Matweld 05400 User manual

1
632 South 3rd Street
P.O. Box 2816 • Paducah, KY 42002
270-444-0085
Fax: [phone]
Website: www.matweld.com
Email: [email protected]
MATWELD, INC. PHONE:[phone] FAX:[phone]
Matweld reserves the right to change parts, features, or specifications without notice.
The Matweld Angle Grinder is a multi-
purpose grinding and cutting tool which
accepts a variety of accessory attach-
ments. It can be used for removing rust
and scale, grinding rail welds, frog
points, or anywhere a detailed grind is
required.The head assembly is a
adjustable to rotate 360 degree for
operator comfort.
05400
ANGLE GRINDER
A
B
C
FLOW PRESSURE RPM DIMENSIONS WEIGHT
10 gpm 2000 psi 3800 A - 21" 15 lbs.
(38 lpm) (140 bar) B - 8" (6.8 kg)
C -12"
REV.8/04

2
MATWELD, INC. PHONE:[phone] FAX:[phone]
Matweld reserves the right to change parts, features, or specifications without notice.
06/00 REV.8/04

3
MATWELD, INC. PHONE:[phone] FAX:[phone]
Matweld reserves the right to change parts, features, or specifications without notice.
06/00
GENERAL SAFETY PRECAUTIONS:
TOOL OPERATORS AND MAINTENANCE PERSONNEL MUST ALWAYS COMPLYWITH THE
SAFETY PRECAUTIONS GIVEN IN THIS MANUAL, AND WITH ALL STICKERS AND TAGS AT-
TACHED TO THE TOOLAND HOSE. ALL SAFETY PRECAUTIONS ARE GIVEN FOR YOUR SAFETY.
READ TO UNDERSTAND AND FOLLOW ALL SAFETY, MAINTENANCE AND OPERATION INSTRUC-
TIONS BEFORE YOU USE OR MAINTAIN THE TOOL. REVIEW THE MANUAL DAILYBEFORE
USING THE TOOL. IN ADDITION, FOLLOW ALL SAFETY GUIDELINES GIVEN YOU BY YOUR
SUPERVISOR. DO NOT USE THE TOOL IF YOU HAVE ANY QUESTIONS ABOUT THE OPERA-
TION, SAFETY OR MAINTENANCE OF THIS TOOL. FAILURE TO FOLLOW THESE INSTRUC-
TIONS CAN RESULTIN PERSONAL INJURYOR EQUIPMENT DAMAGE.
MATWELD HAS NO CONTROL OVER TOOL USE OR OPERATION ONCE IT LEAVES THE
MATWELD PLANT. MATWELD HAS NO CONTROL OVER OPERATOR OR MAINTAINER SELEC-
TION. THE CUSTOMER MUST ASSUME RESPONSIBILITY FOR THE TOOL’S SUITABILITY FOR
APARTICULAR FUNCTION. DURING USE OF TOOL, GOOD JUDGEMENT MUST BE USED TO
WORK SAFELY AND EFFICIENTLYWITHOUT ENDANGERING THEMSELVES OR BYSTANDERS.
UNDERSTANDING OF THE OPERATION AND MAINTENANCE MANUAL IS ESSENTIAL FOR
ANYONE USING OR MAINTAINING THE TOOL.
•DO NOT OPERATE THE TOOL UNTIL YOU HAVE BEEN THOROUGHLY AND PROPERLY
TRAINED OR UNDER THE SUPERVISION OF AN INSTRUCTOR.
•CHECK POWER SOURCE DAILY TO DETERMINE IF CORRECT FLOW AND PRESSURE ARE
AVAILABLE. NEVER EXCEED FLOWS OR PRESSURES FOR THE TOOL BEING USED. PER-
SONAL INJURYOR DAMAGE TO THE TOOL CAN RESULT.
•OPERATORS MUST CLEAR THE WORK AREA OF NON-ESSENTIAL PERSONNEL. FLYING
DEBRIS CAN CAUSE SERIOUS INJURY.
•THE OPERATOR MUST BE FAMILIAR WITH ALL PROHIBITED WORK AREAS SUCH AS UN-
SAFE GRADES, POOR FOOTING AREAS AND OVERHEAD HAZARDS.
•MAINTAIN BALANCE AND PROPER FOOTING AT ALL TIMES. NEVER OVERREACH TO THE
EXTENT THAT A BROKEN PARTOR SUDDEN MOVEMENT OF THE TOOL CAN CAUSE YOU
TO LOSE YOUR BALANCE AND FALL, OR CAUSE INJURY TO YOUR SELF OR SOMEONE
ELSE.
REV.8/04 REV.8/04

