Matrix 1-SERIES User manual

1-SERIES
S1x Stepper

CHAPTER 1: IMPORTANT SAFETY INSTRUCTIONS PAGE #
1.1 Before Getting Started ....................................................................................................
1.2 Proper Usage .................................................................................................................
1.3 Read and Save These Instructions ...................................................................................
CHAPTER 2: SETUP
2.1 Getting Started ..............................................................................................................
2.2 Choosing a Location .......................................................................................................
2.3 Stabilizing the Matrix Stepper..........................................................................................
2.4 Unpacking the stepper ...................................................................................................
CHAPTER 3: SERIAL NUMBER LOCATION
3.1 Serial Number Location ........................................................................................................
CHAPTER 4: STEPPER PARTS & ASSEMBLY GUIDES
4.1 Fasteners and Assembly Tools ..................................................................................................
4.2 Exploded Diagram ..................................................................................................................
4.3 Assembly Steps .....................................................................................................................
CHAPTER 5: OVERLAY DESCRIPTION / ENGINEERING MODE
5.1 Console Display .......................................................................................................................
5.2 Workout Parameter Prompts .....................................................................................................
5.3 Workout Overviews ..................................................................................................................
5.4 Workout Tips ...........................................................................................................................
5.5 Workout Setup Steps ...............................................................................................................
5.6 Using Fitness Networking .........................................................................................................
CHAPTER 6: MANAGER’S CUSTOM MODE
6.1 List of Manager’s Custom Mode ................................................................................................
CHAPTER 7: MAINTENANCE
7.1 Daily Inspection ......................................................................................................................
7.2 Daily Maintenance ...................................................................................................................
7.3 Monthly Maintenance .............................................................................................................
7.4 Recycling the Battery .............................................................................................................
CHAPTER 8: Product Specifications
TABLE OF CONTENTS
02
02
02
03
03
03
03
04
05
06
07
10
11
12
14
14
17
18
20
20
20
20
21
1

2
CHAPTER 2: Setup
3
CHAPTER 1: Important Safety Instructions
2.1 GETTING STARTED
Read the Owner’s Manual before setting up the Matrix Stepper. Place the unit where it will be used before beginning the setup procedure.
2.2 CHOOSING A LOCATION
The site should be well-lit and well-ventilated. Place the S1x on a structurally solid and flat surface a few feet from the wall or any equipment. If the site has
a heavy plush carpet, to protect the carpeting and machinery, you should place a rigid plastic base under the unit.
Please do not place the Stepper in an area of high humidity, such as the
vicinity of a steam room, indoor pool, or sauna. Exposure to intensive water vapour or chlorine could
adversely affect the electronics, as well as other parts of the machine. To make exercise a desirable
daily activity for you, the Stepper should be in an attractive setting.
2.3 STABILIZING THE MATRIX STEPPER
After placing the unit where it will be used, check its stability. If the Stepper is placed on a slightly,
uneven surface, adjusting the adjustable levelers located underneath the base frame can help, but will
not compensate for extremely uneven surfaces. To adjust, loosen the nut, and turn the leveler until
the rocking motion ceases, and both levelers rest firmly on the floor. Retighten the nut.
2.4 UNPACKING THE STEPPER
The Stepper is carefully inspected before shipment so it should arrive in good operating condition.
Matrix Fitness ships the unit in the following pieces:
Hardware Kit
(A)
(B)
(E)
(D)
(H)
(G)
(C) (F)
MAIN FRAME ASSEMBLY
REAR FOOT
HANDLEBAR SET
CONSOLE SET
CONSOLE MAST SET
LOWER HANDLE SUPPORTS
UPPER HANDLE SUPPORTS
HARDWARE KIT
A
B
C
D
E
F
G
H
)
)
)
)
)
)
)
)
1.1 BEFORE GETTING STARTED
It is the sole responsibility of the purchaser of Matrix Fitness Systems
products to instruct all individuals, whether they are the end user or
supervising personnel, on proper usage of the equipment.
It is recommended that all users of Matrix Fitness Systems exercise
equipment be informed of the following information prior to its use.
1.2 PROPER USAGE
Do not use the equipment in any way other than designed or intended by
the manufacturer. It is imperative that all Matrix Fitness Systems
equipment is used properly to avoid injury.
• Keep hands and feet clear of moving parts at all times to avoid injury.
• Unsupervised children must be kept away from this equipment.
• Do not wear loose clothing while on equipment.
READ AND SAVE
THESE INSTRUCTIONS
• This stepper is intended for commercial use
• To insure your safety and protect the equipment, read all instructions before
operating the MATRIX Stepper.
