Matrix SATATYA PARAM NVR Series User manual

Matrix SATATYA PARAM NVR
Video Surveillance Solution
Quick Start
SECURITY SOLUTIONS

Documentation Disclaimer
Matrix Comsec reserves the right to change, at any time, without prior notice, the product design,
specifications, components, as engineering and manufacturing may warrant.
This is a general documentation for all models of the product. The product may not support some of the
features and facilities described in the documentation.
Information in this documentation may change from time to time. Matrix Comsec reserves the right to revise
information in this publication for any reason without prior notice. Matrix Comsec makes no warranties with
respect to this documentation and disclaims any implied warranties. While every precaution has been taken in
the preparation of this quick start, Matrix Comsec assumes no responsibility for errors or omissions. Neither
is any liability assumed for damages resulting from the use of the information contained herein.
Neither Matrix Comsec nor its affiliates shall be liable to the purchaser of this product or third parties for
damages, losses, costs or expenses incurred by the buyer or third parties as a result of: accident, misuse or
abuse of this product or unauthorized modifications, repairs or alterations to this product or failure to strictly
comply with Matrix Comsec's operating and maintenance instructions.
Warranty
For product registration and warranty related details visit us at:
http://www.matrixvideosurveillance.com
Copyright
All rights reserved. No part of this quick start may be copied or reproduced in any form or by any
means without the prior written consent of Matrix Comsec.
Version 1
Release date: October 12, 2021

Table of Contents i
Contents
Introduction .................................................................................................... 1
Know Your Enterprise NVR ........................................................................... 2
The User Interface ............................................................................................. 6
Technical Specifications of SATATYA PARAM NVR ........................................ 7
Application of SATATYA PARAM NVR ............................................................. 9
Installing SATATYA PARAM NVR ............................................................... 10
Package Contents ........................................................................................... 10
Things You Will Need ...................................................................................... 10
Safety Instructions ........................................................................................... 10
Recommendations .......................................................................................... 12
Hardware Installation of SATATYA PARAM NVR ........................................... 13
Software Installation of SATATYA PARAM NVR ............................................ 19
Setting-up the SATATYA PARAM NVR Servers using the Manager Utilities .. 46
SSL Settings .................................................................................................... 65
Connecting SATATYA PARAM NVR ........................................................... 67
Configuring the SATATYA PARAM NVR .................................................... 70
Appendix ....................................................................................................... 87
Disposal of Products/Components after End-Of-Life ...................................... 87

Matrix SATATYA PARAM NVR Quick Start 1
Introduction
Thank you for choosing the Matrix SATATYA PARAM NVR, the video surveillance recorder.
This Quick Start is meant to help you get familiar with SATATYA PARAM NVR, install the device
and configure its basic parameters.
This is a common document for all the configurations of SATATYA PARAM NVR series. The terms
Satatya Param NVR, Matrix SATATYA PARAM NVR, NVR and Network video recorder are used
interchangeably.
If you have any concerns regarding the installation procedure, consult the Matrix Customer Care.
To view or download the documents related to this product, scan the QR Code printed on the
Product Label/Packaging Label.
You may also view or download the documents from https://www.matrixvideosurveillance.com/
product-manuals.html
For product registration and warranty related details, please visit https://
www.matrixcomsec.com/product-registration-form.html
Notices
The following symbols have been used for notices to draw your attention to important points.
Important: to indicate something that requires your special attention or to remind you of
something you might need to do when you are using the system.
Caution: to indicate an action or condition that is likely to result in malfunction or damage
to the system or your property.
Warning: to indicate a hazard or an action that will cause damage to the system and or
cause bodily harm to the user.
Tip: to indicate a helpful hint giving you an alternative way to operate the system or carry
out a procedure, or use a feature more efficiently.