4
MATWELD, INC. PHONE:[phone] FAX:[phone]
Matweld reserves the right to change parts, features, or specifications without notice.
06/00
•WHEN WORKING NEAR ELECTRICAL CONDUCTORS, ALWAYS ASSUME THAT THE CON-
DUCTORS ARE ENERGIZED AND THATHOSES AND CLOTHING CAN CONDUCT HARMFUL
ELECTRICITY. USE HOSES LABELED AND CERTIFIED AS NON-CONDUCTIVE.
•DO NOT OPERATE THE TOOLAT EXCESSIVE FLUID TEMPERATURES OPERATOR DISCOM-
FORT AND POTENTIAL BURNS CAN RESULT AT HIGH OIL TEMPERATURES.
•NEVER WEAR LOOSE CLOTHING THATCAN GET ENTANGLED IN THE WORKING PARTS
OF THE TOOLS OR BE CARELESS WITH HANDS, FEET OR OTHER BODY PARTS AROUND
THE WORKING PARTS OF THE TOOLS. HYDRAULIC TOOLS EXERTHIGH TORQUE AND
FORCE AND CAN CAUSE SERIOUS INJURYOR DEATH IF IMPROPERLYUSED.
•TO AVOID PERSONAL INJURYOR EQUIPMENT DAMAGE, ALL TOOL REPAIR, MAINTENANCE
OR SERVICE MUST ONLYBE PERFORMED BY AUTHORIZED AND PROPERLY TRAINED
PERSONNEL.
•ALWAYS WEAR SAFETY EQUIPMENT SUCH AS OIL INJECTION RESISTANT WORK GLOVES,
SAFETY GLASSES, SAFETY BOOTS, EAR PROTECTION AND OTHER SAFETY APPAREL
DICTATED BY YOUR SUPERVISOR APPLICABLE FOR THE JOB YOU ARE DOING AND THE
TOOL YOU ARE USING.
•DO NOT CLEAN INSPECT OR REPAIR THE TOOL WHILE CONNECTED TO THE POWER
SOURCE. ACCIDENTAL ENGAGEMENT OF THE TOOL CAN CAUSE SERIOUS PERSONAL
INJURY.
•OIL INJECTION HAZARD EXISTS WITH THIS TOOL. OIL INJECTION IS ACONDITION WHERE
HYDRAULIC OIL IS INJECTED UNDER THE SKIN FROM PRESSURE IN THE LINE. ALWAYS
WEAR GLOVES AND REPAIR ANY LEAKS IMMEDIATELY. NEVER CARRY A TOOL BY THE
HOSES.
•DO NOT USE DAMAGED EQUIPMENT. IMMEDIATELYREPLACE ANY DAMAGED HOSES,
FITTINGS, OR OTHER COMPONENTS SHOWING WIRE BRAID, NICKS, CUTS, DAMAGE OR
ABRASIONS. FAILURE TO DO SO MAYRESULTIN EQUIPMENT DAMAGE AND / OR PER-
SONAL INJURYOR DEATH.
•CLEAN UP ANY OIL OR FLUID SPILLS IMMEDIATELY.
REV.8/04

5
MATWELD, INC. PHONE:[phone] FAX:[phone]
Matweld reserves the right to change parts, features, or specifications without notice.
06/00
HAVE SUPERVISOR ADD ADDITIONAL PRECAUTIONS RELATING TO THE SPECIFIC
WORK AREA AND LOCAL SAFETY REGULATIONS BELOW:
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
REV.8/04

