembly until the is against the yoke (reverse thread).
4. Use a ratchet or either 3/8” or 1/2” (no larger) impact wrench release the
bearing cup.
5. Once the first bearing cup has been fully extracted, rotate the driveshaft and
repeat steps 2 through 4.
www.matcotools.com
Item Part Number Description
1 907-1 Puller Frame
2 907-2 Puller Cup
3 907-3 Center Screw Assembly
4 907-4 Cup Plug
5 N/A Retainer Ring
1
2
3
4
5