• Unsupervised Children must be kept away from this equipment
When using an electrical product, basic precautions should always be followed,
including the following:
WARNING: To reduce the risk of burns, fire, electrical shock or
injury to persons that may be associated with using this product:
• This product must be used for its intended purpose described in this Owner’s
Guide. Do not use other attachments that are not recommended by the
manufacturer. Attachments may cause injury.
• To prevent electrical shock, never drop or insert any object into any opening.
• Do not remove side covers. Service should only be done by an authorized
service technician.
• Never operate the Stepper with the air opening blocked. Keep the air opening
clean, free, of lint, hair and the like.
• Never operate the product if it has a damaged cord or plug, if it is not working
properly, if it has been damaged, or immersed in water. Return the unit to a ser-
vice center for examination and repair.
• Do not carry this unit by entertainment equipment power cord or use cord
as handle.
• Keep any of the entertainment equipment power cords away from heated surfaces
• Keep hands and loose clothing away from moving parts.
• Close supervision is necessary when the Stepper is used by or near children or
disabled persons.
• Do not use outdoors.
• Do not operate where aerosol (spray) products are being used or where oxygen is
being administered.
• To disconnect, turn all entertainment controls to the off position, then remove
plug from outlet.
CAUTION: If you experience chest pain, nausea, dizziness or
shortness of breath, STOP exercising immediately and consult a
physician before continuing.
2’ (610 mm)
1’ (305 mm) Stepper
Please leave a 24” (610
mm) behind the stepper. This
zone is to allow easy access
to the stepper and gives the
user an easy exit path from
the machine.
1.3

4 5
CHAPTER 3: Serial number location CHAPTER 4: Stepper parts and assembly Guides
FASTENERS & ASSEMBLY TOOLS
PARTS NO. DESCRIPTION QUANTITY SKETCH
Z11
Z09
Z01
Z02
Z03
Z04
Z06
Z05
Z10
Z09
Z11
Z32
Z33
Red
Pink
Black
Blue
COLOR
OF BAG
SOCKET BUTTON HEAD BOLT
(M8 x 1.25P x 30mm)
SPRING WASHER
( 8.2 x 13.5 x 2.0T)
SOCKET CAP HEAD BOLT
(M8 x 1.25P x 60mm)
SOCKET CAP HEAD BOLT
(M8 x 1.25P x 20mm)
FLAT WASHER
( 8.2 x 13 X 1.4T)
SOCKET BUTTON HEAD BOLT
(M8 x 1.25P x 55mm)
SOCKET BUTTON HEAD BOLT
(M8 x 1.25P x 20mm)
SOCKET BUTTON HEAD BOLT
(M8 x 1.25P x 16mm)
ARC WASHER
( 8.2 x 18.0 x 1.5T)
SPRING WASHER
( 8.2 x 13.5 x 2.0T)
SOCKET BUTTON HEAD BOLT
(M8 x 1.25P x 30mm)
#5 L-TYPE (+ TYPE)
WRENCH (66L)
#6 L-TYPE
WRENCH (120L)
2
2
1
2
3
2
1
4
4
4
4
1
1
3.1 SERIAL NUMBER LOCATION 4.1 FASTNERS & ASSEMBLY TOOLS
The serial number is located in front of right shroud.
SERIAL # PLACEMENT

6 7
4.2 EXPLODED DIAGRAM
CHAPTER 4: Stepper parts and assembly Guides
Z09
Z05
Z04
Z06
C41
C23
Z09
Z11
Z09
Z11
Z09
Z11
N22
Z10
Z10
Z05
Z03
Z02
Z01
CHAPTER 4: Stepper parts and assembly Guides
4.3 ASSEMBLY STEPS
1) Thread the Console Mast through the Console Mast Boot.
2) Feed the cable through the Console Mast. Tape the cable to the top of the
Console Mast to secure it temporarily.
3) Attach the Console Mast to the Base Frame using the bolts (Z01, Z02) and
washers (Z03). Ask your assistant to hold the Console Mast while tighten
screws. Using the #6 L-type Alen Wrench (Z33) tightens the screws
securely.
4) Remove the four mounting bolts from the back of the console with the
Phillips Screwdriver. Plug in the wire harness and the two heart rate wires
to the back of the console. Attach the console to the console mast with the
four bolts removed earlier in this step.
1) Install the rear foot in position at the rear of the stepper with the mat-
ing holes in the frame bracket. Insert the two bolts (Z11) and washers
(Z09) through the frame bracket and rear foot. Using the #5 L-type Allen
Wrench (Z32) tightens the screws securely.