Matrix SATATYA PARAM NVR Quick Start 2
Know Your Enterprise NVR
In today’s era, the technological need of organizations are no longer similar. The business
solutions required by a Small Medium Enterprise are different from that of a Large Enterprise. So,
most of the modern organizations want to invest in an economical business solution that
accomplishes their specific technological needs.
Keeping in mind, the aspect of enterprise functionalities as well as the technological need of each
and every organization, we offer the Matrix SATATYA PARAM NVR Series.
Matrix offers SATATYA PARAM NVR Series as Integrated Hardware and Software Solution. It
consists of SATATYA SAMAS Application ported on the SATATYA PARAM NVR Server. This perfect
combination of a software application with a hardware platform, fulfills the business need of
almost all the modern organizations.
Built on a high performance microprocessor, video compression technology along with dual
redundant Power Supply, the SATATYA PARAM NVR provides uninterrupted performance while
recording, monitoring and playback, best image quality with minimum storage space requirement.
The solution supports Raid 0, 1, 5 and 10 functionality.
The Matrix SATATYA SAMAS is a sophisticated video management solution designed for large
enterprises with multi-site surveillance requirements. This suite of applications provides
comprehensive management and support for large number of cameras and other video
surveillance devices, with centralized monitoring and control. The solution offers centralized
management of Management Server, Recording Server, Admin Client, Media Client (Smart Client),
Media Player (Backup Player), Multi Display, SATATYA devices and Cameras in a distributed
network.
SATATYA PARAM NVR uses Microsoft Windows10 IoT Enterprise Version as an Operating
System. Hence this Server cannot be used as a general purpose application other than as
SATATYA PARAM NVR. The Operating System must only be used in combination with SATATYA
PARAM NVR.The Terms and Conditions for the use of Microsoft Windows Operating System are
regulated by Microsoft’s End User License Agreement. Matrix assumes that these Terms and
Condition are acceptable to the End User.

3 Matrix SATATYA PARAM NVR Quick Start
Variants of SATATYA PARAM NVR
The SATATYA PARAM NVR Series has the following variants:
NVR03208XCTS: SATATYA PARAM NVR having configuration of maximum 32 IP channels and 8
hard disks.
NVR06408XCTS: SATATYA PARAM NVR having configuration of maximum 64 IP channels and 8
hard disks.
NVR12808XCTS: SATATYA PARAM NVR having configuration of maximum 128 IP channels and 8
hard disks.
NVR25608XCTS*1: SATATYA PARAM NVR having configuration of maximum 256 IP channels and
8 hard disks.
Naming Convention
1. Check for availability.

Matrix SATATYA PARAM NVR Quick Start 4
SATATYA PARAM NVR Panel
Front View
Front Controls and Indicators
Label Interface Description
AUSB
USB 2.0, used for Scheduled and Manual Backup.
To connect USB Mouse.
To connect Dongle.
BReset Push button for system reset
CHDD Activity LED Yellow (When HDD is busy)
DPower LED Blue (When power on)
ELAN1, LAN2 LED Green (When Internet is busy)
FPower Switch Push button for system power on
8 Hot-Swap HDD Trays Front Controls and Indicators
ABF
CDE
E

5 Matrix SATATYA PARAM NVR Quick Start
Rear view
General Specifications
Label Interface Description
A
Power Supply To connect the 220V AC Power Cable
Power Supply To connect the 220V AC Power Cable
B40 mm Exhaust Fan area
C
Dedicated Management Port To manage the Server
USB 3.1 - 1 To connect USB Mouse/Keyboard.
To connect Dongle /Hard Disk for Eternal Storage
USB 3.1 - 2 To connect USB Mouse/Keyboard.
To connect Dongle /Hard Disk for Eternal Storage
VGA To connect a VGA compatible Monitor
Display Port 1 To connect a Monitor
Display Port 2 To connect a Monitor
LAN 1, LAN 2,
LAN 3, LAN 4
To connect a standalone personal computer, or a LAN
Switch, or to connect to the Internet over a DSL Modem or
Router.
Parameters Description
Power supply 220V AC
Operating Temperature 0°C to +40°C
Humidity 5% to 95% RH Non-Condensing
A
A
B
C

