Maxouttech RF-CPIR-319-NN User manual

RF-CPIR-319-NN Rev.3 Oct. 2020 For updated Installation Manual Revision go to Maxouttech.com and select Documentation
page.
RF-CPIR-319-NN Installation Instructions
Installation
The motion detector is designed for a ceiling mount
application that provides a 3600detection range.
Do not mount outdoors
Avoid areas with pets
Do not mount near ceiling fans or heating ducts
Avoid looking directly at windows and direct sunlight
Mounting Location
The coverage pattern is dependent on the mounting height
of the detector, areas cans be masked off to prevent
unwanted detection.
Mounting Height
Detection Area
8 ft
20 ft
10 ft
30 ft
12 ft
45 ft
Also, the detectors sensitivity can be set to allow for
harsher environments where movement or
temperatures can vary.
Sensitivity setting:
Low – recommended setting, allows for some
environmental movement.
High – quick response, used for quiet areas that do not
expect environmental noise.
- Lo Sensitivity – move jumper to top two pins
- Hi Sensitivity – move jumper to bottom 2 pins
- LED – jumper installed across pins, LED will light when
movement is detected.
Note: Leaving the LED jumper installed will greatly reduce
the detector’s battery life.
Mounting
Attach tamper spring to plastic foot, see photo 1, and
attach to tamper switch, see photo 2.
Ceiling Mounting:
•Remove the housing base from the detector.
•Using anchors and screws securely mount the base to
the ceiling.
•The detector base will twist onto the base when
installed.
Panel Enrollment
The following steps describe the general guidelines for
programming the sensor into panel memory. Refer to the
specific panel’s documentation for complete programming
details.
1. Set the panel to the program mode.
2. Proceed to the SENSORS menu.
3. Select the appropriate sensor group and sensor
number assignments.
4. When prompted by the panel to trip the sensor for
learning, remove the sensor cover and if present pull
the battery pull tabs. The system should acknowledge
learning the sensor by touchpad display and/or audio
(depending on the panel).
5. Exit program mode.
Testing
1. Press the tamper on the motion board to enter walk test
mode – during this mode the detector will transmit a RF
signal to the control panel whenever it detects motion.
2. Place the jumper across the LED pins, this will allow the
LED to light when motion is detected.
Photo 1.
Photo 2.
The RF-CPIR is a 3600
passive infrared motion
detector designed for ceiling
mount applications.
The compact design allows
for an easy installation. The
sensitivity setting also
provides for different types
for environments.

RF-CPIR-319-NN Rev.3 Oct. 2020 For updated Installation Manual Revision go to Maxouttech.com and select Documentation page.
3. Place the detector back in its location and walk the
coverage area verifying the LED lights when movement is
detected.
4. Walk test will time out after 1 min. of no motion
detection.
5. Remove the LED jumper
Note: Leaving the LED jumper installed will greatly reduce
the detectors battery life
Operation
3-minute lockout – to conserve battery life the detector has
a 3-minute lockout between motion detections
Unless the jumper is installed the red LED will not light
during motion detection.
Note: Leaving the LED jumper installed will greatly reduce
the detectors battery life.
Replacing the Batteries
Battery life depends on how often the detector transmits
signals, but is more dependent on the temperature of the
installation environment. When the battery voltage gets
low, the detector transmits a low battery signal to the
panel. The panel then activates trouble beeps to notify the
customer that the detector battery must be replaced.
Pressing the status button identifies the sensor with the low
battery.
Replace the battery immediately when this condition
occurs, using a Panasonic CR123A 3V. Note: If a low
battery alarm occurs, replace the battery within 7 days.
CAUTION: Battery may explode if mistreated. Do not
recharge, disassemble or dispose of in fire.
Battery Disposal
The batteries used in this sensor are lithium batteries and
are not reusable. Properly dispose of used lithium batteries
according to your local hazardous waste disposal laws.
Specifications
Compatibility: Interlogix 319.5 control panels, Qolsys
Power Source: 2 CR123A 3V Battery
Tamper Switch:Sealed dome-contact
Sensitivity Selectable: 2 event or 3 event
Typical Battery Life:4-6 years at 68°F
Transmitter Frequency:319.5 MHz
Operating Temperature:-40 C - +55 C
Storage Temperature Range:-30° to 140° F (-34° to 60° C)
Maximum Humidity:90% Relative Humidity non-condensing
Dimensions: 2.95in diameter X 1.39in depth
Housing: High impact ABS
