Maxkin KP-A1 User manual

Printed in China
201 V 1.05
SOS
Wireless Keypad
User Manual

02
02
03
05
06
07
08
11
11
12
13
14
15
16
1
Table of Contents
Get to Know Your Keypad
Parts List
Working Status of Keypad
Installations
Digital Keypad Operation
Disarm by RFID Tag/Card
Settings
Enroll the Keypad to the Control Panel
Connecting Electronic Door Lock
Add/Delete RFID Tag/Card
Restore System to Default Settings
Specification
Maintenance
Frequently Asked Question



  

#
SO S
The KP-AI wireless keypad works as arming/disarming
devices, secured with admin and user password. It can be
installed at entry /exit locations. Once there’s an
emergency situation, press the panic button. SOS
Moreover, the keypad can be connected with an electronic
door lock to work as an access control system. RFID tag
enable user to disarm the system and open the door at the
same time, which is very convenient and suitable for homes
and offices.
Get to Know Your System
Parts List
1 x User Manual
RFID tags
1 x Wired Cables
+
-AAA
+
-AAA
+
-AAA
3 x 1.5V AAA
LR03 Battery
4 x Wood screws
with plastic stoppers
Wireless keypad
Working Status of Keypad
Green LED
Blue LED
Red LED
Arm
Stay Arm
Disarm
SOS Key
Wake Up Key
RFID Reader
Up to50 pcs can RFID Tags:
be expanded.
RFID tags
3
2


  

#
SO S
Green LED Normal On: Power on
Blue LED Flashes Once: Arm/Stay Arm or Disarm
Red LED Flashes Once: Wrong programming
Red LED Flashes Once Every 3 Seconds: Low battery indication,
please replace the batteries.

Installation
SOS
2
3
1
Tamper Switch: The tamper switch will be
activated if case is opened.
Screw Hole
Wired Cables Interface
Rear Cover
Positive and Negative
Terminals for Battery
Battery Slot
Tamper Switch
Wired Cables Interface
+-
+
-
+
-AAA
5
4
1. Open the keypad case, fix the rear cover at the suitable
mounting location, please make sure the location level and
fix the rear cover in position on the wall by screws.
2. Fasten the front cover of keypad on the rear cover.
3. Screw the bottom on.

Digital Keypad Operation
Arm
Stay Arm (Home Mode)
Press , keypad beeps once and control panel beeps twice
into disarming state, the electronic door lock will be opened
as well (If connected).
Disarm
In power saving mode, please press “ ” to activate keypad.
Then please enter admin password # or user password #
before operating the digital keypad.
*
Press button, then press or within 3 seconds “ ” “ ” “ ”
to enter arming or disarming state in mute mode without
disturbing someone.
SOS Emergency Call
Once there's an emergency situation,press for 3 SOS
seconds to activate an immediate alarm.
Note! To avoid any false operation, please enable functions of “
Emergency Call with Password” refer to Page9.
Mute Mode
Disarm by RFID Tag/Card
7
6
Press , keypad and control panel beeps once to enter
arming state. Any detectors triggered will activate the
system to alarm immediately. The system simultaneously
calls the preset phone numbers.
Press , control panel beeps once to enter arming state
after 3 seconds. The accessories in home mode are disarmed,
this allows the user to move freely at home, while the rest of
the system is fully armed, the accessories in normal zones will
activate an immediate alarm when triggered.
In power saving mode, press“ ”to activate keypad. Put RFID tag close
to the RFID reader to disarm the system. And the electronic door
lock will be opened as the same time.
User can directly put RFID tag close to the RFID reader to disarm
the system if system is not in power saving mode.
Note! Press“ ”to activate keypad, no operations within 5 seconds,
keypad will exit setup state automatically.
*
+ /
*
Admin password is 123456 as default
User password is 1234 as default

Command Menu Setup
9
8


  

#
SO S
In power saving mode, press“ ”to activate keypad. Enter
“ ”, blue LED light up to enter setup state. admin password#9
Please enter the commands as below to setup. Keypad will
be programmed successfully after one beep is heard.
Settings
Enter Setup State
*#9
admin password
Note! No operation within 30seconds, keypad will automatically
exit setup state. User can press “ ” “ ”, “ ” or “SOS”
during programming, keypad beeps twice to exit setup state.
Quick Arm On
Quick Arm Off
Touch Tone On
Touch Tone Off
RFID Function On
RFID Function Off
Power saving mode. After touch
tone is off, Green LED flashes
once when button is pressed.。
*1#
*1*
*2#
*2*
*3#
*3*
*4#
Function Mark
Press Button
*4*
*5#
Factory
Default
Once RFID function is
enabled, user cannot
disarm the system by the
RFID cards.
Emergency Call
with Password
Emergency Call
without Password
Please enter the password
before triggering SOS button.
Press SOS button for 3
seconds without password
Normal Working
Mode On
If keypad is powered by
DC 12V power, normal
working mode is
recommended.The green
LED keeps on. And digital
keypad can be operated
without pressing activate
key. In normal mode, user
can disarm the systemwith
RFID cards close to the
reader directly
Default
Default
Default
Default
When quick arm function
is enabled, users can press
+ to arm the system
without password.
*
*
Admin password is 123456 as default

