Maxell MXH-C120L User manual

At the time of purchase, size M earpiece are attached to the main
unit. If size M does not fit your ears, please replace with the size S
or size L earpiece in the contents. If the earpiece does not fit
correctly, it will not be possible to seal the ear hole with the
earpiece, which may cause sound leakage and bass to be heard.
Also, if you feel that the volume is low, there is a possibility of
sound leakage.
How to Use
31. Choosing an earpiece
When replacing an earpiece, be sure to attach it securely to the
main body. If it is not firmly attached, the earpiece may come off
and remain in your ear. If it remains in your ear, be careful not to
push it into the back of your ear further.
Lightning EarphonesMXH
-
C120L
manual.●Maxell shall not be responsible for
any loss resulted from malfunction when
connecting to interconnecting devices.●This
product is not being designed to be any
equipment or device which could be
concerned with human life such as medical
device, nuclear device, astronomic device,
transportation device etc., nor equipment or
devices which requires high reliability. In case
this product is used for the above equipment
and/or systems, Maxell do not responsible for
any injuries or fire accident cause by the
failure of this product.●This product is
intended for use only in Japan. We assume no
responsibility for use in any country other
than Japan.
●Contents of this user manual might be
changed in the future without prior notice.
●For product improvement, change of
appearance or specification might not be
announced in advance.
●Maxell shall not be responsible for any
damage caused by fires, earthquakes, action of
a third party, any accidents, intended or
unintended misuse or other usage under
abnormal conditions.●All explicit and implicit
contents not stated in the warranty card are
not covered.●Maxell shall not be responsible
for failure due to any damage caused by usage
other than described in the instruction
Introduction
1About the user manual
Disclaimer
Thank you for purchasing this MAXELL product. Before use, make sure to read this Instruction Manual
and use the product correctly and safely.
Instruction Manual
Safety Precautions
2Warning refers to misuse which might lead to death or seriousinjury※1 . Stands for prohibited actions
when handling the product.
Stands for instruction which
must be followed.
Caution refers to misuse which might lead to injury※2 and may cause property damage※3.
If you continue to use it, it may cause inflammation, rash and other conditions.
When you feel abnormal, stop using it and consult a doctor.
Stop using when your skin feel uncomfortable
It may cause deteriorates,
malfunction, etc.
Do not expose the product
to water
It may hurt the ears.
Do not push the earphones hard
into the ears

※1：Severe injury refers to things that have aftereffects such as blindness, injury, burns, electric shock,
fractures, poisoning, etc., and those requiring hospitalization or long-term regular hospital visits for
treatment.
※2：Minor injury indicate injury, burns, electric shocks that do not require hospitalization or long-term
regular hospital visits for treatment.
※3："Property damage" refers to indirect damage related to houses, household goods, livestock and pets.
Please be sure to observe it for safe use.
WARNING
WARNING
Do not repair, alter or
disassemble the product.
Otherwise, fire, electric shock
or injury may occur.
Even while walking, using it in where it will be dangerous if surrounding
sounds cannot be heard (such as railway crossings, crosswalks, station
platforms, roadways, construction sites, etc.) can cause unexpected serious
accidents.
Do not use at locations where it will be dangerous if surrounding sounds
cannot be heard
Do not use while driving a car,
motorcycle, a bike, etc.
May cause traffic accident as hard to
hear surroundings.
If swallowed or the cord gets entangled around the neck, it may cause
choking etc.In case of accident, seek medical attention immediately.
Store properly at places out of children’s reach
Do not place in a place where the temperature becomes abnormally high
CAUTION
Continuously listening to loud volume can result in overstimulation
of ears for an extended period of time. It may affect the hearing.
Furthermore, if the volume is raised too much from the beginning, the
sudden loud sounds may harm ears. Before using, please reduce the
volume of the connected device.
Not only will the device surface and parts deteriorate, but it may also
cause a fire. Be especially careful inside a closed car in summer, in direct
sunlight, or near a stove.
Do not increase the volume too much
About
Symbols

Pulling the cord may break the wire, so hold the main body when
removing the earphone from your ears and remove them carefully.
Volume UP
＋ButtonMulti Button－ButtonPress the + Button
Volume DOWN Press the – Button
PLAY / PAUSE
Next Song
Receiving a call / Ending a call
Handling precautions
44. Using remote control
●Please read the instruction manual of the device to be connected.●Pulling the cord may break the wire, so hold the plug when connecting and disconnecting the earphone.●Do not apply a strong impact. It may cause failure.●Do not wrap the cord around the device. It may break the wire.●Do not put it in your trousers pocket. It may cause failure.●Do not place them where it is exposed to direct sunlight, high humidity, dust, oily smoke or steam. Also, be sure not to splash with water. It may cause failure.●Please be aware that if the volume is set too high, it may cause the sound leak and disturb other people.●Earpieces may deteriorate with long-term use or storage.●Please note that applying power over the maximum input may distort the sound or damage the diaphragm.Press the Multi Button once
Press the Multi Button once
Press the Multi Button twice
Press the Multi Button thrice
MicrophonePrevious Song
Maintenance
5●If the earphone get dirty, wipe them with a soft, dry cloth.●Wipe the connector with a soft, dry cloth from time to time. If it is left dirty, the sound quality may deteriorate, or the sound may be interrupted.●If the earpieces become dirty, remove them from the main body and wash them with diluted neutral detergent by hand. After washing, wipe off water well before using.6Cannot hear the sound
The sound is too low ●Check the connection between the earphone and the device.●Make sure the connector is fully inserted into the device.●Make sure that the connected device is turned on.●Try increasing the volume of the connected device gradually.●Check the size of the earpieces.The sound is distorted
The sound is intermittent
Hear noise ●Try turning down the volume of the connected device.●Check the connection between the earphone and the device.●Try changing the sound source.Troubleshooting
●Before wearing the earphone, turn
down the volume of the device to
be connected to the earphone.
●Wear the one with R on your right
ear and the one with L on your left
ear. The L/R are indicated behind
the earphone.
●After wearing, listen to the sound
and adjust the volume of the
connected device.
3. Wearing Earphone
R
L
2. Connect to
Device
Microphone Specification
Model Condenser
Directivity Omnidirectional
Sensitivity -38dB
Frequency Response 100〜8,000Hz
● For product improvement, change of appearance or specification might not be
announced in advance.
PA1755-00
7Basic Specification
Model
Used Unit
Impedance
Sensitivity
Maximum Input Power
Earphone Cable Length
Plug Type
Weight
Accessories
Sealed dynamic type
Diameter 8mm
16Ω
93dB/mW
5mW
20〜20,000Hz
Approx.1.2m (Y Type）Lightning Connector
Approx.14g (including earphones）Earpiece (S/M/L 2 units each）＊M earpiece are attached to the main unit
Specification
Frequency Response
Maxell,Ltd.30-13 Motoyoyogi-Cho, Shibuya-Ku, Tokyo 151-8527
