JUMP STARTER OPERATOR’S MANUAL
RA1900
SAVE THESE INSTRUCTIONS: This manual contains
important safety and operang instrucons for the RA1700
jump start. Read through this owner’s manual carefully before
using your new jump start. Pay close aenon to all safety
instrucons, warning and cauon secons. Use your jump start
properly and only for it’s intended use.

WARNING:
1. The appliance is not intended for use by young children or inrm persons
without supervision.
2. Young children should be supervised to ensure that they do not play with
the appliance.
3. The jump start described in this manual is suitable for portable power
source or o-road side baery emergency rescues. Rangs are described as
below,
RA1900: 12V DC power source. 450 amps cranking power, 1900 Amps @ 12
volt.
CAUTION:
1. Contains sealed, non-spillable lead acid baery. Must be disposed of
properly.
2. Unit should be kept at full charge.
3. Recharge upon purchase and immediately aer each use.
4. Recharge if not used for six months.
5. Can be charged connuously without damage to unit.
WARNING: Risk of Explosive Gases
1. A lead-acid baery is dangerous because it can generate explosive gases
during normal baery operaon.
2. To reduce risk of explosion, follow these instrucons and those of the
baery manufacturer and of any equipment you intend to use in vicinity of
baery. Review warning on these products and on baery.
3. Make sure someone is close enough to come to your aid when you are
working with a lead-acid baery.
4. Avoid touching eyes while working with a lead-acid baery.
Wear complete eye and clothing protecon.
5. Keep fresh water and soap nearby in case baery acid contacts skin. Wash
immediately with soap and water if baery acid contacts skin or clothing.
If acid should get into your eye, ush immediately with cold water for 10
minutes, and get medical aenon.
6. Never smoke while working with a lead-acid baery. Do not allow a spark or
ame to get near the baery.
7. Be careful not to drop any metal tool or object onto the baery as sparking
may occur This may create an explosion hazard.

8. A lead-acid baery can produce a short-circuit current strong enough to
weld metal to skin. Remove all jewellery and personal metal items when
working with a lead-acid baery.
9. Do not use the portable power source to charge dry-cell baeries. These
baeries may burst and cause injury and damage to persons or property.
10. Do not aempt to charge or boost a frozen lead-acid baery.
11. Even though the portable power source is equipped with polarity
protecon, prevent clamps from touching each other or contact the same
metal to prevent accidental arcing.
12. Use of an aachment not recommended or sold by the manufacturer may
result in a risk of damage to the unit or personal injury.
13. When using the wall charger or power extension cord, pull on the plug and
NEVER ON THE CORD when disconnecng.
14. Replace damaged wall charger or power extension cord immediately. Do
not aempt to recharge the portable power source with damaged cords.
15. The portable power source is designed for use under all weather
condions.
16. Prevent submersion in water.
17. Do not operate with ammables in the vicinity such as gasoline etc.
18. If the portable power source is damaged in any way, disconnue use If the
portable power source is leaking baery acid do not scrap it. Take it to the
closest baery recycler in your area.
19. The portable power source should never be le in a total discharge state
for any period of me. Damage to the baery could be permanent.
When not in use, leave the portable power source connected to the wall
charger or recharge every six (6) months.
OPERATIONAL AND SAFETY DESIGN FEATURES
1. The portable power source provides more then enough starng power for
most vehicles. May also be used in deep cycle applicaons.
2. The portable power source will power most 12 volt DC equipment with a
male cigaree DC plug.
3. The portable power source comes equipped with DC automac overload
protecon.
4. The portable power source contains 1 x 12 volt sealed baery

Important Note:
Unauthorised modicaons to the portable power source, not expressly
approved by the party responsible for radio frequency emission levels from
the portable power source, may cause an increased amount of radio frequency
energy to be emied. Such a modicaon could void the customer’s authority
to use the portable power source.
FIRST TIME CHARGE PROCEDURES
When rst purchased, the portable power source should be charged for a
minimum of 30 hours, unless all the power level lights and he charged light
comes on when the test buon is pressed.
The power source can only be charged at 12V. Turn switch to 12V System and
Recharge then recharge power source.
Figure 1. Test buon, Charging and Charge Volt meter.
RECHARGING THE PORTABLE POWER SOURCE WITH 240V
CHARGER
1. With the Switching Power Charger DC Extension Cord
a. Plug one end of the power extension courd into the portable
power source DC receptacle and connect to the harness device of the
Switching Power charger.
b. Connect the charger to the AC outlet (the orange standby/charging
light will turn on)
c. Allow the portable power source to charge unl the charged light
illuminates on the Switching Power Charger.
d. Once the charged light comes on, device can be disconnected from
the Switching Power Charger.
Note: You can press the TEST buon to check power level.