6
MATWELD, INC. PHONE:[phone] FAX:[phone]
Matweld reserves the right to change parts, features, or specifications without notice.
06/00
05400 RIGHT ANGLE GRINDER
SAFETY PRECAUTIONS:
1. ALWAYS WEAR PROTECTIVE EQUIPMENT SUCH AS GLOVES, SAFETY GLASSES, EAR
PROTECTION AND SAFETY SHOES.
2. DO NOT WEAR CLOTHING WHICH MAYBECOME ENTANGLED IN THE TOOL.
3. ALWAYS KEEP WORK AREA FREE OF TOOLS OR ANY OTHER OBJECTS
WHICH MAYIMPAIR SOUND FOOTING.
4. CAUTION OIL INJECTION HAZARD EXISTS WITH THIS TOOL. OIL INJECTION IS ACONDI-
TION WHERE THE HYDRAULIC OIL IS FORCED UNDER THE SKIN THROUGH PRESSURE
IN THE LINE. ALWAYS WEAR GLOVES, DO NOT CARRY THE TOOL BY HYDRAULIC HOSES,
AND REPAIR LEAKS IMMEDIATELY..
5. NEVER CHANGE STONES WITH THE POWER SOURCE VALVE(S) IN THE “ON” POSITION,
TURN THE POWER SOURCE “OFF”.
6. NEVER ATTEMPT TO CARRY THE GRINDER WITH THE POWER SOURCE IN THE “ON”
POSITION, TURN THE POWER SOURCE “OFF”.
7. NEVER TOUCH OR TRY TO STOP A MOVING STONE.
8. ALWAYS CHECK THE WORK AREA FOR ANY TRASH WHICH MAYIGNITE FROM SPARKS.
9. ALWAYS CHECK THE AREA FOR SMOLDERING TIES OR TRASH BEFORE LEAVING THE
SITE.
10. WHEN CHANGING STONES, FOLLOW ALL GRINDING STONE MANUFACTURERS INSTRUC-
TIONS FOR SAFETY AND OPERATION. USE ONLYSTONES THATCOMPLYWITH ANSI
STANDARDS. BEFORE USING, RUN NEW GRINDING STONE FOR ONE MINUTE AT FULL
SPEED TO CHECK FOR DEFECTS OR VIBRATION.
11 MOST HYDRAULIC OILS HAVE AFLASHPOINT OF APPROXIMATELY500 DEGREES (F).
MAKE SURE HOSES ARE COMPLETELYCLEAR OF SPARKS AND HOT DEBRIS. HAVE
ANOTHER PERSON STAND CLOSE TO HYDRAULIC POWER SOURCE CONTROLS TO OB-
SERVE OPERATION AND FOR EMERGENCY SHUTDOWN IF NECESSARY.
REV.8/04

7
MATWELD, INC. PHONE:[phone] FAX:[phone]
Matweld reserves the right to change parts, features, or specifications without notice.
06/00
05400 RIGHT ANGLE GRINDER
FLOW:10 GPM (38 LPM)
PRESSURE: 2000 PSI (140 BAR)
MAX BACK PRESSURE: 150 PSI (17 BAR)
ROTATION: COUNTER-CLOCKWISE
RPM: 3800
OPERATION:
1. CONNECT THE HOSES TO THE POWER SOURCE BEFORE TURNING THE POWER
SOURCE “ON”. DO NOT DRAG THE SERVICE HOSES BY PULLING WITH THE TOOL.
LOOP THE SERVICE HOSES IN THE WORK AREA IN SUCH AWAY TO RELIEVE
STRESS ON THE HOSES AND QUICK DISCONNECT FITTINGS WHILE WORKING.
BE AWARE OF HOSE LOCATION AT ALL TIMES.
2. CONNECT THE TOOL TO THE POWER SOURCE.
3. TURN THE POWER SOURCE ON TO SUPPLY10 GPM TO THE TOOL.
4. GRASP THE TOOL FIRMLYBEFORE DISENGAGING THE TRIGGER SAFETY LOCK.
THERE WILL BE ASLIGHT TORQUE REACTION WHEN THE TRIGGER IS ENGAGED
AND THE STONE IS ACTIVATED.
REV.8/04