Z09
Z11
STEP 1
N22
Z02
Z03 Z01
STEP 2

8 9
CHAPTER 4: Stepper parts and assembly GuidesCHAPTER 4: Stepper parts and assembly Guides
1) Feed the heart rate wires of the handlebar through the small hole located in the back of the Console Mast. Pull these wires up through the hole at the top
of the Console Mast. Attach the handlebar to the console mast using two bolts (Z04) and one belt (Z06) for tightening.
1) Attach the lower handle supports to the rear foot using the four bolts (Z11) and washers (Z09).
Tighten with the #5 Allen Wrench (Z32).
2) Install the upper handle supports to the lower handle supports by using the four bolts (Z05) and
washers (Z10). Tighten up all bolts in this step with the #5 Allen Wrench (Z32). And, insert the
left and right upper handle supports together.
Z09
Z11
Z05
Z10
Z09
Z11
Z05
Z10
Z10
Z05
Z10
Z05
STEP 3
Z06
Z04
STEP 4
4.3 ASSEMBLY STEPS 4.3 ASSEMBLY STEPS
ASSEMBLY COMPLETE
Assembly is complete.
Final assembly and optional entertainment shown.

10 11
CHAPTER 5: Overlay description / enGineerinG mode
A) WORKOUT PROFILE WINDOW:
During a workout, this window displays shapes, made of triangle columns of lights, which represent the levels of intensity in a workout-in-progress. The
height of the furthest column is proportional to the current level of the intensity. Information will cycle every 30 seconds.
B) INSTURCTION CENTER:
This window displays step-by-step instructions for setting up a workout.
C) INFORMATIONAL DISPLAY:
During a workout, three sets of numbers, including Speed, Time and Floors Climbed, display statistics about the progress of the workout.
D) PROGRAM PLUS™ KEYS
Press the key to select one of the workouts. The program key with a symbol of plus “+” represents additional workout options. Press this key repeatedly for
similar workout options.
E) LEVEL ARROW KEYS
During a workout, pressing the UP or DOWN arrow can adjust intensity levels.
F) RIGHT / LEFT ARROW KEYS
A pair of RIGHT and LEFT arrows is located on the side of SELECT. Use arrows, when setting up a workout, to change workout parameters displayed on
the LCD console, such as length of workout, weight, age, heart rate, and intensity level. In addition, the pair of RIGHT and LEFT arrows is corresponding
to the arrows in the LCD display.
G) QUICK START
Press QUICK START to begin your workout immediately, without having to select a workout program.
H) RESET
PAUSE: If you need to PAUSE your program during a workout, stop pedaling. It will PAUSE your program for 30 seconds. Pressing START will return you
to your workout. NOTE: Pause time is only available for ellipticals equipped with the battery.
RESET: If you need to RESET the console during your workout, you can do so by holding down the RESET button for three seconds, or until the
display resets.
5.1 CONSOLE DISPLAY
A
B
C
E
F
G
H
D
5.2 WORKOUT PARAMETER PROMPTS
CHAPTER 5: Overlay description / enGineerinG mode
PROMPT DEFAULT MINIMUM MAXIMUM UNIT
TIME
LEVEL
WEIGHT
AGE
DISTANCE
CALORIES
WATTS
Heart Rate
GENDER
20
1
68 / 150
30
5 / 3
500
150
n/a
MALE
5
1
34 / 75
10
1 / 1
50
50
52
MALE
99
20
182 / 400
99
80 / 50
5000
350
200
FEMALE
minute
kg / lbs
years old
km / mile
cal.
watt
beat
This section lists the default value and value range of workout parameters appeared in the PROMPT AREA, located in the bottom of WORKOUT
PROFILE WINDOW. Before an exercise session, each parameter prompt will appear here depending on different programs.
NOTE: The workout time is a “countdown” display according to the default time or the maximum time that a user inputs. When the workout time is
inputted as “0”, the time will count up from a zero to the maximum time.

12 13
CHAPTER 5: Overlay description / enGineerinG mode CHAPTER 5: Overlay description / enGineerinG mode
5.3 WORKOUT OVERVIEWS 5.3 WORKOUT OVERVIEWS
This chart lists the Matrix Stepper’s pre-programmed workouts.