OPERATING INSTRUCTIONS
USE AS A BATTERY CHARGER
The portable power source can be used to restore a limited charge to the
vehcile baery.
1. Using the DC extension cord included with the portable power source, plug
one end into the portable power source.
Plug the other end into the vehcile cigaree outlet. Allow the baery to
charge for 30 minutes.
2. Some vehicle ignions must be turned to accessory to acvate the cigaree
lighter socket. Adefecve baery may not accept a charge from the
portable power source.
3. Remove the port extension cord and start the vehicle.
USE AS A JUMP STARTER IN EMERGENCIES
For opmum performance, do not store below 10oC when using as a jump
starter. The portable power source will only jump start a baery if there is
more than 3 volt DC of power remaining in the baery. If the baery is below 3
volt DC, please refer to “Operang Instrucons: Use as a baery charger”, and
follow the instrucons to recharge the baery.
1. Ignion MUST be turned o before making cable connecon.
2. Be sure you operate the portable power source in a well venlated area.
3. Be sure eyes are appropriately protected with safety eyewear.
4. Aach the red (posive +) clamp to the posive terminal on the baery.
5. Aach the black (negave -) clamp to the vehicle frame.
6. Be sure that all cables clear of moving belts or fan blades.
7. Keep a safe distance from baery while jump starng.
8. Turn on the vehicle ignion. If the vehicle does not start aer 6 seconds,
let the portable power source cool for 3 minutes before aempng to
start the vehicle again. Damage could result to the unit if this is not done.
9. Aer the vehicle has started, disconnect the black (negave -) clamp from
the vehicle frame. Then remove the red (posive +) from the baery
terminal. The yellow Charging light will remain lit unl the red (posive +)
cable is disconnected from the baery. Aer use, store the clamps in the
compartments.

USE AS AN ALTERNATIVE POWER SUPPLY
Since most vehicles have electronic components (alarm systems, radios, etc)
whose memory can be lost when the baery is disconnected, the portable
power source is a useful tool when replacing a baery. By connecng the DC
extension cord to the vehicle’s cigaree lighter, the memory can be retained.
USE AS A MULTIPURPOSE POWER SOURCE
1. The portable power source can also be used to power any equipment that
incorporates a 12 volt DC male adapter. the DC outlet on the portable
power source comes equipped with overload protecon. DC power will be
generated only through the DC outlet.
2. Used with an inverter, the portable power source can operate appliances
normally powered by 220 Vac. A 300 Wa maximum inverter is
recommended.
ANTIZAP®PROTECTION
The RA1900 has built in Anzap® Surge Protecon, which will
protect against surge and spikes. When the clamps are connected,
the Anzap Protected Safety LED indicator should light up, indicang
that the enre circuit is now protected.
If the Reverse Connecon & Warning Buzzer LED’s will illuminaon
and a warning buzzer will sound. Stop immediately as you have
connected the clamps in reverse.

TROUBLESHOOTING
Charger works well but there is no
volt charge on the volt meter when
the Switching Power Charger is
connected to the Portable Power
Source
a) Possible defecve baery or faulty
breaker. Try using a deice (light, TV,
etc) with a DC plug on it to see if it
works.
b) If it works, the portable power
source breaker is operaonal and the
baery may be the issue.
Charger comes up fully charged but
when test buon is pressed, volt
meter shows low voltage.
a) Portable power source has a
defecve baery. May be caused
by intense use without allowing a
cooling down period.
b) Use a DC plug to connect other
baery or device to see if volt meter
analogue indicator moves. If not,
replace volt meter.
Portable power source is fully
charged, but has no power.
a) Check where the wire meets the
jaw on the portable power source
clamp. Male sure they are well
crimped, or if your unit has a power
switch, make sure it is in the ‘On’
posion.
When trying to use an accessory
through the DC outlet, a clicking
sound comes from inside the portable
power source.
a) The accessory is drawing too many
amps, causing the internal circuit
break to cycle ON and OFF.