8
MATWELD, INC. PHONE:[phone] FAX:[phone]
Matweld reserves the right to change parts, features, or specifications without notice.
06/00
05400 RIGHT ANGLE GRINDER
MAINTENANCE:
MAINTENANCE:
1. CHECK TOOL DAILYFOR PROPER OPERATION, LEAKS, OR DAMAGE.
2. INSPECT HOSES DAILY. REPLACE CUT, BURNED, OR OTHERWISE DAMAGED HOSES.
3. KEEP QUICK DISCONNECT COUPLERS CLEAN AND LUBRICATED.
4. USE HYDRAULIC FLUIDS THATCOMPLYWITH HTMA SPECIFICATION 5.7, THE HYDRAULIC
FLUID SHOULD HAVE AVISCOSITY BETWEEN 100 AND 400 SSU (20-82 CENTISTOKES) AT
THE MAXIMUM AND MINIMUM EXPECTED OPERATING TEMPERATURES. PETROLEUM BASED
HYDRAULIC FLUIDS WITH ANTI-WEAR PROPERTIES AND AVISCOSITY INDEX OF OVER 140
WORK FOR AWIDE RANGE OF OPERATING CONDITIONS.
THE FOLLOWING OILS MEET HTMA SPECIFICATION 5.7:
AMOCO RYKON MV CITGO A/W ALL TEMP
SUNVIS 706 MOBIL D.T.E. 13
CHEVRON EP-MV TEXACO “RANDO” HDAZ
OTHER FLUIDS THATMEET OR EXCEED THIS SPECIFICATION CAN BE USED.
*SEE COLD WEATHER OPERATION HYDRAULIC OIL NOTE.
5. HAVE TOOL INSPECTED, AT LEAST ANNUALLY, BY MATWELD OR AMATWELD QUALIFIED
SERVICE REPRESENTATIVE TO DETERMINE IF TOOL IS IN NEED OF SAFETY CHANGES
OR WORN PARTREPLACEMENT.
6. CONTACT MATWELD ON APERODIC BASIS, AT LEAST ANNUALLY, FOR SERVICE BULLE-
TINS, SAFETY NOTICES, OR OTHER IMPORTANT INFORMATION PERTAINING TO THIS TOOL.
REV.8/04

9
MATWELD, INC. PHONE:[phone] FAX:[phone]
Matweld reserves the right to change parts, features, or specifications without notice.
06/00
05400 RIGHT ANGLE GRINDER
CHANGING STONES:
1.) TURN THE POWER SOURCE “OFF” AND DISCONNECT HOSES FROM THE TOOL.
2.) WHILE FACING GRINDING DISK, TURN COUNTER CLOCKWISE, WHILE HOLDING BACK-
ING FLANGE WITH SPANNER WRENCH PROVIDED.
ADJUSTING ANGLE OF GRINDING HEAD:
1.) TURN POWER SOURCE “OFF” WHEN MAKING ADJUSTMENTS TO ANGLE OF THE GRIND-
ING HEAD.
2.) LOOSEN THE 2 JAM NUTS ON THE BOTTOM OF THE GRINDING BODY. BACK THE BOLTS
OFF HALF A TURN.
3.) TURN THE GRINDING HEAD BY HAND TO THE DESIRED POSITION AND RETIGHTEN BOLTS
AND JAM NUTS.
REV.8/04

10
MATWELD, INC. PHONE:[phone] FAX:[phone]
Matweld reserves the right to change parts, features, or specifications without notice.
06/00
05400 RIGHT ANGLE GRINDER
GENERAL NOTES:
REV.8/04

