Matrix MX-U5 User manual

CYCLES
OWNER’S MANUAL
06'_Cycle's_M.indd 1 7/18/06 1:04:50 PM

06'_Cycle's_M.indd 2 7/18/06 1:04:51 PM

CHAPTER 1: IMPORTANT SAFETY INSTRUCTIONS PAGES
1.1 Read and Save These Instructions ......................................................................................
1.2 Setting Up the Cycle .........................................................................................................
1.3 Installation Requirements ..................................................................................................
1.4 Preventative Maintenance and Cleaning Tips .......................................................................
CHAPTER 2: USING MANAGER PREFERENCE
2.1 Using Manager Mode ........................................................................................................
2.2 Using CSAFE ....................................................................................................................
2.3 Console (back side) Access Layout .....................................................................................
CHAPTER 3: ADJUSTING THE SEAT
3.1 Recumbent Seat Height ....................................................................................................
3.2 Upright Seat Height ..........................................................................................................
3.3 Hybrid Seat Height ...........................................................................................................
CHAPTER 4: PLACEMENT OF SERIAL NUMBER ON CYCLES
4.1 Recumbent Cycle ...............................................................................................................
4.2 Upright Cycle .....................................................................................................................
4.3 Hybrid Cycle ......................................................................................................................
CHAPTER 5: USING THE UPRIGHT, RECUMBENT OR HYBRID CYCLE
5.1 Pausing the Unit ...............................................................................................................
5.2 Console Description ..........................................................................................................
5.3 Manual Operation .............................................................................................................
5.4 Operating Level Based Programs ........................................................................................
5.5 Fit Test ............................................................................................................................
5.6 Heart Rate Control ............................................................................................................
5.7 Constant Watts .................................................................................................................
CHAPTER 6: G2 QUICK CIRCIT OPERATION
6.1 Pausing the Unit ..............................................................................................................
6.2 Console Description ..........................................................................................................
6.3 Manual Operation .............................................................................................................
CHAPTER 7: RECUMBENT CYCLE SPECIFICATIONS, PARTS AND ASSEMBLY GUIDES
7.1 Model Specifications .........................................................................................................
7.2 Fasteners and Assembly Tools ............................................................................................
7.3 Assembly Steps ................................................................................................................
7.4 Optional Entertainment Accessory ......................................................................................
CHAPTER 6: UPRIGHT CYCLE SPECIFICATIONS, PARTS AND ASSEMBLY GUIDES
8.1 Model Specifications .........................................................................................................
8.2 Fasteners and Assembly Tools ............................................................................................
8.3 Assembly Steps ................................................................................................................
8.4 Optional Entertainment Accessory ......................................................................................
CHAPTER 7: HYBRID CYCLE SPECIFICATIONS, PARTS AND ASSEMBLY GUIDES
9.1 Model Specifications .........................................................................................................
9.2 Fasteners and Assembly Tools ............................................................................................
9.3 Assembly Steps ................................................................................................................
9.4 Optional Entertainment Accessory ......................................................................................
Table of Contents
01
01
01
01
02
02
02
03
03
03
03
03
03
04
04
04
04
05
05
06
07
07
07
08
09
10
13
14
15
16
19
20
21
22
23
i
06'_Cycle's_M.indd 3 7/18/06 1:04:51 PM