FREQUENTLY ASKED QUESTIONS
Q: How many jump starts can I expect from a fully charged unit before needing
to be recharged?
A: Depending on the engine type and size, condion of baery and
temperature, the portable power source can be used 30 mes before
recharging.
Q: What is the ideal storage temperature of the portable power source?
A: The portable power source will operate most eecvely when stored at roo
temperature. The unit will also operate under below zero degree condions,
but with less cranking power. Excessive heat will accelerate self discharge.
Q: How long should I charge the portable power source?
A: The portable power source should be charged for a minimum of 30 hours
when rst purchased. To recharge with the A/C adapter, the unit should 4 to 6
hours for every light not lit when the test buon is pushed. The unit can be le
on the wall charger connuously without damaging the unit.
Q: Can the self contained baery be recycled.
A: Yes. Please see REMOVAL AND DISPOSAL instrucons.
BATTERY REMOVAL AND DISPOSAL INSTRUCTIONS
Contains sealed, non-spillable lead acid baery. Must be disposed of properly.
IMPORTANT:
REMOVAL AND DISPOSAL
The baery inside this portable power source is a sealed lead-acid baery. It is
required by law to be removed and recycled or disposed of properly. Naonal,
as well as any addional local regulaons must be followed. When the baery
in this product is in need of disposal, remove it according to the instrucons
provided below and take it to your local recycling centre for proper recycling or
disposal. If you don’t have a local recycling centre that handles sealed lead-acid
baeries, contact your local environmental agency for instrucons.
REMOVAL INSTRUCTIONS
Begin by making sure that both booster clamps are securely stored in their
compartments on each side of the portable power source.

1. Lay the portable power source front side down. On the back of the unit,
locate the screws that hold the portable power source enclosure together.
2. Remove the screws, then li o the back lid of the portbale power source
enclosure.
3. On the top of the baery there are two terminals, each with wires
connected to them. Disconnect these wires from the baery by removing
the bolts that hold them to the baery terminals. Be careful not to touch
both the baery terminals with the tools being used to remove the bolts
to prevent accidental arcing.
4. Li the baery out of the front of the enclosure.
LIMITED WARRANTY
The Matson Group Pty Ltd warrant the product for one year from the date
of original retail purchase, for faults arising from defecve workmanship or
materials that may develop under normal working condions and proper use.
The Company will repair the product at no charge for parts and labour.
The warranty does not operate where:
1. The customer fails to provide documentary evidence of date of purchase
and delivery of the product.
2. The product has been altered, abused, misused, worn out or used for a
purpose other than which it was intended.
3. The product has been used in a manner inconsistent with any instrucons
regarding its use.
4. Unauthorised repairs, alteraons or modicaons have been made to the
appliance.
5. The product has been improperly packaged and damaged when returned
for repair.
The Warranty excludes fair wear and tear, damage arising from circumstances
outside the control of The Matson Group Pty Ltd, including without limitaon,
faulty installaon. This warranty applies to the product only and does not
apply to any accessory items included with the product or product parts which
are subject to wear from usage, including, but not limited to, clamps and
cables; the replacement or repair of these items shall be at the expense of the
owner. This warranty gives you specic legal rights, and you many also have
other rights which vary from state to state.

THE COMPANY DOES NOT AND SHALL NOT BE LIABLE FOR ANY LOSS,
CLAIM, INJURY OR DAMAGE, TO ANY PERSON OR PROPERTY, OR
LOST PROFITS OR OTHER SIMILAR LOSS OR DAMAGE, WHICH MAY
ARISE, DIRECTLY OR INDIRECTLY, RESULT OR BE CLAIMED TO HAVE
RESULTED FROM A DEFECT IN MATERIALS OR WORKMANSHIP OF
THE PRODUCT THE COMPANY’S LIABILITY, IF ANY, SHALL NEVER
EXCEED THE PURCHASE PRICE OF THIS PRODUCT REGARDLESS OF
WHETHER LIABILITY IS PREDICATED UPON BREACH OR WARRANTY
(EXPRESS OR IMPLIED), NEGLIGENCE, STRICT TORT OR ANY OTHER
THEORY.
TO OBTAIN SERVICES UNDER THIS WARRANTY
DO NOT RETURN THE BATTERY CHARGER TO THE STORE WHERE PURCHASED.
For answers to quesons regarding warranty service, out of warrant service or
product use, call the phone number listed below or email [e-mail].
au
Customers are requied to call The Matson Group Pty Ltd Warrant Department
between the hours of 7 am - 5pm Monday to Thursday to obtain a return
authority number prior to the return of any goods. Freight on return goods
must be paid by the sender. Goods will not be accepted for credit or warranty
aer 12 months from the date of the original invoice.
Matson reserves the right to refuse credit for any goods returned in a condion
unt for repair/replacement.
Unsolicited returns will not be accepted and will be returned to the sender at
the sender’s expense.
The Matson Group Pty Ltd
100 Links Road
St Marys NSW 2760 Australia
Ph: [phone] Fax: [phone]
[email protected]
www.matson.com.au
G
r
o
u
p
