MAXBIK MX-18 User manual

USER’S MANUAL
Read this manual completely before riding electric bicycle

1809 USE MANUAL
Table of contents
Diagram of e-bike specific components-------------------2
Specification---------------------------------------------------2
Display---------------------------------------------------------3
How to Use----------------------------------------------------10
Battery--------------------------------------------------------13
Charger-------------------------------------------------------16

Diagram of e-bike specific components
1.Handlebar
2.Display
3.Front fork
4.Tyre
5.Saddle
6.Battery
7.Controller
8.Chainwheel & Crank
9.Motor
Specification
Frame: 26 inch aluminium-alloy
Motor: 250W brushless
Battery: lithium battery,48V 13Ah
Display: LCD with 5 mode.

Sensor: speed sensor 1:1
Derailleur: Shimano 7 speed outside
Brake: F/R disc-brake
Charger: 110-220V optional
Charge time: 4-6 hours
Max speed: 35km/h
Range: 50km
Max loading: 150kg
Display
1. Features

How to use
1. The process of opening and working.
Turn on the switch button on the display and turn to a level of power which
you like and then ride it.
（The level of beginning is second level and you can turn to any level by level
button）
C.go to ride like normal bicycle, you will get power assistant.
D.Each bike with throttle, after display open, you just turn it will be go .
2.The process of closing .
A.Stop ride and keep the bike is not moving.
B.Turn off the switch button on the display.
3. Warning

A. Keep the connection( motor and
battery )
is well and stable before ride.
B. Don’t turn on/off the switch button(battery and display) when you a
riding.
C.
Keep fix well the
QR of seat post and
pedal are fixed.
2. Change or take out battery .
Turn the key and pull the battery box out directly.

Battery
1.Important safety notes concerning the battery
WARNING
To prolong battery life, store the scooter in garage to prevent low
temperatures and affect the battery performance.
- Do not dismantled or dispersed the battery cells.
- Keep away the battery from children.
- Do not connect cathode and anode of charger during charging and
discharge process. Prohibited to use any conductor to connect both cathode
and anode. This will cause short circuit.
- Prohibited battery dip in the water.
- Prohibited placed the battery in the temperature over 60℃ next
to the high-temperature heat source, such as ingle, heating, etc.
13
- Prohibited knock on, throwing and trample the batteries, etc.
- Prohibited edge tool or nails lacerate and cut through the battery.
- If the leak occurred, electrolyte has come into the eyes, please do not rub.
Wash immediately with plenty of water.
- If the battery in smell, heat, smoke, changed colors, distortion or any
abnormal, stop using the battery and away from it immediately.
2.Protection
To extend the battery life and be Intelligent Use of li-battery , here are the
regulations:
Firstly: Requirements on charging and discharging

A. charge:the charger must be the assorted one . First, connect the power
to the charger. second,insert the charger’s out-put connector to the battery’s
in-put connector. Third, when the signal light is on,please pull out the
battery’s in-put connector first. The common single charging time is about
6-8 hours.if the battery be blow-up, the charging or discharging must be
stopped.
B. avoid over discharge: charge the battery timely after discharging, in
order to avoid the over-discharge.
14
Secondly: Requirements on storage
A . li-battery cannot be stored at the place where is over hot and over
humidity.therefore the temperature of the storage should between -20 to
55degree,and further more the storage must be kept in dry,clean and the
battery should not be piled up.
B . the battery cannot be stored for a longtime without charging. The battery
should be charged once a month. The battery should be stored with fully
charged.
Thirdly: Maintenance
A . When you test the voltage of the single piece of the battery-cell, you
have to test the cell directly ,not by the wire. By doing that, it can avoid the
voltage decline.
B . You have to wear the gloves or clip the finger nails before you take out

the single piece of the battery. So as to avoid damage the cover of the
battery.
C . Forbid bending the battery cell,the top edge of the seal-up.And also the
falling ,hitting and short circuit are prohibited .
D . When you re-assemble the battery,there are some special notes we have
to concerned in mind. The temperature of the
electric iron should below 350℃; the welding time must be less than 3
seconds; and the frequency of welding should be no more than 5 times;the
second welding must be done after cooling.
Charger
1.Charger function
Trouble shooting:
Should there be any difficulties with charging please check if:
-the power cable is connected properly.
-the charger plug or the battery socket is damaged.
-the battery shows any damage on the surface.
-the power socket works and whether the correct voltage is provided. (if
necessary, plug in another gadget and check).
Please use only the original charger which was supplied with the
supplier
This charger is specially made for the lithium
battery.

The LED light indicates the battery status as shown on the table below:
Charging cycle and LED indication for lithium battery
LED
Mode
green
the battery is not connected
red
the batter is charging
green
the battery is charged, the charger switches off
16
2.Important safety notes concerning the charge
Before you first use the charger please read the following notes
regarding safety carefully!
WARNING
-Keep the charger away from children!
-In order to prevent any possible injury this charger should only be used for the
original lithium battery which is supplied together with the WBLDDC. Any other
battery is not compatible and risks to explode while charging, causing serious
injury to people as well as damage to other equipment.
- Using this charger for batteries not supplied by WBLDDC,for the E-RIDE could
risk catching fire, provoke electric shock and/or cause serious injury.
-Please make sure that the charger is always kept dry and does not get wet at
any time.
-Should there be an incidence of contact with water or any other liquid,make
sure to unplug the charger immediately from the power socket and have it
inspected by a specialty dealer.
-Make sure the charge is always placed on a flat surface when in use.
-Please make sure that the charger is always unplugged tand removed from
the power socket when not in use.

-Before using the charger, always make sure that the plug and the
17
cables are not damaged.
-Never connect a damaged cable or plug to the power socket.
-Never try to disassemble the charger. Wrong re-assembling could cause an
electric shock and serious injury.
-Always unplug the charger before cleaning it.
-The charger should only be cleaned with a dry cloth. Never use a wet cloth, oil
or any other liquid.
-Do not use an extension cable. Only use the original cable
supplied with the charger.
-An extension cable might, if not 100 % compatible,catch fire or cause an
electric shock.