11
MATWELD, INC. PHONE:[phone] FAX:[phone]
Matweld reserves the right to change parts, features, or specifications without notice.
06/00
REVIEW OF HYDRAULIC PRINCIPLES
A. TOOL CIRCUIT
1. HYDRAULIC FORMULAS:
CID X RPM GPM X PSI
GPM = 231 HP = 1714 (.85)
1456.9
Example: HP required to deliver 10 GPM at 1500 PSI.
10 GPM X 1500 PSI = 15000 = 10.3 HP
1456.9 1456.9
(subtract back pressure for tool HP)
Estimated HP delivered by pump or used by tool.
PSI
GPM 500 1,000 1,500 2,000 2,500 3,000
3 1.03 2.06 3.09 4.12 5.15 6.18
5 1.72 3.43 5.15 6.86 8.58 10.30
10 3.43 6.86 10.3 13.70 17.20 20.60
15 5.15 10.30 15.40 20.60 25.70 30.90
2. BACK PRESSURE
BACK PRESSURE MEASURED AT THE TOOL RETURN PORTMUST NOT EXCEED THE MANU-
FACTURERS BACK PRESSURE RATING. MOST MANUFACTURERS LIST THE MAXIMUM BACK
PRESSURE FOR THEIR HYDRAULIC TOOLS AT 250 PSI. BACK PRESSURE MEASURED ON THE
RETURN SIDE OF THE TOOL IS THE FORCE REQUIRED TO GET THE OIL BACK TO THE TANK. IN
ALMOST ALL CASES THE LOWER THE BACK PRESSURE THE BETTER THE TOOL PERFOR-
MANCE. FIRST, THE BACK PRESSURE IS SUBTRACTED FROM THE MAXIMUM TOOL PRES-
SURE TO ARRIVE AT A MAXIMUM TOOL OPERATING PRESSURE. FOR EXAMPLE, TOOLS WITH
2000 PSI OPERATING PRESSURE ARE INSTALLED ON ASYSTEM WITH 250 PSI BACK PRES-
SURE. THIS LEAVES 1750 PSI AS AMAXIMUM TOOL PRESSURE. IMAGINE ASYSTEM WITH 500
PSI BACK PRESSURE. 2000 MINUS 500 PSI BACK PRESSURE LEAVES ONLY1500 PSI FOR THE
TOOL. SECOND, TOOLS ARE DESIGNED FOR PRESSURE TO BUILD ON THE PRESSURE SIDE
OF THE TOOL. IF TOO MUCH PRESSURE BUILDS ON THE RETURN SIDE, NOT ONLYIS PER-
FORMANCE EFFECTED, BUT SEALS MAYBLOW. THIS IS WHY IT IS VERYIMPORTANT TO DI-
RECT THE FLOW INTO THE TOOL CORRECTLY. REVERSING THE HOSES TO TEST MAYRESULT
IN BLOWN SEALS, DAMAGE TO THE TOOL, AND PERSONAL INJURY.
REV.8/04

12
MATWELD, INC. PHONE:[phone] FAX:[phone]
Matweld reserves the right to change parts, features, or specifications without notice.
06/00
05400
RIGHT ANGLE GRINDER
REV.8/04

13
MATWELD, INC. PHONE:[phone] FAX:[phone]
Matweld reserves the right to change parts, features, or specifications without notice.
06/00
05400
RIGHT ANGLE GRINDER
DESCRIPTION
GEARBOX HOUSING
GEAR BOX INPUT SHAFT
GEAR BOX OUTPUT PINION SHAFT
BACKING FLANGE
MANIFOLD
COUPLER
INSPECTION PLUG
HANDLE ASSEMBLY
FLANGE BODY
#4 O-RING PLUG
TRIGGER
HYDRAULIC MOTOR
TYPE 27 GUARD
5” STONE GUARD
9” STONE GUARD
SIDE HANDLE
1 -3/8” RETAINING RING
INPUT SHAFT GLAND
GLAND SEAL
O-RING (-026)
10-32 X 1/2” SET SCREW
BALL BEARING
O-RING (-033)
3/16” X 7/8” SPRING PIN
BEVEL GEAR RH
BEARING
PINION SHAFT SPACER
1/4-20 X 1” BHCS
INPUT SHAFT SPACER
1/4 - 20 X 1/2” SET SCREW
5/16-24 CONE POINT BOLT
5/16-24 JAM NUT
3/8-16 X 1 BHCS
3/8 LOCK WASHER
TRIGGER VALVE
8 X 150MM SHCS
1/4 X 1” SHOULDER BOLT
BELLOWS SEAL
GUIDE BUSHING
LOCKING PIN
CLEVIS PIN
PIN RETAINER
SPRING
1/4-20 X 1” SHCS
HANDLE GRIP
QUICK DISCONNECT NIPPLE
QUICK DISCONNECT COUPLER
PIGTAIL HOSES
#2 STR. PLUG
ADAPTER WASHER
HANDLE PLUG
1/4 LOCK WASHER
GEARBOX PLUG CAP
BEVEL GEAR LH
GEARBOX COMPLETE
SPANNER WRENCH
1/4” DETENT PIN
WING NUT
1/4-20 X 1” SET SCREW
PINION SHAFT OUT PUT GLAND
SAFETY LEVER
1/8” SPRING PIN
ITEM NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
13A
13B
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
PART NO.
05401
05405
05406
05407
05408
05409
05410
05412
05414
231P-04
05416
05427
05425
05424
05485
05426
RI-138
05418
05413
05420
A5593
02711
05421
A6077
05422
05423
05428
A6350
05429
A5604
A1033M
A1453
A6360
A3811
045021
A1605
A6910
045036
045037
00412
A7123
A7124
046594
A5435
00106
00146
00145
05430
231P-02
045052
05436
A3809
05415
05402
05411
03975A
A6200
A2499
A5608
05419
05435
A6062
QUANTITY
1
1
1
1
1
1
1
1
1
6
1
1
1
1
1
1
4
1
2
4
1
28
1
2
1
5
1
7
1
1
2
2
2
2
1
4
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
4
1
1
1
1
1
1
1
1
1
2
REV.8/04