PROGRAM
NAME
GOAL+
TIME
GOAL
DISTANCE
GOAL
CALORIES
GOAL
TARGET
HR
WEIGHT
LOSS
HEART
RATE+
FIT TEST
PROGRAM
NAME
DEFAULT
TIME
PROMPT
INPUT
DESCRIPTION
QUICK START
WARM UP
COOL DOWN
MANUAL
HILL
INTERVAL
RANDOM
HILL
INTERVAL+
MULTI FX+
N/A
N/A
N/A
20 min
20 min
20 min
20 min
20 min
N/A
Time
Time
Time,
Weight
Level,
Time,
Weight
Time,
Weight
Watts,
Time,
Weight
Level,
Time,
Weight
Quick Start is the fastest way to begin exercising and
bypasses the setup prompts. After pressing the QUICK
START key, a constant-level workout begins.
Warm-up is a low-intensity phase that brings the
heart rate into the lower end of the target zone and
increases respiration and blood flow to working
muscles.
Cool-down is a low-intensity phase that allows the
body to begin removing lactic acid, and other exercise
by-products, which build up in muscles and contrib-
ute to soreness.
Manual is a constant intensity level unless it is
manually changed.
Hill Interval is an efficient workout by alternating work
intervals and recovery intervals.
Random Hill is an interval training workout that
occurs in no regular pattern or progression.
CONSTANT
WATTS
RANDOM
Constant Watts is designed to maintain your watts
expenditure at a constant level by controlling pedal-
ing resistance and prompting you to pedal at a speci-
fied RPM. Watts level may vary above and below your
target watts level during this program.
Random is a workout of constantly changing intensity
levels that occur in no regular pattern or progression.
DEFAULT
TIME
PROMPT
INPUT
DESCRIPTION
20 min
N/A
N/A
20 min
20 min
5 min
Time,
Weight
Distance,
Weight
Calories,
Weight
Age,
HR,
Time,
Weight
Age,
HR,
Time,
Weight
Gender,
Age,
Weight
Time Goal sets exercise duration as the workout goal.
Once the objective is met, the workout automatically
goes into a cool-down phase and ends afterward.
Distance Goal is designed to build endurance in a
certain distance. Once the objective is met, the
workout automatically goes into a cool-down phase, and
ends afterward.
Calories Goal is designed to burn a certain number of
selected calories. Once the objective is met, the
workout automatically goes into a cool-down phase
and ends afterward.
Target HR is a higher intensity workout for maintain-
ing a heart rate to achieve maximum exercise results.
The user must wear a heart rate chest strip, or keep
hands on contact heart rate grips continuously. The
program adjusts the intensity level, based on the
actual heart rate, to maintain the rate at 80 percent of
the theoretical maximum.
Weight Loss is a low-intensity workout for
burning the body’s fat reserves. The user must wear a
heart rate chest strip, or keep hands on contact heart
rate grips continuously. The program adjusts the
intensity level, based on the actual heart rate, to
maintain the rate at 65 percent of the theoretical
maximum.
Fit Test measures cardiovascular fitness and can be
used to monitor improvements in your endurance.
PROGRAM
NAME
GOAL+
TIME
GOAL
DISTANCE
GOAL
CALORIES
GOAL
TARGET
HR
WEIGHT
LOSS
HEART
RATE+
FIT TEST
PROGRAM
NAME
DEFAULT
TIME
PROMPT
INPUT
DESCRIPTION
QUICK START
WARM UP
COOL DOWN
MANUAL
HILL
INTERVAL
RANDOM
HILL
INTERVAL+
MULTI FX+
N/A
N/A
N/A
20 min
20 min
20 min
20 min
20 min
N/A
Time
Time
Time,
Weight
Level,
Time,
Weight
Time,
Weight
Watts,
Time,
Weight
Level,
Time,
Weight
Quick Start is the fastest way to begin exercising and
bypasses the setup prompts. After pressing the QUICK
START key, a constant-level workout begins.
Warm-up is a low-intensity phase that brings the
heart rate into the lower end of the target zone and
increases respiration and blood flow to working
muscles.
Cool-down is a low-intensity phase that allows the
body to begin removing lactic acid, and other exercise
by-products, which build up in muscles and contrib-
ute to soreness.
Manual is a constant intensity level unless it is
manually changed.
Hill Interval is an efficient workout by alternating work
intervals and recovery intervals.
Random Hill is an interval training workout that
occurs in no regular pattern or progression.
CONSTANT
WATTS
RANDOM
Constant Watts is designed to maintain your watts
expenditure at a constant level by controlling pedal-
ing resistance and prompting you to pedal at a speci-
fied RPM. Watts level may vary above and below your
target watts level during this program.
Random is a workout of constantly changing intensity
levels that occur in no regular pattern or progression.