06'_Cycle's_M.indd 4 7/18/06 1:04:51 PM

CHAPTER 1: Important Safety Instructions
1.1 READ AND SAVE THESE INSTRUCTIONS
• This Cycle is intended for commercial use.
•To insure your safety and protect the equipment, read all instructions
before operating the MATRIX Cycle.
When using an electrical product, basic precautions should always be
followed, including the following:
•Always unplug this equipment from the electrical outlet immediately
after using and before cleaning.
Your MATRIX Cycle is self-generating (requiring no external power source)
and must be pedaled to power up the console.
WARNING: To reduce the risk of burns, fire, electrical shock or injury to
persons that may be associated with using this product:
•An appliance should never be left unattended when plugged in.
Unplug the entertainment equipment from outlet when not in use and before
putting on or taking off parts.
•This product must be used for its intended purpose described in this
Owner’s Guide. Do not use other attachments that are not
recommended by the manufacturer. Attachments may cause injury.
• To prevent electrical shock, never drop or insert any object into any opening.
•Do not remove the side covers. Service should only be done by an authorized
service technician.
•Never operate the Cycle with the air opening blocked. Keep the air opening
clean, free of lint, hair and the like.
• Never operate the product if it has a damaged cord or plug, if it is not
working properly, if it has been damaged, or immersed in water.
Return the unit to a service center for examination and repair.
• Do not carry this unit by entertainment equipment power cord or use cord
as handle.
• Keep any of the entertainment equipment power cords away from heated surfaces.
• Keep hands and loose clothing away from moving parts.
•Close supervision is necessary when the Cycle is used by or near children
or disabled persons.
• Do not use outdoors.
• Do not operate where aerosol (spray) products are being used or where
oxygen is being administered.
• Connect this Cycle to a properly grounded outlet only.
• To disconnect, turn all entertainment controls to the off position, then
remove plug from outlet.
CAUTION: If you experience chest pain, nausea, dizziness or shortness
of breath, STOP exercising immediately and consult a physician before
continuing.
1.2 SETTING UP THE CYCLE
Assembly instructions have been provided with your Cycle. For your
safety, please read and follow each of the steps in the assembly guide.
1.3 INSTALLATION REQUIREMENTS
Your MATRIX Cycle is designed to be self contained and does not require
a power supply to operate.
CAUTION:Use of the wrong power supply for the entertainment device
may cause damage to your Cycle and/or entertainment device.
Locate a level, stable surface to position the Cycle. The Cycle has leveling
feet located under the foot support and the center of the frame. If your
Cycle wobbles in the location where you intended to use it, loosen
the lock nut on the adjusting foot and adjust the feet until stable.
Once level, lock the adjusting feet by tightening the lock nut to the frame.
1.4 PREVENTATIVE MAINTENANCE AND CLEANING TIPS
Preventative maintenance and daily cleaning will prolong the life and
look of your MATRIX Cycle.
Please read and follow these tips.
• Position the equipment away from direct sunlight. The intense UV light
can cause discoloration of plastics.
• Locate your equipment in an area with cool temperatures and low
humidity.
• Clean with a soft, 100% cotton cloth.
• Clean with soap and water or other non-ammonia based all purpose
cleaners.
• Wipe seats, handles, heart rate grips, and handlebars clean after each use.
• Do not pour liquids directly onto your equipment. This can cause damage
to the equipment and in some cases electrocution.
• Check pedal safety straps weekly for wear.
• Adjust leveling feet when equipment wobbles or rocks.
• Maintain a clean area around equipment free from dust and dirt.
1
06'_Cycle's_M.indd 5 7/18/06 1:04:52 PM

CHAPTER 2: Using Manager Preference
2.1 USING MANAGER PREFERENCE MODE
Your MATRIX Cycle is designed to allow you to customize settings for your
preferences and diagnostics. The Manager Mode can only be accessed
while the Cycle is powered up. Follow the instructions to adjust the Cycle
computer for your desired setting.
STEP 1: Power up the Cycle and hold the UP and DOWN arrow keys for
3 seconds. The word ‘Manager’ will appear in the alphanumeric
window and will enter into the Manager setting automatically
after 3 seconds. Continue to pedal until finished.
STEP 2: Select information you would like to view or change from the
following list by using the UP or DOWN arrows. Press SELECT.
Manager mode will allow you to view and set the following.
STEP 3: Use UP or DOWN arrows to increase or decrease values.
STEP 4: Press START to save and enter selected values and exit to STEP 2.
STEP 5: Exit by pressing START. Screen will reset to Start up.
DISPLAY
Manager
CODE: INFORMATION
P0: Maximum program time
P1: Default time
P2: Default level
P3: Default weight
P4: Speed
P5: Machine
P6: Cardio Entertainment
P7: Accumulated Distance
P8: Accumulated Time
P9: Software Version
DEFAULT VALUE
95 min
20 min
L1
150 lbs
Miles
BI
On
On
MIN.
5
5
L1
80lbs
Miles
BI
On
On
MAX.
95
95
L20
400lbs
KM
RE,EL
OFF
OFF
USER DEFINABLE
Y
Y
Y
Y
Y
Y
Y
Y
2.2 USING CSAFE
Matrix is the leader in entertainment availability. On the back of the console
are two RJ45 receptacles. They are marked CSAFE and ENTERTAINMENT.
Use the CSAFE port to plug in a CSAFE device using an RJ45 connector.
The connection is as follows:
CPU
UNIT 1
CSAFE
UNIT 2
ENTERTAINMENT
2
2.3 CONSOLE (BACK SIDE) ACCESS LAYOUT:
CSAFE
ENTERTAINMENT
REPROGRAMMING
CONNECTOR
BATTERY
LOCATION
CSAFE
PO RT
ENTERTAINMENT
PO RT
Below is a layout to all of the access ports on the back of your Matrix Console.
06'_Cycle's_M.indd 6 7/18/06 1:04:54 PM