Matrix SATATYA PARAM NVR Quick Start 6
The User Interface
The SATATYA SAMAS Application provided various user interfaces which servers different user
requirements:
SATATYA SAMAS Admin Client
The SATATYA Admin Client enables you to configure — Users, Servers, Access Control, Features
etc offered by the Matrix SATATYA SAMAS.
To know more, refer to the SATATYA SAMAS Administrator’s Guide.
SATATYA SAMAS Smart Client
The SATATYA Smart Client enables access to live and stored video images of SATATYA PARAM
NVR from a remote location through the Web. Using the Smart Client you can access, search,
browse, display and transfer stored video to a remotely connected workstation. You can configure
the SATATYA PARAM NVR and camera settings, receive notification of events such as alarm,
motion detection and video loss.
To know more, refer to the SATATYA SAMAS Smart Client System Manual.
SATATYA SAMAS Vision
SATATYA Vision is a mobile application which supports live view of the channels and allows the
user to view the live recordings any time, anywhere, on your smart devices. SATATYA Vision
supports Android and iOS-based devices.
To know more, refer to the FAQs for Android and iOS respectively.

7Matrix SATATYA PARAM NVR Quick Start
Technical Specifications of SATATYA PARAM NVR
HARDWARE
Processor - CPU Intel® Xeon® E-2246G 3.6GHz
Memory 16GB DDR4(32/64/128 Channels), 32GB DDR4 (32/64/128/
256 Channels)
OS Drive 1 x 250 GB SSD M.2
SATA 3.0 Channels 8
Storage Capacity 144 TB (8 Hard Disks of 18 TB)
GPU Intel® UHD Graphics P630
Video Display 2x Display Ports; 1xVGA
Chassis 2U, 17" Rack Mount Server
Hot Swap HDD Bays 8x SATA 3.5" or 2.5"
RAID Intel® VRoC (Virtual RAID on CPU)
RAID Support RAID 0/1/5/10
USB 1 (F) x USB 2.0 + 4 (R) x USB 3.1
NETWORK MANAGEMENT & SECURITY
Network 4 X RJ45 (1 GbpS)
Server Management Dedicated 1 GbpS RJ45 Port
Security TPM 2.0 Support, SSL Communication
ELECTRICAL
Input Voltage 220V AC at 50/60 Hz
Power Supply System 1+1 550W Hot Swap Platinum Redundant Power Supply
MECHANICAL
Dimension (D x W x H) 660 x 430 x 88 (mm)
26” x 16.9” x 3.5”
Material SGCC
Nett Weight 13.9 kg (without Hard Disk drives)
ENVIRONMENTAL
Operating Temperature 0° to 40° C
Relative Humidity 5 - 90% RH
SOFTWARE
OS Microsoft Windows 10 IoT Enterprise 2019 LTSC
Software VMS SAMAS - upto 256 Channels, 10 User Default
VIDEO SURVEILLANCE MANAGEMENT
IP Camera Channels 32/64/128/256 IP Channels
Resolution Support 12MP, 8MP, 5MP, 3MP, 2MP, 720P, D1, CIF
Compression H.265, H.264, MJPEG
Onvif Profile Support Onvif S
IP Camera Supports Matrix Brand, Third Party - Onvif Profile S Supported
Active Directory Support Yes