DEFAULT
TIME
PROMPT
INPUT
DESCRIPTION
20 min
N/A
N/A
20 min
20 min
5 min
Time,
Weight
Distance,
Weight
Calories,
Weight
Age,
HR,
Time,
Weight
Age,
HR,
Time,
Weight
Gender,
Age,
Weight
Time Goal sets exercise duration as the workout goal.
Once the objective is met, the workout automatically
goes into a cool-down phase and ends afterward.
Distance Goal is designed to build endurance in a
certain distance. Once the objective is met, the
workout automatically goes into a cool-down phase, and
ends afterward.
Calories Goal is designed to burn a certain number of
selected calories. Once the objective is met, the
workout automatically goes into a cool-down phase
and ends afterward.
Target HR is a higher intensity workout for maintain-
ing a heart rate to achieve maximum exercise results.
The user must wear a heart rate chest strip, or keep
hands on contact heart rate grips continuously. The
program adjusts the intensity level, based on the
actual heart rate, to maintain the rate at 80 percent of
the theoretical maximum.
Weight Loss is a low-intensity workout for
burning the body’s fat reserves. The user must wear a
heart rate chest strip, or keep hands on contact heart
rate grips continuously. The program adjusts the
intensity level, based on the actual heart rate, to
maintain the rate at 65 percent of the theoretical
maximum.
Fit Test measures cardiovascular fitness and can be
used to monitor improvements in your endurance.

14 15
CHAPTER 5: Overlay description / enGineerinG mode CHAPTER 5: Overlay description / enGineerinG mode
5.4 WORKOUT TIPS
1) Matrix Fitness strongly recommends seeing your physician for a complete physical examination before beginning any fitness program. Know your
physician-recommended heart rate target zone. If, at any time while exercising, you experiences faintness, dizziness, pain, or shortness of breathe, you must
stop immediately.
2) To mount the stepper, grasp the front stationary handlebars and place your feet on the pedals. When you are comfortably situated, begin pedaling. To dis-
mount the elliptical trainer, stop pedaling, grasp the front stationary handlebars and get off the unit.
3) It is highly recommended that you always incorporate the warm-up and cool-down period into your workout. Warm-up brings the heart rate into the lower
end of the target zone and increases respiration and blood flow to working muscles. Cool-down takes time for a user’s heart rate to return to a resting state
after vigorous exercise and reduces the amount of lactic acid in muscle tissue.
5.5 WORKOUT SETUP STEPS
Different stepper workouts require different setup procedure. This section provides details for settling up any workout program.
1) Begin to pedal the stepper.
2) Use the PROGRAM PLUS™ KEYS to enter the program, or use RIGHT / LEFT ARROW keys to scroll to desired program. The program name is displayed in
the PROMPT AREA.
3) Use the RIGHT / LEFT ARROW keys to scroll to desired parameter values displayed in the PROMPT AREA.
4) Press the SELECT key to confirm each selection. Follow the steps to set up each workout.
NOTE: The PROGRAM PLUS™ KEYS with a symbol of plus “+” have couple of similar workout options included. Press the key repeatedly to select the desired program. Or, press the program
key once and use RIGHT / LEFT ARROW keys to scroll to the desired program.
QUICK START
Press the “QUICK START” key and the WORKOUT PROFILE WINDOW will display “3, 2, 1, GO!” The workout begins at the default intensity level, and the
workout time counts up from “0” to the maximum workout time.
WARM UP
1) Press the “WARM-UP” key to enter the program.
2) “SELECT TIME” using the RIGHT / LEFT ARROW keys, and then press SELECT.
3) Press START to begin a warm-up.
COOL DOWN
1) Press the “COOL-DOWN” key to enter the program.
2) “SELECT TIME” using the RIGHT / LEFT ARROW keys, and then press SELECT.
3) Press START to begin a cool-down.
MANUAL
1) Press the “MANUAL” key to enter the program.
2) “SELECT TIME” using the RIGHT / LEFT ARROW keys, and then press SELECT.
3) “SELECT WEIGHT” using the RIGHT / LEFT ARROW keys, and then press SELECT.
4) Press START to begin the workout.
5.5 WORKOUT SETUP STEPS
INTERVAL +
A) HILL INTERVAL
1) Repeatedly Press the “INTERVAL+” key to select “HILL INTERVAL”, and then press SELECT.
2) “SELECT LEVEL” using the RIGHT / LEFT ARROW keys, and then press SELECT.
3) “SELECT TIME” using the RIGHT / LEFT ARROW keys, and then press SELECT.
4) “SELECT WEIGHT” using the RIGHT / LEFT ARROW keys, and then press SELECT.
5) Press START to begin the workout.
