Max BC-SC-Rd-WM-2 User manual

Window Sensor
BC-SC-Rd-WM-2
Operating manual

2
Scope of delivery
Quan-
tity
Item
1x MAX! Window Sensor
(electronic and magnet unit)
2x Cap (white/brown)
6x Spacers
2x Adhesive stripes
6x Screws
2x 1.5 V LR03/micro/AAA batteries
3x Brief instruction in German/English, French/
Dutch and Polish/Italian
Scope of delivery

3
Table of contents
Table of contents
1 Information about this manual .............................4
2 Safety instructions.................................................4
3 Function.................................................................5
4 Device overview .....................................................7
5 Start-up .................................................................8
6 Teaching-in..........................................................15
7 Restore factory settings ......................................18
8 Flashing sequences and transmission behaviour. 19
9 Maintenance and cleaning ..................................19
10 Information about radio operation......................20
11 Technical specifications ......................................21
Documentation © 2014 eQ-3 AG, Deutschland
All rights reserved.
Translation of the original version in German.
Version 1.1 (11/2016)

4
Information about this manual
1
InformatIon about thIs manual
Read this manual carefully before starting to use the de-
vice. Keep the manual so you can refer to it at a later date
if you need to. If you hand over the device to other persons
for use, please hand over the operating manual as well.
Symbols used:
Attention!
This indicates a hazard.
Note.
This section contains important additional in-
formation.
2
safety InstructIons
The device is not a toy; do not allow children to
play with it. Do not leave packaging material lying
around, as it can be dangerous in the hands of a
child.
Do not open the device: it does not contain any
components that need to be serviced by the user.
In the event of an error, please return the device
to the service department.
The device may only be operated indoors and must
be protected from the effects of damp and dust,
as well as solar or heat radiation.

5
Function
Using the device for any purpose other than that
described in this operating manual does not fall
within the scope of intended use and shall inval-
idate any warranty or liability. This also applies
to any conversion or modification work. The de-
vice is intended for private use only.
3
functIon
The MAX! Window Sensor signals when windows or
doors are opened and closed. To save energy, the device
ensures that MAX! Radiator Thermostats automatically
reduce the temperature when a window or door is open
and increase it again when the window or door is closed.
The reduction temperature can be set separately for each
room via the MAX! software.
The MAX! Window Sensor can be used in the follow-
ing solutions:
MAX! House Solution
This is the solution for the entire house. With a
MAX! Cube, all settings of connected devices in
the house can comfortably be made via the MAX!
software. By using the MAX! Cube, several MAX!
Radiator solutions and MAX! Room solutions can
be connected to a MAX! House solution in a new
installation.

6
Function
MAX! Room solution
In the room solution, the settings of all connected
devices in your room can comfortably be made via
the MAX! Wall Thermostat+. Up to 8 MAX! Radiator
Thermostats+and 8 MAX! Window Sensors can be
connected and controlled via the MAX! Wall Ther-
mostat+. With a MAX! Cube, the solution can be
extended to a House solution.
MAX! Radiator solution
With the MAX! Radiator solution you can easily
start using the MAX! system. The ambient tem-
perature within a room can be flexibly controlled
and regulated with up to 2 MAX! Radiator Ther-
mostats+and 3 MAX! Window Sensors. Configu-
ration is performed directly on the MAX! Radiator
Thermostat+.
With a MAX! Wall Thermostat+, the solution can
be extended to a room solution, with a MAX! Cube
it can be extended to a House solution.

7
Device overview
4
DevIce overvIew
The MAX! Window Sensor (A+B) consists of a large elec-
tronic unit (A) and a small magnet (B):
B
AA+B
The device is supplied with spacers and caps in white
and brown.
C
D
(C) Teach-in button
(D) Device LED

8
Start-up
5
start-up
5.1
InsertIng (replacIng) batterIes
The MAX! Window Sensor is operated with two LR03/
micro/AAA batteries.
• Remove the cap of the electronic unit (A) by pulling
it forward and off the device (1). To release the cap,
squeeze it gently from above and below with your
thumb and index finger (2).
• Carefully lift the release clip (3) from the side.

9
Start-up
3
• Pull the electronic unit (A) forward (4) and off the
bracket.
• After removing the old batteries, please wait approx.
60 seconds.
• Insert two new LR03/micro/AAA batteries in the bat-
tery compartment (making sure that you insert them
the right way round).
• Place the electronic unit (A) back onto the bracket,
allowing it to latch into place.
• Put the cap back to the electronic unit (A). Make sure
that the LED opening on the cover is positioned over
the LED (D) on the electronic unit.
Never recharge standard batteries. Do not throw
the batteries into a fire. Do not expose batteries
to excessive heat. Do not short-circuit batteries.
Doing so will present a risk of explosion.

10
Start-up
Used batteries should not be disposed of with
regular domestic waste! Instead, take them
to your local battery disposal point.
5.2
mountIng
The MAX! Window Sensor consists of two elements: an
electronic unit (A) and a magnet (B) (see sec. „4 Device
overview“ on page 7). The electronic unit (A) must be
mounted on the frame and the magnet (B) on the window.
• First select the window that is frequently used for
ventilation and which the MAX! Window Sensor is to
be attached to.
• The magnet (B) can be mounted on either side of the
electronic unit (A). Installation must be in parallel with
a maximum spacing of 8 mm.
• The magnet (B) must be centre-aligned with the elec-
tronic unit (A).