Matrix SATATYA PARAM NVR Quick Start 8
User Roles and Rights Yes
DISPLAY
Split (Through LAN/HDMI) 1x1, 2x2, 3x3, 4x4, 5x5, 6x6, 8x8, 1+3, 1+5, 1+7 and
Sequential Views and Windows Sequence
Local Decoding 1x 4K/ 4x 1080P/ 16 x D1 @H.264
Digital Zoom on Live Yes
Snapshot Yes
Multiple Display View on Single
SATATYA PARAM NVR
Yes, Max 3 Display in Extended Mode
OSD Channel Number and Name, Status, Video Loss, Recording
and Disabled Channel (As per camera support)
RECORDING
Pre-Record Up to 30 Sec
Post-Record 10-300 Sec
Snapshot Format JPEG
Recording Format Native
Recording Types Scheduled, Manual, Alarm and Motion Detection
Adaptive Recording Automatically Reduces the Number of Frames Captured Per
Second Where There is No Motion, Thereby Saving Storage
Space
PLAYBACK & BACKUP
Synchronous Playback 64 channels @ 1080P (via Ethernet)
Search Mode Date, Camera, Recording Type
Playback Modes Fast Forward, Fast Reverse at Different Speed Control,
Backup & Archive 3 Levels, Video Grooming Technology
Maximum User 100
Remote Operation Monitor, PTZ Control, Playback, System Setting, File
Download, Log Information,
EVENTS & ACTIONS
EVENTS Video Surveillance Events, System Events, User Events,
Audit Trails Events
ACTION Recording on Selected Channel, Upload Images on FTP/
Email server, Email Notification with Snapshot, Trigger IVA,
Recall PTZ Preset Position, Turn On/Off Alarm Outputs,
Buzzer Notification, SMS Notification, Calling from Mobile
App,Share files data, Trigger Aux Output
SYSTEM SETUP
LED Indication System Power; Ethernet Connection 1 & 2, SATA
Connectivity, OS Drive Connectivity
Power On & Reset Switch Yes

9Matrix SATATYA PARAM NVR Quick Start
Application of SATATYA PARAM NVR

Matrix SATATYA PARAM NVR Quick Start 10
Installing SATATYA PARAM
NVR
Package Contents
• SATATYA PARAM NVR unit
• 2 qty 220V-15A Power Cable
• 2 qty Sliding Rails for Rack installation
• 4 qty Rack Installation Screws (plus flat head)
• 6 qty Inner Rack Installation Screws (plus circular head)
• 8 qty Outer Rack Installation Screws (plus circular head)
• 32 qty HDD Installation Screws (plus circular head)
Things You Will Need
• A Power Hand Drill
• A Wire Stripper
• Insulation Tape
• A Screwdriver set
• Cameras (IP Cameras, PTZ cameras).
• Monitors with the appropriate cables to connect.
• At least one SATA Hard Disk (upto 18TB), if you want to record on a hard disk in the SATATYA
PARAM NVR. You can install eight hard disks.
• A USB Mouse or Keyboard (Wired or Wireless) to operate the SATATYA PARAM NVR, if
required.
• A personal computer or a LAN computer to access the Admin Client or the Smart Client.
• An Ethernet cable to connect to a computer/LAN/WAN (over a DSL Modem or Router).
• A rack to mount the SATATYA PARAM NVR in a rack.
Safety Instructions
• The Matrix device is intended for indoor use and can only be Rack Mounted. Equipment must
thus be installed into a controlled, dry, clean and secure environment where temperature and
humidity are within product specifications.
• Examine site conditions prior to installation. Notify the person concerned if unsuitable
conditions are encountered. Do not start installation until site conditions are acceptable.

11 Matrix SATATYA PARAM NVR Quick Start
• Use the power cord which is supplied along with the equipment. The product should be
operated with appropriate power voltage supply as mentioned in the specification sheet.
Ensure adequate earthing at the installation site.
• Do not touch the product with wet hands. Equipment must be installed by a trained
professional.
• Prevent metallic, foreign or liquid substances from getting inside the product. This includes
insecticide or flammable cleaning spray.
• Make sure in the Rack there is minimum 1-2 inches air gap between two systems (bottom
and top). Vent holes are provided in the system for air ventilation, make sure there is no
obstruction to block it.
• Make sure the ambient temperature for the systems is below operating temperature of the
system (40 degree centigrade) day and night.
• Ensure appropriate mains filtering and UPS are used in areas where the power source is
susceptible. Damage through power source fluctuations, spikes, etc. is not covered by
warranty.
• Do not cut off the power or move the unit when hard drives are operating. Doing so may
cause damage and loss of data.
• Make sure you have complete the wiring and installation of all the devices you want to
connect to SATATYA PARAM NVR.