B) RANDOM HILL
1) Repeatedly Press the “INTERVAL+” key to select “RANDOM HILL”, and then press SELECT.
2) “SELECT TIME” using the RIGHT / LEFT ARROW keys, and then press SELECT.
3) “SELECT WEIGHT” using the RIGHT / LEFT ARROW keys, and then press SELECT.
4) Press START to begin the workout.
MULTI FX +
A) CONSTANT WATTS
1) Repeatedly Press the “MULTI FX+” key to select “CONSTANT WATTS”, and then press SELECT.
2) “SELECT WATTS” using the RIGHT / LEFT ARROW keys, and then press SELECT.
3) “SELECT TIME” using the RIGHT / LEFT ARROW keys, and then press SELECT.
4) “SELECT WEIGHT” using the RIGHT / LEFT ARROW keys, and then press SELECT.
5) Press START to begin the workout.
B) RANDOM
1) Repeatedly Press the “MULTI FX+” key to select “RANDOM ”, and then press SELECT.
2) “SELECT LEVEL” using the RIGHT / LEFT ARROW keys, and then press SELECT.
3) “SELECT TIME” using the RIGHT / LEFT ARROW keys, and then press SELECT.
4) “SELECT WEIGHT” using the RIGHT / LEFT ARROW keys, and then press SELECT.
5) Press START to begin the workout.
GOAL +
A) TIME GOAL
1) 1) Repeatedly Press the “GOAL+” key to select “TIME GOAL”, and then press SELECT.
2) 2) “SELECT TIME” using the RIGHT / LEFT ARROW keys, and then press SELECT.
3) 3) “SELECT WEIGHT” using the RIGHT / LEFT ARROW keys, and then press SELECT.
4) 4) Press START to begin the workout.
B) DISTANCE GOAL
1) 1) Repeatedly Press the “GOAL+” key to select “DISTANCE GOAL”, and then press SELECT.
2) 2) “SELECT DISTANCE” using the RIGHT / LEFT ARROW keys, and then press SELECT.
3) 3) “SELECT WEIGHT” using the RIGHT / LEFT ARROW keys, and then press SELECT.
4) 4) Press START to begin the workout.
C) CALORIES GOAL
1) 1) Repeatedly Press the “GOAL+” key to select “CALORIES GOAL”, and then press SELECT.
2) 2) “SELECT CALORIES” using the RIGHT / LEFT ARROW keys, and then press SELECT.
3) 3) “SELECT WEIGHT” using the RIGHT / LEFT ARROW keys, and then press SELECT.
4) 4) Press START to begin the workout.

16 17
CHAPTER 5: Overlay description / enGineerinG mode CHAPTER 5: Overlay description / enGineerinG mode
5.5 WORKOUT SETUP STEPS
HEART RATE +
A) TARGET HR / WEIGHT LOSS
1) Repeatedly Press the “HEART RATE+” key to select “TARGET HR” or “WEIGHT LOSS”, and then press SELECT
2) “SELECT AGE” using the RIGHT / LEFT ARROW keys, and then press SELECT.
3) “SELECT HR” using the RIGHT / LEFT ARROW keys, and then press SELECT.
4) “SELECT TIME” using the RIGHT / LEFT ARROW keys, and then press SELECT.
5) “SELECT WEIGHT” using the RIGHT / LEFT ARROW keys, and then press SELECT.
6) Press START to begin the workout.
B) FIT TEST
1) “SELECT GENDER” using the RIGHT / LEFT ARROW keys, and then press SELECT.
2) “SELECT AGE” using the RIGHT / LEFT ARROW keys, and then press SELECT.
3) “SELECT LEVEL” using the RIGHT / LEFT ARROW keys, and then press SELECT.
4) “SELECT WEIGHT” using the RIGHT / LEFT ARROW keys, and then press SELECT.
5) Press START to begin the workout.
