Max-Thrust RIOT User guide

1
R/C AEROBATIC SPORTS AIRCRAFT
ASSEMBLY AND INSTRUCTION MANUAL
Copyright Century UK Limited 2012 www.centuryuk.com
Designed by Mark Tilbury & Alan He.
©

2
Warning:
This radio controlled model is not a toy. It re uires skill to fly and is not recommended for use by
beginners without assistance from an experienced model pilot. It should not be operated by
children without the supervision of a suitably experienced adult.
Max-Thrust reserves the right to modify the specification of this model at any time.
Safety Precautions
1. Do not attempt to repair or modify this aircraft with non-factory parts.
2. Never fly this model over roads, railway lines, near to power lines, airports, do not fly this model in
excessively strong winds, in the rain, or thunderstorms.
. Do not fly or launch the model towards people.
4. Keep hands and face away from rotating propeller at all times.
5. We strongly recommend that all fixings and fasteners used in the construction of this model are
checked regularly for integrity. Failure to do so could cause a crash, injury to yourself or others
around you.
6. We only recommend the use of 2.4GHz radio e uipment with this model .
Disclaimer
1. This radio controlled model is not a toy. Used incorrectly it is capable of inflicting serious injury to
persons or damage to property. The owner/pilot assumes all responsibility for any damage to persons
or property resulting from the use of this product.
2. The manufacturer and distributor decline all responsibility for any liability arising from use of this
product.
. It is very important that you follow all instructions for assembling and setting up of this model.
Failure to do so could result in a loss of control and possibly a crash.
© Copyright Century UK Limited 2012 www.centuryuk.com
“EPOFLEXY” is a ver
y tough and durable material perfect for the manufacture of model aircraft. When
using screwed fixings with “EPOFLEXY” components it is important to tighten the screws sufficiently to
provide a firm fixing.
Excess tightening could result in the foam material becoming compressed, possibly damaging or
distorting the part. Take care to ensure that all screws are tightened sufficiently to provide a firm fixing,
but do-not over tighten. We recommend that all fixings are checked regularly for security and safety
purposes.
“EPOFLEXY”

3
Overview
Thank-you for purchasing this MAX-THRUST RIOT radio controlled model aircraft. The RIOT offers a
stunning combination of terrific looks and sensational flight performance. Manufactured from
“EPOFLEXY” it is extremely robust, however, in the event of a “less than perfect” arrival, we supply a
range of spares to get you flying again in the shortest time. It is capable of a wide range of amazing
aerobatic manoeuvres to thrill the experienced pilot, but with reduced control throws it provides a
solid and predictable flight performance, perfect for the sports flyer.
We are certain you will enjoy your new model, please take the time to read this manual thoroughly and
understand its contents completely prior to commencing assembly.
© Copyright Century UK Limited 2012 www.centuryuk.com
Key Features
Powerful Brushless Motor
40A Brushless Electronic Speed Controller
Efficient 2 Blade Propeller
Pre-Installed servos
“Live” Control Surface Hinging
Durable “EPOFLEXY” Construction
Steerable Tail Wheel
Superb Flight Performance
High Brightness LED Lighting System
Specification
Wingspan: 1400mm
Length: 1130mm
Weight: 1480g
Wing Loading: 40.3g/dm2
Motor: ST3511-KV850 Out-Runner Brushless
ESC: 40A Brushless
Servos: 4
Battery Re uired: 2200 - 2400mAh 11.1v Li-Po (Not Included)
Recommended Battery: Power-Tech 2250mAh 11.1V 33C (Order Code: PT-B-3322503S)

4
© Copyright Century UK Limited 2012 www.centuryuk.com
4 x Screw 2.6 x 12mm
Assembly Instructions
1. Undercarriage.
Fix the undercarriage in position
with the four 2.6 x 12mm self-
tapping screws as shown, (image A).
Note: The undercarriage legs are
angled towards the front of the
fuselage.
2. Horizontal Tail
-
Plane.
Slide the horizontal tail
-
plane into
the fuselage slot as shown, (image
B). Make certain that the holes in
the tail-plane line-up with the
corresponding fuselage holes.
If desired, a small amount of foam
glue can be used for maximum
security.
A
B
Install the vertical fin and rudder
assembly into the slot in the
fuselage. Please make certain
that the tail-wheel control wire is
located correctly in the rudder
slot as shown, (image C).
If desired, a small amount of
foam glue can be used for
maximum se
curity.
. Vertical Fin & Rudder.
C