12V GND
push GND
11
10
*6#
*#
*6*
123456
1234
Disarm System by
RFID Card in
Mute Mode
Function Press Button Mark
Disarm System
by RFID Card in
Sound Mode
Change Admin
Password
Change User
Password 4digits
6digits
new password
*#
new password
Enroll the keypad to the control panel
Press enroll button of control panel, the enroll LED light up,
press“ ”to activate keypad, and then press “ ”, the SOS
connection is successful after ‘enroll’ LED flashes once and
one beep is heard.
Note! System will exit automatically after 20 seconds; User can
press the enrolling button to exit.
Connecting Electronic Door Lock
Power Supply Electronic Door Lock
Door Release Exit Button
Connect PUSH and GND of electronic lock, when system is
disarmed, door will be opened at the same time.
Connect PUSH and GND of Door Release Exit Button; User can
press the exit button to open the electronic door lock.
Connect 12V and GND to offer power supply for wireless keypad.
Disarm the system
without 2 beeps are heard
2 beeps will be heard
when system disarm
Factory
Default
*5*
Normal Working
Mode Off
If keypad is powered
by the batteries,
power saving mode
is recommended.
Keypad should be
activated by pressing
activate key before
operating. No operation
within 5 seconds,
system enters power
saving mode.
Default
Default
*

13
12


  

#
SOS


  

#
SOS
Add/Delete RFID Tag/Card
RFID Enrollment (Up to 50 pcs can be expanded)
Note! If 2 deeps are heard and red LED flashes twice, it indicates
that RFID tag has been enrolled before. RFID tags can be
continuously enrolled into keypad within 30 seconds.
Press“ ”to activate keypad, then enter “ ”, admin password# 8
green LED light up; Put RFID tag close to the RFID reader, the
enrollment is successful after one beep is heard and blue LED
flashes once.
*
*#8
admin password
Clearing a RFID Tag
Press “ ” to activate keypad, then enter “ ” , admin password# 0
red LED light up; Put RFID tag close to the RFID reader, the RFID
tag is deleted after blue LED flashes once and one beepis heard.
Note! RFID tags can be continuously deleted within 30 seconds.
*
Clearing All RFID Tags
*#0
admin password
Press“ ”to activate keypad, then enter “ ” , admin password # 0
red LED light up; Press and hold “0 “ button up to 3 seconds,
all RFID tags are deleted after one long beep is heard.
*
Restore System to Default Settings
Please press the up to 5 times, keypad is tamper switch
successfully restored after one long beep is heard.
Note: Restoring operation will not delete the enrolled RFID tags.

15
14
Specification
Keypad
3pcsof1.5VAAA/LR03Battery
≤6μA
≤40mA
50pcs
315MHZ/433MHZ(±75KHz)
ABSplastic
Temperature:-20°C~55°C
Humidity:80% (non-condensing)
141×96×14.5mm
ProductName:
PowerSupply:
StandbyCurrent:
DisarmbyRFIDCurrent:
ExpandableRFIDCard/Tags:
Rf无线频率：
HousingMaterial:
Operationcondition:
Size (L×W×H):
Maintenance
Keypad requires an adequate maintenance to make sure it
works properly and prolong its usage life.
Regular check & Forbiddance
1. Make sure the keypad is enrolled into control panel before use.
2. The power supply of keypad should be checked as often as
necessary to avoid any transmitting distance caused by
lower battery.
3. Check the keypad regularly to ensure the system works
properly in case of emergency.
4. Please install the keypad in place where is shading,
ventilative and drying.
5. Do not install the keypad at flammable and explosive place.
6. The keypad is made of ABS. Please keep it away from strong light.
7. Do not disassemble the system to avoid causing malfunction
or any unnecessary accidents.
8. Please keep away from air conditioner, waver.
Light dusting or clearing fingerprint with a soft cloth or tissue.
Please wipe the surface by a soft cloth with a little dilute
alkaline detergent slightly wipe the surface and then wipe
again with a dry cloth.
Maintenance

16
A.Please check if the keypad is in low battery or the positive
and negative terminals are revered.
B.No programming within 30 seconds, the keypad will enter
power saving mode, please press “*” to activate.
Frequently Asked Questions
1.Why wireless keypad cannot work?
A.Make sure the alarm panel is powered on. And confirm
wireless keypad had been enrolled to control panel.
B.Please check whether any metals are nearby to interfere
the signal.
C.The distance between wireless keypad to control panel is
80 meters in open area. It is suggested that the distance
should not be too far.
A.Please check if the RFID tags were enrolled to the keypad,
Please refer to Page 12 for operation guide.
B.Please check the LED indication and to see if system is in
power saving mode. Before using the RFID tags to disarm
the system, please press “*” to active first.
C.Please check if the RFID disarming function is disabled,
Please follow the user manual Page9 to enter setup state
and enable the RFID disarming function.
2.Why wireless keypad cannot connect to control panel?
3.Why RFID tags cannot disarm the system?