The tables below list fit test results:
FIT TEST’S RESULT FOR MALE
Male
Rating
Age
Estimated VO2 Max (ml/kg/min) Per Age Category
Excellent GOOD
AVERAGE POOR
18 – 25
26 – 35
36 – 45
46 – 55
56 – 65
65 +
<79
<81
<83
<87
<86
<88
79-89
81-89
83-96
87-97
86-97
88-96
90-99
90-99
97-103
98-105
98-103
97-103
100-105
100-107
104-112
106-116
104-112
104-113
106-116
108-117
113-119
117-122
113-120
114-120
117-128
118-128
120-130
123-132
121-129
121-130
>128
>128
>130
>132
>129
>130
ABOVE
AVERAGE BELOW AVERAGE VERY POOR
FIT TEST RESULT FOR FEMALE
Female
Rating
Age
Estimated VO2 Max (ml/kg/min) Per Age Category
Excellent GOOD
AVERAGE POOR
18 – 25
26 – 35
36 – 45
46 – 55
56 – 65
65 +
<85
<88
<90
<94
<95
<90
85-98
88-99
90-102
94-104
95-104
90-102
99-108
100-111
103-110
105-115
105-112
103-115
109-117
112-119
111-118
116-120
113-118
116-122
118-126
120-126
119-128
121-129
119-128
123-128
127-140
127-138
129-140
130-135
129-139
129-134
>140
>138
>140
>135
>139
>134
ABOVE
AVERAGE BELOW AVERAGE VERY POOR
5.6 USING FITNESS NETWORKING
The two RJ45 networking ports are equipped in Matrix Stepper S1x. These ports allow the stepper to be connected to a fitness entertainment
system and/or a fitness network, such as FitLinxx®.
C-SAFE / CARDIO PORT
The ports are located on the back of the console. The C-SAFE port enables the stepper to upload user workout statistics to a fitness network database. The
CARDIO port is compatible to entertainment protocol such as Cardio Theater® or BroadcastVision™.
C-SAFE
CARDIO
C-SAFE
CARDIO

18 19
CHAPTER 6: ManaGer’s Custom ModeCHAPTER 6: ManaGer’s Custom Mode
6.1 LIST OF MANAGER’S CUSTOM MODE
The Manager’s Custom Mode allow the club owner to customize the elliptical trainer for the club.
To enter the Manager’s Custom Mode, press and hold down the “LEVEL ARROW keys“ . Continue to hold down these two keys until the INSTRUCTION
CENTER displays “MANAGER MENU”.
1. To scroll through the list of Manager’s Custom Mode, use the “LEFT / RIGHT ARROW keys”, or “LEVEL ARROW keys”. The INSTRUCTION CENTER will display, in
turn, each of custom settings.
2. To select a custom mode, press the SELECT key to enter.
3. To change the value of the setting, use the “LEFT / RIGHT ARROW keys”, or “LEVEL ARROW keys”.
4. To confirm and save the value of the setting, press the QUICK START key. “SETTING SAVED” will appear in the INSTRUCTION CENTER. To exit the setting
without saving, press the RESET key within 5 seconds, or if there is no key pressed, the system will resume automatically.
LIST OF MANAGER’S CUSTOM MODES:
P0
P1
P2
P3
P4
P5
P6
99 min
20 min
1
68kg /
150lbs
N/A
20 min
5 min
1
34kg /
75lbs
0
99 min minute
max.
time
10
182kg /
400lbs
104,000
km /
65,000
mile
MAXIMUM
TIME
DEFAULT
TIME
DEFAULT
LEVEL
MAXIMUM
LEVEL
DEFAULT
WEIGHT
DEFAULT
AGE
ACCUMU-
LATED
DISTANCE
CUSTOM
SETTING DEFAULT MINIMUM MAXIMUM UNIT STEP DESCRIPTION
Control the default program time.
Control the starting resistance level for
all programs.
Control the default weight used in calorie
calculations. Set to default unit change
(kilograms or pounds). Displayed in
native units.
Enable fitness club managers to set the
program maximum workout duration limits
during peak and non-peak hours of club
traffic. Active variable displayed in the TIME
display after change.
Enable to set maximum resistance level for all
programs.
Control the default users age used in target
heart rate calculations.
1
minute 1
1
1
n/a
20 1 20
n/a
30 10 99
age
kg/lbs
1
1
N/A
km /
mile
Accumulated distance is not editable, but only
for display. Displayed in native units (miles or
kilometers). After the equipment reaches the
maximum distance, it will reset to "0"
automatically.
6.1 LIST OF MANAGER’S CUSTOM MODE
P7
P8
N/A 0 65,000 hrs N/Ahour
30 sec 30 sec 180 sec 1second
ACCUMU-
LATED
TIME
PAUSE
TIME
Accumulated time is not editable, but only for
display. After the machine reaches the
maximum time, it will reset to "0" automati-
cally.
This is the maximum time during which a
workout can remain in pause mode. Restric-
tions exist for the machine not equipped with a
battery.
P9
P10
P11
P12
P13
P14
P15
EL N/A N/A N/A
MODEL
SOFTWARE
VERSION
ERROR
LOG
METS
LANGUAGE
CB - Upright Bike
RB - Recumbent Bike
EL – Elliptical Trainer
ST - Stepper
Software version is not editable, but only
for display.