14
MATWELD, INC. PHONE:[phone] FAX:[phone]
Matweld reserves the right to change parts, features, or specifications without notice.
06/00
05400 RIGHT ANGLE GRINDER
DECAL LEGEND
REV.8/04

15
MATWELD, INC. PHONE:[phone] FAX:[phone]
Matweld reserves the right to change parts, features, or specifications without notice.
06/00
LIMITED WARRANTY
MATWELD, INC., PADUCAH, KY., WARRANTS TO THE ORIGINAL PURCHASE OF THIS PRODUCT
THAT THE PRODUCT WILL BE FREE FROM DEFECTS IN MATERIAL AND WORKMANSHIP FOR
THE PERIOD OF ONE (1) YEAR AFTER THE DELIVERYOF SUCH PRODUCT TO THE CUSTOMER.
OTHER EQUIPMENT AND PARTS USED, BUT NOT MANUFACTURED BY MATWELD INC. ARE
COVERED DIRECTLYBY THE WARRANTY OF THE MANUFACTURER OF THOSE PRODUCTS.
PROOF OF PURCHASE MUST BE DOCUMENTED INCLUDING REFERENCE TO ASERIAL NUM-
BER LOCATED ON EACH TOOL. THE PURCHASER’S ONLYREMEDIES UNDER THIS LIMITED
WARRANTY SHALL BE LIMITED AT MATWELD’S SOLE OPTION TO THE FOLLOWING: REPAIR,
REPLACEMENT OR REFUND OF THE PURCHASE PRICE OF THE DEFECTIVE PRODUCTS. EACH
OF THESE REMEDIES REQUIRES TIMELYNOTIFICATION OF THE DEFECT IN THE PRODUCT
AND SUBSTANTIATION THAT THE PRODUCT HAS BEEN PROPERLYSTORED, MAINTAINED AND
USED. MATWELD’S OBLIGATIONS HEREUNDER EXTEND ONLY TO THE PURCHASER OF THE
PRODUCT AND NOT TO ANY THIRD PARTY.
AS ACONDITION PRECEDENT TO MATWELD’S OBLIGATION HEREUNDER, THE DEFECTIVE PROD-
UCT MUST NOT HAVE BEEN ALTERED OR MODIFIED WITHOUT THE EXPRESS WRITTEN APPROVAL
OF MATWELD, INC. THE PRODUCT MUST NOT HAVE BEEN SUBJECTED TO DELIBERATE DAMAGE,
SHIPPING DAMAGE, NEGLECT, TAMPERING BY UNAUTHORIZED PERSONNEL OR DAMAGE BY
IMPROPER USE, STORAGE OR MAINTENANCE. SERIAL NUMBERS MUST NOT HAVE BEEN AL-
TERED, DEFACED OR REMOVED. SUCH ACTION VOIDS LIMITED WARRANTY.
EXCLUSIONS TO LIMITED WARRANTY
THIS LIMITED WARRANTY IS EXCLUSIVE AND IS IN LIEU OF ANY OTHER WARRANTY, WRITTEN
OR ORAL, EXPRESSED OR IMPLIED, INCLUDING, WITHOUT LIMITATION, ANY IMPLIED WAR-
RANTY OR MERCHANTABILITY OR FITNESS FOR APARTICULAR PURPOSE.
LIMITED WARRANTY DOES NOT COVER NORMAL WEAR AND TEAR ITEMS SUCH AS FILTERS,
HOSES, COUPLERS, BITS, SOCKETS, AUGERS, AND BATTERIES.
LIMITATION OF LIABILITY
EXCEPT AS PROVIDED ABOVE, MATWELD SHALL IN NO EVENT BE LIABLE OR RESPONSIBLE
FOR ANY INJURY, LOSS OR DAMAGE, DIRECT, INCIDENTAL OR CONSEQUENTIAL, ARISING
OUT OF THE USE OR MISUSE OR INABILITY TO USE THE PRODUCT, HOWEVER CAUSED AND
ON ANY THEORYOF LIABILITY INCLUDING, WITHOUT LIMITATIONS, BREACH OF CONTRACT,
TORT, (INCLUDING NEGLIGENCE OR STREET LIABILITY) AND NOT WITHSTANDING ANY FAIL-
URE OF ANY REMEDY HEREIN OF ITS ESSENTIAL PURPOSE, EVEN IF MATWELD WAS AWARE
OF THIS POSSIBILITY OF SUCH DAMAGE. MATWELD’S LIMITED WARRANTY AS SET FORTH
ABOVE SHALL NOT BE ENLARGED, DIMINISHED OR AFFECTED BY, AND NO OBLIGATION OR
LIABILITY SHALLARISE OR GO OUT OF THE RENDERING OF TECHNICAL ADVICE OR SERVICE
BY MATWELD OR ITS AGENTS. THE FOREGOING MAYNOT BE CHANGED EXCEPT BY WRITTEN
AGREEMENT SIGNED BY AN AUTHORIZED OFFICER OF MATWELD, THE REMEDIES SET FORTH
HEREIN ARE EXCLUSIVE.
REV.8/04