Matrix SATATYA PARAM NVR Quick Start 12
SATATYA PARAM NVR will be provided with the following Services and Clients (in XCTS variants):
• Management Server
• License Server
• Recording Server
• Notification Server
• Admin Client
•SmartClient
The following Devices, Services and Clients are supported by SATATYA PARAM NVR and can be
installed/connected as per your requirement:
• SAMAS IVA Server
• Multi Monitor Client
• NVRs, DVRs and IP Cameras
•COSECCENTRAServer
•COSECPANEL200
• ARC IO 800 Controller
•SmartClient
•MediaPlayer
• Third Party / Business Application for Integration
Further the Installation instructions have been divided into two sections:
• Hardware Installations, refer “Hardware Installation of SATATYA PARAM NVR”
• Software Installations, refer “Software Installation of SATATYA PARAM NVR”
Recommendations
• Make sure you configure recording of maximum 64 channels in each HDD. If multiple HDD’s
are installed make sure you distribute the recordings. For example, if you have installed 8
HDD’s and 128 camera’s, then in each HDD recording of 16 camera’s can be configured.
• Make sure the throughput is 512 mbps down-link and 512 mbps up-link.
• Make sure both the Power Supplies are connected. If one Power Supply is connected it will
result in degraded performance.

13 Matrix SATATYA PARAM NVR Quick Start
Hardware Installation of SATATYA PARAM NVR
• Unpack SATATYA PARAM NVR and check the package contents.
Do not discard the packaging material. If any of the items is missing or damaged, please
contact the source from where you purchased the product.
• You are recommended to first install the hard disk(s and make the required cable
connections. Refer to “Opening the Top Cover” and “Installing the Hard Disk”.
• For Rack mounting, refer to “Rack Mounting” instructions.
SATATYA PARAM NVR Dimensions

Matrix SATATYA PARAM NVR Quick Start 14
Opening the Top Cover
• Always wear an electrostatic discharge preventive wrist strap or belt and use a grounding
mat.
• Make sure the power supply is disconnected. Unplug the power cable, if you have connected
it to SATATYA PARAM NVR.
• Release two screws on the back side and two screws on both left and right side.
• Make sure the thumb finger touches downward, and then push back the rear back cover.
• Release four screws on both left and right side.
• Release two screws on the top side.
• Place your hand on the front top cover and pull it out.
Installing the Hard Disk
SATATYA PARAM NVR series supports maximum eight Hard disks. The storage capacity of each
hard disk is upto 18 Terabytes. By default, no Hard disk is provided with the system. You can
install them as per your requirement.
You are recommended to install video surveillance SATA Hard disks of any standard brand.

15 Matrix SATATYA PARAM NVR Quick Start
Any electrostatic energy coming in contact with the hard disk or the internal parts of the
NVR can cause permanent damage to them. Before you begin the installation of the
hard disk, make sure your workstation is static-free. Always wear an electrostatic
discharge preventive wrist strap or belt and use a grounding mat.
• Insert the hard drive on the tray.
• Use four screws to fix the HDD.
• Slide the tray into the HDD bay.
• Push the lever to latch HDD tray.
Maximum torque to be applied for tightening the screws is 3 kgf.cm. Applying more
than specified torque will cause a damage to the HDD and the emboss.
Rack Mounting
There are two rails — inner rail and outer rail. You can install the rails into the racks using the
round holes or square holes.
Follow the instructions given below:

Matrix SATATYA PARAM NVR Quick Start 16
• Release and detach the inner rail from the outer rail.
• Align the inner rail with the system.