If this option is "ON", the METs prompt
becomes an individual display in PROMPT
AREA. If "OFF", there will be an alternate
prompt in RPM and METs at the lower-right
corner of the WORKOUT PROFILE WINDOW.
The function would clear all custom settings
had stored on the unit and all settings return
to manufacturer default value. Holding the Left
and Right Arrow keys simultaneously to clear
all custom settings values.
N/A
English N/A N/A N/A N/A
N/A N/A N/A N/A N/A
UNITS The measurement unit prompts for weight,
distance, and speed.
English English Metric N/A N/A
N/A N/A N/A N/A N/A
OFF ON OFF N/A N/A
RESET
ALL
N/A N/A N/A N/A N/A
The native language prompts in the
INSTRUCTION CENTER.
Error log is not editable, but only for display.
Holding the Left and Right Arrow keys
simultaneously to erase the error log.
CUSTOM
SETTING DEFAULT MINIMUM MAXIMUM UNIT STEP DESCRIPTION

20 21
CHAPTER 7: Maintenance
MAINTENANCE
Matrix Stepper S1x is built for commercial environment 12 hours a day and seven days a week. However, as a club manager or owner, you are responsible
for cleaning and maintaining the unit’s integrity. If you fail to maintain the elliptical trainer as described below, it could affect or void the Matrix limited war-
ranty.
NOTE: Safety of the equipment can be maintained only if the equipment is examined regularly for damage or wear. Keep the equipment out of use until
defective parts are repaired or replaced. Pay special attention to parts that are subject to wear, such as display console, console mounting screws, handrails,
link arms, pedal arms and pedals.
7.1 DAILY INSPECTION
Look and listen for loose fasteners, unusual noises, and any other indications that the
equipment may be in need of service. If you notice any of these, obtain service.
7.2 DAILY MAINTENANCE
Matrix Fitness recommends the S1x be cleaned before and after each workout. The following daily maintenance tips will keep your unit operating at peak
performance:
1) Use a damp, soft cloth with water or mild liquid detergent to clean all exposed surfaces. DO NOT use ammonia, chlorine, or acid-based cleaners.
2) Keep the display console free of fingerprints and salt build-up caused by sweat.
3) Frequently vacuum the floor underneath the unit to prevent the accumulation of dust and dirt, which can affect the smooth operation of the unit.
7.3 MONTHLY MAINTENANCE
Perform the following services each month, or as needed:
1) Check that the console, handrails, link arms, pedal arms and pedals are secure.
2) Tighten the pedals and side handrails.
7.4 RECYCLING THE BATTERY
When the Matrix stepper is about to be discarded at the end of its useful life, the rechargeable battery must first be removed and recycled. If the elliptical
trainer is being equipped with the battery. To access the battery, unscrew the cover on the back of the console. To remove the battery, disconnect the cable.
CHAPTER 8: Product Specifications
*Product specifications are subject to change without notice.
CONSOLE
Display Screen
Display Readout
Programs
On-the-fly Program Change
Telemetric Receiver
Contact HR Sensors
Program Quick Keys
One-Touch Quick Start
Pause Time
Language Options
TECHNICAL DATA
Resistance Technology
Resistance Levels
Drive System
Step System
Step Length
Dimensions (L×W×H)
Product Weight
Max User Weight
Power Requirement
SPECIAL FEATURES
Handrail Design
Pedals
Integrated Reading Rack
Bottle Rack
ENTERTAINMENT SOLUTIONS
JOHNSON® LCD TV Mount
Networking Capabilities
Workout Profile Window – 7” blue backlit graphic LCD display
Instruction Center – 14-character red LED alphanumeric display
Informational Display – 3 numeric 7-segment display (3 sets)
Time, Floors Climbed, Calories, Speed, Level, Watts, METS, Heart Rate, Profile
Manual, Interval+(Hill Interval, Random Interval), Goal+(Time Goal, Distance Goal,
Calories Goal), Multi FX+(Constant Watts, Random), Heart Rate+(Target HR, Weight
Loss), Fit Test, Warm Up, Cool Down
Yes
Yes
Yes
Yes
Yes
30 seconds
English, Italian, German, Spanish, French, Dutch, Portuguese, Japanese
JID™ generator
20
Chain / Multi-groove Ploy-V belt
Independent Step
290 mm / 11.4”
118 × 93 × 161 cm / 46.5” × 37” × 63.5”
93 kg / 205 lbs
182 kg / 400 lbs
Plug-in
Multi-position support handrails
Over-sized pedals with non-slip footpads
Yes
Yes
Yes
Yes
S1x

|
                      
REV. 1.0