16
MATWELD, INC. PHONE:[phone] FAX:[phone]
Matweld reserves the right to change parts, features, or specifications without notice.
06/00
Name _____________________________________________________
Company___________________________________________________
Serial # of your Matweld tool___________________________________
( Upon receiving your Matweld tool, make sure to list serial number above so that a good record is kept for order
information.)
MATWELD HYDRAULIC TOOL LIST
All Matweld Hydraulic Tools operate at
5 or 10 GPM @ 2000 PSI
18. CUSTOMER INFORMATION
REV.11/06
POWER UNITS:
07000 – HYDRA POWERED MODULAR SYSTEM
02900A – DIESEL POWER UNIT
00100K – DUAL CIRCUIT POWER UNIT
02050 – GASOLINE 1-5 GPM
05500 – TWIN POWER DUAL CIRCUIT UNIT 1-10 GPM OR 2-5 GPM & 5000 WATT GENERATOR
03700A – ELECTRIC POWER UNIT
09800 - TRACK ROVER
TRACK TOOLS:
01600A – 5 GPM 1” IMPACT WRENCH
02500 - 10 GPM 1” IMPACT WRENCH
04500D – ½” IMPACT DRILL
00800A – 16” RAIL SAW
03900A – REVERSING RAIL SAW
01100 A– SPIKE PULLER
08200– TIE TAMPER
08300– SPIKE DRIVER
01500 – RAIL DRILL
01000 – CHAIN SAW
03500 – SELF FEED RAIL DRILL
03100C - RAIL PULLER
02800 - BRIDGE SPREADER
05000- HAND PUMP WELD SHEAR
05100A - POWER WELD SHEAR
06600 - POWER UNIT TRANSPORT CART
07500 - CHAMFER TOOL
OTHER PRODUCTS:
HYDRAULIC MANIFOLDS
HYDRAULIC TEST GAUGES
HOSE REELS
HYDRAULIC HOSES
ACCESSORIES
GRINDERS:
04600 & 04650– STRAIGHT STONE CW & TRIGGER VERSION
04700 & 04750 – STRAIGHT STONE CCW & TRIGGER VERSION
00600 & 00600C - 8” CUPSTONE GRINDER
04800 & 04850 – CUPSTONE & TRIGGER VERSION
00700 – RAIL SURFACING GUIDE
02400 – 10” OR 14” FROG AND SWITCH GRINDER
05900 – FROG/PROFILE GRINDER – ON/OFF FLOW CONTROL
05950 – FROG/PROFILE GRINDER – SAFETY TRIGGER
06000 – PROFILE GRINDER
05400 – ANGLE GRINDER
05600 – BULL NOSE GRINDER
06950 & 06950A - MULTI-PURPOSE GRINDER