4.1 RECUMBENT CYCLE
4.2 UPRIGHT CYCLE
4.3 HYBRID CYCLE
CHAPTER 4: Serial Number Location
3.1 RECUMBENT SEAT HEIGHT
To adjust the seat height on the Recumbent Cycle, locate the yellow
lever under the right side of the seat before you mount the Cycle. Place
your right hand on the yellow adjustment handle under the right side
of the seat. Place feet on the ground while seated and slide forward
if needed. Place feet on pedals, gently lift lever under the right side
of the seat. Using legs slowly push and slide the seat up or down to
desired position. Release lever and allow to lock into place.
3.2 UPRIGHT SEAT HEIGHT
To adjust the seat height on the Upright Cycle, locate the yellow pull
pin before you mount the Cycle. To raise or lower the seat, pull the
yellow knob while holding the seat with the other hand and slide up
or down accordingly. Make sure you are not seated when you pull the
knob or pull the seat up.
3.3 HYBRID SEAT HEIGHT
To adjust the seat height on the Hybrid Cycle, pull the yellow lever
under the seat and lower the seat to the lowest position before getting
on the machine. With the seat in the lowest position, stand over the
seat and grab the yellow lever. Pull the lever and lift until the seat base
makes contact with your pelvic bone.
3
CHAPTER 3: Adjusting the seat
SERIAL #
PLACEMENT
SERIAL #
PLACEMENT
SERIAL #
PLACEMENT
06'_Cycle's_M.indd 7 7/18/06 1:04:57 PM

CHAPTER 5: Using The Recumbent, upright, or hybrid cycle
5.1 PAUSING THE UNIT
PROGRAMS: Simple program selection buttons make MATRIX Cycles
easy to use. Matrix Cycles feature eight programs.
START/QUICK START: One Touch Quick Start and Start any time
during preference selection.
UP/DOWN: Easy information and level selection.
SELECT/SELECT SCREEN/RESET: This multi-function button
enters information when setting up programming options, toggles
information displayed, and if held down for 5 seconds, resets the Cycle
to Start-up mode.
5.3 MANUAL OPERATION
MATRIX design makes using the programs as easy as a touch of a but-
ton.
QUICK START: Start pedaling and press START to begin your workout.
Manual mode allows you to enter your desired time, level and weight.
STEP 1: Select SELECT program button.
Press SELECT or wait 5 seconds.
Selecting START will start program.
STEP 2: Select TIME by using the UP or DOWN arrow keys.
Press SELECT or wait 5 seconds.
Selecting START will start program.
STEP 3: Select Weight by using the UP or DOWN arrow keys.
Press START or SELECT to begin workout.
Display, Starting 3, Starting 2, Starting 1.
5.4 OPERATING LEVEL BASED PROGRAMS
Your MATRIX Cycle offers versatile programs to keep the user motivated.
The following instructions will guide you through simple steps to select
INTERVALS, ROLLING, FAT BURN and RANDOM programs.
STEP 1: Select the PROGRAM button.
Press SELECT or wait 5 seconds.
Selecting START will start program.
STEP 2: Select LEVEL by using the UP or DOWN arrow keys.
You can change the level at anytime during the workout.
Press SELECT or wait 5 seconds.
Selecting START will start program.
STEP 3: Select TIME by using UP or DOWN arrow keys.
Press SELECT or Wait 5 seconds.
Selecting START will start program.
STEP 4: Select Weight by using the UP or DOWN arrow keys.
Press START or SELECT to begin workout.
Display, Starting 3, Starting 2, Starting 1
4
5.2 CONSOLE DESCRIPTION
Once you stop pedaling, your console has a 30 second pause feature. You
will know that machine is paused because the console will display
a bouncing green dot. If the dot is not displayed, then the 9-volt battery
located in the back of the console needs to be replaced. Simply remove the
screw to access the battery compartment and replace the 9-volt battery.
QUICKS TART
06'_Cycle's_M.indd 8 7/18/06 1:04:58 PM