5
© Copyright Century UK Limited 2012 www.centuryuk.com
4. Tail
-
Plane Fixing.
Fix the horizontal tail
-
plane and
vertical fin in position with the two
2.6 x 35mm screws provided, (image
D). The screws must be tightened
sufficiently to securely fix the parts
in position, however be careful not
to over-tighten the screws.
2 x Screw 2.6 x 35mm
D
E
5. Tail Control Horns.
Connect the rudder and elevator
snap-links to their respective control
horns as shown in images E & F.
Minor adjustment to obtain perfect
neutral positions of the control
surfaces can be achieved by rotating
the plastic link on the threaded
portion of the control push-rod.
Make certain the plastic link is
securely “snapped” closed when
connected to the control horn.
F

6
© Copyright Century UK Limited 2012 www.centuryuk.com
Plastic Collar
Locate the 500mm
aluminium wing
joining spar and slide into the round
aperture of one wing panel up to the
centre locating collar. Locate the small
plywood wing locking plate and insert
into the rectangular aperture behind
the main wing spar, (image G). Slide the
remaining wing panel onto the exposed
portion of the aluminium spar. The
plywood locking plate will ensure
perfect alignment of the two wing
halves. Be certain that all wires are
routed correctly via the moulded slots
and do not foul the joint between the
wing roots. If desired, a small amount of
foam glue can be used for maximum
security.
6. Wing Assembly.
G
Connect the two black aileron servo
plugs from the wing to the “Y” lead
as shown, (image H). The remaining
plug from the “Y” connector should
be plugged into socket “A” of the
pre-installed circuit board located in
the fuselage, (image I). Please pay
particular attention to the polarity of
this connection as shown in the
diagram.
H
I
Socket “A”
The two remaining white plugs from
the wing are for the model’s built-in
LED lighting system and should be
connected to the corresponding
sockets on the circuit board, (image
I). You will note these plugs are
polarity protected to prevent
incorrect connection.

7
J
Note:
The plastic connectors are angled for
the wing camber.
3 x Screw M4 x 50mm
1 x
1 x
Insert the front and rear plastic
connectors into the wing, (image J).
They are angled to provide a perfect
fit. Make certain you have them
located correctly! The wing can now
be trial-fixed in position onto the
fuselage using the 3 x M4 x 50mm
screws provided.
7. Wing Fixings.
8. Propeller & Spinner.
Fit the propeller and spinner to
the motor as shown, (images K &
L).
Note: It is essential that the
propeller is securely fixed.
Failure to do so could result in
serious injury.
L
K
Tighten
Securely

8
© Copyright Century UK Limited 2012 www.centuryuk.com
9. Receiver Installation.
© Copyright Century UK Limited 2012 www.centuryuk.com
Connect the speed controller to the throttle channel of your receiver, (not included). This wire is easily
identified, it is the only one that is routed from the front of the model.
Connect the rudder and elevator servos to the corresponding channel outputs of the receiver and
connect the one remaining lead from the circuit board to the aileron channel output. There is a
moulded recess in this compartment which is sufficient to accommodate most popular 2.4GHz
receivers; however there is ample room elsewhere to locate yours if it does not.
We recommend that it should be securely positioned with self-adhesive “Velcro”.
You must adhere to the receiver manufacturer recommendations regarding positioning and aerial
routing.
10. Battery Installation.
The battery compartment is accessed by gently s ueezing the two ra
ised white tags and lifting the
rear of the front hinged cover, (image M). Your flight battery, (not-included) can easily be installed and
connected to the factory fitted “T” style connector, (image N). Make certain the battery and cover are
both secure before flight.
M
N
11. Control Surfaces.
Check that all control surfaces are centred and responding correctly to transmitter inputs.
Adjustments can be made to control surface centres by carefully rotating the plastic control horns on
the threaded portion of the metal control rods. Use the servo reversing function on your transmitter
for any control that is not responding in the correct sense to control inputs. Make certain that all
plastic links are securely “snapped” closed and that all control surface hinges are secure. Use a small
amount of foam glue if any hinges are not firmly attached.
12. Propeller Rotation.
Double
-
check that the propell
er is securely fixed and it is
rotating in the correct direction, (image O).
O

9
© Copyright Century UK Limited 2012 www.centuryuk.com
1 . Centre of Gravity.
P
It is vital that you check that the
centre of gravity is correct. Failure
to do so could result in a complete
loss of control. We recommend the
balance point of the model,
complete with battery, should be
75 -90mm back from the leading
edge of the wing for initial flights,
(image P). Very experienced pilots
may wish to move the balance
point further back after initial flight
testing.
14. Control Surface Deflecti
ons.
We make the following recommendations for control surface deflections. Experienced pilots may
wish to increase these movements after initial flight testing.
Ailerons: 10mm each way.
Elevator: 10mm each way.
Rudder: 12mm each way.
Mark Tilbury: Designer.
We hope you enjoy many happy and safe flights with
your new Max-Thrust RIOT model aircraft.
Check-out other aircraft in the Max-Thrust range at your
local model dealer, or by visiting www.max-thrust.com.