CHAPTER 5: Using The Recumbent, upright, or hybrid cycle
5
5.5 FIT TEST
FIT TEST program allows you to measure our fitness level by using one
of two unique tests. Test one takes 12 minutes to complete and test two
take 15 minutes to complete.
Follow these easy steps to enter in the Fit Test Program.
STEP 1: Select the FIT TEST button.
Select TEST 1 or 2 by using the UP or DOWN arrow keys.
STEP 2: Select AGE by using the UP or DOWN arrow keys.
Press SELECT or wait 5 seconds.
STEP 3: Select GENDER by using the UP or DOWN arrow keys.
Press SELECT or wait 5 seconds.
STEP 4: Select WEIGHT by using the UP or DOWN arrow keys.
Press START or SELECT to begin workout.
Display, Starting 3, Staring 2, Starting 1.
STEP 5: Display will read results of FIT TEST.
STEP 6: Display will read 2:00 MINUTE COOL DOWN.
Display will show totals for time, distance, calories,
speed, RPM, watts.
AGE EXCELLENT ABOVE AVERAGE BELOW POOR
AVERAGE AVERAGE
13-14 >2700m 2400-2700m 2200-2399M 2100-2199M <2100M
15-16 >2800m 2500-2800m 2300-2499M 2200-2299M <2200M
17-20 >3000m 2700-3000m 2500-2699M 2300-2499M <2300M
20-29 >2800m 2400-2800m 2200-2399M 1600-2199M <1600M
30-39 >2700m 2300-2700m 1900-2299M 1500-1999M <1500M
40-49 >2500m 2100-2500m 1700-2099M 1400-1699M <1400M
50 + >2400m 2000-2400m 1600-1999M 1300-1599M <1300M
MEN’S OUTPUT TABLE FOR TEST #1 AND #2
WOMEN’S OUTPUT TABLE FOR TEST #1 AND #2
AGE EXCELLENT ABOVE AVERAGE BELOW POOR
AVERAGE AVERAGE
13-14 >2000m 1900-2000m 1600-1899M 1500-1599M <1500M
15-16 >2100m 2000-2100m 1700-1999M 1600-1699M <1600M
17-20 >2300m 2100-2300m 1800-2099M 1700-1799M <1700M
20-29 >2700m 2200-2700m 1800-2199M 1500-1799M <1500M
30-39 >2500m 2000-2500m 1700-1999M 1400-1699M <1400M
40-49 >2300m 1900-2300m 1500-1899M 1200-1499M <1200M
50 + >2200m 1700-2200m 1400-1699M 100-1399M <1100M
06'_Cycle's_M.indd 9 7/18/06 1:04:59 PM

CHAPTER 5: Using The Recumbent, upright, or hybrid cycle
6
5.6 HEART RATE CONTROL
For your convenience, MATRIX FITNESS Cycles come standard
with digital contact heart rate sensors and are POLAR telemetry
compatible.
Locate the metal sensors on the handrail of the Cycle. Notice
there are two separate pieces of metal on each grip. You must be
making contact with both pieces of each grip to get an accurate
heart rate reading. You can grab these sensors in any program
to view your current heart rate. The heart rate readout is located
in the lower right hand corner and is labeled HEART HR.
Follow these easy steps to enter into the Target HR Program.
STEP 1: Select the TARGET HR button.
Press SELECT or wait 5 seconds.
Selecting START will start program.
STEP 2: Select AGE by using the UP or DOWN arrow keys.
Press SELECT or wait 5 seconds.
Selecting START will start program.
STEP 3: Select PERCENT by using UP or DOWN arrow keys.
Press SELECT or wait 5 seconds.
Selecting START will start program.
STEP 4: Select TIME by using UP or DOWN arrow keys.
Press SELECT or wait 5 seconds.
Selecting START will start program.
STEP 5: Select Weight by using the UP or DOWN arrow keys.
Press START or SELECT to begin workout.
Display, Starting 3, Starting 2, Starting 1
5.7 CONSTANT WATTS
CONSTANT WATTS program is a unique program that allows you
to vary your cadence or RPM and the Cycle’s resistance will adjust
accordingly to your selected goal. The quicker you pedal the less
resistance for the goal selected.
Follow these easy steps to enter into the Constant Watts Program.
STEP 1: Select the PROGRAM button.
Press SELECT or wait 5 seconds.
Selecting START will start program.
STEP 2: Select WATTS by using the UP or DOWN arrow keys.
Press SELECT or wait 5 seconds.
Selecting START will start program.
STEP 3: Select TIME by using UP or DOWN arrow keys.
Press SELECT or wait 5 seconds.
Selecting START will start program.
STEP 4: Select Weight by using the UP or DOWN arrow keys.
Press START or SELECT to begin workout.
Display, Starting 3, Starting 2, Starting 1
®
06'_Cycle's_M.indd 10 7/18/06 1:05:01 PM

6.1 PAUSING THE UNIT
PROGRAMS: Simplified Quick Circuit cycle was designed to allow a timed
warm-up or cool-down period as a part of the G2 Quick Circuit workout.
CHAPTER 6 G2 Quick circuit Operation
6.2 G2 CONSOLE DESCRIPTION
Once you stop pedaling, your console has a 30 second pause feature. You
will know that machine is paused because the console will display
a bouncing green dot. If the dot is not displayed, then the 9-volt battery
located in the back of the console needs to be replaced. Simply remove the
screw to access the battery compartment and replace the 9-volt battery.
QUICKS TART
BEGINNER
MID-LEVEL
ADVANCED
ELITE
INSTRUCTIONS
STEP 1) SELECT YOUR FITNESS LEVEL - BEGINNER, MID-LEVEL, ADVANCED OF ELITE
STEP 2) PRESS START
6.3 OPERATING THE FOUR BASED PROGRAMS
There are four pre-set programs to choose from with adjustable resistance in
each program.
Follow these easy steps to enter into the G2 Quick Circuit Workout.
STEP 1: Select one of the four program level buttons.
BEGINNER default resistance level choices are 1-6.
MID-LEVEL default resistance level choices are 7-12.
ADVANCED default resistance level choices are 13-18.
ELITE default resistance level choices are 19-25.
Press SELECT or LEVEL UP to choose starting resistance.
STEP 2: Select TIME by using the UP arrow key.
If no TIME change is required - press SELECT.
Default time is 4:00 minutes.
Press SELECT
STEP 3: Press START key to begin workout.
Display, Display starting 3, starting 2, Starting 1
7
06'_Cycle's_M.indd 11 7/18/06 1:05:02 PM

SPECIFICATIONS
Product Name R5x
Foot Print inches = 64”Lx 29”Wx 51”H
cm = 162.5 x 73.5 x 129.5
Weight 170 lbs
77 kg
Max User Weight 400 lbs = 181 kg
Frame Construction Steel
Self Contained Yes
Resistance Type Generator
Resistance Level 25
PROGRAMS
One Button Quick Start Yes
Random (20 profiles) Yes
Target Heart Rate Yes
Interval Yes
Constant Watts Yes
Rolling Yes
Fat Burn Yes
Fit Test Yes
HEART RATE
Wireless Heart Rate Yes
Contact Heat Rate Yes
ENTERTAINMENT READY
Coaxial Cable Connection Yes
AC TV Power Connection Yes
Monitor Mount Yes - Optional Fitconnexion
CHAPTER 7: Recumbent cycle specifications, parts, and assembly steps
7.1 MX-R5XRECUMBENT CYCLE SPECIFICATIONS
8
06'_Cycle's_M.indd 12 7/18/06 1:05:03 PM

MX-R5X• RECUMBENT CYCLE
CHAPTER 7: Recumbent cycle specifications, parts, and assembly steps
9
7.2 MX-R5XRECUMBENT CYCLE REQUIRED FASTENERS & ASSEMBLEY TOOLS
20 Z11 SOCKET HEAD CAP SCREW M8 x 20
01 4mm ALLEN WRENCH
01 5mm ALLEN WRENCH
01 6mm ALLEN WRENCH
01 OPEN WRENCH [ #15 # 17 325L ]
01 #2 PHILLIPS SCREW DRIVER [ 4.5 x 50 ]
03 Z51 FLAT HEAD MACHINE SCREW M8 x 16
02 Z13 BUTTON HEAD MACHINE SCREW M5 x 10
12 Z23 FLAT WASHER M8
04 Z41 BUTTON HEAD CAP SCREW M8 x 50
20 Z12 LOCK WASHER
04 Z42 CUPPED WASHER M8
QTY PART # SKETCH DESCRIPTION NOTES
04 N51 BUTTON HEAD MACHINE SCREW M5 x 12 Included in console
06'_Cycle's_M.indd 13 7/18/06 1:05:04 PM

CHAPTER 7: Recumbent cycle specifications, parts, and assembly steps
7.3 MX-R5XRECUMBENT CYCLE ASSEMBLY STEPS
10
MX-R5X• RECUMBENT CYCLE
STEP 1
Z11
Z23
Z12
Z11
Z23
Z12
Z23
Z11
Z12
STEP 2
Lightly grease
06'_Cycle's_M.indd 14 7/18/06 1:05:06 PM

CHAPTER 7: Recumbent cycle specifications, parts, and assembly steps
11
7.3 MX-R5XRECUMBENT CYCLE ASSEMBLY STEPS
STEP 4
STEP 3
Z51
Z41
Z11
Z13
Z12
Z42
Z20
Z11
06'_Cycle's_M.indd 15 7/18/06 1:05:07 PM

CHAPTER 7: Recumbent cycle specifications, parts, and assembly steps
7.3 MX-R5XRECUMBENT CYCLE ASSEMBLY STEPS
12
STEP 5 FINAL ASSEMBLY
INCLUDED
WITH CONSOLE
N51
06'_Cycle's_M.indd 16 7/18/06 1:05:09 PM

CHAPTER 7: Recumbent cycle specifications, parts, and assembly steps
13
7.4 MX-R5X OPTIONAL ENTERTAINMENT ACCESSORY SHOWN
06'_Cycle's_M.indd 17 7/18/06 1:05:10 PM

SPECIFICATIONS
Product Name U5x
Foot Print inches = 47”Lx 29”Wx 56”H
cm = 119.4 x 73.5 x 142.2
Weight 129 lbs
59 kg
Max User Weight 400 lbs = 181 kg
Frame Construction Steel
Self Contained Yes
Resistance Type Generator
Resistance Level 25
PROGRAMS
One Button Quick Start Yes
Random (20 profiles) Yes
Target Heart Rate Yes
Interval Yes
Constant Watts Yes
Rolling Yes
Fat Burn Yes
Fit Test Yes
HEART RATE
Wireless Heart Rate Yes
Contact Heat Rate Yes
ENTERTAINMENT READY
Coaxial Cable Connection Yes
AC TV Power Connection Yes
Monitor Mount Yes - Optional Fitconnexion
14
CHAPTER 8: Upright cycle specifications, parts, and assembly steps
8.1 MX-U5XUPRIGHT CYCLE SPECIFICATIONS
06'_Cycle's_M.indd 18 7/18/06 1:05:12 PM

15
MX-U5X • UPRIGHT CYCLE
CHAPTER 8: Upright cycle specifications, parts, and assembly steps
8.2 MX-U5XUPRIGHT CYCLE REQUIRED FASTENERS & ASSEMBLEY TOOLS
16 Z11 SOCKET HEAD CAP SCREW M8 x 20
01 4mm ALLEN WRENCH
01 5mm ALLEN WRENCH
01 6mm ALLEN WRENCH
01 OPEN WRENCH [ #15 # 17 325L ]
01 #2 PHILLIPS SCREW DRIVER [ 4.5 x 50 ]
02 Z13 BUTTON HEAD MACHINE SCREW M5 x 10
12 Z23 FLAT WASHER M8
16 Z12 LOCKED WASHER
QTY PART # SKETCH DESCRIPTION NOTES
04 N51 BUTTON HEAD MACHINE SCREW M5 x 12 Included in console
06'_Cycle's_M.indd 19 7/18/06 1:05:13 PM

16
8.3 MX-U5XUPRIGHT CYCLE ASSEMBLY STEPS
MX-U5X • UPRIGHT CYCLE
CHAPTER 8: Upright cycle specifications, parts, and assembly steps
STEP 1 STEP 2
Lightly grease
Z11
Z23
Z12
Z11
Z23
Z12
INCLUDED
WITH SEAT
Z11
Z12
Z23
06'_Cycle's_M.indd 20 7/18/06 1:05:14 PM
